Model Electrolux FLSE72GCS2 LAUNDRY CENTER – Common Parts &amp; Diagrams

*56526

5303309503 Frigidaire Clip Assembly Backorder WCI 5303309503 $4.46

*56527

INSERT-SPRING ADJ WCI 5303212877 Contact Us For Availability

1

131295200 Frigidaire Seal Backorder WCI 131295200 $10.24

2

131168200 Frigidaire Dryer Screw In Stock WCI 131168200 $8.89

2

134418700 Frigidaire Agitator Drive Hub Backorder WCI 134418700 $47.61

3

131551103 Frigidaire Splash Tub Cover P1 O/S1 Backorder WCI 131551103 $127.86

3

134075500 Frigidaire Lid Bumper Backorder WCI 134075500 $10.70

3

TRANSMISSION COMPL. WCI 131373500 Contact Us For Availability

4

131212301 Frigidaire Washer Capacitor Motor In Stock WCI 131212301 $6.68

4

131362400 Frigidaire Fastener In Stock WCI 131362400 $5.78

4

5303161307 Frigidaire Dryer Seal Assembly In Stock WCI 5303161307 $13.37

4

5304489657 Frigidaire Bar Hinge Kit Backorder WCI 5304489657 $51.59

5

5303208743 Frigidaire Grommet Backorder WCI 5303208743 $3.53

5

5303281019 Frigidaire Ball Assembly Backorder WCI 5303281019 $10.22

5

RING-RETAINING WCI 5303161223 Contact Us For Availability

6

134197900 Frigidaire Screw Backorder WCI 134197900 $8.89

6

5303212872 Frigidaire Lid Assembly Backorder WCI 5303212872 $196.86

6

5303281020 Frigidaire Ball Clip Backorder WCI 5303281020 $10.68

6

5303912532 Frigidaire Inlet Hose 60" Backorder WCI 5303912532 $53.75

7

3204490 Frigidaire Seal Backorder WCI 3204490 $8.89

7

5303161296 Frigidaire Washer Inlet Hose (1 Pi Backorder WCI 5303161296 $8.48

7

PLUG-PIPE WCI 5303161224 Contact Us For Availability

8

131437500 Frigidaire Washer Timer Backorder WCI 131437500 $280.80

8

SCREW-BLOWER HSG, PPH AB ST/Z/CH, 6-18 X .60 WCI 3205245 Contact Us For Availability

