Model Whirlpool KHMS2050SBL0 MICROWAVE HOOD COMBINATION – Common Parts &amp; Diagrams

1

W10110267 Whirlpool Microwave Door Handle Backorder WPL W10110267 $102.90

1

Handle (Stainless Steel) WPL 8206504 Contact Us For Availability

1

Housing, Blower (Left) WPL 8206092 Contact Us For Availability

1

Handle (White) WPL 8206501 Contact Us For Availability

1

Handle (Biscuit) WPL 8206503 Contact Us For Availability

1

Case, Outer (White) WPL 8206027 Contact Us For Availability

1

Case, Outer (Black) WPL 8206028 Contact Us For Availability

1

Case, Outer (Biscuit) WPL 8206029 Contact Us For Availability

1

Case, Outer (Apollo Grey) WPL 8206030 Contact Us For Availability

2

W10843943 Whirlpool Microwave Vent Damper In Stock WPL W10843943 $55.48

2

Reflector, Lamp WPL 8184194 Contact Us For Availability

2

Rack WPL 8206117 Contact Us For Availability

3

W10315274 Whirlpool Microwave Meal Rack Backorder WPL W10315274 $26.90

3

Lid, Power Cord WPL 8184897 Contact Us For Availability

4

8204670 Whirlpool Microwave Halogen Lamp 10W In Stock WPL 8204670 $10.58

4

W10115577 Whirlpool Microwave Sensor Backorder WPL W10115577 $56.29

4

W11380570 Whirlpool Microwave Screw In Stock WPL W11380570 $9.86

4

Control Panel WPL 8206635 Contact Us For Availability

5

8206079 Whirlpool Microwave Magnetron In Stock WPL 8206079 $148.65

5

Button (Stainless Steel) WPL 8206485 Contact Us For Availability

5

Outer Door Frame (White) WPL 8206518 Contact Us For Availability

5

Button (Biscuit) WPL 8206484 Contact Us For Availability

5

Holder, Lamp WPL W10113781 Contact Us For Availability

5

Vent Screen (Middle) WPL 8206475 Contact Us For Availability

6

Motor, Capacitor WPL 8206080 Contact Us For Availability

6

Deflector, Air WPL 8205980 Contact Us For Availability

6

Support, Vent Screen (White) WPL 8206011 Contact Us For Availability

6

Support, Vent Screen (Universal Silver) WPL 8206016 Contact Us For Availability

6

Support, Vent Screen (Black) WPL 8206012 Contact Us For Availability

6

Support, Vent Screen (Biscuit) WPL 8206015 Contact Us For Availability

7

Vent Screen (Left) WPL 8206207 Contact Us For Availability

7

Housing, Valve WPL 8206081 Contact Us For Availability

8

CAM PLATE, UPPER WPL W10113786 Contact Us For Availability

8

Plate, Back WPL 8206051 Contact Us For Availability

9

Cntrl Panel Plate WPL 8206511 Contact Us For Availability

9

Plate, Mounting WPL 8206319 Contact Us For Availability

10

Cntrl Panel Cover WPL 8206512 Contact Us For Availability

10

Cord, Power WPL 8206182 Contact Us For Availability

11

4393836 Whirlpool Microwave Screw Backorder WPL 4393836 $2.73

11

Reflector, Lamp WPL 8184132 Contact Us For Availability

11

Cover, Inverter WPL 8206085 Contact Us For Availability

8206185 Whirlpool Microwave Wire Harness Backorder WPL 8206185 $33.53

W10470173 Whirlpool Microwave Wire Harness Backorder WPL W10470173 $8.02

W10470175 Whirlpool Microwave Wire Harness Backorder WPL W10470175 $7.69

W10470176 Whirlpool Microwave Wire Harness Backorder WPL W10470176 $7.47

W10470191 Whirlpool Microwave Wire Harness As Backorder WPL W10470191 $54.55

W10553076 Whirlpool Microwave Wire Harness Backorder WPL W10553076 $67.97

W10748097 Whirlpool Microwave Crisp Pan In Stock WPL W10748097 $31.42

WP8206493 Whirlpool Microwave Electronic Cont In Stock WPL WP8206493 $113.87

Installation, Hardware WPL 8205979 Contact Us For Availability

