Model Whirlpool KUCS02FRPA0 TRASH COMPACTOR – Common Parts &amp; Diagrams

2

9870867 Whirlpool Shield Backorder WPL 9870867 $8.05

2

Screw, Power (Available Only As Complete Asse WPL ARI113259A Contact Us For Availability

3

WP9870975 Whirlpool Compactor Slide Backorder WPL WP9870975 $34.59

3

Plate, Bearing (2) WPL 779121 Contact Us For Availability

4

776327 Whirlpool Compactor Motor Plate Backorder WPL 776327 $42.93

4

W10540355 Whirlpool Deodorant In Stock WPL W10540355 $5.95

4

W10917043 Whirlpool Compactor Bearing Backorder WPL W10917043 $9.59

4

Fan Mount Assembly WPL 9871893 Contact Us For Availability

5

Hub, Power Screw (2) WPL 776941 Contact Us For Availability

6

WP777108 Whirlpool Compactor Bag Handle Backorder WPL WP777108 $8.16

6

Race, Thrust (2) WPL 775481 Contact Us For Availability

7

WP454512 Whirlpool Compactor Spring Pin Backorder WPL WP454512 $3.70

7

GREASE 4 OZ. (USE ON POWER SCREW AND RAM PRES WPL 675351 Contact Us For Availability

8

WP780263 Whirlpool Compactor Screw In Stock WPL WP780263 $2.51

8

Nut, Power Screw (2) WPL 4154842 Contact Us For Availability

8

Washer, Wave WPL 776035 Contact Us For Availability

8

Wire, 25`` Roll (Black 12 GA.) WPL 47261 Contact Us For Availability

8

Wire, 25`` Roll (White 12 GA.) WPL 47263 Contact Us For Availability

9

WP279368 Whirlpool High-Temperature Silicone In Stock WPL WP279368 $29.08

9

WP777332 Whirlpool Compactor Washer Backorder WPL WP777332 $2.38

8171651 Whirlpool Touch Up Backorder WPL 8171651 $8.40

8171652 Whirlpool Touch-Up Backorder WPL 8171652 $10.07

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

WP8204624 Whirlpool Bolt In Stock WPL WP8204624 $8.82

WP9871971 Whirlpool Compactor Off Switch In Stock WPL WP9871971 $63.84

PAINT, TOUCH-UP (1/2OZ. WHI WPL 72017 Contact Us For Availability

WPL 72032 WPL 72032 Contact Us For Availability

WPL 8171571 WPL 8171571 Contact Us For Availability

Paint, Touch-Up 1/2 Oz. (Biscuit) WPL 4892899 Contact Us For Availability

WPL 8171653 WPL 8171653 Contact Us For Availability

882763 Whirlpool Compactor Front Trim Backorder WPL 882763 $70.59

WP9871920 Whirlpool Compactor Switch Knob Backorder WPL WP9871920 $42.51

WPL 350930 WPL 350930 Contact Us For Availability

WPL 285006 WPL 285006 Contact Us For Availability

WPL 4392901 WPL 4392901 Contact Us For Availability

WPL 350956 WPL 350956 Contact Us For Availability

WPL 9871383 WPL 9871383 Contact Us For Availability

WPL 9871600 WPL 9871600 Contact Us For Availability

WP777383 Whirlpool Compactor Nut In Stock WPL WP777383 $4.89

WP9870163 Whirlpool Compactor Trunnion Nut In Stock WPL WP9870163 $31.26

Chain, Drive WPL 780477 Contact Us For Availability

Spring, Safety Switch WPL 9871125 Contact Us For Availability

13

9871829 Whirlpool Trash Compactor Door Switch In Stock WPL 9871829 $29.85

13

Handle WPL 9871564 Contact Us For Availability

14

WP3196175 Whirlpool Screw In Stock WPL WP3196175 $2.51

15

WP489478 Whirlpool Refrigerator Screw Backorder WPL WP489478 $2.51

16

WP9870037 Whirlpool Ram Stop Backorder WPL WP9870037 $3.70

16

WP9871602 Whirlpool Compactor Bearing In Stock WPL WP9871602 $7.01

17

WP776356 Whirlpool Compactor Nut Backorder WPL WP776356 $2.51

17

Bracket, Top Limit Switch WPL 9870498 Contact Us For Availability

W11032731 Whirlpool Compactor OFF Switch Backorder WPL W11032731 $32.30

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $2.51

WP777811 Whirlpool Compactor Directional Swit In Stock WPL WP777811 $40.68

WPW10242557 Whirlpool Compactor Guard Backorder WPL WPW10242557 $54.86

19

777849 Whirlpool Compactor Screw Backorder WPL 777849 $4.85

19

WP9871099 Whirlpool Air Freshener Cover In Stock WPL WP9871099 $45.40

20

W10917246 Whirlpool Compactor RAM Slide Backorder WPL W10917246 $47.93

20

WP4151750 Whirlpool Charcoal Air Filter In Stock WPL WP4151750 $6.59

21

9872118 Whirlpool Compactor Wire Harness Backorder WPL 9872118 $105.65

21

Spring, Latch WPL 775736 Contact Us For Availability

23

775665 Whirlpool Compactor Plate Latch Backorder WPL 775665 $37.04

30

WP9870444 Whirlpool Compactor Inner Panel Backorder WPL WP9870444 $37.55

33

WP777180 Whirlpool Compactor Spring In Stock WPL WP777180 $30.25
