JGBS04PPA2WH

Model JGBS04PPA2WH – Common Parts & Diagrams

Common parts from model JGBS04PPA2WH

WB2K20 GE Oven Bracket Assembly A-T

WB2K20 GE Oven Bracket Assembly A-T Out of Stock GEN WB2K20 $24.57

WB03K10035 GE Oven Knob Top Burner

WB03K10035 GE Oven Knob Top Burner In Stock GEN WB03K10035 $50.08

WB28K10033 GE Oven Orifice Spud

WB28K10033 GE Oven Orifice Spud In Stock GEN WB28K10033 $13.61

WB28K10376 GE Oven Orifice

WB28K10376 GE Oven Orifice In Stock GEN WB28K10376 $5.11

WB16K10026 GE Oven Range Stove Cooktop Double

WB16K10026 GE Oven Range Stove Cooktop Double In Stock GEN WB16K10026 $45.79

WB01K10002 GE Oven Screw 8-32

WB01K10002 GE Oven Screw 8-32 In Stock GEN WB01K10002 $14.24

WB21K38 GE Oven Valve-Burner

WB21K38 GE Oven Valve-Burner Out of Stock GEN WB21K38 $75.34

WB28K10009 GE Oven Tube-Burner

WB28K10009 GE Oven Tube-Burner Out of Stock GEN WB28K10009 $19.89

WB28K10010 GE Oven Front Tube Assembly

WB28K10010 GE Oven Front Tube Assembly In Stock GEN WB28K10010 $52.68

WB28K10011 GE Oven Tube-Burner LT Rear

WB28K10011 GE Oven Tube-Burner LT Rear Out of Stock GEN WB28K10011 $53.87

WB28K10012 GE Oven Tube-Burner RT Rear

WB28K10012 GE Oven Tube-Burner RT Rear Out of Stock GEN WB28K10012 $14.02

WB1K83 GE Oven Screw

WB1K83 GE Oven Screw In Stock GEN WB1K83 $5.11

WB7K380 GE Oven Cover End RI

WB7K380 GE Oven Cover End RI Out of Stock GEN WB7K380 $15.32

WB31K10026 GE Oven Grate-HAIRPI

WB31K10026 GE Oven Grate-HAIRPI Out of Stock GEN WB31K10026 $68.62

WB62K10001 GE Oven Cooktop

WB62K10001 GE Oven Cooktop Out of Stock GEN WB62K10001 $214.61

WB1K45 GE Oven Screw & Washer Assembly

WB1K45 GE Oven Screw & Washer Assembly Out of Stock GEN WB1K45 $5.11

WB10K18 GE Oven Guide Hinge

WB10K18 GE Oven Guide Hinge Out of Stock GEN WB10K18 $5.11

WB1K5062 GE Oven Screw

WB1K5062 GE Oven Screw In Stock GEN WB1K5062 $5.11

WZ4X345D GE Screw Package 12 C92

WZ4X345D GE Screw Package 12 C92 Out of Stock GEN WZ4X345D $15.53

WR01X10065 GE Screw

WR01X10065 GE Screw Out of Stock GEN WR01X10065 $5.11

WB2K65 GE Oven Bracket SAF Valve

WB2K65 GE Oven Bracket SAF Valve Out of Stock GEN WB2K65 $5.11

WB10K12 GE Oven Hinge Assembly

WB10K12 GE Oven Hinge Assembly Out of Stock GEN WB10K12 $38.56

WB2K11 GE Oven Door Spring Hook

WB2K11 GE Oven Door Spring Hook In Stock GEN WB2K11 $11.92

ANGLE SUPPRT E97

ANGLE SUPPRT E97 Out of Stock GEN WB2K3 $4.86

WB2K5 GE Oven Broiler Stop

WB2K5 GE Oven Broiler Stop Out of Stock GEN WB2K5 $22.50

WB32K2 GE Oven Gasket OV Seal

WB32K2 GE Oven Gasket OV Seal Out of Stock GEN WB32K2 $4.73

WB35K16 GE Oven Insulation Back

WB35K16 GE Oven Insulation Back Out of Stock GEN WB35K16 $40.39

WB1X1293 GE Oven Screw

WB1X1293 GE Oven Screw In Stock GEN WB1X1293 $5.11

WB39K6 GE Oven Broil Weld A

WB39K6 GE Oven Broil Weld A Out of Stock GEN WB39K6 $63.76

WB10K5 GE Oven Hinge Broil R

WB10K5 GE Oven Hinge Broil R Out of Stock GEN WB10K5 $8.89

WB10K6 GE Oven Hinge Broil L

WB10K6 GE Oven Hinge Broil L In Stock GEN WB10K6 $7.92

WB1K7 GE Oven Pin Broiler

WB1K7 GE Oven Pin Broiler Out of Stock GEN WB1K7 $5.11

WB39K9 GE Oven Slide BroilR

WB39K9 GE Oven Slide BroilR Out of Stock GEN WB39K9 $21.55

WB9K3 GE Oven Spring Broil L

WB9K3 GE Oven Spring Broil L Out of Stock GEN WB9K3 $5.11

WB56X21199 GE Oven Panel Drawer

WB56X21199 GE Oven Panel Drawer Out of Stock GEN WB56X21199 $26.19

WB2K14 GE Oven Spacer

WB2K14 GE Oven Spacer In Stock GEN WB2K14 $5.11

WB2K15 GE Oven Grate Bumper/Foot

WB2K15 GE Oven Grate Bumper/Foot In Stock GEN WB2K15 $5.11

GE Range Washer

GE Range Washer Out of Stock GEN WB1X119D $9.27

WB1X5731D GE Oven Nut PKG/12

WB1X5731D GE Oven Nut PKG/12 Out of Stock GEN WB1X5731D $18.34

WB15K1 GE Oven Handle Broil

WB15K1 GE Oven Handle Broil Out of Stock GEN WB15K1 $31.19

WB35X29720 GE Oven Door Gasket

WB35X29720 GE Oven Door Gasket In Stock GEN WB35X29720 $11.54

WB1X558D GE Oven Screw Package 12

WB1X558D GE Oven Screw Package 12 Out of Stock GEN WB1X558D $14.61

WB1K10 GE Oven GROM Handle

WB1K10 GE Oven GROM Handle Out of Stock GEN WB1K10 $5.11

WB1K37 GE Oven Screw

WB1K37 GE Oven Screw Out of Stock GEN WB1K37 $5.00
