Model Electrolux FGGS3065PWM RANGE/OVEN, GAS, SLIDE-IN, 30 INCH – Common Parts &amp; Diagrams

1

MANIFOLD, RIGHT SIDE WCI 318913400 Contact Us For Availability

1A

MANIFOLD, PIPE, LH WCI 318907200 Contact Us For Availability

1B

TUBE, CONNECTION, MANIFOLD WCI 318913500 Contact Us For Availability

2

5303935306 Frigidaire Oven Valve Backorder WCI 5303935306 $50.26

2A

316536006 Frigidaire Oven Valve Backorder WCI 316536006 $20.94

2C

VALVE, TOP BURNER, YELLOW STEM, HC WCI 316560903 Contact Us For Availability

3

139023301 Frigidaire Oven Trim Backorder WCI 139023301 $32.07

3

SWITCH ASSEMBLY, IGNITOR, 4 VALVE, W/HARNESS WCI 5304491103 Contact Us For Availability

3A

139014401 Frigidaire Oven Trim Backorder WCI 139014401 $19.15

4

316240600 Frigidaire Igniter Mounting Screw In Stock WCI 316240600 $7.11

4

318298906 Frigidaire Oven Panel Backorder WCI 318298906 $87.89

4

808950005 Frigidaire Door Assembly Backorder WCI 808950005 $317.53

4

SUPPORT, AUTO RACK, (2) WCI 318927600 Contact Us For Availability

5

318175503 Frigidaire Screw with Bolt Backorder WCI 318175503 $10.22

6

139006905 Frigidaire Oven Baffle Backorder WCI 139006905 $70.52

6

5304514983 Frigidaire Oven Rack Backorder WCI 5304514983 $89.16

6A

139012400 Frigidaire Oven Rack Backorder WCI 139012400 $102.04

7

318372017 Frigidaire Insulation Backorder WCI 318372017 $10.22

7A

318372016 Frigidaire Insulation Backorder WCI 318372016 $11.13

8

139005003 Frigidaire Oven Panel Backorder WCI 139005003 $80.69

8

5304503232 Frigidaire Oven Inner Door Glass In Stock WCI 5304503232 $72.74

8

808608802 Frigidaire Oven Spark Ignition Four In Stock WCI 808608802 $51.59

9

318138801 Frigidaire Oven Pan Backorder WCI 318138801 $24.03

10

316082001 Frigidaire Oven Insert Backorder WCI 316082001 $30.50

10

316438200 Frigidaire Range Sealed Burner, 5K In Stock WCI 316438200 $35.65

10

SCREW, WAFER HEAD, 10-24 X 1.81, (2), HANDLE WCI 316001002 Contact Us For Availability

