Model Whirlpool KBFN506EPA05 REFRIGERATOR, ALL – Common Parts &amp; Diagrams

1

W10780417 Whirlpool Refrigerator Upper Grille Backorder WPL W10780417 $135.87

1

W11655239 Whirlpool Inverter Box Backorder WPL W11655239 $151.55

2

W10321050 Whirlpool Refrigerator Shield Backorder WPL W10321050 $26.21

2

W10529562 Whirlpool Refrigerator Front Panel Backorder WPL W10529562 $206.15

2

W10545068 Whirlpool Refrigerator Unit Cover Backorder WPL W10545068 $71.97

2

W10744328 Whirlpool Refrigerator Support Asse Backorder WPL W10744328 $122.57

2

SCREW WPL 489473 Contact Us For Availability

3

2307584 Whirlpool Refrigerator Grommet Backorder WPL 2307584 $12.70

3

W10529581 Whirlpool Refrigerator Crisper Pan Backorder WPL W10529581 $232.94

3

W10555476 Whirlpool Refrigerator Evaporator C Backorder WPL W10555476 $87.80

3

W11557671 Whirlpool Refrigerator Compressor In Stock WPL W11557671 $445.05

3

W11624204 Whirlpool Screw Backorder WPL W11624204 $9.59

4

W10672300 Whirlpool Refrigerator Slide Assemb Backorder WPL W10672300 $31.68

4

W11649686 Whirlpool Thermistor Backorder WPL W11649686 $17.95

4

W11661567 Whirlpool Wire Harness Backorder WPL W11661567 $37.50

4

W11673500 Whirlpool Door Hinge In Stock WPL W11673500 $61.63

4

WPW10138054 Whirlpool Refrigerator Cabinet Ro In Stock WPL WPW10138054 $15.79

4

COVER, CONDENSER SUPPORT WPL W11443120 Contact Us For Availability

4A

W10672302 Whirlpool Refrigerator Slide Backorder WPL W10672302 $25.60

5

W10803566 Whirlpool Shroud Assembly Backorder WPL W10803566 $32.28

5

W11712700 Whirlpool Insulation Backorder WPL W11712700 $32.67

5

SCREW WPL W10061370 Contact Us For Availability

6

2258903 Whirlpool Refrigerator Door Trim Backorder WPL 2258903 $87.01

6

W10529449 Whirlpool Refrigerator Cantilever B Backorder WPL W10529449 $137.99

6

W10759522 Whirlpool Screw Backorder WPL W10759522 $2.51

6

W11553819 Whirlpool Refrigerator Insulation In Stock WPL W11553819 $9.59

6

W11661108 Whirlpool Grommet Backorder WPL W11661108 $5.51

6

WP1163283 Whirlpool Air Conditioner Screw Backorder WPL WP1163283 $2.51

7

2309230 Whirlpool Refrigerator Clip Backorder WPL 2309230 $9.33

7

W10273369 Whirlpool Refrigerator Door Hinge Backorder WPL W10273369 $13.52

7

W10780423 Whirlpool Refrigerator Door Trim Backorder WPL W10780423 $48.29

7

W11311043 Whirlpool Heater Backorder WPL W11311043 $125.83

7

SUPPORT, CONDENSER (LEFT HAND) WPL W11443116 Contact Us For Availability

7A

2309231 Whirlpool Refrigerator Clip Backorder WPL 2309231 $30.58

7A

W10273367 Whirlpool Refrigerator Door Hinge Backorder WPL W10273367 $13.52

7A

SUPPORT, CONDENSER (RIGHT HAND) WPL W11443117 Contact Us For Availability

8

W10215666 Whirlpool Refrigerator Screw Backorder WPL W10215666 $5.65

8

W10570040 Whirlpool Refrigerator Door Trim Backorder WPL W10570040 $55.64

8

W10780421 Whirlpool Refrigerator Door Trim Backorder WPL W10780421 $48.29

8

W11368839 Whirlpool Refrigerator Inverter Box In Stock WPL W11368839 $126.29

8

WP8281164 Whirlpool Refrigerator Screw In Stock WPL WP8281164 $4.56

8

ASSEMBLY, FREEZER WIRE (NOT SERVICED) WPL ARI979C8CC753F702B16BE321F51DE68B7D Contact Us For Availability

