Model Whirlpool GH4184XSB1 Microwave Oven 1.8 Cu. Ft. – Common Parts &amp; Diagrams

1

Pivot, Door WPL 8184922 Contact Us For Availability

1

Deflector, Air WPL 8205350 Contact Us For Availability

1

Motor, Stirrer WPL 8205044 Contact Us For Availability

1

Cook Guide Label WPL 8205198 Contact Us For Availability

1

Tech Sheet WPL 8205607 Contact Us For Availability

1

U & C Guide WPL 8206416 Contact Us For Availability

2

W10246505 Whirlpool Microwave Door Handle In Stock WPL W10246505 $81.52

2

Panel Asy, Control Includes Lens and Membrane WPL 8206463 Contact Us For Availability

2

Cover, Lamp WPL 8206453 Contact Us For Availability

2

Stirrer Shaft/Blade WPL 8205202 Contact Us For Availability

2

Handle, Door (Stainless) WPL 8206176 Contact Us For Availability

2

Panel Asy, Control Includes Lens and Membrane WPL 8206464 Contact Us For Availability

3

Duct, Air WPL 8205368 Contact Us For Availability

3

Shield, Nomex WPL 8205369 Contact Us For Availability

3

Lower Hinge WPL 8204678 Contact Us For Availability

3

Bracket, Control WPL 8205378 Contact Us For Availability

4

8169479 Whirlpool Microwave Screw Backorder WPL 8169479 $2.51

4

Thermostat/Bracket WPL 8206454 Contact Us For Availability

4

Lid, Power Cord WPL 8184897 Contact Us For Availability

4

Microcomputer WPL 8205379 Contact Us For Availability

5

8169480 Whirlpool Microwave Screw Backorder WPL 8169480 $9.13

5

W10843943 Whirlpool Microwave Vent Damper In Stock WPL W10843943 $44.05

5

Thermostat WPL 8183703 Contact Us For Availability

5

Cover, Inlet Includes Nails and Bushings WPL 8184476 Contact Us For Availability

6

W10708076 Whirlpool Microwave Power Cord In Stock WPL W10708076 $5.20

6

WP8533914 Whirlpool Lock Backorder WPL WP8533914 $2.91

6

Cover WPL 8204676 Contact Us For Availability

7

8206232A Whirlpool Microwave 40W 125V Incande In Stock WPL 8206232A $2.76

7

Nails/Bushings (4 of each) WPL 8184549 Contact Us For Availability

7

Case, Outer WPL 8205348 Contact Us For Availability

7

Upper Hinge WPL 8204679 Contact Us For Availability

8

W10450187 Whirlpool Microwave Oven Vent Grill In Stock WPL W10450187 $26.99

8

Air Guide, Back WPL 8205354 Contact Us For Availability

8

Turntable WPL 8206226 Contact Us For Availability

8

Grille, Vent (Stainless) WPL 8205217 Contact Us For Availability

8

Complete Door (Black) WPL 8206461 Contact Us For Availability

8

Complete Door (Stainless) WPL 8206462 Contact Us For Availability

9

W10615742 Whirlpool Microwave Clip In Stock WPL W10615742 $3.24

9

W11252182 Whirlpool Glass Tray Support In Stock WPL W11252182 $20.42

9

Motor, Fan Assy WPL 8206175 Contact Us For Availability

10

4393836 Whirlpool Microwave Screw Backorder WPL 4393836 $2.73

10

Shield WPL 8205355 Contact Us For Availability

W10435116 Whirlpool Microwave Turntable Rolle Backorder WPL W10435116 $12.02

Screw WPL 8169475 Contact Us For Availability

Spring, Interlock WPL 8169438 Contact Us For Availability

SHIELD WPL 8206460 Contact Us For Availability

12

W10642989 Whirlpool Microwave Oven Turntable In Stock WPL W10642989 $72.24

12

W11380570 Whirlpool Microwave Screw In Stock WPL W11380570 $9.86

13

Support, Interlock WPL 8185189 Contact Us For Availability

13

Cover, Terminal WPL W10110598 Contact Us For Availability

14

W10222507 Whirlpool Microwave Magnetron Backorder WPL W10222507 $150.53

15

Screw WPL 8169474 Contact Us For Availability

15

Thermostat WPL 8184951 Contact Us For Availability

16

Air Guide (Right) WPL 8205352 Contact Us For Availability

16

Air Guide (Left) WPL 8205367 Contact Us For Availability

16

Rack WPL 8205549 Contact Us For Availability

17

Humidity, Sensor WPL 8206446 Contact Us For Availability

8205948 Whirlpool Microwave Mount In Stock WPL 8205948 $7.50

W10539840 Whirlpool Microwave Wire Harness In Stock WPL W10539840 $9.20

WP8169704 Whirlpool Screw In Stock WPL WP8169704 $2.85

Filter WPL 8206624 Contact Us For Availability

Screw WPL 4393838 Contact Us For Availability

Template, Upper WPL 8184731 Contact Us For Availability

H.V. Wire Assembly WPL 8205693 Contact Us For Availability

Main Wire Assy WPL 8206195 Contact Us For Availability

Plate, Damper WPL 8206452 Contact Us For Availability

FOLLOWING PARTS NOT ILLUSTRATED Miscellaneous WPL ARI148854A Contact Us For Availability

Wire-Grnd, Thrmst WPL W10111829 Contact Us For Availability

Wire-Grnd, Sensor WPL W10111830 Contact Us For Availability

Wire-Grnd, AC Line WPL W10111831 Contact Us For Availability

Wire-Grnd, Cavity WPL W10111832 Contact Us For Availability

Wire-Grnd, Fuse WPL W10111833 Contact Us For Availability

19

Rod-Locking Link WPL 8185190 Contact Us For Availability

20

Base Plate, Air Guide WPL 8205351 Contact Us For Availability

21

4393832 Whirlpool Microwave Screw Backorder WPL 4393832 $9.59

24

Socket, Motor Wire WPL 8185097 Contact Us For Availability

25

W10315274 Whirlpool Microwave Meal Rack Backorder WPL W10315274 $19.22

36

8169539 Whirlpool Microwave Light Bulb Socket Backorder WPL 8169539 $30.93

38

Transformer, H.V. WPL 8206456 Contact Us For Availability

40

Capacitor, H.V. WPL 8206458 Contact Us For Availability

41

W11256462 Whirlpool Microwave Diode In Stock WPL W11256462 $10.01

42

Chassis WPL 8206567 Contact Us For Availability
