Model Whirlpool KBCS24LSBS00 BEVERAGE CENTER – Common Parts &amp; Diagrams

1

Use & Care Guide WPL 2300276 Contact Us For Availability

1

Wiring Diagram WPL 4344901 Contact Us For Availability

1

Drain Pan WPL 4344772 Contact Us For Availability

2

Wine Rack, Top WPL 4344846 Contact Us For Availability

2

Bracket, Defrost Timer WPL 4344773 Contact Us For Availability

3

W11609704 Whirlpool Refrigerator Defrost Time In Stock WPL W11609704 $53.20

3

Lens, Light WPL 4344739 Contact Us For Availability

3

Wine Rack, Middle WPL 4344847 Contact Us For Availability

4

4344787 Whirlpool Refrigerator Door Hinge Backorder WPL 4344787 $83.59

4

4344797 Whirlpool Screw Backorder WPL 4344797 $9.15

4

WP22002263 Whirlpool Dryer 10W Light Bulb In Stock WPL WP22002263 $7.83

4

Wine Rack, Lower WPL 4344849 Contact Us For Availability

5

4344754 Whirlpool Refrigerator Door Hinge Backorder WPL 4344754 $48.13

5

W11230119 Whirlpool Refrigerator Heater Backorder WPL W11230119 $54.68

5

WP4344776 Whirlpool Refrigerator Start Device Backorder WPL WP4344776 $65.72

5

Ladder, Shelf (Left Side) WPL 4344842 Contact Us For Availability

5

Ladder, Shelf (Right Side) WPL 4344843 Contact Us For Availability

6

4344747 Whirlpool Refrigerator Shield Backorder WPL 4344747 $27.52

6

Screw WPL 4344794 Contact Us For Availability

6

Mounting Plate, Compressor WPL 4344777 Contact Us For Availability

7

Grille WPL 4344761 Contact Us For Availability

7

Grommet, Fan Motor WPL 4344778 Contact Us For Availability

7

Washer WPL 4344795 Contact Us For Availability

8

WP4344779 Whirlpool Refrigerator Grommet Backorder WPL WP4344779 $3.70

8

Plate, Bottom WPL 4344762 Contact Us For Availability

8

Stop, Lower Rack WPL 4344850 Contact Us For Availability

9

W10772873 Whirlpool Screw Backorder WPL W10772873 $29.87

9

W11106296 Whirlpool Refrigerator Leveler Backorder WPL W11106296 $6.35

9

Screw WPL 4344851 Contact Us For Availability

10

WPW10299090 Whirlpool Refrigerator Condenser In Stock WPL WPW10299090 $150.21

10

Brace, Support WPL 4344764 Contact Us For Availability

10

Trim, Top And Middle Racks WPL 4344882 Contact Us For Availability

Control Box WPL 4344898 Contact Us For Availability

Support (Right) WPL 4344866 Contact Us For Availability

Support (Left) WPL 4344867 Contact Us For Availability

Baffle, Air WPL 4344782 Contact Us For Availability

4344789 Whirlpool Refrigerator Support Backorder WPL 4344789 $128.11

Frame, Side (Right Side) WPL 4344790 Contact Us For Availability

Fan Blade WPL 4344783 Contact Us For Availability

Trim, Lower Rack WPL 4344884 Contact Us For Availability

4344771 Whirlpool Refrigerator Clip Backorder WPL 4344771 $36.11

4344784 Whirlpool Bracket Backorder WPL 4344784 $88.58

4344886 Whirlpool Support Backorder WPL 4344886 $77.59

Support, Bumper (Right) WPL 4344885 Contact Us For Availability

4344785 Whirlpool Bracket Backorder WPL 4344785 $70.48

Evaporator Fan Assembly WPL 4344841 Contact Us For Availability

Screw (Right) WPL 4344914 Contact Us For Availability

Screw (Left) WPL 4344915 Contact Us For Availability

15

4344786 Whirlpool Back Cover Backorder WPL 4344786 $88.58

15

W11211930 Whirlpool Refrigerator Thermostat Backorder WPL W11211930 $84.89

15

Shelf, Large WPL 4344870 Contact Us For Availability

