Model Whirlpool KTRS25KGBT3 REFRIGERATOR – Common Parts &amp; Diagrams

1

Refrigerator Door Panel (Includes Insulation) WPL 8170614 Contact Us For Availability

1

Refrigerator Door Panel (Includes Insulation) WPL 8170615 Contact Us For Availability

1

Refrigerator Door Panel (Includes Insulation) WPL 8170616 Contact Us For Availability

1

Literature Parts (Owner`s Manual) WPL LIT8170415 Contact Us For Availability

1

Literature Parts (Tech Sheet) WPL LIT8170416 Contact Us For Availability

1

Separator, Comp. WPL 4344466 Contact Us For Availability

1

Freezer Door Panel (Includes Insulation) (Bla WPL 8170618 Contact Us For Availability

1

Freezer Door Panel (Includes Insulation) (Bis WPL 8170619 Contact Us For Availability

1

Freezer Door Panel (Includes Insulation) (Whi WPL 8170620 Contact Us For Availability

1

Support, Crisper WPL 4344444 Contact Us For Availability

2

Interior Panel WPL 4344531 Contact Us For Availability

2

Shim (White) WPL 4344200 Contact Us For Availability

2

Shim (Black) WPL 4344201 Contact Us For Availability

2

Insert, Drain WPL 8170607 Contact Us For Availability

2

Retainer, Insert (Black) WPL 8170629 Contact Us For Availability

2

Retainer, Insert (Biscuit) WPL 8170630 Contact Us For Availability

2

Retainer, Insert (White) WPL 8170631 Contact Us For Availability

2

Crisper, Cross Member WPL 4344445 Contact Us For Availability

2

Fan, Blade WPL 4344271 Contact Us For Availability

3

W10709784 Whirlpool Refrigerator Handle Plug Backorder WPL W10709784 $10.23

3

WP2189000 Whirlpool Refrigerator Handle Plug Backorder WPL WP2189000 $3.70

3

WP2189009 Whirlpool Refrigerator Handle Plug Backorder WPL WP2189009 $3.51

3

WP67001255 Whirlpool Ice Bucket In Stock WPL WP67001255 $82.10

3

Door, Compartment WPL 4344369 Contact Us For Availability

3

Plug, Button (White) WPL 4344227 Contact Us For Availability

3

Plug, Button (Black) WPL 4344364 Contact Us For Availability

3

Plug, Button (Biscuit) WPL 8170497 Contact Us For Availability

3

Tray, Drip WPL 4344464 Contact Us For Availability

3

Condenser & Pan Assembly WPL 8170610 Contact Us For Availability

4

A3076901 Whirlpool Refrigerator Plug Backorder WPL A3076901 $5.53

4

Screw WPL 4344588 Contact Us For Availability

4

Plug, Button WPL 4343926 Contact Us For Availability

4

Harness, Drn Blk WPL 8170426 Contact Us For Availability

4

Shelf, Frz. Wire WPL 4344438 Contact Us For Availability

5

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $2.51

5

End Cap (White) WPL 4344589 Contact Us For Availability

5

End Cap (Black) WPL 4344591 Contact Us For Availability

5

Endcap (Biscuit) WPL 8175020 Contact Us For Availability

5

Roller, Front Assy. WPL 8170374 Contact Us For Availability

5

Insulation WPL 4344461 Contact Us For Availability

5

Interior Panel WPL 8170442 Contact Us For Availability

6

Shelf Bin (1) WPL 4344532 Contact Us For Availability

6

Clip, Grille WPL 4344155 Contact Us For Availability

6

Insert, Air Sply WPL 4344470 Contact Us For Availability

6

Screw WPL 4343860 Contact Us For Availability

6

Trivet, Door WPL 8170307 Contact Us For Availability

7

Handle (Black) WPL 8170626 Contact Us For Availability

7

Handle (Biscuit) WPL 8170627 Contact Us For Availability

7

Handle (White) WPL 8170628 Contact Us For Availability

7

Pin, Center Hinge WPL 4344428 Contact Us For Availability

7

Gasket, Air Sply WPL 4344473 Contact Us For Availability

7

Heat Shield WPL 4344486 Contact Us For Availability

8

WPM0274057 Whirlpool Refrigerator Shim In Stock WPL WPM0274057 $2.51

8

WPM0274062 Whirlpool Refrigerator Shim In Stock WPL WPM0274062 $12.94

8

Door Gasket, Magnetic (Black) WPL 8170683 Contact Us For Availability

8

Door Gasket, Magnetic (White) WPL 8170684 Contact Us For Availability

8