Vent Screen (Right) WPL 8206206 Contact Us For Availability

Ferrite Ring WPL 8206086 Contact Us For Availability

Template, Upper WPL 8205274 Contact Us For Availability

Miscellaneous WPL ARI88582A6 Contact Us For Availability

Harns-Wire,71 RCB WPL W10112290 Contact Us For Availability

Main Harness WPL W10113062 Contact Us For Availability

Harns-Wire, RCB - Inverter WPL W10113777 Contact Us For Availability

Harns-Wire 75 P64 RCB WPL W10113779 Contact Us For Availability

Harns-Wire 76 P2 RCB WPL W10113780 Contact Us For Availability

13

8205992 Whirlpool Microwave Cook Tray Backorder WPL 8205992 $43.48

13

W10217711 Whirlpool Microwave Inverter In Stock WPL W10217711 $204.09

14

8206035 Whirlpool Microwave Thermostat In Stock WPL 8206035 $45.57

14

Ring, Turntable WPL 8206222 Contact Us For Availability

15

8205994 Whirlpool Microwave Support Backorder WPL 8205994 $11.93

15

Holder, Filter WPL 8206060 Contact Us For Availability

15

Holder, Inverter WPL 8206089 Contact Us For Availability

16

W10851464 Whirlpool Microwave Handle Panel In Stock WPL W10851464 $8.45

16

Resistor (50W) WPL W10113782 Contact Us For Availability

16

Air Guide, Magnetron WPL 8206494 Contact Us For Availability

8205572 Whirlpool Microwave Interlock In Stock WPL 8205572 $3.70

8206525 Whirlpool Microwave Spacer Backorder WPL 8206525 $2.51

W10113783 Whirlpool Microwave Resistor Backorder WPL W10113783 $37.06

Spacer, Side (6) (White) WPL 8206522 Contact Us For Availability

Spacer, Side (6) (Black) WPL 8206523 Contact Us For Availability

Clip, Cavity Lamp WPL 8206034 Contact Us For Availability

18

8184109 Whirlpool Microwave Spacer Backorder WPL 8184109 $3.70

18

Spring, Interlock WPL 8206091 Contact Us For Availability

18

Support & Base Thermostat Assy WPL 8206212 Contact Us For Availability

W10211972 Whirlpool Microwave Switch In Stock WPL W10211972 $32.67

Connector Shaft WPL 8206263 Contact Us For Availability

Spacer, Bottom (2) WPL 8206178 Contact Us For Availability

Motor, Turntable WPL 8206102 Contact Us For Availability

4393832 Whirlpool Microwave Screw Backorder WPL 4393832 $9.59

SPRING WPL 8206499 Contact Us For Availability

Frame, Glass WPL 8169646 Contact Us For Availability

Holder, Fuse WPL 8184312 Contact Us For Availability

21

W11707984 Whirlpool Thermal Fuse In Stock WPL W11707984 $19.18

21

Housing, Blower (Right) WPL 8206112 Contact Us For Availability

22

W10269458 Whirlpool Microwave Door Switch In Stock WPL W10269458 $15.87

22

Door Plate Assy WPL W10112215 Contact Us For Availability

23

W10211974 Whirlpool Microwave Door Interlock In Stock WPL W10211974 $24.34

23

Hinge Screw WPL 8206181 Contact Us For Availability

23

Spacer WPL 8206116 Contact Us For Availability

Humidity Sensor & Thermostat Assy WPL 8206026 No Longer Available

Spring, Hook WPL W10113792 Contact Us For Availability

Dr Innr Frm Assy WPL 8206531 Contact Us For Availability

Cover, Inlet WPL 8206066 Contact Us For Availability

25

Lid, Lamp WPL 8206476 Contact Us For Availability

25

Support, Air Guide WPL 8206031 Contact Us For Availability

26

Protector, Wire WPL 8206477 Contact Us For Availability

27

Clip, Saddle WPL 8206037 Contact Us For Availability

28

8206038 Whirlpool Clip Assembly Backorder WPL 8206038 $6.30

29

8206209 Whirlpool Microwave Interlock Switch Backorder WPL 8206209 $3.70

30

Piston Assembly WPL 8206210 Contact Us For Availability

31

Cam Plate (Lower) WPL W10113787 Contact Us For Availability
