Model LG L1510M – Common Parts & Diagrams
Diagram 0
Common parts from model LG L1510M
0
SCREW, LGE 1SZZTER001A Contact Us For Availability
0
LGE 3313TL5068A LGE 3313TL5068A Contact Us For Availability
0
BACK COVER ASSEMBLY LGE 3809TKL032K Contact Us For Availability
0
LGE 3880TAZ001C LGE 3880TAZ001C Contact Us For Availability
0
Plate LGE 4950TKK337A Contact Us For Availability
0
LGE 6304FLP074A LGE 6304FLP074A Contact Us For Availability
0
SPEAKER ASSEMBLY LGE 6401TZZ025B Contact Us For Availability
0
POWER CORD LGE 6410TUW008B Contact Us For Availability
0
LGE 3091TKL050U LGE 3091TKL050U Contact Us For Availability
0
LGE 3890TSE323M LGE 3890TSE323M Contact Us For Availability
0
SCREW,DRAWING LGE 332-122F Contact Us For Availability
0
LGE 3920TKE194A LGE 3920TKE194A Contact Us For Availability
0
LGE 6631T20020D LGE 6631T20020D Contact Us For Availability
0
LGE 6871TST306K LGE 6871TST306K Contact Us For Availability
0
TILT SWIVEL ASSEMBLY LGE 3043TKK097A Contact Us For Availability
0
SCREW, LGE 1SZZTPP001B Contact Us For Availability
0
DISKETTE ASSEMBLY LGE 3171TZ1289C Contact Us For Availability
0
SCREW,DRAWING LGE 332-068U Contact Us For Availability
0
CORD,A/V LGE 6852TAZ006F Contact Us For Availability
0
TILT SWIVEL ASSEMBLY LGE 3043TKK092A Contact Us For Availability
0
SCREW,DRAWING LGE 332-112F Contact Us For Availability
0
LGE 3920TKE170E LGE 3920TKE170E Contact Us For Availability
0
LGE 4950TKK466A LGE 4950TKK466A Contact Us For Availability
0
CABLE,D-SUB LGE 6850TD9001A Contact Us For Availability
0
PWB(PCB) ASSEMBLY,SU LGE 6871TST307F Contact Us For Availability
0
SCREW MACHINE,BINDIN LGE 1MBC0251723 Contact Us For Availability
0
SCREW, LGE 332-105H Contact Us For Availability
0
BAG,VINYL LGE 3880TKZ029C Contact Us For Availability
0
METAL ASSEMBLY LGE 4951TKK083A Contact Us For Availability
0
LGE 4951TKS089G LGE 4951TKS089G Contact Us For Availability
0
CONNECTOR ASSEMBLY LGE 6631T11012R Contact Us For Availability
0
PWB(PCB) LGE 6870T432D12 Contact Us For Availability
0
SCREW LGE 332-095B Contact Us For Availability
0
LGE 332-110A LGE 332-110A Contact Us For Availability
0
SCREW, LGE 332-113D Contact Us For Availability
0
KNOB LGE 4940TKT162B Contact Us For Availability
0
Harness,Single LGE 6631T20015E Contact Us For Availability
0
INVERTER ASSEMBLY LGE 6633TZA003H Contact Us For Availability
0
LGE 6871TPT254A LGE 6871TPT254A Contact Us For Availability
BD901
LGE 0DD260000BE LGE 0DD260000BE Contact Us For Availability
C701
Capacitor,AL,Radial LGE 0CE107CH610 Contact Us For Availability
C711
CAPACITOR,FIXED CERA LGE 0CK103CK51A Contact Us For Availability
C731
CAPACITOR,FIXED CERA LGE 0CC680CK41A Contact Us For Availability
C803
CAPACITOR,FIXED CERA LGE 0CK105CD56A Contact Us For Availability
C901
LGE 0CBZTBU002D LGE 0CBZTBU002D Contact Us For Availability
C902
CAPACITOR,FIXED CERA LGE 0CK104CK56A Contact Us For Availability
C903
