Model Whirlpool GS445LEMS4 30`` GAS FREESTANDING SELF CLEAN RANGE SEALED BURN – Common Parts &amp; Diagrams

350930 Whirlpool White Spray Paint In Stock WPL 350930 $13.94

350956 Whirlpool Spray Assembly In Stock WPL 350956 $20.04

4392899 Whirlpool Biscuit Touch-Up Paint In Stock WPL 4392899 $8.03

4392901 Whirlpool Biscuit Spray Paint In Stock WPL 4392901 $28.40

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $4.25

8523599 Whirlpool Range Wire Harness Backorder WPL 8523599 $80.82

WP72107 Whirlpool Touchup In Stock WPL WP72107 $6.62

WPW10208653 Whirlpool Insulation Backorder WPL WPW10208653 $30.25

WPL 8524207 WPL 8524207 Contact Us For Availability

FOIL, ALUMINUM OVEN (18`` X 25 ) WPL 241430 Contact Us For Availability

WPL 799344 WPL 799344 Contact Us For Availability

1

Screw, Valve WPL 8273096 Contact Us For Availability

1

Endcap (Left Hand) WPL 3186188 Contact Us For Availability

1

Endcap (Right Hand) WPL 3186189 Contact Us For Availability

1

Safer Cooking Tips WPL 3191638 Contact Us For Availability

1

Anti-Tip Template (English/Spanish) WPL 9757142 Contact Us For Availability

1

Anti-Tip Template (English/French) WPL 9757143 Contact Us For Availability

1

Tech Sheet WPL 9758087 Contact Us For Availability

1

Installation Instructions Anti-Tip Template WPL 9758657 Contact Us For Availability

1

Guide, Use & Care WPL 9762363 Contact Us For Availability

2

WP3191898 Whirlpool Surface Burner Cap Black Backorder WPL WP3191898 $44.27

2

WP3191901 Whirlpool Burner Cap Backorder WPL WP3191901 $56.96

2

WP3191904 Whirlpool Burner Cap Backorder WPL WP3191904 $100.55

2

WP3195996 Whirlpool Pan Grid Backorder WPL WP3195996 $44.05

2

WP3196164 Whirlpool Screw In Stock WPL WP3196164 $3.46

2

WP8273700 Whirlpool Base Burner In Stock WPL WP8273700 $59.26

2

Support, Endcap (Left Hand) WPL 8523408 Contact Us For Availability

2

Support, Endcap (Right Hand) WPL 8523409 Contact Us For Availability

3

WP3196076 Whirlpool Broil Pan Backorder WPL WP3196076 $176.34

3

Tubing, Burner W/Orifice (Right Front) WPL 8273695 Contact Us For Availability

3

Tubing, Burner W/Orifice (Left Front) WPL 8273692 Contact Us For Availability

3

Tubing, Burner W/Orifice (Right Rear) WPL 8273697 Contact Us For Availability

3

Panel, Control WPL 8524105 Contact Us For Availability

3

Tubing, Burner W/Orifice (Left Rear) WPL 8273694 Contact Us For Availability

4

WP4455979 Whirlpool Range Small Burner Head Backorder WPL WP4455979 $35.85

4

WP4455980 Whirlpool Burner Head In Stock WPL WP4455980 $39.31

4

WP4455981 Whirlpool Burner Head Backorder WPL WP4455981 $54.75

4

Screw WPL 4449746 Contact Us For Availability

4

Liner, Door WPL 3186292 Contact Us For Availability

4

Tubing (Manifold to Regulator) WPL 8523402 Contact Us For Availability

5

W11213958 Whirlpool Range Cooktop Backorder WPL W11213958 $253.93

5

WPW10295998 Whirlpool Wire Harness In Stock WPL WPW10295998 $86.45

5

WPW10331686 Whirlpool Range Spark Module In Stock WPL WPW10331686 $178.45

6

8053505 Whirlpool Range Shield Backorder WPL 8053505 $57.07

6

8523249 Whirlpool Range Support Bracket Backorder WPL 8523249 $25.99

6

8523855 Whirlpool Range Manifold Panel Backorder WPL 8523855 $65.09

6

WP8053948 Whirlpool Door Glass In Stock WPL WP8053948 $68.30

6

WP8523793 Whirlpool Oven Surface Igniter In Stock WPL WP8523793 $18.50

6

WP9781235 Whirlpool Clip Backorder WPL WP9781235 $5.22

7

8523412 Whirlpool Mounting Bracket Backorder WPL 8523412 $98.66

7

WPW10316950 Whirlpool Window Frame Backorder WPL WPW10316950 $30.25

7

Knob, Control (2) WPL 8273279 Contact Us For Availability

7

Pipe, Manifold WPL 8523407 Contact Us For Availability

8

WP8053334 Whirlpool Drawer Glide In Stock WPL WP8053334 $4.70

8

WP9757218 Whirlpool Burner Valve In Stock WPL WP9757218 $129.60

8

Valve (Right Rear) WPL 8273004 Contact Us For Availability

8

Cover, Upper WPL 9756301 Contact Us For Availability

8

Knob, Accusimmer WPL 8273280 Contact Us For Availability

9

WP3196037 Whirlpool Leveling Foot In Stock WPL WP3196037 $28.64

9

WPW10278991 Whirlpool Insulation Backorder WPL WPW10278991 $42.51

9

Nut (4) WPL 8273060 Contact Us For Availability

9

Knob, Powerburner WPL 8273281 Contact Us For Availability

9

Shield, Heat WPL 8053910 Contact Us For Availability

WP8273062 Whirlpool Screw In Stock WPL WP8273062 $3.33

Hinge, Door WPL 8272822 Contact Us For Availability

Cover, Lower WPL 8273132 Contact Us For Availability

Grate, Center WPL 8522846 Contact Us For Availability

W11539580 Whirlpool Retainer Backorder WPL W11539580 $84.51

WP3195097 Whirlpool Range Bottom In Stock WPL WP3195097 $86.28

WP3196557 Whirlpool Screw In Stock WPL WP3196557 $3.33

WPW10447925 Whirlpool Grate Kit In Stock WPL WPW10447925 $199.55

W10761014 Whirlpool Right Door Trim In Stock WPL W10761014 $28.73

W10761018 Whirlpool Dishwasher Left Door Trim In Stock WPL W10761018 $37.20

WP8054078 Whirlpool Broiler Burner Backorder WPL WP8054078 $98.14

Control, Range WPL 8524252 Contact Us For Availability

13

8053967 Whirlpool Range Heat Baffle Backorder WPL 8053967 $112.34

13

Spreader, Flame (Oven) WPL 8053970 Contact Us For Availability

13

Glass, Outer Door WPL 9756435 Contact Us For Availability

W10491985 Whirlpool Screw Backorder WPL W10491985 $3.33

WP3368921 Whirlpool Screw In Stock WPL WP3368921 $2.34

WP9758078 Whirlpool Range Burner In Stock WPL WP9758078 $100.55

Badge Assembly WPL 8523552 Contact Us For Availability

15

WPW10293048 Whirlpool Gas Valve In Stock WPL WPW10293048 $314.56

15

Clip, Door Glass WPL 3196025 Contact Us For Availability

16

WP8054129 Whirlpool Range Igniter In Stock WPL WP8054129 $78.63

16

WP9758079 Whirlpool Range Igniter In Stock WPL WP9758079 $27.82

17

Tubing (Broiler Fitting To Valve) WPL 8272222 Contact Us For Availability

18

WP179051 Whirlpool Screw Backorder WPL WP179051 $3.46

18

Seal, Oven Flange WPL 8524109 Contact Us For Availability

18

Fitting, Broiler WPL 3186489 Contact Us For Availability

W10877054 Whirlpool Spacer Assembly Backorder WPL W10877054 $28.09

WP8273564 Whirlpool Clip Backorder WPL WP8273564 $5.22

WP8523180 Whirlpool Door Trim Assembly Backorder WPL WP8523180 $55.15

Cover, Igniter WPL 8272403 Contact Us For Availability

20

WP8273065 Whirlpool Orifice Backorder WPL WP8273065 $34.55

20

WP8273067 Whirlpool Orifice Backorder WPL WP8273067 $34.62

20

Orifice, Burner (Left Front) WPL 8273063 Contact Us For Availability

21

W10137062 Whirlpool Burner Baffle Backorder WPL W10137062 $161.91

21

Bracket, Window WPL 3196794 Contact Us For Availability

22

WP3196175 Whirlpool Screw In Stock WPL WP3196175 $3.33

23

3196265 Whirlpool Range Screw Backorder WPL 3196265 $9.59

23

WP3196925 Whirlpool Clip Assembly Backorder WPL WP3196925 $5.16

24

W11233072 Whirlpool Screw In Stock WPL W11233072 $10.41

25

W11684507 Whirlpool Screw In Stock WPL W11684507 $8.93

25

WP9757891 Whirlpool Power Cord Backorder WPL WP9757891 $50.80

9757239 Whirlpool Oven Door Rod Backorder WPL 9757239 $33.16

W11234415 Whirlpool Orifice Spud Backorder WPL W11234415 $45.62

WP3400016 Whirlpool Screw Assembly Backorder WPL WP3400016 $2.51

FOLLOWING PARTS NOT ILLUSTRATED WPL ARI70065A8 Contact Us For Availability

27

WP9757262 Whirlpool Light Switch In Stock WPL WP9757262 $62.28

30

WP9761013 Whirlpool Door Latch Backorder WPL WP9761013 $90.99

35

W11169708 Whirlpool Screw Backorder WPL W11169708 $9.59

36

WP4449743 Whirlpool Screw Backorder WPL WP4449743 $2.51

38

Screw WPL 3196152 Contact Us For Availability

47

W11684915 Whirlpool Insulation Backorder WPL W11684915 $47.58