Cap, Switch WPL 4344467 Contact Us For Availability

8

Door Gasket, Magnetic (Black) WPL 8170668 Contact Us For Availability

8

Door Gasket, Magnetic (White) WPL 8170685 Contact Us For Availability

8

Rack, Ice Tray WPL 4344513 Contact Us For Availability

8

Drain Pan WPL 4344510 Contact Us For Availability

9

W11679940 Whirlpool Refrigerator Light Bulb A In Stock WPL W11679940 $2.75

9

Tube, Drain WPL 4344504 Contact Us For Availability

9

Divider, Door Shelf WPL 4344300 Contact Us For Availability

9

Meat Pan WPL 8170419 Contact Us For Availability

Gasket WPL 4344370 Contact Us For Availability

Hinge Cover, Bottom (Black) WPL 4344202 Contact Us For Availability

Hinge Cover, Bottom (White) WPL 4344204 Contact Us For Availability

Hinge Cover, Bottom (Biscuit) WPL 8170490 Contact Us For Availability

Membrane, Breaker WPL 4344465 Contact Us For Availability

Insulation WPL 4344524 Contact Us For Availability

Shelf, Meat Pan WPL 4344496 Contact Us For Availability

Evaporator Heater WPL 8170433 Contact Us For Availability

WP67006380 Whirlpool Screw Backorder WPL WP67006380 $2.51

Bottom, Comp. Separator WPL 4344462 Contact Us For Availability

Nameplate (Black) WPL 8170503 Contact Us For Availability

Nameplate (White) WPL 8170505 Contact Us For Availability

Nameplate (Biscuit) WPL 8170512 Contact Us For Availability

Shelf, S/G (3) WPL 8170421 Contact Us For Availability

Cover WPL 4343852 Contact Us For Availability

12968202W Whirlpool Refrigerator Door Stop Backorder WPL 12968202W $27.71

67003781 Whirlpool Refrigerator Door Stop (BS Backorder WPL 67003781 $33.62

W11708403 Whirlpool Door Stop Backorder WPL W11708403 $5.07

WP4344040 Whirlpool Refrigerator Overload Backorder WPL WP4344040 $47.47

Shelf Bin (3) WPL 8170300 Contact Us For Availability

Clamp WPL 4344509 Contact Us For Availability

Screw WPL 4344469 Contact Us For Availability

Frame Assy (3) WPL 8170420 Contact Us For Availability

WPW10348409 Whirlpool Screw In Stock WPL WPW10348409 $2.51

Shim, Hinge Top (White (.062)) WPL 8170678 Contact Us For Availability

Shim, Hinge Top (Almond (.031)) WPL 8170679 Contact Us For Availability

Shim, Hinge Top (Black (.015)) WPL 8170680 Contact Us For Availability

Frame, Breaker WPL 8170608 Contact Us For Availability

Rack, Wine WPL 4344294 Contact Us For Availability

Gasket WPL 4344275 Contact Us For Availability

14

Trim, Door WPL 4344536 Contact Us For Availability

14

Socket (2) WPL 8170384 Contact Us For Availability

14

Bi-Metal WPL 8170432 Contact Us For Availability

15

WPW10189190 Whirlpool Start Device In Stock WPL WPW10189190 $64.45

15

Hinge, Center WPL 4344431 Contact Us For Availability

15

Screw (2) WPL 4343861 Contact Us For Availability

Shim, Center Hinge (Black) WPL 4344425 Contact Us For Availability

Shim, Center Hinge (Almond) WPL 4344426 Contact Us For Availability

Shim, Center Hinge (White) WPL 4344427 Contact Us For Availability

Shield, Light (2) WPL 4344472 Contact Us For Availability

Clip, Heat WPL 4344497 Contact Us For Availability

WP65889-4 Whirlpool Refrigerator Capacitor In Stock WPL WP65889-4 $38.80

Bushing (Black) WPL 4344361 Contact Us For Availability

Bushing (White) WPL 4344362 Contact Us For Availability

Clamp, Tube WPL 8170436 Contact Us For Availability

Knob (2) WPL 4344468 Contact Us For Availability

Pan, Crisper WPL 8170425 Contact Us For Availability

Plug, Button (Black) WPL 4344432 Contact Us For Availability

Plug, Button (White) WPL 4344434 Contact Us For Availability

Plug, Button (Biscuit) WPL 8170686 Contact Us For Availability

Elbow, Drain Tube WPL 4344506 Contact Us For Availability

Screw WPL 4344167 Contact Us For Availability

Support, Crisper Cvr WPL 8170423 Contact Us For Availability

Shield, Capacitor WPL 4344277 Contact Us For Availability

