Model Electrolux GCWS2438AWA WALL OVEN, ELECTRIC, SINGLE, 24 INCH – Common Parts & Diagrams

1
FRAME ASSEMBLY, FRONT
FRAME ASSEMBLY, FRONT WCI 5304533754 Contact Us For Availability
View on Model
1
DOOR ASSEMBLY, OUTER, WHITE, GRILL BOX
DOOR ASSEMBLY, OUTER, WHITE, GRILL BOX WCI 5304533794 Contact Us For Availability
View on Model
2
CONTROLLER, ELECTRONIC, PUX, OVEN
CONTROLLER, ELECTRONIC, PUX, OVEN WCI 5304535850 Contact Us For Availability
View on Model
2
CHANNEL, FRONT FRAME, LH
CHANNEL, FRONT FRAME, LH WCI 140204159028 Contact Us For Availability
View on Model
3
SPACER, CONTROLLER
SPACER, CONTROLLER WCI 5304533775 Contact Us For Availability
View on Model
3
CHANNEL, FRONT FRAME, RH
CHANNEL, FRONT FRAME, RH WCI 140204159010 Contact Us For Availability
View on Model
4
BRACKET, GROUNDING
BRACKET, GROUNDING WCI 5304533777 Contact Us For Availability
View on Model
4
HANDLE, DOOR, WHITE
HANDLE, DOOR, WHITE WCI 5304533796 Contact Us For Availability
View on Model
5
CAP, MOUNT, LH FRAME
CAP, MOUNT, LH FRAME WCI 5304533755 Contact Us For Availability
View on Model
5
INSULATION, OVEN, BACK
INSULATION, OVEN, BACK WCI 140215866017 Contact Us For Availability
View on Model
5
SCREW, T20 PAN, M4 X 16, HANDLE
SCREW, T20 PAN, M4 X 16, HANDLE WCI 5612311166 Contact Us For Availability
View on Model
6
CAP, MOUNT, RH FRAME
CAP, MOUNT, RH FRAME WCI 5304533756 Contact Us For Availability
View on Model
6
INSULATION, INSERT, OVEN BACK
INSULATION, INSERT, OVEN BACK WCI 4055549499 Contact Us For Availability
View on Model
7
SCREW, W/HD PH NIB, #8 X 12, SILVER
SCREW, W/HD PH NIB, #8 X 12, SILVER WCI 4055578613 Contact Us For Availability
View on Model
7
BRACE, OVEN, REAR
BRACE, OVEN, REAR WCI 4055578589 Contact Us For Availability
View on Model
8
TRIM, SURROUND, CONTROL
TRIM, SURROUND, CONTROL WCI 5304535371 Contact Us For Availability
View on Model
8
SPACER, RUBBER, DOOR GLASS
SPACER, RUBBER, DOOR GLASS WCI 4055549754 Contact Us For Availability
View on Model
9
PANEL, AIR DUCT, LOWER, & FLUE COVER
PANEL, AIR DUCT, LOWER, & FLUE COVER WCI 140233381015 Contact Us For Availability
View on Model
10
PANEL, AIR DUCT, MIDDLE
PANEL, AIR DUCT, MIDDLE WCI 140199855028 Contact Us For Availability
View on Model
10
NUT, FAN BLADE
NUT, FAN BLADE WCI 4055549481 Contact Us For Availability
View on Model
10
HINGE, DOOR, RH-W/SPRING, GRILL
HINGE, DOOR, RH-W/SPRING, GRILL WCI 4055561510 Contact Us For Availability
View on Model
11
PANEL, AIR DUCT, UPPER
PANEL, AIR DUCT, UPPER WCI 4055549515 Contact Us For Availability
View on Model
11
HINGE, DOOR, LH-NO SPRING, GRILL
HINGE, DOOR, LH-NO SPRING, GRILL WCI 4055562716 Contact Us For Availability
View on Model
12
CATALYST, OVEN VENT
CATALYST, OVEN VENT WCI 3370874020 Contact Us For Availability
View on Model
12
COVER, CONVECTION FAN
COVER, CONVECTION FAN WCI 4055548855 Contact Us For Availability
View on Model
12
SCREW, T20, 4.2 X 13MM, BLACK, ZINC PLATED
SCREW, T20, 4.2 X 13MM, BLACK, ZINC PLATED WCI 5304533830 Contact Us For Availability
View on Model
13
RETAINER, OVEN CATALYST
RETAINER, OVEN CATALYST WCI 5304533759 Contact Us For Availability
View on Model
13
COVER, ELEMENT LATCH
COVER, ELEMENT LATCH WCI 4055549440 Contact Us For Availability
View on Model
14
LATCH, ELEMENT SUPPORT
LATCH, ELEMENT SUPPORT WCI 4055549432 Contact Us For Availability
View on Model
15
COVER, BAKE ELEMENT
COVER, BAKE ELEMENT WCI 4055549465 Contact Us For Availability
View on Model
17
ELEMENT, GRILL BOOST, BROIL
ELEMENT, GRILL BOOST, BROIL WCI 5304533560 Contact Us For Availability
View on Model
18
CLIP, STANDOFF, PC BOARD
CLIP, STANDOFF, PC BOARD WCI 4055549531 Contact Us For Availability
View on Model
18
CLIP, ELEMENT MTG.
