Model Whirlpool KGCT365GWH1 GAS COOKTOP – Common Parts &amp; Diagrams

8186533 Whirlpool Hardware Backorder WPL 8186533 $30.25

W10392007 Whirlpool Power Cord Backorder WPL W10392007 $37.33

WP3192741 Whirlpool LP Conversion Kit In Stock WPL WP3192741 $21.74

Seal, Foam-Cooktop Miscellaneous WPL 3191933 Contact Us For Availability

Hardware, Mounting WPL 3188310 Contact Us For Availability

Harness, Ignitor 15`` (2) WPL 3192229 Contact Us For Availability

Harness, Ignitor 28`` (2) WPL 3192230 Contact Us For Availability

Tinnerman Nut WPL 4167077 Contact Us For Availability

Safer Cooking Tips WPL LIT3191638 Contact Us For Availability

Installation Instructions WPL LIT3191827 Contact Us For Availability

Wiring Diagram WPL LIT3192098 Contact Us For Availability

Conversion Instructions WPL LIT3192742 Contact Us For Availability

Use & Care Guide WPL LIT3193071 Contact Us For Availability

1

W10203756 Whirlpool Support Backorder WPL W10203756 $6.37

2

3192491 Whirlpool Support Bracket Backorder WPL 3192491 $6.00

2

W10854242 Whirlpool Grommet In Stock WPL W10854242 $3.92

2

WP3180081 Whirlpool Grommet In Stock WPL WP3180081 $3.79

2

Pipe, Manifold WPL 3191316 Contact Us For Availability

3

Valve, Gas Burner Burner, (RF) WPL 3191292 Contact Us For Availability

4

WP3188425 Whirlpool Seal Switch In Stock WPL WP3188425 $30.25

5

Valve, Gas Burner (RR & LR) WPL 3191293 Contact Us For Availability

6

Cap, (RF) (Black) WPL 3191728 Contact Us For Availability

6

Valve, Gas Burner (LF) WPL 3192157 Contact Us For Availability

7

Cap, (LR) (Black) WPL 3191731 Contact Us For Availability

7

Rail, Center WPL 3192819 Contact Us For Availability

8

Cap, (RR) (Black) WPL 3191734 Contact Us For Availability

8

Bolt, Gas Valve WPL 307630 Contact Us For Availability

9

Cap, (LF) (Black) WPL 3191737 Contact Us For Availability

10

Grate, Burner (Black) WPL 3191485 Contact Us For Availability

10

Grate, Burner (White) WPL 3191486 Contact Us For Availability

10

Grate, Burner (Almond) WPL 3191487 Contact Us For Availability

11

Grate, Filler (Black) WPL 3191280 Contact Us For Availability

11

Grate, Filler (White) WPL 3191281 Contact Us For Availability

11

Grate, Filler (Almond/Biscuit) WPL 3191282 Contact Us For Availability

WP3191334 Whirlpool Wire Harness Backorder WPL WP3191334 $147.65

WP3191922 Whirlpool Control Knob In Stock WPL WP3191922 $3.88

Knob, Control (4) (White) WPL 3191923 Contact Us For Availability

Knob, Control (4) (Biscuit) WPL 3191925 Contact Us For Availability

Knob, Control (4) (Almond) WPL 3191924 Contact Us For Availability

13

WP9754215 Whirlpool Surface Igniter Backorder WPL WP9754215 $26.47

WP3192523 Whirlpool Orifice Backorder WPL WP3192523 $33.91

WP9753930 Whirlpool Orifice Backorder WPL WP9753930 $36.45

WPL 3192525 WPL 3192525 Contact Us For Availability

Tubing, Gas Burner (RF) WPL 3191324 Contact Us For Availability

WPL 3192528 WPL 3192528 Contact Us For Availability

814513 Whirlpool Top Burner In Stock WPL 814513 $87.69

WPL 9754188 WPL 9754188 Contact Us For Availability

WPL 9754182 WPL 9754182 Contact Us For Availability

WPL 9754187 WPL 9754187 Contact Us For Availability

Tubing, Gas Burner (LF) WPL 3191326 Contact Us For Availability

WP4455980 Whirlpool Burner Head In Stock WPL WP4455980 $39.31

WP4455981 Whirlpool Burner Head Backorder WPL WP4455981 $54.75

Tubing, Gas Burner (RR) WPL 3191325 Contact Us For Availability

WPL 8273216 WPL 8273216 Contact Us For Availability

WPL 9754181 WPL 9754181 Contact Us For Availability

17

WP3177991 Whirlpool Screw Backorder WPL WP3177991 $2.51

17

Tubing, Gas Burner (LR) WPL 3191327 Contact Us For Availability

18

3191462 Whirlpool Oven Heat Shield Backorder WPL 3191462 $10.91

19

WPL 3148442 WPL 3148442 Contact Us For Availability

21

Regulator, Pressure WPL 3177120 Contact Us For Availability

22

Burner Box WPL 3192494 Contact Us For Availability

27

WP8053421 Whirlpool Oven Spark Module In Stock WPL WP8053421 $83.70
