Model Whirlpool GH5184XPB4 Microwave Oven 1.8 Cu. Ft. – Common Parts & Diagrams

1
Pivot, Door
Pivot, Door WPL 8184922 Contact Us For Availability
View on Model
1
Cook Guide Label
Cook Guide Label WPL 8204933 Contact Us For Availability
View on Model
1
Tech Sheet
Tech Sheet WPL 8205609 Contact Us For Availability
View on Model
1
U & C Guide
U & C Guide WPL 8205973 Contact Us For Availability
View on Model
1
Instrctn, Instlltn
Instrctn, Instlltn WPL 8206579 Contact Us For Availability
View on Model
1
Reflector, Lamp
Reflector, Lamp WPL 8205096 Contact Us For Availability
View on Model
1
Motor, Stirrer
Motor, Stirrer WPL 8205044 Contact Us For Availability
View on Model
2
Panel Asy, Control Includes Lens and Membrane
Panel Asy, Control Includes Lens and Membrane WPL 8205417 Contact Us For Availability
View on Model
2
Panel Asy, Control Includes Lens and Membrane
Panel Asy, Control Includes Lens and Membrane WPL 8205418 Contact Us For Availability
View on Model
2
Panel Asy, Control Includes Lens and Membrane
Panel Asy, Control Includes Lens and Membrane WPL 8205419 Contact Us For Availability
View on Model
2
Panel Asy, Control Includes Lens and Membrane
Panel Asy, Control Includes Lens and Membrane WPL 8205923 Contact Us For Availability
View on Model
2
Stirrer Shaft/Blade
Stirrer Shaft/Blade WPL 8205202 Contact Us For Availability
View on Model
3
Bracket, Control
Bracket, Control WPL W10114256 Contact Us For Availability
View on Model
3
Thermostat/Bracket
Thermostat/Bracket WPL 8206454 Contact Us For Availability
View on Model
4
Microcomputer
Microcomputer WPL 8205421 Contact Us For Availability
View on Model
4
Cover, Inlet Includes Nails and Bushings
Cover, Inlet Includes Nails and Bushings WPL 8184476 Contact Us For Availability
View on Model
5
Thermostat
Thermostat WPL 8183999 Contact Us For Availability
View on Model
5
Plate, Bottom
Plate, Bottom WPL 8205366 Contact Us For Availability
View on Model
6
Glass, Lamp
Glass, Lamp WPL 8184141 Contact Us For Availability
View on Model
6
Nails/Bushings (5 of each)
Nails/Bushings (5 of each) WPL 8184549 Contact Us For Availability
View on Model
7
Grille, Vent (Biscuit)
Grille, Vent (Biscuit) WPL 8205216 Contact Us For Availability
View on Model
7
Grille, Vent (Stainless)
Grille, Vent (Stainless) WPL 8205217 Contact Us For Availability
View on Model
7
Holder, Glass
Holder, Glass WPL 8184889 Contact Us For Availability
View on Model
7
Turntable
Turntable WPL 8206226 Contact Us For Availability
View on Model
8
Complete Door (Black)
Complete Door (Black) WPL 8205414 Contact Us For Availability
View on Model
8
Complete Door (Biscuit)
Complete Door (Biscuit) WPL 8205415 Contact Us For Availability
View on Model
9
Motor, Fan Assy
Motor, Fan Assy WPL W10114253 Contact Us For Availability
View on Model
9
Cover, Inverter
Cover, Inverter WPL W10110596 Contact Us For Availability
View on Model
10
Screw
Screw WPL 8169475 Contact Us For Availability
View on Model
11
Spring, Interlock
Spring, Interlock WPL 8169438 Contact Us For Availability
View on Model
12
Installation, Hardware
Installation, Hardware WPL 8205947 Contact Us For Availability
View on Model
12
Template, Upper
Template, Upper WPL 8184781 Contact Us For Availability
View on Model
12
Miscellaneous
Miscellaneous WPL ARI148861A Contact Us For Availability
View on Model
12
Plate, Damper
Plate, Damper WPL W10110597 Contact Us For Availability
View on Model
12
Harns-Wire Magnetron
Harns-Wire Magnetron WPL W10110600 Contact Us For Availability
View on Model
12
Harns-Wire Ground, Main