Screw WPL 4343811 Contact Us For Availability

Hinge Bottom (Black) WPL 8170635 Contact Us For Availability

Hinge Bottom (White) WPL 8170636 Contact Us For Availability

Clip, Wire WPL 4343969 Contact Us For Availability

WP67006715 Whirlpool Refrigerator Screw Backorder WPL WP67006715 $3.70

Insulation WPL 4344459 Contact Us For Availability

Filter WPL 4344544 Contact Us For Availability

Cover, Pan WPL 8170422 Contact Us For Availability

Gasket WPL 4344495 Contact Us For Availability

67007018 Whirlpool Refrigerator Bottom Hinge Backorder WPL 67007018 $3.70

Bushing (Black) WPL 4344542 Contact Us For Availability

Bushing (White) WPL 4344543 Contact Us For Availability

Glass, Crisper Cover WPL 8170424 Contact Us For Availability

Grille (Black) WPL 4344519 Contact Us For Availability

Grille (White) WPL 4344521 Contact Us For Availability

Grille (Biscuit) WPL 8170613 Contact Us For Availability

Plate, Tap WPL 4344453 Contact Us For Availability

Ladder, Center WPL 8170437 Contact Us For Availability

Evaporator WPL 4344418 Contact Us For Availability

Screw WPL 4344267 Contact Us For Availability

Insulation WPL 4344454 Contact Us For Availability

Plug, Button (Biscuit) WPL 8170623 Contact Us For Availability

Plug, Button (Black) WPL 8170624 Contact Us For Availability

Plug, Button (White) WPL 8170625 Contact Us For Availability

Ladder, Side WPL 4344323 Contact Us For Availability

24

Plug, I/M WPL 4344264 Contact Us For Availability

24

Heater, Mullion WPL 8170418 Contact Us For Availability

24

Motor, Fan WPL 4344419 Contact Us For Availability

W11673433 Whirlpool Clip Backorder WPL W11673433 $59.77

Mullion (Black) WPL 8170605 Contact Us For Availability

Mullion (White) WPL 8170606 Contact Us For Availability

Screw WPL 4344523 Contact Us For Availability

WP489349 Whirlpool Refrigerator Screw In Stock WPL WP489349 $2.51

Plate, Cover WPL 4344485 Contact Us For Availability

Plug-Trim WPL 4344346 Contact Us For Availability

Wire Cover (2) WPL 4344503 Contact Us For Availability

Harness, Unit WPL 8170611 Contact Us For Availability

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $23.50

Gasket WPL 4344492 Contact Us For Availability

Back Cover WPL 8170375 Contact Us For Availability

Screw WPL 4344458 Contact Us For Availability

Screw WPL 4344493 Contact Us For Availability

W10309994 Whirlpool Refrigerator Compressor In Stock WPL W10309994 $298.57

Screw WPL 8170431 Contact Us For Availability

Butter Dish WPL 4344296 Contact Us For Availability

Harness, Control WPL 8170430 Contact Us For Availability

Insulation WPL 8170429 Contact Us For Availability

Screw WPL 4344494 Contact Us For Availability

W10833899 Whirlpool Refrigerator Water Inlet In Stock WPL W10833899 $140.35

Gasket WPL 4344499 Contact Us For Availability

Holder, Beverage WPL 4344374 Contact Us For Availability

Thermostat (Includes Items 30 & 33) WPL 8170428 Contact Us For Availability

Spacer, Crisper WPL 4344446 Contact Us For Availability

W10136387A Whirlpool Refrigerator Egg Contain In Stock WPL W10136387A $5.98

WP12246608 Whirlpool Refrigerator Button In Stock WPL WP12246608 $3.70

WP67001130 Whirlpool Refrigerator White Butto Backorder WPL WP67001130 $3.70

Cover, Unit WPL 8170434 Contact Us For Availability

Pinion, Control WPL 4344476 Contact Us For Availability

WP841180A Whirlpool Microwave Glass Turntable In Stock WPL WP841180A $3.92

Screw WPL 8170313 Contact Us For Availability

Plug, Button WPL 4344210 Contact Us For Availability

Rack, Control WPL 4344475 Contact Us For Availability

Shroud WPL 4344554 Contact Us For Availability

WP2264462 Whirlpool Refrigerator Grommet In Stock WPL WP2264462 $16.25

Power Cord WPL 4344263 Contact Us For Availability

Control, Damper (Includes Items 30, 33, 34 & WPL 4344406 Contact Us For Availability

