Model Whirlpool KDDC24CVS01 DOUBLE DRAWER – Common Parts &amp; Diagrams

1

WPW10287744 Whirlpool Refrigerator Compressor Backorder WPL WPW10287744 $276.88

1

Drawer Box Assy. WPL W10204697 Contact Us For Availability

1

BRACKET, FILTER WPL W10281555 Contact Us For Availability

2

W10772873 Whirlpool Screw Backorder WPL W10772873 $28.44

2

SCREW WPL W10281556 Contact Us For Availability

2

Top Mat WPL W10204698 Contact Us For Availability

3

WP2186494B Whirlpool Refrigerator Filter Cap In Stock WPL WP2186494B $25.25

3

WP4344779 Whirlpool Refrigerator Grommet Backorder WPL WP4344779 $3.70

3

Drawer Partition WPL W10204699 Contact Us For Availability

4

8201597 Whirlpool Inlet Water Fill Tube Kit F In Stock WPL 8201597 $25.33

4

WPW10233777 Whirlpool Refrigerator Slide Backorder WPL WPW10233777 $133.50

4

SUPPORT SHELF, LH (TOP DRAWER) WPL W10233778 Contact Us For Availability

4

Rear Insulation WPL W10204672 Contact Us For Availability

5

WP2225521 Whirlpool Water Filter Housing In Stock WPL WP2225521 $92.74

5

WPW10204700 Whirlpool Refrigerator Gasket In Stock WPL WPW10204700 $116.84

5

SUPPORT SHELF, RH (TOP DRAWER) WPL W10233779 Contact Us For Availability

5

REAR COVER WPL W10281501 Contact Us For Availability

6

EDR6D1 Whirlpool EveryDrop® Ice and Water Re In Stock WPL EDR6D1 $43.40

6

CABINET BASE PLATE WPL W10238066 Contact Us For Availability

6

TOP DOOR ASSY. WPL W10392451 Contact Us For Availability

7

W10204674 Whirlpool Refrigerator Baffle Backorder WPL W10204674 $47.20

7

W10204808 Whirlpool Refrigerator Screw Backorder WPL W10204808 $26.21

7

W10281561 Whirlpool Refrigerator Block Backorder WPL W10281561 $26.21

8

4344771 Whirlpool Refrigerator Clip Backorder WPL 4344771 $34.39

8

W10772928 Whirlpool Refrigerator Water Tube Backorder WPL W10772928 $55.59

8

W11106296 Whirlpool Refrigerator Leveler Backorder WPL W11106296 $6.35

8

SCREW WPL W10204809 Contact Us For Availability

9

4344820 Whirlpool Refrigerator Support Backorder WPL 4344820 $78.90

9

W10163273 Whirlpool Refrigerator Tube Backorder WPL W10163273 $29.43

9

W10204810 Whirlpool Screw Backorder WPL W10204810 $26.21

9

WP2307650 Whirlpool Refrigerator Inlet Valve In Stock WPL WP2307650 $91.62

10

4344821 Whirlpool Refrigerator Support Backorder WPL 4344821 $44.01

10

W10281565 Whirlpool Refrigerator Bracket Backorder WPL W10281565 $26.21

10

Top Wrap WPL W10204861 Contact Us For Availability

W10204640 Whirlpool Refrigerator Clip Backorder WPL W10204640 $26.21

W10837731 Whirlpool Screw Assembly In Stock WPL W10837731 $2.51

WP2196157 Whirlpool Fill Tube In Stock WPL WP2196157 $4.59

Drain Tray WPL W10163193 Contact Us For Availability

W10163276 Whirlpool Refrigerator Trap Backorder WPL W10163276 $28.80

W10281315 Whirlpool Refrigerator Bi-Metal Backorder WPL W10281315 $176.59

WP488878 Whirlpool Refrigerator Tube Clamp Backorder WPL WP488878 $4.81

Plate, Door Handle WPL 4344809 Contact Us For Availability

13

W10163274 Whirlpool Pad Backorder WPL W10163274 $40.15

13

W10859467 Whirlpool Refrigerator Screw Backorder WPL W10859467 $26.21

13

SCREW WPL W10281585 Contact Us For Availability

14

W10204867 Whirlpool Front Drawer Backorder WPL W10204867 $41.85

14

W10281586 Whirlpool Refrigerator Fitting Backorder WPL W10281586 $40.99

14

WPW10204676 Whirlpool Refrigerator Power Cord Backorder WPL WPW10204676 $45.31

W10204677 Whirlpool Refrigerator Condenser Mo Backorder WPL W10204677 $166.63

W10204868 Whirlpool Front Drawer Backorder WPL W10204868 $9.10

CABINET (NOT A SERVICABLE PART) WPL NP Contact Us For Availability

TUBE CLAMP WPL W10281587 Contact Us For Availability

16

W10287745 Whirlpool Refrigerator Overload Backorder WPL W10287745 $55.93

16

W10488357 Whirlpool Refrigerator Wire Harness Backorder WPL W10488357 $176.09

17

W10287848 Whirlpool Refrigerator Thermistor Backorder WPL W10287848 $65.54

17

SCREW WPL W10281588 Contact Us For Availability

17

LEAD WIRE SUPPORT WPL W10488627 Contact Us For Availability