8

WCI 5308002804 WCI 5308002804 Contact Us For Availability

9

131390000 Frigidaire Door Catch-Strike Backorder WCI 131390000 $34.02

9

5304488479 Frigidaire Washer Hose Clamp In Stock WCI 5304488479 $12.46

9

GASKET WCI 5308015778 Contact Us For Availability

10

HOSE & NOZZLE WCI 3204400 Contact Us For Availability

10

GEAR-SECTOR WCI 5308011268 Contact Us For Availability

11

3204368 Frigidaire Strike Screw Backorder WCI 3204368 $8.00

11

WCI 131427200 WCI 131427200 Contact Us For Availability

11

ROD-CONNECTING WCI 5303161169 Contact Us For Availability

12

131476300 Frigidaire Dryer Blower Wheel In Stock WCI 131476300 $29.10

12

WCI 131221300 WCI 131221300 Contact Us For Availability

12

GEAR-CRANK WCI 5308015496 Contact Us For Availability

13

137546400 Frigidaire Screw 5/16-18 x 0.625 In Stock WCI 137546400 $17.81

13

SHAFT-LOWER WCI 5308014905 Contact Us For Availability

14

131205400 Frigidaire Screw Backorder WCI 131205400 $8.02

14

137539500 Frigidaire Washer Lock Plate Trunni Backorder WCI 137539500 $12.48

14

WASHER-THRUST WCI 5303161226 Contact Us For Availability

137107000 Frigidaire Plate Backorder WCI 137107000 $16.92

3204307 Frigidaire Dryer Thermostat Control, Backorder WCI 3204307 $82.74

SWITCH-WATER TEMP WCI 5308008463 Contact Us For Availability

WASHER WCI 5303161232 Contact Us For Availability

16

131545101 Frigidaire Dryer Washer Transmissio Backorder WCI 131545101 $88.31

16

WCI 131362000 WCI 131362000 Contact Us For Availability

17

3204254 Frigidaire Baffle Assembly In Stock WCI 3204254 $80.24

17

WCI 131219900 WCI 131219900 Contact Us For Availability

18

WCI 131557200 WCI 131557200 Contact Us For Availability

18

WASHER-SPACER WCI 5308002475 Contact Us For Availability

20

3204374 Frigidaire Pin Backorder WCI 3204374 $48.93

20

3205150 Frigidaire Tub Bearing Screw Backorder WCI 3205150 $2.22

20

WCI 131288101 WCI 131288101 Contact Us For Availability

21

5308002401 Frigidaire Washer Primary Backorder WCI 5308002401 $9.86

21

KNOB-TIMER WASHER, WHITE WCI 131167601 Contact Us For Availability

21

OIL-TRANSMISSION (1 QT) WCI 3005242 Contact Us For Availability

3205241 Frigidaire Idler Spring Backorder WCI 3205241 $47.18

WCI 131373610 WCI 131373610 Contact Us For Availability

SCREW-SWITCH, 6-32 X .19-2A, (2) WCI 3161259 Contact Us For Availability

WCI 131417600 WCI 131417600 Contact Us For Availability

134885900 Frigidaire Spring Backorder WCI 134885900 $13.37

134886600 Frigidaire Spring Primary Backorder WCI 134886600 $23.61

5303283286 Frigidaire Drum Felt Seal Lower Fr In Stock WCI 5303283286 $25.14

GEAR-IDLER WCI 5303161175 Contact Us For Availability

24

134736400 Frigidaire Gearcase Backorder WCI 134736400 $614.86

24

WCI 131373900 WCI 131373900 Contact Us For Availability

25

WCI 5303294437 WCI 5303294437 Contact Us For Availability

26

3204405 Frigidaire Outer Tub Spin Bearing Backorder WCI 3204405 $60.82

26

SEAL-TUB WCI 5303279394 Contact Us For Availability

26

SPACER-TIMER-SHAFT WCI 3205248 Contact Us For Availability

27

5303270023 Frigidaire Screw Set Backorder WCI 5303270023 $18.70

27

WCI 5303212834 WCI 5303212834 Contact Us For Availability

28

134511600 Frigidaire Washer Drive Belt In Stock WCI 134511600 $8.37

28

WCI 5303281074 WCI 5303281074 Contact Us For Availability

29

131382300 Frigidaire Vane Screw Backorder WCI 131382300 $8.44

29

WCI 131498300 WCI 131498300 Contact Us For Availability

30

ARM-IDLER WCI 3204422 Contact Us For Availability

31

131202300 Frigidaire Screw Backorder WCI 131202300 $8.46

31

WCI 131288211 WCI 131288211 Contact Us For Availability

31

WCI 3204423 WCI 3204423 Contact Us For Availability

32

PIN-ROLL WCI 3204424 Contact Us For Availability

33

134190200 Frigidaire Washer Water Valve In Stock WCI 134190200 $88.25

33

3204267 Frigidaire Dryer Safety Thermostat In Stock WCI 3204267 $46.66

33

WCI 3204425 WCI 3204425 Contact Us For Availability

34

131205500 Frigidaire Screw Backorder WCI 131205500 $8.46

34

SLEEVE-IDLER WCI 3204426 Contact Us For Availability

35

3161433 Frigidaire Retainer Backorder WCI 3161433 $11.57

35

WCI 5308002385 WCI 5308002385 Contact Us For Availability

36

WCI 5303261031 WCI 5303261031 Contact Us For Availability

36

WCI 3204380 WCI 3204380 Contact Us For Availability

37

WASHER-SPRING WCI 5303161306 Contact Us For Availability

37

SCREW-SHIPPING, HH AB YEL, 1/4-14 X 0.750 WCI 131102900 Contact Us For Availability

