Model Whirlpool KFCP02IRWH0 TRASH COMPACTOR – Common Parts &amp; Diagrams

1

Panel, Container Front/Handle (Black/Black) WPL 4396296 Contact Us For Availability

1

Panel, Container Front/Handle (White/White) WPL 4396297 Contact Us For Availability

1

Panel, Container Front/Handle (Biscuit/Biscui WPL 4396298 Contact Us For Availability

1

Panel, Container Front/Handle (Cobalt Blue/SS WPL 4396299 Contact Us For Availability

1

Panel, Container Front/Handle (Empire Red/SSt WPL 4396300 Contact Us For Availability

1

Panel, Container Front/Handle (Majestic Yello WPL 9871805 Contact Us For Availability

2

9870867 Whirlpool Shield Backorder WPL 9870867 $8.05

2

W10165294RB Whirlpool Trash Compactor Bags (1 In Stock WPL W10165294RB $42.55

2

W10165295RP Whirlpool Trash Compactor Bags 15 In Stock WPL W10165295RP $10.21

3

779121 Whirlpool Compactor Plate Backorder WPL 779121 $12.32

3

W11722978 Whirlpool Slide Backorder WPL W11722978 $51.02

3

WP9870975 Whirlpool Compactor Slide Backorder WPL WP9870975 $32.94

3

Deodorizer, Solid Stick-Ups (2-Pack) WPL 777635 Contact Us For Availability

4

776327 Whirlpool Compactor Motor Plate Backorder WPL 776327 $40.88

4

W10540355 Whirlpool Deodorant In Stock WPL W10540355 $5.95

4

W10917043 Whirlpool Compactor Bearing Backorder WPL W10917043 $9.59

4

Deodorizer Block (Lavender) WPL 9872166L Contact Us For Availability

4

Deodorizer Block (Lemongrove) WPL 9872166LG Contact Us For Availability

5

13030RP Whirlpool Compactor Bag Caddy In Stock WPL 13030RP $21.05

5

776941 Whirlpool Compactor Power Crew Hub Backorder WPL 776941 $8.86

6

775481 Whirlpool Compactor Bearing Backorder WPL 775481 $29.74

6

WP777108 Whirlpool Compactor Bag Handle Backorder WPL WP777108 $8.16

7

675351 Whirlpool Compactor Grease In Stock WPL 675351 $34.20

7

9871989W Whirlpool Compactor Foot Pedal Assem Backorder WPL 9871989W $52.70

7

WP454512 Whirlpool Compactor Spring Pin Backorder WPL WP454512 $3.70

8

4154842 Whirlpool Compactor Nut Backorder WPL 4154842 $29.10

8

776035 Whirlpool Compactor Washer Backorder WPL 776035 $9.59

8

WP780263 Whirlpool Compactor Screw In Stock WPL WP780263 $2.51

8

Wire (16 Ga. 80 c Blue) WPL 10875 Contact Us For Availability

8

Wire (14 Ga. 150 c Black) WPL 242820 Contact Us For Availability

8

Wire (14 Ga. 150 c Red) WPL 242825 Contact Us For Availability

8

Wire, 25`` Roll (White 14 GA.) WPL 242826 Contact Us For Availability

8

Wire, 25` Roll (Red 12 Ga.) WPL 299885 Contact Us For Availability

8

Wire, 25`` Roll (Black 12 GA.) WPL 47261 Contact Us For Availability

8

Wire, 25`` Roll (White 12 GA.) WPL 47263 Contact Us For Availability

9

W11214485 Whirlpool Compactor Washer Backorder WPL W11214485 $9.59

9

WP279368 Whirlpool High-Temperature Silicone In Stock WPL WP279368 $29.08

9

WP777332 Whirlpool Compactor Washer Backorder WPL WP777332 $2.38

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

8171571 Whirlpool Touch-Up Paint Cobalt Blue Backorder WPL 8171571 $12.81

8171651 Whirlpool Touch Up Backorder WPL 8171651 $8.40

8171652 Whirlpool Touch-Up Backorder WPL 8171652 $10.07

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

Paint, Touch-Up 1/2 Oz. (Biscuit) WPL 4892899 Contact Us For Availability

WPL 8171653 WPL 8171653 Contact Us For Availability

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $26.26

882763 Whirlpool Compactor Front Trim Backorder WPL 882763 $70.59

W11696573 Whirlpool Ram Backorder WPL W11696573 $129.98

WP9871799 Whirlpool Compactor Switch Knob In Stock WPL WP9871799 $37.08

WPL 9871383 WPL 9871383 Contact Us For Availability

WPL 9871600 WPL 9871600 Contact Us For Availability

780477 Whirlpool Compactor Drive Chain Backorder WPL 780477 $80.02

9871125 Whirlpool Compactor Actuator Backorder WPL 9871125 $9.52

WP777383 Whirlpool Compactor Nut In Stock WPL WP777383 $4.89

WP9870163 Whirlpool Compactor Trunnion Nut In Stock WPL WP9870163 $29.77

13

WP90296 Whirlpool Clip Backorder WPL WP90296 $2.51

15

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

16

WP9870037 Whirlpool Ram Stop Backorder WPL WP9870037 $3.70

16

WP9871602 Whirlpool Compactor Bearing In Stock WPL WP9871602 $7.01

17

WP776356 Whirlpool Compactor Nut Backorder WPL WP776356 $2.51

17

Bracket, Top Limit Switch WPL 9870498 Contact Us For Availability

18

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $2.51

18

WP777811 Whirlpool Compactor Directional Swit In Stock WPL WP777811 $38.74

18

Switch Assembly (White) WPL 9871766 Contact Us For Availability

19

777849 Whirlpool Compactor Screw Backorder WPL 777849 $4.85

19

Cover, Air Freshener (White) WPL 9870911 Contact Us For Availability

20

W10917246 Whirlpool Compactor RAM Slide Backorder WPL W10917246 $45.64

20

WP4151750 Whirlpool Charcoal Air Filter In Stock WPL WP4151750 $6.59

21

775736 Whirlpool Compactor Spring Backorder WPL 775736 $28.80

23

775665 Whirlpool Compactor Plate Latch Backorder WPL 775665 $35.28

24

WP3196175 Whirlpool Screw In Stock WPL WP3196175 $2.51

30

WP9870444 Whirlpool Compactor Inner Panel Backorder WPL WP9870444 $35.76

33

WP777180 Whirlpool Compactor Spring In Stock WPL WP777180 $28.80