9

2207457 Whirlpool Refrigerator Door Trim Backorder WPL 2207457 $42.33

9

W10600690 Whirlpool Refrigerator Ice Pan Backorder WPL W10600690 $115.38

9

W11247667 Whirlpool Refrigerator Cover Backorder WPL W11247667 $39.18

9

W11676465 Whirlpool Grommet Backorder WPL W11676465 $5.38

2006324 Whirlpool Refrigerator Cover Trim Backorder WPL 2006324 $19.00

2309022S Whirlpool Refrigerator Trim Cover Backorder WPL 2309022S $42.11

W11396715 Whirlpool Refrigerator Evaporator M In Stock WPL W11396715 $74.68

W11517121 Whirlpool Tube Assembly Backorder WPL W11517121 $40.39

WP488130 Whirlpool Air Conditioner Nut Backorder WPL WP488130 $3.09

2209084S Whirlpool Refrigerator Trim Cover Backorder WPL 2209084S $49.03

W10109030 Whirlpool Refrigerator Screw Backorder WPL W10109030 $8.73

W10555480 Whirlpool Refrigerator Shield Backorder WPL W10555480 $61.00

W10568445 Whirlpool Refrigerator Jumper Wire Backorder WPL W10568445 $24.85

W11712696 Whirlpool Clip Backorder WPL W11712696 $6.62

WPW10624574-includeCORE Whirlpool WPW10624574 Backorder WPL WPW10624574-includeCORE $196.64