CAPACITOR,CERAMIC (H LGE 0CKZTBU003D Contact Us For Availability
C905
LGE 0CZZTAB004B LGE 0CZZTAB004B Contact Us For Availability
C906
CAPACITOR,CHIP[CERAMIC LD-LESS LGE 0CH3105F946 Contact Us For Availability
C907
LGE 0CE105EK638 LGE 0CE105EK638 Contact Us For Availability
C908
CAPACITOR,AL.ELECTROLYTIC LGE 0CE476EH638 Contact Us For Availability
C914
LGE 0CE335EK638 LGE 0CE335EK638 Contact Us For Availability
C915
Capacitor,AL,Radial LGE 0CE477EF638 Contact Us For Availability
C916
CAPACITOR,FIXED CERA LGE 0CC121CK41A Contact Us For Availability
C916
Capacitor,Film,DIP LGE 181-288L Contact Us For Availability
C917
CAPACITOR,FIXED CERA LGE 0CK562CK51A Contact Us For Availability
C918
CAPACITOR,AL.ELECTROLYTIC LGE 0CE108EF630 Contact Us For Availability
C919
CAPACITOR,CHIP[CERAM LGE 0CH3334K946 Contact Us For Availability
C920
LGE 0CKZTBU003C LGE 0CKZTBU003C Contact Us For Availability
C923
CAPACITOR CERAMIC (HIGH DIELE LGE 0CK10201515 Contact Us For Availability
C924
LGE 0CH3473K946 LGE 0CH3473K946 Contact Us For Availability
C927
CAPACITOR,CHIP[AL. E LGE 0CH8106F611 Contact Us For Availability
C934
Capacitor,Ceramic,Chip LGE 0CH3224K946 Contact Us For Availability
C939
CAPACITOR,CHIP[AL. ELECTROLYTI LGE 0CH8107F611 Contact Us For Availability
D801
DIODE,SWITCHING LGE 0DS181009AA Contact Us For Availability
D901
Diode,Rectifier LGE 0DD400709CB Contact Us For Availability
D902
DIODE,SWITCHING LGE 0DS226009AA Contact Us For Availability
D903
LGE 0DRGS00281A LGE 0DRGS00281A Contact Us For Availability
D904
DIODE,RECTIFIER LGE 0DR400409AB Contact Us For Availability
D906
Diode,Schottky LGE 0DR206000AA Contact Us For Availability
D908
LGE 0DZ620009AP LGE 0DZ620009AP Contact Us For Availability
IC901
LGE 0IPMGPF004A LGE 0IPMGPF004A Contact Us For Availability
IC904
IC,Voltage Regulator LGE 0ISS431000A Contact Us For Availability
L905
Filter,Bead LGE 6210TCE001P Contact Us For Availability
L920
LGE 6140TBZ016G LGE 6140TBZ016G Contact Us For Availability
LED301
LED LGE 0DLLT0089AA Contact Us For Availability
LF901
FILTER(CIRC),DRAWING LGE 6200TZZ001B Contact Us For Availability
P901
SOCKET(CIRC),POWER LGE 6620K00018A Contact Us For Availability
P902
LGE 6631T20008N LGE 6631T20008N Contact Us For Availability
PC901
IC,LITEON LGE 0ILI817000E Contact Us For Availability
Q503
IC,KEC LGE 0IKE704200H Contact Us For Availability
Q505
TRANSISTOR LGE 0TR390409AE Contact Us For Availability
Q704
TRANSISTOR LGE 0TR390609FA Contact Us For Availability
Q902
TR,Bipolar LGE 0TR162309CA Contact Us For Availability
R207
RESISTOR,METAL GLAZE LGE 0RJ3900D677 Contact Us For Availability
R301
LGE 0RD4701Q509 LGE 0RD4701Q509 Contact Us For Availability
R303
LGE 0RD1001Q509 LGE 0RD1001Q509 Contact Us For Availability
R304
LGE 0RD1601Q509 LGE 0RD1601Q509 Contact Us For Availability
R306
LGE 0RD6801Q509 LGE 0RD6801Q509 Contact Us For Availability
R307
LGE 0RD2701Q509 LGE 0RD2701Q509 Contact Us For Availability
