Model Electrolux FGHI1865SE4 REFRIGERATOR, TOP MOUNT, W/ICE MAKER – Common Parts &amp; Diagrams

1

242230902 Frigidaire Refrigerator Cover In Stock WCI 242230902 $49.40

1

5304502821 Frigidaire Refrigerator Condenser In Stock WCI 5304502821 $80.24

2

241798231 Frigidaire Refrigerator Ice Maker A In Stock WCI 241798231 $63.51

2

242193212 Frigidaire Refrigerator Door Gasket In Stock WCI 242193212 $126.70

2

242229401 Frigidaire Refrigerator Knob Backorder WCI 242229401 $434.36

4

5303305677 Frigidaire Replacement Filters Fil In Stock WCI 5303305677 $16.79

4

BIN, DOOR, FULL WIDTH, WHITE, REFRIGERATOR, P WCI 5304498927 Contact Us For Availability

5

242219302 Frigidaire Refrigerator Evaporator In Stock WCI 242219302 $10.41

5

BIN, DOOR, 1/2 WIDTH, REFRIGERATOR, W/TRIM WCI 242308201 Contact Us For Availability

6

241872713 Frigidaire Refrigerator Harness Backorder WCI 241872713 $66.32

6

5304497413 Frigidaire Refrigerator Ring Backorder WCI 5304497413 $3.16

7

242287501 Frigidaire Refrigerator Grommet In Stock WCI 242287501 $11.32

8

242237301 Frigidaire Grommet Backorder WCI 242237301 $10.41

8

5304498909 Frigidaire Refrigerator Bin Backorder WCI 5304498909 $35.70

9

242229301 Frigidaire Refrigerator Shroud Brac In Stock WCI 242229301 $19.45

10

240381303 Frigidaire Hinge Plug Backorder WCI 240381303 $41.22

10

242239304 Frigidaire Refrigerator Cover Backorder WCI 242239304 $39.15

11

DOOR-FRZR, BLACK, COMPLETE ASSY WCI 240437409 Contact Us For Availability

11A

GLASS-SHELF, FULL SHELF WCI 242087902 Contact Us For Availability

12

242015201 Frigidaire Nameplate In Stock WCI 242015201 $4.38

13

240312422 Frigidaire Refrigerator Door Stop Backorder WCI 240312422 $9.06

13

242219204 Frigidaire Refrigerator Blower Moto In Stock WCI 242219204 $78.40

13A

240312415 Frigidaire Refrigerator Door Stop Backorder WCI 240312415 $13.59

14

240494003 Frigidaire Refrigerator Button Plug In Stock WCI 240494003 $10.85

14

241554901 Frigidaire Refrigerator Light/Lamp In Stock WCI 241554901 $44.82

15

5303918274 Frigidaire Refrigerator Evaporator In Stock WCI 5303918274 $190.06

15

LIGHT ASSEMBLY, LED, W/LENS & BOARD WCI 5304498911 Contact Us For Availability

15

DOOR-REFR, BLACK, COMPLETE ASSY WCI 5304499329 Contact Us For Availability

16

5308000110 Frigidaire Refrigerator Evaporator In Stock WCI 5308000110 $39.44

17

241801301 Frigidaire Refrigerator Drain Troug Backorder WCI 241801301 $38.09

17

HOUSING, AIR & WATER WCI 5304498968 Contact Us For Availability

19

242320401 Frigidaire Refrigerator Shield In Stock WCI 242320401 $39.88

20

5304527429 Frigidaire Refrigerator Block Backorder WCI 5304527429 $6.69

20A

5304527430 Frigidaire Refrigerator Block Backorder WCI 5304527430 $6.82

21

240383408 Frigidaire Refrigerator Screw In Stock WCI 240383408 $8.12

21

242249002 Frigidaire Refrigerator Control Ass Backorder WCI 242249002 $126.77

215774918 Frigidaire Refrigerator Button Plug Backorder WCI 215774918 $5.88

240597220 Frigidaire Sensor In Stock WCI 240597220 $3.05

241665606 Frigidaire Refrigerator Compressor Backorder WCI 241665606 $111.64

5304507147 Frigidaire Refrigerator Hinge Bear In Stock WCI 5304507147 $4.51

23

218513300 Frigidaire Refrigerator Compressor In Stock WCI 218513300 $27.16

23

241842301 Frigidaire Refrigerator Thermistor Backorder WCI 241842301 $21.73

24

240358926 Frigidaire Safe Spill Shelf In Stock WCI 240358926 $78.67

24

241812301 Frigidaire Refrigerator Compressor Backorder WCI 241812301 $7.71

25

242037701 Frigidaire Refrigerator Compressor In Stock WCI 242037701 $1.78

25

242201802 Frigidaire Refrigerator Crisper Pan In Stock WCI 242201802 $74.09

26

241920605 Frigidaire Refrigerator Defrost Pan In Stock WCI 241920605 $32.71

26

242218505 Frigidaire Refrigerator Pan In Stock WCI 242218505 $99.43

28

5304499445 Frigidaire Refrigerator Roller Ass Backorder WCI 5304499445 $19.99

29

5304537072 Frigidaire Compressor with Clip, E In Stock WCI 5304537072 $177.51

29