COVER, SAFETY SWITCH WPL W11356980 Contact Us For Availability

W10555484 Whirlpool Refrigerator Housing Backorder WPL W10555484 $82.95

W10578289 Whirlpool Refrigerator Cantilever B Backorder WPL W10578289 $152.58

WP2163777 Whirlpool Refrigerator Fan Blade In Stock WPL WP2163777 $30.29

WP2203075 Whirlpool Refrigerator Spacer Backorder WPL WP2203075 $6.59

LINE, WATER WPL W10577944 Contact Us For Availability

INSULATION, UNIT BACK PANEL WPL W11244166 Contact Us For Availability

2256328 Whirlpool Bracket Assembly Backorder WPL 2256328 $28.20

2314030S Whirlpool Refrigerator Door Trim Backorder WPL 2314030S $131.08

2320554 Whirlpool Bracket Backorder WPL 2320554 $26.21

W10538315 Whirlpool Refrigerator Housing Backorder WPL W10538315 $30.38

W11291510 Whirlpool Refrigerator Valve Backorder WPL W11291510 $41.41

2309031S Whirlpool Refrigerator Door Trim Backorder WPL 2309031S $193.37

W10826105 Whirlpool Refrigerator Pro Service Backorder WPL W10826105 $60.18

W11661569 Whirlpool Thermistor Backorder WPL W11661569 $49.90

WP965173 Whirlpool Dishwasher Screw Backorder WPL WP965173 $2.64

GASKET, EVAPORATOR BYPASS WPL W11556942 Contact Us For Availability

2006329 Whirlpool Refrigerator Cover Trim Backorder WPL 2006329 $28.80

W10568582 Whirlpool Refrigerator CANT Shelf Backorder WPL W10568582 $0.00

W10570038 Whirlpool Refrigerator Door Trim Backorder WPL W10570038 $50.97

W10710400 Whirlpool Refrigerator Deflector Backorder WPL W10710400 $61.92

W11649689 Whirlpool Evaporator Backorder WPL W11649689 $152.90

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $2.51

2005032 Whirlpool Refrigerator Leveler Backorder WPL 2005032 $65.09

W10735008 Whirlpool Refrigerator Drain Pan He Backorder WPL W10735008 $243.81

W11678257 Whirlpool Fan In Stock WPL W11678257 $110.16

WP2006346 Whirlpool Refrigerator Washer In Stock WPL WP2006346 $4.59

CONDENSER WPL W11601407 Contact Us For Availability

2318189 Whirlpool Refrigerator Drip Pan Backorder WPL 2318189 $50.98

W10538317 Whirlpool Refrigerator Housing Backorder WPL W10538317 $30.14

W10701859 Whirlpool Refrigerator Wine Rack Backorder WPL W10701859 $11.33

ASSEMBLY, HV WIRE WPL W11442534 Contact Us For Availability

COVER, WIRE BOX WPL W10321048 Contact Us For Availability

2306117 Whirlpool Refrigerator Slide Backorder WPL 2306117 $110.88

W11218690 Whirlpool Refrigerator Door Hinge Backorder WPL W11218690 $26.55

WP8281250 Whirlpool Refrigerator Screw In Stock WPL WP8281250 $4.56

WPW10309012 Whirlpool Wire Cover Backorder WPL WPW10309012 $26.21

TUBE, HEAT LOOP WPL W11602253 Contact Us For Availability

18A

2306116 Whirlpool Refrigerator Slide Backorder WPL 2306116 $122.91

W10852725 Whirlpool Refrigerator Grommet In Stock WPL W10852725 $3.70

W11246413 Whirlpool Refrigerator Inlet Valve In Stock WPL W11246413 $72.49

WP488163 Whirlpool Refrigerator Screw In Stock WPL WP488163 $3.70

GROMMET WPL W10587113 Contact Us For Availability

2310195 Whirlpool Refrigerator Wire Jumper Backorder WPL 2310195 $46.67

520965 Whirlpool Refrigerator Support Backorder WPL 520965 $10.14

WP2004994 Whirlpool Refrigerator Hinge Bushin Backorder WPL WP2004994 $3.70

BLOCK, EVAPORATOR SIDE WPL W11550598 Contact Us For Availability

2006617 Whirlpool Refrigerator Bracket Backorder WPL 2006617 $28.80

W10600630 Whirlpool Refrigerator Support Backorder WPL W10600630 $55.97

W11109499 Whirlpool Refrigerator Tube In Stock WPL W11109499 $20.17

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

21A

W10569886 Whirlpool Refrigerator Slide Backorder WPL W10569886 $97.40

W10414681 Whirlpool Bracket Backorder WPL W10414681 $26.21

W10567169 Whirlpool Diverter Backorder WPL W10567169 $10.16

W10672548 Whirlpool Refrigerator Shim Backorder WPL W10672548 $7.65

W11403572 Whirlpool Refrigerator Bracket In Stock WPL W11403572 $24.28

W10569890 Whirlpool Refrigerator Slide Backorder WPL W10569890 $109.79

W11127829 Whirlpool Refrigerator Condenser Mo In Stock WPL W11127829 $103.19

WPW10121140 Whirlpool Refrigerator Housing In Stock WPL WPW10121140 $106.14