CLIP, ELEMENT MTG. WCI 4055548723 Contact Us For Availability
View on Model
20
INSULATION, OVEN, WRAPPER
INSULATION, OVEN, WRAPPER WCI 4055549473 Contact Us For Availability
View on Model
21
GRILL BOX, ASSEMBLY, LOWER
GRILL BOX, ASSEMBLY, LOWER WCI 5304533758 Contact Us For Availability
View on Model
22
PANEL, GRILL TOP
PANEL, GRILL TOP WCI 4055549978 Contact Us For Availability
View on Model
23
BUMPER, STOP, BLACK
BUMPER, STOP, BLACK WCI 4055470712 Contact Us For Availability
View on Model
24
BRACKET, TEMP PROBE
BRACKET, TEMP PROBE WCI 4055549598 Contact Us For Availability
View on Model
26
BRACKET, TERMINAL BLOCK
BRACKET, TERMINAL BLOCK WCI 5304533768 Contact Us For Availability
View on Model
27
PANEL, OVEN, RH SIDE
PANEL, OVEN, RH SIDE WCI 140203265032 Contact Us For Availability
View on Model
28
PANEL, OVEN, LH SIDE
PANEL, OVEN, LH SIDE WCI 140203265040 Contact Us For Availability
View on Model
29
PANEL, OVEN, BOTTOM
PANEL, OVEN, BOTTOM WCI 4055548582 Contact Us For Availability
View on Model
30
COVER, BOTTOM PANEL, SHIELD
COVER, BOTTOM PANEL, SHIELD WCI 5304533769 Contact Us For Availability
View on Model
31
PANEL, OVEN, BACK, WIRE COVER
PANEL, OVEN, BACK, WIRE COVER WCI 5304533770 Contact Us For Availability
View on Model
33
PANEL, OVEN, TOP
PANEL, OVEN, TOP WCI 4055548624 Contact Us For Availability
View on Model
34
HANDLE, OVEN MOVING
HANDLE, OVEN MOVING WCI 5304533563 Contact Us For Availability
View on Model
35
KIT, CABINET INSTALL
KIT, CABINET INSTALL WCI 140071555019 Contact Us For Availability
View on Model
36
SEAL, OVEN DOOR
SEAL, OVEN DOOR WCI 4055549309 Contact Us For Availability
View on Model
39
BRACKET, CONDUIT
BRACKET, CONDUIT WCI 5304533786 Contact Us For Availability
View on Model
40
TRIM, INSTALLATION, WHITE, LOWER
TRIM, INSTALLATION, WHITE, LOWER WCI 5304535328 Contact Us For Availability
View on Model
NI
SCREW, PAN PHIL, #6 X 9.5, ZINC
SCREW, PAN PHIL, #6 X 9.5, ZINC WCI 4055548707 Contact Us For Availability
View on Model
NI
SCREW, #2 PH AB MUSH, #8 X 1/2, BLACK
SCREW, #2 PH AB MUSH, #8 X 1/2, BLACK WCI 4055548921 Contact Us For Availability
View on Model
NI
SCREW, PAN #2PH, #8 X 50
SCREW, PAN #2PH, #8 X 50 WCI 4055549689 Contact Us For Availability
View on Model
NI
HARNESS, WIRING, USER INTERFACE, PUX
HARNESS, WIRING, USER INTERFACE, PUX WCI 5304533776 Contact Us For Availability
View on Model
NI
SCREW, HEX PH2 T/CUT, 6-20 X 9.3
SCREW, HEX PH2 T/CUT, 6-20 X 9.3 WCI 5304533778 Contact Us For Availability
View on Model
NI
CABLE TIE, PLT1M-M30
CABLE TIE, PLT1M-M30 WCI 4055541587 Contact Us For Availability
View on Model
NI
SCREW, PH2 NYLON WASHR, #8 X 1/2
SCREW, PH2 NYLON WASHR, #8 X 1/2 WCI 4055549952 Contact Us For Availability
View on Model
NIA
HARNESS, WIRING, DOOR LOCK
HARNESS, WIRING, DOOR LOCK WCI 5304533765 Contact Us For Availability
View on Model
NIA
SCREW, PH2 HEX 1/4, M4 X 5, BLACK, DOOR HINGE
SCREW, PH2 HEX 1/4, M4 X 5, BLACK, DOOR HINGE WCI 85801500052716 Contact Us For Availability
View on Model