4344796 Whirlpool Refrigerator Screw Backorder WPL 4344796 $9.61

WP1188476 Whirlpool Air Conditioner Capacitor Backorder WPL WP1188476 $60.00

WP3402573 Whirlpool Appliance Knob Backorder WPL WP3402573 $40.17

Glass, Shelf WPL 4344871 Contact Us For Availability

17

WP4344767 Whirlpool Refrigerator Switch Backorder WPL WP4344767 $12.08

17

WP4344836 Whirlpool Clip Backorder WPL WP4344836 $27.52

17

Shelf, Small WPL 4344868 Contact Us For Availability

18

Glass, Shelf WPL 4344869 Contact Us For Availability

18

Tube, Drain WPL 4344839 Contact Us For Availability

19

Trim, Shelf WPL 4344872 Contact Us For Availability

19

Power Cord WPL 4344861 Contact Us For Availability

20

4344829 Whirlpool Tie Wire Backorder WPL 4344829 $9.15

20

Clip, Grille WPL 4344819 Contact Us For Availability

20

Seal, Rear WPL 4344873 Contact Us For Availability

21

WP4344828 Whirlpool Refrigerator Dryer Tube Backorder WPL WP4344828 $14.38

21

Screw WPL 4344825 Contact Us For Availability

21

Seal, Side (2) WPL 4344874 Contact Us For Availability

22

4344823 Whirlpool Refrigerator Seal Backorder WPL 4344823 $35.32

22

Seal, Front WPL 4344875 Contact Us For Availability

22

Bushing WPL 4344838 Contact Us For Availability

4344820 Whirlpool Refrigerator Support Backorder WPL 4344820 $82.84

4344821 Whirlpool Refrigerator Support Backorder WPL 4344821 $46.21

Transformer Cable WPL 4344895 Contact Us For Availability

Clip, Bushing WPL 4344831 Contact Us For Availability

24

W11456069 Whirlpool Refrigerator Clamp In Stock WPL W11456069 $10.76

24

WPW10238180 Whirlpool Refrigerator Display Backorder WPL WPW10238180 $194.11

24

Bushing WPL 4344835 Contact Us For Availability

25

4344826 Whirlpool Refrigerator Screw Backorder WPL 4344826 $9.61

25

4344857 Whirlpool Refrigerator Wire Harness Backorder WPL 4344857 $27.52

25

Cable WPL 4344897 Contact Us For Availability

26

Screw WPL 4344827 Contact Us For Availability

26

Support, Shelf (Large) WPL 4344905 Contact Us For Availability

27

4344792 Whirlpool Refrigerator Bi-Metal Backorder WPL 4344792 $44.71

27

W11380570 Whirlpool Microwave Screw In Stock WPL W11380570 $9.86

28

4344793 Whirlpool Screw Backorder WPL 4344793 $9.15

28

8201787 Whirlpool Refrigerator Compressor Backorder WPL 8201787 $373.05

29

Screw WPL 4344791 Contact Us For Availability

29

Screw WPL 4344834 Contact Us For Availability

30

WP90767 Whirlpool Screw In Stock WPL WP90767 $3.08

31

W10238070 Whirlpool Refrigerator Transformer Backorder WPL W10238070 $138.47

31

Screw WPL 4344878 Contact Us For Availability

32

Evaporator Fan Motor WPL 4344865 No Longer Available

32

Thermostat WPL 4344863 Contact Us For Availability

33

Harness, Wire WPL 4344877 Contact Us For Availability

33

Bracket, Thermostat WPL 4344864 Contact Us For Availability

34

TRIM Backorder WPL 4344907 $83.71

35

Support, Drain WPL 4344908 Contact Us For Availability

36

4344899 Whirlpool Refrigerator Bracket Backorder WPL 4344899 $66.83

38

4344858 Whirlpool Refrigerator Switch Backorder WPL 4344858 $41.67

39

Transformer Cable WPL 4344917 Contact Us For Availability

40

Temperature Sensor WPL 4344918 Contact Us For Availability

NI

REFRIGERANT CHARGE (3.5 OUNCES (R-134A)) WPL NP Contact Us For Availability