R701
CAPACITOR,FIXED ELEC LGE 0CE107EF610 Contact Us For Availability
R706
RESISTOR,METAL GLAZE LGE 0RJ0752D677 Contact Us For Availability
R707
RESISTOR,METAL GLAZE LGE 0RJ0682D677 Contact Us For Availability
R725
RESISTOR,METAL GLAZE LGE 0RJ4701D677 Contact Us For Availability
R726
RESISTOR,METAL GLAZE LGE 0RJ1002D677 Contact Us For Availability
R750
RESISTOR,METAL GLAZE LGE 0RJ1001D677 Contact Us For Availability
R814
Resistor,Chip LGE 0RJ0221D677 Contact Us For Availability
R901
Resistor,Carbon Film LGE 0RD6803A609 Contact Us For Availability
R902
RESISTOR,METAL GLAZE LGE 0RJ0471D677 Contact Us For Availability
R903
LGE 0RD1004Q609 LGE 0RD1004Q609 Contact Us For Availability
R905
RESISTOR,METAL GLAZE LGE 0RJ1202D677 Contact Us For Availability
R905
LGE 0RD4704Q609 LGE 0RD4704Q609 Contact Us For Availability
R906
LGE 0RX4702J609 LGE 0RX4702J609 Contact Us For Availability
R908
LGE 0RD0681Q609 LGE 0RD0681Q609 Contact Us For Availability
R908
RESISTOR,METAL GLAZE LGE 0RJ2001D677 Contact Us For Availability
R909
Resistor,Carbon Film LGE 0RD1001Q609 Contact Us For Availability
R918
RESISTOR,FIXED CARBON FILM LGE 0RD1000Q609 Contact Us For Availability
R920
RESISTOR,METAL GLAZE LGE 0RJ2202D677 Contact Us For Availability
R920
Resistor,Metal Film LGE 0RN1302F409 Contact Us For Availability
R921
Resistor,Metal Film LGE 0RN2701F409 Contact Us For Availability
R923
RESISTOR,FIXED CARBON FILM LGE 0RD1202Q609 Contact Us For Availability
R924
Resistor,Chip LGE 0RJ2702D677 Contact Us For Availability
R926
RESISTOR,METAL GLAZE LGE 0RJ1501D677 Contact Us For Availability
R932
Resistor,Chip LGE 0RJ6802D677 Contact Us For Availability
SW306
SWITCH LGE 140-058E Contact Us For Availability
T901
LGE 6170TMZ133A LGE 6170TMZ133A Contact Us For Availability
TH901
LGE 6322A00002B LGE 6322A00002B Contact Us For Availability
U201
LGE 0IPRPM3003A LGE 0IPRPM3003A Contact Us For Availability
U201
IC,PERIPHERALS LGE 0IPRPM3007A Contact Us For Availability
U501
LGE 0IZZTSZ270A LGE 0IZZTSZ270A Contact Us For Availability
U502
IC,MEMORIES LGE 0ISG240860B Contact Us For Availability
U801
IC,POWER MANAGEMENT LGE 0IPMGKE011A Contact Us For Availability
U802
TRANSISTOR,FETS LGE 0TFVI80023A Contact Us For Availability
U803
IC,POWER MANAGEMENT LGE 0IPMGK2001C Contact Us For Availability
U804
IC,SAMSUNG ELECTRONICS LGE 0ISS780500H Contact Us For Availability
U901
IC,SGS-THOMSON LGE 0ISG749600A Contact Us For Availability
U902
IC,Tone LGE 0ISG744900B Contact Us For Availability
U903
IC,SAMSUNG ELECTRONICS LGE 0ISS780800J Contact Us For Availability
X501
RESONATOR,CRYSTAL LGE 6212AA2004A Contact Us For Availability
ZD302
DIODE,ZENER LGE 0DZ560009CE Contact Us For Availability
ZD703
DIODE,ZENERS LGE 0DZ560009GB Contact Us For Availability
ZD901
Diode,Zener LGE 0DZ910009FE Contact Us For Availability
ZD901
DIODE,ZENER LGE 0DZ750009AG Contact Us For Availability
× ![]()