W10281589 Whirlpool Refrigerator Tape Backorder WPL W10281589 $26.21

PCB Box Film WPL W10204646 Contact Us For Availability

CAPACITOR WPL W10287954 Contact Us For Availability

CONTROL PANEL ASSY WPL W10273123 Contact Us For Availability

W11625904 Whirlpool Refrigerator Ice Pan In Stock WPL W11625904 $24.25

MAIN PCB WPL W10281497 Contact Us For Availability

CLAMP, CORD WPL W10270517 Contact Us For Availability

HANDLE WPL W10204888 Contact Us For Availability

20

4317943 Whirlpool Refrigerator Ice Maker Asse In Stock WPL 4317943 $88.85

20

W10204920 Whirlpool Refrigerator Nut Backorder WPL W10204920 $26.21

20

Edge Trim WPL 4344907 Contact Us For Availability

W10204659 Whirlpool Refrigerator Spacer Backorder WPL W10204659 $26.21

W10204889 Whirlpool Refrigerator Gasket Backorder WPL W10204889 $42.60

W10281546 Whirlpool Refrigerator Arm Shut Backorder WPL W10281546 $44.47

Screw WPL 4344825 Contact Us For Availability

2256178 Whirlpool Shield Assembly Backorder WPL 2256178 $69.97

W10204897 Whirlpool Refrigerator Gasket Backorder WPL W10204897 $46.83

W10281498 Whirlpool Refrigerator Wire Harness Backorder WPL W10281498 $136.44

W11380570 Whirlpool Microwave Screw In Stock WPL W11380570 $9.86

23

W10205081 Whirlpool Refrigerator Tape Backorder WPL W10205081 $33.93

23

Screw WPL W10205069 Contact Us For Availability

23

BOLT WPL W10270492 Contact Us For Availability

24

4344826 Whirlpool Refrigerator Screw Backorder WPL 4344826 $9.61

24

W10488628 Whirlpool Refrigerator Bracket Backorder WPL W10488628 $114.12

24

CONTROL PANEL WPL W10281502 Contact Us For Availability

25

4344797 Whirlpool Screw Backorder WPL 4344797 $9.15

25

LABEL, PANEL WPL W10281504 Contact Us For Availability

25

SCREW WPL W10281549 Contact Us For Availability

26

4344913 Whirlpool Label Assembly Backorder WPL 4344913 $25.22

26

W10204929 Whirlpool Cover Backorder WPL W10204929 $28.80

26

HARNESS, DEFROST WPL W10281550 Contact Us For Availability

27

W10204930 Whirlpool Refrigerator Light Lens Backorder WPL W10204930 $127.61

27

W10281551 Whirlpool Refrigerator Wire Harness Backorder WPL W10281551 $31.00

27

Fan Cover WPL W10204687 Contact Us For Availability

28

W10204688 Whirlpool Plate Assembly Backorder WPL W10204688 $26.21

28

W10204931 Whirlpool Socket Assembly Backorder WPL W10204931 $26.21

28

W10281552 Whirlpool Refrigerator Extension Backorder WPL W10281552 $81.34

29

W10281553 Whirlpool Refrigerator Shield Backorder WPL W10281553 $26.21

29

Vibration Rubber A WPL W10204689 Contact Us For Availability

30

W10204933 Whirlpool Refrigerator Wire Harness Backorder WPL W10204933 $71.88

30

WPW10289690 Whirlpool Ice Maker Cover Backorder WPL WPW10289690 $2.51

30

Vibration Rubber B WPL W10204690 Contact Us For Availability

31

4344829 Whirlpool Tie Wire Backorder WPL 4344829 $9.15

31

W10304194 Whirlpool Refrigerator Wire Harness Backorder WPL W10304194 $54.97

32

Bracket, Timer WPL 4344773 Contact Us For Availability

32

Screw WPL W10204935 Contact Us For Availability

33

W10205063 Whirlpool Thermistor Backorder WPL W10205063 $72.83

33

Panel Insulation WPL W10204936 Contact Us For Availability

34

W10205062 Whirlpool Wire Cover Backorder WPL W10205062 $26.21

34

Panel Insulation B WPL W10204937 Contact Us For Availability

35

Fan Cover WPL W10204941 Contact Us For Availability

36

W10854409 Whirlpool Refrigerator Evaporator M Backorder WPL W10854409 $132.50

37

W10270520 Whirlpool Refrigerator Switch Backorder WPL W10270520 $33.47

38

Sensor Case WPL W10204945 Contact Us For Availability

39

WPW10204946 Whirlpool Refrigerator Thermistor Backorder WPL WPW10204946 $37.46

40

W10204947 Whirlpool Refrigerator Wire Harness Backorder WPL W10204947 $131.28

41

W10204948 Whirlpool Refrigerator Control Box Backorder WPL W10204948 $26.21

42

W10281541 Whirlpool Refrigerator Sealer Backorder WPL W10281541 $25.22

43

PLATE COVER WPL W10281542 Contact Us For Availability

44

W10205061 Whirlpool Screw Assembly Backorder WPL W10205061 $26.21

45

NUT WPL W10270493 Contact Us For Availability