CLIP, DEFROST HEATER WPL W11538317 Contact Us For Availability

23A

W10615641 Whirlpool Refrigerator Slide Backorder WPL W10615641 $98.93

24

W10555472 Whirlpool Refrigerator Insulation Backorder WPL W10555472 $14.62

24

W10762685 Whirlpool Gasket Backorder WPL W10762685 $10.01

24

WPW10139483 Whirlpool Refrigerator Condenser In Stock WPL WPW10139483 $28.58

25

W10415670 Whirlpool Orifice Backorder WPL W10415670 $27.03

26

W11751592 Whirlpool Sleeve In Stock WPL W11751592 $12.17

27

WP8533993 Whirlpool Refrigerator Screw Backorder WPL WP8533993 $4.56

28

W10674648 Whirlpool Refrigerator Bracket Backorder WPL W10674648 $8.55

28

BRACKET, 3-WAY VALVE WPL W11233715 Contact Us For Availability

29

W10337505 Whirlpool Refrigerator Door Hinge Backorder WPL W10337505 $62.68

29

W11647768 Whirlpool Refrigerator Valve In Stock WPL W11647768 $68.04

30

WP8533928 Whirlpool Refrigerator Screw In Stock WPL WP8533928 $2.51

30

TUBE, CONDENSER/DRIER WPL W11602254 Contact Us For Availability

31

TUBE, PROCESS WPL W11482820 Contact Us For Availability

32

WPW10188547 Whirlpool Refrigerator Front Gril Backorder WPL WPW10188547 $64.51

33

ASSEMBLY, HUMIDITY SENSOR WIRE WPL W11534165 Contact Us For Availability

34

2310196 Whirlpool Refrigerator Power Cord Backorder WPL 2310196 $31.55

34

W11739145 Whirlpool Front Grille Backorder WPL W11739145 $72.71

35

BRACKET, CONTROL ASSEMBLY WPL W11435371 Contact Us For Availability

36

W11234470 Whirlpool Refrigerator Clamp Backorder WPL W11234470 $10.76

36A

WP2307857 Whirlpool Refrigerator Extension In Stock WPL WP2307857 $32.17

37

SWITCH, POWER DISCONNECT WPL W11311927 Contact Us For Availability

38

W11511844 Whirlpool Tube Backorder WPL W11511844 $40.39

39

W11238395 Whirlpool Refrigerator Filter Cap In Stock WPL W11238395 $26.88

39

ASSEMBLY, LV WIRE WPL W11442533 Contact Us For Availability

40

W10550831 Whirlpool Refrigerator Housing Backorder WPL W10550831 $33.58

41

W10625259 Whirlpool Refrigerator Jumper Wire Backorder WPL W10625259 $82.12

42

W10782423 Whirlpool Refrigerator Ring Backorder WPL W10782423 $8.53

42

SCREW WPL W10068580 Contact Us For Availability

42A

W10782424 Whirlpool Refrigerator Ring Backorder WPL W10782424 $8.53

43

BRACKET, CONDENSER BOTTOM WPL W11443119 Contact Us For Availability

44

2314023 Whirlpool Bushing Backorder WPL 2314023 $25.73

45A

W10847927 Whirlpool Refrigerator Extension In Stock WPL W10847927 $35.81

46

2005433 Whirlpool Refrigerator Spacer Backorder WPL 2005433 $10.23

47

WP9741232 Whirlpool Dishwasher Screw In Stock WPL WP9741232 $2.51

48

WP2221240 Whirlpool Refrigerator Heater In Stock WPL WP2221240 $67.89

49

W10482373 Whirlpool Refrigerator Jumper Wire Backorder WPL W10482373 $43.21

50

W10619899 Whirlpool Refrigerator Water Tube Backorder WPL W10619899 $16.07

51

2317847 Whirlpool Refrigerator Water Tube Backorder WPL 2317847 $29.43

52

WP1106508 Whirlpool Refrigerator Gasket Backorder WPL WP1106508 $4.14

53

W10635851 Whirlpool Refrigerator Water Tube Backorder WPL W10635851 $32.87

54

W11225845 Whirlpool Refrigerator Inlet Valve In Stock WPL W11225845 $72.49

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

285006 Whirlpool Spray In Stock WPL 285006 $27.45

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

8003RP Whirlpool Refrigerator 25' 1/4" Copper In Stock WPL 8003RP $21.98

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $96.00

W10134625 Whirlpool Refrigerator Touch-Up Pai In Stock WPL W10134625 $7.48

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

TOUCH-UP PAINT (MIDNIGHT GREY) WPL W10917540 Contact Us For Availability

MISCELLANEOUS, KIT, FOAM SLAB (30" X 32 1/2" WPL 876029 Contact Us For Availability

MISCELLANEOUS, TAPE, VINYL (3/4 X 108") WPL 479502 Contact Us For Availability

TORX SCREW WRENCH, TORX KEY WPL 1117510 Contact Us For Availability

REFRIGERANT CHARGE 56.7 GRAMS (R600A) WPL ARI5ABD8795F1D1E157F1B64FDCC10396D1 Contact Us For Availability

MISCELLANEOUS, CEMENT, ALUMILASTIC (1 1/4 OZ. WPL 542639 Contact Us For Availability
