Model Electrolux FPZ21TFW3 REFRIGERATOR – Common Parts &amp; Diagrams

*39561

HOT TUBE REPAIR KIT WCI 5300189383 Contact Us For Availability

1

PROTECTOR-CAP (2) WCI 3201150 No Longer Available

1

5303212918 Frigidaire Refrigerator Control Backorder WCI 5303212918 $60.84

1

5303305677 Frigidaire Replacement Filters Fil In Stock WCI 5303305677 $8.69

1

WCI 5303001037 WCI 5303001037 Contact Us For Availability

2

WCI 01121808 WCI 01121808 Contact Us For Availability

2

BRACKET-UPPER HINGE WCI 5308012843 Contact Us For Availability

2

TRIM, SHELF WCI 3017427 Contact Us For Availability

2

WCI 5300163133 WCI 5300163133 Contact Us For Availability

2A

PLATE-TAPPING UPPER (2) (NON-ILLUSTRATED) WCI 5308012296 Contact Us For Availability

3

WCI 5308012820 WCI 5308012820 Contact Us For Availability

3

TRIM-SHELF WCI 3017428 Contact Us For Availability

3

GLASS-SHELF (3) WCI 3200614 Contact Us For Availability

3

BRACKET-MTG (4) WCI 5303001342 Contact Us For Availability

3A

SUPPORT-SHELF GLASS (4) (NON-ILLUSTRATED) WCI 3200901 Contact Us For Availability

3A

WASHER - NO. 10 EXT TOOTH LOCK (2) (NON-ILLUS WCI 5308009617 Contact Us For Availability

4

WASHER, NYLON WCI 5308000186 Contact Us For Availability

4

WCI 0803661 WCI 0803661 Contact Us For Availability

4

TRIM-FRONT (3) WCI 3018732 Contact Us For Availability

4

WCI 5303211232 WCI 5303211232 Contact Us For Availability

5

WASHER-NYLON (3) WCI 530800007 Contact Us For Availability

5

TOP, REFRIGERATOR WCI 3019038 Contact Us For Availability

5

WCI 5303019035 WCI 5303019035 Contact Us For Availability

5

WCI 5303209254 WCI 5303209254 Contact Us For Availability

5A

WCI 3018984 WCI 3018984 Contact Us For Availability

6

215846604 Frigidaire Refrigerator Defrost Tim In Stock WCI 215846604 $15.08

6

ROLLER, FRONT (2) WCI 5303212490 Contact Us For Availability

6

GLASS-COVER WCI 3200389 Contact Us For Availability

6

WCI 5303001197 WCI 5303001197 Contact Us For Availability

6A

GASKET-CRISPER CVR (NON-ILLUSTRATED) WCI 5303200329 Contact Us For Availability

7

DAMPER WCI 5303001331 Contact Us For Availability

7

PAN, CRISPER, LH WCI 3018873 Contact Us For Availability

7

WIRING HARNESS, COMPRESSOR, WCI 5303001347 Contact Us For Availability

8

PLUG BUTTON-WHITE WCI 5308000134 Contact Us For Availability

8

NUT, PUSH WCI 5303001028 Contact Us For Availability

8

PAN, CRISPER, RH WCI 3018982 Contact Us For Availability

8

WCI 5316254901 WCI 5316254901 Contact Us For Availability

9

WCI 5308009773 WCI 5308009773 Contact Us For Availability

9

WCI 5308009793 WCI 5308009793 Contact Us For Availability

9

WCI 3017422 WCI 3017422 Contact Us For Availability

9

CLIP-COMPRESSOR MTG (4) WCI 5308003596 Contact Us For Availability

BOLT, ROLLER MTG (2) WCI 5308009762 Contact Us For Availability

LABEL, KNOB WCI 08009823 Contact Us For Availability

WCI 3017423 WCI 3017423 Contact Us For Availability

WASHER-COMPRESSOR MTG WCI 5308003633 Contact Us For Availability

11

218513300 Frigidaire Refrigerator Compressor Backorder WCI 218513300 $26.72

11

FAN COVER WCI 08009825 Contact Us For Availability

11

ADJ SUPPORT-CRISPER COVER WCI 5303206507 Contact Us For Availability

12

WCI 08009934 WCI 08009934 Contact Us For Availability

12

FRAME-CANTILEVER MEAT KEEPER WCI 3203094 Contact Us For Availability

12

DEFROST PAN - SERVICE COMPRESSOR WCI 5300184715 Contact Us For Availability

12A

DEFROST PAN-ORIGINAL COMPRESSOR WCI 5300171129 Contact Us For Availability

13

5304455651 Frigidaire Refrigerator Screw In Stock WCI 5304455651 $8.44

13

WCI 5303007173 WCI 5303007173 Contact Us For Availability

13

FRAME-CANTILEVER (2) WCI 3200616 Contact Us For Availability

13A

RETAINER-GLASS (2) (NON-ILLUSTRATED) WCI 3018724 Contact Us For Availability

13B

RETAINER-GLASS, SNACK PAN (NON-ILLUSTRATED) WCI 3203087 Contact Us For Availability

14

SPOUT DRAIN WCI 5308000056 Contact Us For Availability

14

RETAINER-REAR WCI 3203088 Contact Us For Availability

14

COMPRESSOR-SERVICE WCI 5303916012 Contact Us For Availability

15

5303208309 Frigidaire Refrigerator Plug Hole Backorder WCI 5303208309 $26.74

15

PAN-SNACK WCI 3018987 Contact Us For Availability

15

WCI 3206096 WCI 3206096 Contact Us For Availability

15A

OVERLOAD-CLIP (NON-ILLUSTRATED) WCI 3202891 Contact Us For Availability

5308000010 Frigidaire Refrigerator Evaporator In Stock WCI 5308000010 $31.41

WCI 5303212488 WCI 5303212488 Contact Us For Availability

TRIM-SNACK PAN WCI 3018986 Contact Us For Availability

CAPACITOR & SCREW WCI 5303916391 Contact Us For Availability

16A

PIN - PUSH (NON-ILLUSTRATED) WCI 5303001361 Contact Us For Availability

16A

WCI 5033001343 WCI 5033001343 Contact Us For Availability

17

RING-ORIFICE-FAN WCI 5308000124 Contact Us For Availability

17

WCI 5303212489 WCI 5303212489 Contact Us For Availability

17

HANGER, MEAT PAN, LH WCI 5303210016 Contact Us For Availability

17A

PLATE-TAPPING-GUSSET-LH LOWER (1) (NON-ILLUST WCI 5303212596 Contact Us For Availability

17A

HANGER, MEAT PAN, RH (NON ILLUSTRATED) WCI 5303210017 Contact Us For Availability

17B

PLATE-TAPPING-GUSSET-RH LOWER (1) (NON-ILLUST WCI 5303212597 Contact Us For Availability

WCI 5308000107 WCI 5308000107 Contact Us For Availability

SUPPORT, COIL COVER (2) WCI 5308000097 Contact Us For Availability

SCREW, HANGER (2) WCI 08014528 Contact Us For Availability

WCI 5308013663 WCI 5308013663 Contact Us For Availability

19

5300158289 Frigidaire Evaporator Fan Motor In Stock WCI 5300158289 $80.01

19

PLUG, FREEZER LINER (3) WCI 5308016571 Contact Us For Availability

19

INSULATION BLOCK, LH WCI 5308017227 Contact Us For Availability

20

WCI 5308012258 WCI 5308012258 Contact Us For Availability

20

BRACKET-FRONT-MOTOR MTG WCI 5303001226 Contact Us For Availability

20

INSULATION BLOCK, RH WCI 5308013648 Contact Us For Availability

21

DRAIN TUBE & RING SEAL ASSY WCI 5303210377 Contact Us For Availability

21

BRACKET-REAR-MOTOR MTG WCI 5303205119 Contact Us For Availability

21

INSULATION PLUG, RH WCI 5303007287 Contact Us For Availability

22

5303917954 Frigidaire Refrigerator Defrost Li In Stock WCI 5303917954 $17.84

22

G187559 Frigidaire Refrigerator Bushing Backorder WCI G187559 $30.30

22

RING SEAL, TUBE WCI 5303207353 Contact Us For Availability

23

WCI 5303019039 WCI 5303019039 Contact Us For Availability

23

WCI 5300162506 WCI 5300162506 Contact Us For Availability

5303323480 Frigidaire Refrigerator Right Door In Stock WCI 5303323480 $8.89

5308000110 Frigidaire Refrigerator Evaporator Backorder WCI 5308000110 $38.80

BRACKET-CTR HINGE WCI 5303001369 Contact Us For Availability

COVER, COIL WCI 5308013665 Contact Us For Availability

24A

5303001449 Frigidaire Refrigerator Seal Backorder WCI 5303001449 $1.33

24B

EXTENSION AIR DEFLECTOR & INSULATION (NON-ILL WCI 5303200590 Contact Us For Availability

24C

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $8.91

5303323481 Frigidaire Refrigerator Left Hand In Stock WCI 5303323481 $8.89

PIN, CTR HINGE WCI 5308000184 Contact Us For Availability

WCI 5303001470 WCI 5303001470 Contact Us For Availability

HEAT EXCHANGER WCI 5308000728 Contact Us For Availability

5309918806 Frigidaire Refrigerator Light Swit Backorder WCI 5309918806 $13.79

5317842502 Frigidaire Defrost Heater Assembly Backorder WCI 5317842502 $81.01

PANEL-REFRIG-WHITE WCI 5308009928 Contact Us For Availability

CHANNEL, RH & LH WCI 5308000302 Contact Us For Availability

5304455852 Frigidaire Refrigerator Screw In Stock WCI 5304455852 $8.00

WCI 5316651102 WCI 5316651102 Contact Us For Availability

WCI 3019032 WCI 3019032 Contact Us For Availability

WCI 5303001380 WCI 5303001380 Contact Us For Availability

REFR HANDLE ASSY WCI 3202009 Contact Us For Availability

WCI 5303200366 WCI 5303200366 Contact Us For Availability

BOTTOM, FREEZER WCI 5303210641 Contact Us For Availability

WIRING HARNESS-DIVIDER WCI 3019040 Contact Us For Availability

5304455846 Frigidaire Refrigerator Clamp In Stock WCI 5304455846 $6.68

DOOR STOP, FREEZER (1) WCI 5308000255 Contact Us For Availability

WASHER-STEEL NO. 10 (4) WCI 5303206754 Contact Us For Availability

AIR DEFLECTOR WCI 5308014667 Contact Us For Availability

30

5308000039 Frigidaire Refrigerator Screw Backorder WCI 5308000039 $7.55

30

WCI 5303001448 WCI 5303001448 Contact Us For Availability

30A

NUT-NO. 8 (A) U-TYPE (NON-ILLUSTRATED) WCI 5303209814 Contact Us For Availability

31

241710601 Frigidaire Refrigerator Screw In Stock WCI 241710601 $8.46

31

5303001199 Frigidaire Refrigerator Wiring Har Backorder WCI 5303001199 $40.97

31

CONTROL, COLD WCI 5303018894 Contact Us For Availability

32

218906802 Frigidaire Light Lamp Socket In Stock WCI 218906802 $11.13

32

5308000133 Frigidaire Refrigerator Clamp Backorder WCI 5308000133 $7.13

32

WCI 5303001286 WCI 5303001286 Contact Us For Availability

33

DEFROST PAN RETAINER KIT-SERVICE COMPR WCI 5303916001 Contact Us For Availability

33

WCI 5303001287 WCI 5303001287 Contact Us For Availability

33

HOUSING, CAP TUBE WCI 3018891 Contact Us For Availability

34

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $10.44

34

WCI 5303001198 WCI 5303001198 Contact Us For Availability

35

CORNER-TRIM (WHITE) WCI 5303202336 Contact Us For Availability

35

WCI 3018893 WCI 3018893 Contact Us For Availability

36

5304509705 Frigidaire Refrigerator Grommet In Stock WCI 5304509705 $5.78

36

WCI 5303001260 WCI 5303001260 Contact Us For Availability

37

5304455649 Frigidaire Refrigerator Screw Backorder WCI 5304455649 $10.68

37

5304500407 Frigidaire Refrigerator Shelf Moun Backorder WCI 5304500407 $4.00

38

5303916855 Frigidaire Refrigerator Tube In Stock WCI 5303916855 $37.92

38

WCI 5303212487 WCI 5303212487 Contact Us For Availability

39

PLUG, WHITE WCI 5303001388 Contact Us For Availability

39

WCI 5303018896 WCI 5303018896 Contact Us For Availability

40

WCI 5303210351 WCI 5303210351 Contact Us For Availability

40

CONTROL BOX WCI 3018895 Contact Us For Availability

41

SPACER, MULLION (2) WCI 5303200464 Contact Us For Availability

41

PLUG, DECORATIVE WCI 5308013636 Contact Us For Availability

42

WCI 5308010008 WCI 5308010008 Contact Us For Availability