Harns-Wire Ground, Main WPL W10110601 Contact Us For Availability
View on Model
12
Harns-Wire Filter Capacitor
Harns-Wire Filter Capacitor WPL W10110602 Contact Us For Availability
View on Model
12
Harns-Wire Ground, Hum Sensor
Harns-Wire Ground, Hum Sensor WPL W10111830 Contact Us For Availability
View on Model
12
Harns-Wire AC Line Filter
Harns-Wire AC Line Filter WPL W10114260 Contact Us For Availability
View on Model
12
Harns-Wire, Main
Harns-Wire, Main WPL W10114261 Contact Us For Availability
View on Model
12
Harns-Wire Lamp/TT
Harns-Wire Lamp/TT WPL W10114262 Contact Us For Availability
View on Model
12
Harns-Wire Ground, Inverter
Harns-Wire Ground, Inverter WPL W10114263 Contact Us For Availability
View on Model
12
Harns-Wire Cavity Therm 1-2
Harns-Wire Cavity Therm 1-2 WPL W10114264 Contact Us For Availability
View on Model
12
Harns-Wire Cavity Therm 2-3
Harns-Wire Cavity Therm 2-3 WPL W10114265 Contact Us For Availability
View on Model
12
Plate, Cam
Plate, Cam WPL 8205211 Contact Us For Availability
View on Model
12
Cover, Terminal
Cover, Terminal WPL W10110598 Contact Us For Availability
View on Model
13
Support, Interlock
Support, Interlock WPL 8185189 Contact Us For Availability
View on Model
14
Fan, DC 12 Volt
Fan, DC 12 Volt WPL 8184875 Contact Us For Availability
View on Model
14
Thermostat
Thermostat WPL 8183994 Contact Us For Availability
View on Model
15
Screw
Screw WPL 8169474 Contact Us For Availability
View on Model
15
Housing, Fan
Housing, Fan WPL 8184894 Contact Us For Availability
View on Model
15
Rack
Rack WPL 8205549 Contact Us For Availability
View on Model
16
Wheel (3)
Wheel (3) WPL 4393861 Contact Us For Availability
View on Model
17
Humidity, Sensor
Humidity, Sensor WPL 8206446 Contact Us For Availability
View on Model
17
Bracket, Holder
Bracket, Holder WPL 8206565 Contact Us For Availability
View on Model
17
Screw
Screw WPL 4393838 Contact Us For Availability
View on Model
18
Holder, Inverter
Holder, Inverter WPL 8184670 Contact Us For Availability
View on Model
19
Thermostat/Bracket
Thermostat/Bracket WPL 8205578 Contact Us For Availability
View on Model
20
Capacitor, 125 V
Capacitor, 125 V WPL 8184093 Contact Us For Availability
View on Model
20
Bracket, Plug
Bracket, Plug WPL W10110595 Contact Us For Availability
View on Model
21
Spacer, Copper Pipe
Spacer, Copper Pipe WPL 8184129 Contact Us For Availability
View on Model
22
Plate, Damper
Plate, Damper WPL 8204674 Contact Us For Availability
View on Model
22
Plate, Side
Plate, Side WPL 8185031 Contact Us For Availability
View on Model
23
Cushion, Mtr
Cushion, Mtr WPL 8169635 Contact Us For Availability
View on Model
23
Holder, Lamp
Holder, Lamp WPL 8184926 Contact Us For Availability
View on Model
24
Cable
Cable WPL 8184887 Contact Us For Availability
View on Model
25
Cover, Terminal
Cover, Terminal WPL 8184202 Contact Us For Availability
View on Model
26
Capacitor
Capacitor WPL 8184204 Contact Us For Availability
View on Model
27
Holder, Fuse
Holder, Fuse WPL 8184312 Contact Us For Availability
View on Model
29
Thermostat
Thermostat WPL 8183998 Contact Us For Availability
View on Model
30
SCREW
SCREW WPL 8184199 Contact Us For Availability
View on Model
32
SCREW
SCREW WPL 8184200 Contact Us For Availability
View on Model
35
Foil, Lamp
Foil, Lamp WPL 8184203 Contact Us For Availability
View on Model
36
Brkt-Support Ferrite Holder
Brkt-Support Ferrite Holder WPL W10114257 Contact Us For Availability
View on Model
37
Ferrite Ring
Ferrite Ring WPL 8206086 Contact Us For Availability
View on Model