38

WCI 5303311213 WCI 5303311213 Contact Us For Availability

38

WCI 5303210285 WCI 5303210285 Contact Us For Availability

38

NUT-LOCK, MOTOR WCI 5303283079 Contact Us For Availability

39

131205100 Frigidaire Screw In Stock WCI 131205100 $8.91

40

WCI 131460500 WCI 131460500 Contact Us For Availability

41

131302800 Frigidaire Drum Vane Screw In Stock WCI 131302800 $8.46

41

131513300 Frigidaire Shield Backorder WCI 131513300 $53.86

42

WCI 131104303 WCI 131104303 Contact Us For Availability

43

WCI 131268401 No Longer Available

43

131422200 Frigidaire P-1 Self Level Leg Pad In Stock WCI 131422200 $35.65

43

WCI 131422100 WCI 131422100 Contact Us For Availability

44

134548800 Frigidaire Washer Leg Levelling In Stock WCI 134548800 $8.89

44

137551901 Frigidaire Gasket In Stock WCI 137551901 $24.07

45

131346401 Frigidaire Pin In Stock WCI 131346401 $10.24

45

WCI 131346400 WCI 131346400 Contact Us For Availability

45A

HOSE-DRAIN WCI 131461200 No Longer Available

45B

CLIP-DRAIN HOSE (NOT ILLUSTRATED) WCI 131506500 Contact Us For Availability

46

WCI 131452800 WCI 131452800 Contact Us For Availability

47

131306234 Frigidaire Pump Clamp Backorder WCI 131306234 $28.05

47

WCI 131091001 WCI 131091001 Contact Us For Availability

47

WCI 131106701 WCI 131106701 Contact Us For Availability

49

WCI 131434500 WCI 131434500 Contact Us For Availability

50

LOCK-LID WCI 3205646 Contact Us For Availability

50

WCI 131268600 WCI 131268600 Contact Us For Availability

51

BRACKET-LID LOCK WCI 5303306138 Contact Us For Availability

51

SCREW-LEG TO TUB, HWH 23, .31-18 X .875 WCI 3204459 Contact Us For Availability

52

RIVET-LID SWITCH WCI 08002420 Contact Us For Availability

52

WCI 131315800 WCI 131315800 Contact Us For Availability

53

5304401845 Frigidaire Pressure Tube Backorder WCI 5304401845 $36.13

53

PANEL-TOP WHITE WCI 131452510 Contact Us For Availability

54

WCI 3204394 WCI 3204394 Contact Us For Availability

54

WCI 131266800 WCI 131266800 Contact Us For Availability

55

134890500 Frigidaire Spring Backorder WCI 134890500 $12.46

55

WCI 131206100 WCI 131206100 Contact Us For Availability

56

131243800 Frigidaire Screw Backorder WCI 131243800 $6.42

56

WCI 131468900 WCI 131468900 Contact Us For Availability

57

131339600 Frigidaire P1 Spacer Backorder WCI 131339600 $11.59

58

WCI 131464900 WCI 131464900 Contact Us For Availability

59

CLIP-SHIELD WCI 5303283052 Contact Us For Availability

60

WCI 131268700 WCI 131268700 Contact Us For Availability

61

WCI 131268500 WCI 131268500 Contact Us For Availability

62

131420300 Frigidaire Screw Backorder WCI 131420300 $8.46

63

WCI 131494300 WCI 131494300 Contact Us For Availability

64

5303283072 Frigidaire Shield Screw Backorder WCI 5303283072 $5.73