Ladder, Frz RS WPL 4344489 Contact Us For Availability

Bracket, Fan Motor WPL 4344272 Contact Us For Availability

WPW10189703 Whirlpool Refrigerator Evaporator In Stock WPL WPW10189703 $35.77

Grommet WPL 4344259 Contact Us For Availability

Tube, Plastic WPL 4344481 Contact Us For Availability

Ladder, Frz LS WPL 4344490 Contact Us For Availability

Bracket, Lower WPL 4344393 Contact Us For Availability

PLug WPL 4344260 Contact Us For Availability

Insert, Damper WPL 4344477 Contact Us For Availability

Clip, Drier WPL 4343763 Contact Us For Availability

35

Insulation WPL 4344478 Contact Us For Availability

Gasket WPL 4344507 Contact Us For Availability

Shield, Wire WPL 4344480 Contact Us For Availability

Block, Evaporator (Left Side) WPL 4344482 Contact Us For Availability

Block, Evaporator (Right Side) WPL 4344500 Contact Us For Availability

37

Closure, Door (Black Model) WPL 4344429 Contact Us For Availability

37

Closure, Door (White) WPL 4344430 Contact Us For Availability

37

Switch WPL 4344422 Contact Us For Availability

38

W11384469 Whirlpool Door Switch In Stock WPL W11384469 $12.68

38

Clip WPL 8170435 Contact Us For Availability

39

WPM0104106 Whirlpool Refrigerator Clip Backorder WPL WPM0104106 $2.51

39

Housing WPL 8170609 Contact Us For Availability

39

Grommet (4) WPL 4343845 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

4396418 Whirlpool Ice Maker Backorder WPL 4396418 $192.72

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $26.21

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $96.00

R0168027 Whirlpool Refrigerator Defrost Timer Backorder WPL R0168027 $86.79

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

WPL 876029 WPL 876029 Contact Us For Availability

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

Torx Key WPL 1117510 Contact Us For Availability

Shim, Hinge (White) WPL 8170662 Contact Us For Availability

Shim, Hinge (Black) WPL 8170663 Contact Us For Availability

Ice Container Assembly WPL 4343700 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

WPL 799340 WPL 799340 Contact Us For Availability

WPL 799833 WPL 799833 Contact Us For Availability

WPL 978883 WPL 978883 Contact Us For Availability

Screw WPL 4344562 Contact Us For Availability

41

Hinge Top WPL 8170659 Contact Us For Availability

41

Screw (2) WPL 4344511 Contact Us For Availability

Hinge Cover (Black) WPL 4344195 Contact Us For Availability

Hinge Cover (White) WPL 8170379 Contact Us For Availability

Hinge Cover (Biscuit) WPL 8170488 Contact Us For Availability

Clip, Evaporator WPL 4344487 Contact Us For Availability

43

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $2.51

44

WPL 8170380 WPL 8170380 Contact Us For Availability

44

Screw (2) WPL 4343847 Contact Us For Availability

45

W11573574 Whirlpool Screw In Stock WPL W11573574 $9.59

46

W11177593 Whirlpool Leveling Feet Backorder WPL W11177593 $7.08

46

Clamp WPL 4343661 Contact Us For Availability

47

WPL ARI112917A WPL ARI112917A Contact Us For Availability

48

Screw WPL 4343749 Contact Us For Availability

48

WPL 4343759 WPL 4343759 Contact Us For Availability

49

Cabinet, Brace WPL 4344518 Contact Us For Availability

50

67006425 Whirlpool Refrigerator Screw In Stock WPL 67006425 $2.51

51

Axle-Roller WPL 4344289 Contact Us For Availability

52

Roller-Rear WPL 4344288 Contact Us For Availability

53

Screw WPL 4344292 Contact Us For Availability

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

Brace WPL 8170612 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability
