Model Whirlpool GH6208XRQ0 MICROWAVE HOOD COMBINATION – Common Parts &amp; Diagrams

1

Handle (Universal Silver) WPL 8206123 Contact Us For Availability

1

Housing, Blower (Left) WPL 8206092 Contact Us For Availability

1

Handle (Black) WPL 8206121 Contact Us For Availability

1

Case, Outer (White) WPL 8206027 Contact Us For Availability

1

Case, Outer (Black) WPL 8206028 Contact Us For Availability

1

Case, Outer (Apollo Grey) WPL 8206030 Contact Us For Availability

1

Installation Instructions WPL 8205272 Contact Us For Availability

1

Cook Guide Label WPL 8205279 Contact Us For Availability

1

Quick Reference WPL 8205746 Contact Us For Availability

1

Use & Care Guide WPL 8206205 Contact Us For Availability

1

Tech Sheet WPL 8206216 Contact Us For Availability

1

Handle (White) WPL 8206120 Contact Us For Availability

2

W10843943 Whirlpool Microwave Vent Damper In Stock WPL W10843943 $44.05

2

Trim, Door (White) WPL 8206144 Contact Us For Availability

2

Support, Cavity (Left) WPL 8206039 Contact Us For Availability

2

Trim, Door (Black) WPL 8206145 Contact Us For Availability

2

Trim, Door (Stainless Steel) WPL 8206147 Contact Us For Availability

2

Housing, Fan WPL 8206076 Contact Us For Availability

3

W10527358 Whirlpool Microwave Plate Backorder WPL W10527358 $10.27

3

Lid, Power Cord WPL 8184897 Contact Us For Availability

3

Door Control Assy (White) WPL 8206151 Contact Us For Availability

3

Door Control Assy (Black/Stainless) WPL 8206152 Contact Us For Availability

3

Plate, Divider WPL 8206077 Contact Us For Availability

4

8204670 Whirlpool Microwave Halogen Lamp 10W In Stock WPL 8204670 $10.07

4

W10115577 Whirlpool Microwave Sensor Backorder WPL W10115577 $54.20

4

W11380570 Whirlpool Microwave Screw In Stock WPL W11380570 $9.86

4

Side Panel, Left (White) WPL 8206041 Contact Us For Availability

4

Side Panel, Left (Black) WPL 8206042 Contact Us For Availability

4

Side Panel, Left (Stainless Steel) WPL 8206044 Contact Us For Availability

5

8206079 Whirlpool Microwave Magnetron Backorder WPL 8206079 $148.65

5

Vent Screen (Middle) WPL 8206017 Contact Us For Availability

5

Button (White) WPL 8206045 Contact Us For Availability

5

Button (Black) WPL 8206046 Contact Us For Availability

5

Button (Universal Silver) WPL 8206048 Contact Us For Availability

5

Outer Door Frame (White) WPL 8206157 Contact Us For Availability

5

Outer Door Frame (Black) WPL 8206158 Contact Us For Availability

5

Outer Door Frame (Stainless Steel) WPL 8206160 Contact Us For Availability

6

Motor, Capacitor WPL 8206080 Contact Us For Availability

6

Support, Vent Screen (White) WPL 8206011 Contact Us For Availability

6

Support, Vent Screen (Universal Silver) WPL 8206016 Contact Us For Availability

6

Support, Vent Screen (Black) WPL 8206012 Contact Us For Availability

6

Hood/Light Switch Board WPL 8206049 Contact Us For Availability

7

Vent Screen (Left) WPL 8206207 Contact Us For Availability

7

Side Panel, Right (White) WPL 8206056 Contact Us For Availability

7

Side Panel, Right (Black) WPL 8206057 Contact Us For Availability

7

Side Panel, Right (Stainless Steel) WPL 8206059 Contact Us For Availability

7

Board, User (Interface) WPL 8206161 Contact Us For Availability

7

Housing, Valve WPL 8206081 Contact Us For Availability

8

Plate, Back WPL 8206051 Contact Us For Availability

8

Control Board, (Relay) WPL 8206055 Contact Us For Availability

8

LCD Module WPL 8206162 Contact Us For Availability

9

Plate, Mounting WPL 8206052 Contact Us For Availability

9

Plate, Protection (Right) WPL 8206061 Contact Us For Availability

9

Deflector, Air Guide WPL 8206163 Contact Us For Availability

9

Lid, Valve WPL 8206083 Contact Us For Availability

8206084 Whirlpool Spring Assembly Backorder WPL 8206084 $30.40

WPW10510203 Whirlpool Microwave Heater In Stock WPL WPW10510203 $100.31

Cord, Power WPL 8206182 Contact Us For Availability

Plate, Chassis WPL 8206067 Contact Us For Availability

Air Guide WPL 8206164 Contact Us For Availability

4393836 Whirlpool Microwave Screw Backorder WPL 4393836 $2.73

Support, Cavity (Right) WPL 8206065 Contact Us For Availability

Cable Cover, Door WPL 8206165 Contact Us For Availability

Cover, Inverter WPL 8206085 Contact Us For Availability

8206185 Whirlpool Microwave Wire Harness Backorder WPL 8206185 $31.93

W10470173 Whirlpool Microwave Wire Harness Backorder WPL W10470173 $8.02

Installation, Hardware WPL 8205979 Contact Us For Availability

Vent Screen (Right) WPL 8206206 Contact Us For Availability

Template, Upper WPL 8205274 Contact Us For Availability

Main Harness WPL 8206184 Contact Us For Availability

H.V. Wire Assy WPL 8206186 Contact Us For Availability

Lights, Fan, & Turntable Harness WPL 8206187 Contact Us For Availability

Miscellaneous WPL ARI65313A8 Contact Us For Availability

Board, Relay WPL 8206064 Contact Us For Availability

Inner Door (White) WPL 8206140 Contact Us For Availability

Inner Door (Black/Stainless) WPL 8206141 Contact Us For Availability

Ferrite Ring WPL 8206086 Contact Us For Availability

8205992 Whirlpool Microwave Cook Tray Backorder WPL 8205992 $43.48

W10217711 Whirlpool Microwave Inverter Backorder WPL W10217711 $204.09

Holder, Microcomputer WPL 8206053 Contact Us For Availability

Gasket (2) WPL 8206166 Contact Us For Availability

14

Thermostat, Base Assembly WPL 8183998 Contact Us For Availability

14

Screw (2) WPL 8206167 Contact Us For Availability

14

AC Line Filter WPL 8206062 Contact Us For Availability

8205994 Whirlpool Microwave Support In Stock WPL 8205994 $11.93

8206168 Whirlpool Washer Backorder WPL 8206168 $4.85

Holder, Inverter WPL 8206089 Contact Us For Availability

Holder, Filter WPL 8206060 Contact Us For Availability

16

Screw (3) WPL 8206169 Contact Us For Availability

16

Air Guide, Magnetron WPL 8206090 Contact Us For Availability

17

8205572 Whirlpool Microwave Interlock Backorder WPL 8205572 $3.70

17

Spacer, Side (6) WPL 8206170 Contact Us For Availability

18

Spring, Interlock WPL 8206091 Contact Us For Availability

18

Support & Base Thermostat Assy WPL 8206212 Contact Us For Availability

W10211972 Whirlpool Microwave Switch In Stock WPL W10211972 $28.44

W11661547 Whirlpool Turntable Motor In Stock WPL W11661547 $44.76

Connector Shaft WPL 8206263 Contact Us For Availability

Spacer, Bottom (2) WPL 8206178 Contact Us For Availability

20

4393832 Whirlpool Microwave Screw Backorder WPL 4393832 $9.59

20

8206179 Whirlpool Microwave Screw Backorder WPL 8206179 $4.61

20

Holder, Fuse WPL 8184312 Contact Us For Availability

8205262RB Whirlpool Refrigerator Crusher Blad Backorder WPL 8205262RB $28.58

W11707984 Whirlpool Thermal Fuse In Stock WPL W11707984 $19.18

Housing, Blower (Right) WPL 8206112 Contact Us For Availability

Screw (2) WPL 8169478 Contact Us For Availability

22

8206180 Whirlpool Microwave Screw Backorder WPL 8206180 $9.59

22

W10269458 Whirlpool Microwave Door Switch In Stock WPL W10269458 $15.87

22

Frame, Glass WPL 8169646 Contact Us For Availability

23

W10211974 Whirlpool Microwave Door Interlock In Stock WPL W10211974 $24.34

23

Hinge Screw WPL 8206181 Contact Us For Availability

23

Spacer WPL 8206116 Contact Us For Availability

24

Humidity Sensor & Thermostat Assy WPL 8206026 Contact Us For Availability

24

Cover, Inlet WPL 8206066 Contact Us For Availability

25

Lid, Lamp WPL 8206032 Contact Us For Availability

25

Support, Air Guide WPL 8206031 Contact Us For Availability

26

Glass, Lamp WPL 8169499 Contact Us For Availability

26

Protector, Wire WPL 8206036 Contact Us For Availability

27

Clip, Saddle WPL 8206037 Contact Us For Availability

28

8206038 Whirlpool Clip Assembly Backorder WPL 8206038 $6.30

29

8206209 Whirlpool Microwave Interlock Switch Backorder WPL 8206209 $3.70

30

Piston Assembly WPL 8206210 Contact Us For Availability