10A

316558300 Frigidaire Oven 9.5L Sealed Burner In Stock WCI 316558300 $32.96

10B

316438600 Frigidaire Range Sealed Burner, 14K Backorder WCI 316438600 $49.38

10C

316438400 Frigidaire Range Sealed Burner, 16/ In Stock WCI 316438400 $48.50

11

316540800 Frigidaire Igniter/Orifice Assembly Backorder WCI 316540800 $7.02

11

807545502 Frigidaire Oven Seal Backorder WCI 807545502 $84.88

11

BRACKET, DRAWER SUPPORT, (2) WCI 318298600 Contact Us For Availability

11A

316540700 Frigidaire Igniter/Orifice Assembly In Stock WCI 316540700 $7.00

11B

316543206 Frigidaire Igniter Orifice Assembly In Stock WCI 316543206 $88.78

11C

316543203 Frigidaire Igniter Orifice Assembly Backorder WCI 316543203 $7.66

12B

318916600 Frigidaire Oven Tube Backorder WCI 318916600 $40.56

12C

318916700 Frigidaire Oven Tube Backorder WCI 318916700 $32.54

13

GLIDE, WARMER, INNER RH WCI 318259504 Contact Us For Availability

13A

GLIDE, WARMER, INNER LH WCI 318259505 Contact Us For Availability

15

5304528790 Frigidaire Lamp Assembly Appliance In Stock WCI 5304528790 $13.35

16

316446401 Frigidaire Oven Glass In Stock WCI 316446401 $72.75

16

TUBE, REGULATOR VALVE WCI 318289500 Contact Us For Availability

17

316031501 Frigidaire Oven Valve In Stock WCI 316031501 $168.94

18

5304502520 Frigidaire Oven Burner Backorder WCI 5304502520 $98.19

18

LINK, DOOR, (2), AUTO RACK WCI 316547900 Contact Us For Availability

19

139059408 Frigidaire Panel Assembly Backorder WCI 139059408 $420.47

20

139005100 Frigidaire Oven Baffle Backorder WCI 139005100 $59.51

20

5304503989 Frigidaire Controller Backorder WCI 5304503989 $236.36

20A

318560470 Frigidaire Oven Grate Backorder WCI 318560470 $159.51

21

5303013272 Frigidaire Oven Nut Backorder WCI 5303013272 $11.11

22

5304508441 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508441 $20.05

22A

5304508442 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508442 $20.95

22B

5304508443 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508443 $26.28

22C

5304508468 Frigidaire Oven Cap Assembly In Stock WCI 5304508468 $28.07

23

139007101 Frigidaire Burner Backorder WCI 139007101 $72.30

23

316575915 Frigidaire Oven Hinge Backorder WCI 316575915 $95.80

23

BRACKET, CONTROL MTG, (2) WCI 318921300 Contact Us For Availability

24

ELBOW, MIXER WCI 316409703 Contact Us For Availability

25

139075001 Frigidaire Oven Cover Backorder WCI 139075001 $37.03

25

BAFFLE, BROIL BURNER WCI 316401301 Contact Us For Availability

26

139013700 Frigidaire Igniter In Stock WCI 139013700 $103.76

26A

139013701 Frigidaire Igniter Backorder WCI 139013701 $103.32

29

139023400 Frigidaire Oven Spacer Backorder WCI 139023400 $12.02

29

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $7.57

30

318928502 Frigidaire Oven Bracket Backorder WCI 318928502 $9.80

37

5304504897 Frigidaire Oven Temperature Sensor In Stock WCI 5304504897 $26.72

39

5304534000 Frigidaire Cord Backorder WCI 5304534000 $19.59

39

HANDLE, DOOR/DRAWER, WHITE WCI 318927400 Contact Us For Availability

40

318242702 Frigidaire Oven Bracket Assembly Backorder WCI 318242702 $11.59

40

PANEL, SERVICE, WHITE WCI 318912900 Contact Us For Availability

41

318370602 Frigidaire Oven Bracket Backorder WCI 318370602 $8.02

42

318382302 Frigidaire Bracket Backorder WCI 318382302 $29.87

43

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $6.22

44

316527504 Frigidaire Oven Orifice Assembly In Stock WCI 316527504 $14.24

44A

316527500 Frigidaire Oven Burner Orifice Asse In Stock WCI 316527500 $13.35

44B

316527513 Frigidaire Oven Orifice In Stock WCI 316527513 $12.91

44C

316527509 Frigidaire Oven 18.2K Burner Orific Backorder WCI 316527509 $12.44

47

318565405 Frigidaire Conversion Kit Backorder WCI 318565405 $65.25

50

PANEL, SERVICE, FAN WCI 318578803 Contact Us For Availability

52

318291126 Frigidaire Cover Backorder WCI 318291126 $57.31

53

5304504202 Frigidaire Red Meat Temperature Pr Backorder WCI 5304504202 $70.09

56

5303324184 Frigidaire Wall Oven Range Screw Backorder WCI 5303324184 $8.91

57

316283600 Frigidaire Oven Cover Backorder WCI 316283600 $7.13

59

139078002 Frigidaire Oven Duct Backorder WCI 139078002 $48.93

64

318165800 Frigidaire Oven Door Glass Spacer w Backorder WCI 318165800 $11.13

70

139000601 Frigidaire Oven Shield Backorder WCI 139000601 $41.86

72

316215600 Frigidaire Oven Screw Backorder WCI 316215600 $8.89

76

WCI 318906703 WCI 318906703 Contact Us For Availability

86

318561100 Frigidaire Receptacle Backorder WCI 318561100 $12.46

89

5304528836 Frigidaire Motor Backorder WCI 5304528836 $45.40

90

PANEL, FILLER, WHITE, RH WCI 318296902 Contact Us For Availability

90A

5304511888 Frigidaire Panel Backorder WCI 5304511888 $42.76

91

TRIM, FILLER, WHITE, REAR WCI 318304301 Contact Us For Availability

97

WCI 808743401 WCI 808743401 Contact Us For Availability

107

139013903 Frigidaire Oven Vent Hood Cover Backorder WCI 139013903 $26.72

108

318575612 Frigidaire Oven Cooling Fan Motor In Stock WCI 318575612 $116.62

109

318398302 Frigidaire Stove Oven Range Convect In Stock WCI 318398302 $15.13

111

316136600 Frigidaire Oven Range Lock Nut Backorder WCI 316136600 $12.01

119

807144901 Frigidaire Thermostat Backorder WCI 807144901 $34.31

124

GLIDE, DRAWER, OUTER/RH & LH, (2) WCI 318330600 Contact Us For Availability

125

139008601 Frigidaire Oven Motor Backorder WCI 139008601 $89.18

131

139078102 Frigidaire Oven Duct Backorder WCI 139078102 $40.11

161

139013800 Frigidaire Oven Element Backorder WCI 139013800 $51.14

165

DEFLECTOR, BOX, FRONT WCI 318913300 Contact Us For Availability

166

318298410 Frigidaire Oven Bracket Backorder WCI 318298410 $44.09

166A

5304511884 Frigidaire Oven Bracket Assembly Backorder WCI 5304511884 $38.35

170

5304486410 Frigidaire Oven Kit Backorder WCI 5304486410 $89.60

200

WCI 318298232 WCI 318298232 Contact Us For Availability

201

318298233 Frigidaire Oven Frame Backorder WCI 318298233 $28.52

272

139021700 Frigidaire Oven Tube Backorder WCI 139021700 $11.13

284

316536100 Frigidaire Transformer Backorder WCI 316536100 $115.77

316021105 Frigidaire Oven Screw Backorder WCI 316021105 $7.11

316021109 Frigidaire Oven Screw In Stock WCI 316021109 $8.91

316418901 Frigidaire Oven Screw Backorder WCI 316418901 $8.91

318199776 Frigidaire Electrical Harness Backorder WCI 318199776 $32.07

5304511240 Frigidaire Harness Backorder WCI 5304511240 $74.07

808041201 Frigidaire Oven Harness Backorder WCI 808041201 $30.30

316001017 Frigidaire Screw Backorder WCI 316001017 $1.80

316418900 Frigidaire Oven Screw In Stock WCI 316418900 $8.91

318531701 Frigidaire Spacer Backorder WCI 318531701 $7.57

318946500 Frigidaire Oven Light Bulb Range/Wa Backorder WCI 318946500 $33.42

NIB

5303289910 Frigidaire Oven Screw Backorder WCI 5303289910 $3.55
