Model Whirlpool KUCC151JBT1 TRASH COMPACTOR – Common Parts &amp; Diagrams

2

9870867 Whirlpool Shield Backorder WPL 9870867 $8.05

2

Handle, Container (Biscuit) WPL 9871573 Contact Us For Availability

2

Cover, Top WPL 9871825 Contact Us For Availability

3

779121 Whirlpool Compactor Plate Backorder WPL 779121 $12.32

3

W11722978 Whirlpool Slide Backorder WPL W11722978 $51.02

3

W11729437 Whirlpool Retaining Bracket Backorder WPL W11729437 $8.78

3

WP9870975 Whirlpool Compactor Slide Backorder WPL WP9870975 $32.94

3

WP9871311 Whirlpool Compactor Panel Backorder WPL WP9871311 $59.13

4

776327 Whirlpool Compactor Motor Plate Backorder WPL 776327 $40.88

4

W10917043 Whirlpool Compactor Bearing Backorder WPL W10917043 $9.59

4

Insert, Escutcheon (Stainless) WPL 9871773 Contact Us For Availability

5

776941 Whirlpool Compactor Power Crew Hub Backorder WPL 776941 $8.86

5

WP780239 Whirlpool Compactor Bracket Retainer Backorder WPL WP780239 $12.32

6

775481 Whirlpool Compactor Bearing Backorder WPL 775481 $29.74

6

WP777108 Whirlpool Compactor Bag Handle Backorder WPL WP777108 $8.16

7

675351 Whirlpool Compactor Grease In Stock WPL 675351 $34.20

7

9871577 Whirlpool Compactor Foot Pedal Backorder WPL 9871577 $51.39

7

WP454512 Whirlpool Compactor Spring Pin Backorder WPL WP454512 $3.70

7

WP9871031 Whirlpool Compactor Foot Pedal Backorder WPL WP9871031 $51.39

7

Escutcheon, Control (Black) WPL 9871747 Contact Us For Availability

7

Escutcheon, Control (White) WPL 9871746 Contact Us For Availability

7

Escutcheon, Control (Biscuit) WPL 9871749 Contact Us For Availability

7

Escutcheon, Control (Grey) WPL 9871772 Contact Us For Availability

8

4154842 Whirlpool Compactor Nut Backorder WPL 4154842 $29.10

8

776035 Whirlpool Compactor Washer Backorder WPL 776035 $9.59

8

WP780263 Whirlpool Compactor Screw In Stock WPL WP780263 $2.51

8

Screw, 6-20 x 3/8 (2) WPL 246131 Contact Us For Availability

9

4152703 Whirlpool Fan Strap Backorder WPL 4152703 $26.21

9

W11214485 Whirlpool Compactor Washer Backorder WPL W11214485 $9.59

9

WP279368 Whirlpool High-Temperature Silicone In Stock WPL WP279368 $29.08

9

WP777332 Whirlpool Compactor Washer Backorder WPL WP777332 $2.38

675382 Whirlpool Trash Compactor On/Off Start In Stock WPL 675382 $76.87

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

72110 Whirlpool Dryer Touch-Up Paint, Golden In Stock WPL 72110 $10.07

72113 Whirlpool Touch-Up Paint Backorder WPL 72113 $10.07

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

9871801 Whirlpool Compactor Switch Knob Backorder WPL 9871801 $26.21

W11696573 Whirlpool Ram Backorder WPL W11696573 $129.98

WP9871799 Whirlpool Compactor Switch Knob In Stock WPL WP9871799 $37.08

WP9871800 Whirlpool Compactor Switch Knob In Stock WPL WP9871800 $36.97

Knob, Rotary Switch (Grey) WPL 9871798 Contact Us For Availability

780477 Whirlpool Compactor Drive Chain Backorder WPL 780477 $80.02

9871125 Whirlpool Compactor Actuator Backorder WPL 9871125 $9.52

WP777383 Whirlpool Compactor Nut In Stock WPL WP777383 $4.89

WP9870163 Whirlpool Compactor Trunnion Nut In Stock WPL WP9870163 $29.77

13

WP4387911 Whirlpool Refrigerator Switch In Stock WPL WP4387911 $13.43

13

WP90296 Whirlpool Clip Backorder WPL WP90296 $2.51

14

WP3196175 Whirlpool Screw In Stock WPL WP3196175 $2.51

15

9871893 Whirlpool Compactor Fan Filter Backorder WPL 9871893 $153.81

15

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

16

WP9870037 Whirlpool Ram Stop Backorder WPL WP9870037 $3.70

16

WP9871602 Whirlpool Compactor Bearing In Stock WPL WP9871602 $7.01

17

WP3351614 Whirlpool Screw Backorder WPL WP3351614 $2.51

17

WP776356 Whirlpool Compactor Nut Backorder WPL WP776356 $2.51

17

Bracket, Top Limit Switch WPL 9870498 Contact Us For Availability

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $2.51

WP777328 Whirlpool Compactor Guard Backorder WPL WP777328 $49.32

WP777811 Whirlpool Compactor Directional Swit In Stock WPL WP777811 $38.74

Switch Assembly (Stainless) WPL 9871869 Contact Us For Availability

Switch Assembly (Black) WPL 9871767 Contact Us For Availability

Switch Assembly (Biscuit) WPL 9871769 Contact Us For Availability

Switch Assembly (White) WPL 9871766 Contact Us For Availability

777849 Whirlpool Compactor Screw Backorder WPL 777849 $4.85

WP9871099 Whirlpool Air Freshener Cover In Stock WPL WP9871099 $43.24

Cover, Air Freshener (White) WPL 9870911 Contact Us For Availability

Cover, Air Freshener (Biscuit) WPL 9871576 Contact Us For Availability

20

W10917246 Whirlpool Compactor RAM Slide Backorder WPL W10917246 $45.64

20

WP4151750 Whirlpool Charcoal Air Filter In Stock WPL WP4151750 $6.59

21

775736 Whirlpool Compactor Spring Backorder WPL 775736 $28.80

21

9872117 Whirlpool Compactor Wire Harness Backorder WPL 9872117 $78.25

23

775665 Whirlpool Compactor Plate Latch Backorder WPL 775665 $35.28

25

4151897 Whirlpool Compactor Clip Backorder WPL 4151897 $4.85

30

WP9870444 Whirlpool Compactor Inner Panel Backorder WPL WP9870444 $35.76

33

WP777180 Whirlpool Compactor Spring In Stock WPL WP777180 $28.80