TRIM-SHELF, FRONT WCI 242110902 Contact Us For Availability

30

241941005 Frigidaire Refrigerator Start Devic In Stock WCI 241941005 $91.14

31

240530811 Frigidaire Refrigerator Meat Crispe In Stock WCI 240530811 $88.77

32

297030500 Frigidaire Refrigerator Clip Backorder WCI 297030500 $7.67

34

240311303 Frigidaire Refrigerator Nylon Hinge In Stock WCI 240311303 $6.88

34

240385201 Frigidaire Refrigerator Ice Contain In Stock WCI 240385201 $67.44

34

240405201 Frigidaire Refrigerator Grommet Backorder WCI 240405201 $12.67

35

240313803 Frigidaire Refrigerator Center Hing Backorder WCI 240313803 $99.00

35A

240336803 Frigidaire Refrigerator Hinge Space Backorder WCI 240336803 $7.25

37

TRIM-CABINET CORNER, BLACK, (2) WCI 242161202 No Longer Available

38

240313703 Frigidaire Refrigerator Hinge In Stock WCI 240313703 $20.62

40

240354404 Frigidaire Refrigerator Upper Hinge In Stock WCI 240354404 $37.05

41

5304500407 Frigidaire Refrigerator Shelf Moun Backorder WCI 5304500407 $4.07

42

240578902 Frigidaire Screw Mounting Hinge In Stock WCI 240578902 $9.04

47

240350608 Frigidaire Refrigerator Crisper Gla In Stock WCI 240350608 $30.39

49A

BIN-TILT OUT, TILT-OUT WCI 242332201 Contact Us For Availability

50

242333104 Frigidaire Refrigerator Main Power Backorder WCI 242333104 $172.91

51

809170801 Frigidaire Refrigerator Harness Backorder WCI 809170801 $57.37

54

SUPPORT, HOUSING, MAIN BOARD WCI 807854301 Contact Us For Availability

55

242252603 Frigidaire Refrigerator Water Inlet In Stock WCI 242252603 $31.75

55

297286803 Frigidaire Refrigerator Run Capacit In Stock WCI 297286803 $16.17

56

240516502 Frigidaire Refrigerator Lower Hinge In Stock WCI 240516502 $43.03

58

240569202 Frigidaire Refrigerator Screw In Stock WCI 240569202 $1.35

58

5304453707 Frigidaire Oven Screw In Stock WCI 5304453707 $9.50

59

240442707 Frigidaire Refrigerator Screw #10-3 In Stock WCI 240442707 $1.79

59

242050604 Frigidaire Refrigerator Shroud Backorder WCI 242050604 $17.66

60

218362501 Frigidaire Refrigerator Screw Backorder WCI 218362501 $7.71

60

242018301 Frigidaire Refrigerator Condenser F In Stock WCI 242018301 $80.30

61

241639502 Frigidaire Refrigerator Condenser F In Stock WCI 241639502 $11.41

64

5304455846 Frigidaire Refrigerator Clamp In Stock WCI 5304455846 $6.79

72

5304498916 Frigidaire Refrigerator Toe Grille Backorder WCI 5304498916 $24.46

72A

COVER, LOWER HINGE, BLACK, LH WCI 5304498920 Contact Us For Availability

72B

COVER, LOWER HINGE, BLAC WCI 5304498921 Contact Us For Availability

80

218755504 Frigidaire Refrigerator Shoulder Sc In Stock WCI 218755504 $8.60

81

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $9.06

82

240335202 Frigidaire Refrigerator Roller Backorder WCI 240335202 $13.59

83

5304455655 Frigidaire Refrigerator Rivet Backorder WCI 5304455655 $23.04

84

240500801 Frigidaire Refrigerator Drain Tube In Stock WCI 240500801 $41.24

85

TUBE-CONNECTOR, SUCTION WCI 5304502967 Contact Us For Availability

89

241733911 Frigidaire Refrigerator Access Cove In Stock WCI 241733911 $32.30

92

241710601 Frigidaire Refrigerator Screw In Stock WCI 241710601 $8.60

101

241953902 Frigidaire Refrigerator Screw In Stock WCI 241953902 $10.93

218843801 Frigidaire Refrigerator Screw Backorder WCI 218843801 $8.58

240494001 Frigidaire Refrigerator Plug Button In Stock WCI 240494001 $10.85

5303918263 Frigidaire Refrigerator Primary He In Stock WCI 5303918263 $316.98

HOT TUBE REPAIR KIT, SERVICE WCI 5303918222 Contact Us For Availability

218252201 Frigidaire Refrigerator Screw Backorder WCI 218252201 $9.04

218515401 Frigidaire Refrigerator Clip In Stock WCI 218515401 $11.32

240346701 Frigidaire Refrigerator Foam Seal T Backorder WCI 240346701 $19.01

241500305 Frigidaire Refrigerator Screw In Stock WCI 241500305 $1.83

5303299664 Frigidaire Refrigerator Shelf Spac In Stock WCI 5303299664 $15.40

NIB

240359403 Frigidaire Refrigerator Fan Shroud Backorder WCI 240359403 $2.26
