Model Electrolux FGBD2432KB1 DISHWASHER – Common Parts &amp; Diagrams

1

5304533200 Frigidaire Dishwasher Rack with Wh In Stock WCI 5304533200 $90.02

1

WCI 154729401 WCI 154729401 Contact Us For Availability

1A

154325201 Frigidaire Linkage Spring In Stock WCI 154325201 $24.96

2

154093301 Frigidaire Dishwasher ARM Assembly In Stock WCI 154093301 $1.33

2

154465101 Frigidaire Dishwasher Heating Eleme Backorder WCI 154465101 $7.13

2

5304532796 Frigidaire Dishwasher Strike In Stock WCI 5304532796 $7.11

2

5304535382 Frigidaire Basket Assembly In Stock WCI 5304535382 $12.68

2

WCI 154778003 WCI 154778003 Contact Us For Availability

3

154637401 Frigidaire Dishwasher Fill Valve Wa In Stock WCI 154637401 $21.83

3

WCI 154319526 WCI 154319526 Contact Us For Availability

3A

5304513274 Frigidaire Dishwasher Counterbalan In Stock WCI 5304513274 $42.32

4

154522902 Frigidaire Dishwasher Wheel and Bus In Stock WCI 154522902 $18.28

4

154718801 Frigidaire Dishwasher Cover Backorder WCI 154718801 $20.05

4

WCI 154669301 WCI 154669301 Contact Us For Availability

5

5304506510 Frigidaire Dishrack Slide Rail Sto In Stock WCI 5304506510 $4.44

5

WCI 154734301 WCI 154734301 Contact Us For Availability

6

154597801 Frigidaire Dishwasher Upper Rack Sl In Stock WCI 154597801 $5.58

6

5303943103 Frigidaire Dishwasher P-1 Screw Ki Backorder WCI 5303943103 $11.13

7

5304532229 Frigidaire Dishwasher Lower Rack W In Stock WCI 5304532229 $3.13

7

WCI 154494603 WCI 154494603 Contact Us For Availability

8

154745503 Frigidaire Dishwasher Toe Panel In Stock WCI 154745503 $10.24

9

5304501484 Frigidaire Dishwasher Assembly Toe In Stock WCI 5304501484 $31.61

154103702 Frigidaire Dishwasher Screw Backorder WCI 154103702 $8.46

154294701 Frigidaire Dishwasher Screw Backorder WCI 154294701 $5.77

154724001 Frigidaire Lower Arm Support In Stock WCI 154724001 $6.22

154754801 Frigidaire Dishwasher Screw In Stock WCI 154754801 $1.33

13

154246801 Frigidaire Dishwasher Primary Gaske Backorder WCI 154246801 $30.29

13

WCI 154755801 WCI 154755801 Contact Us For Availability

13A

154740304 Frigidaire Dishwasher Fold-Down Tin In Stock WCI 154740304 $20.50

14

154723801 Frigidaire Dishwasher SUMP Assembly In Stock WCI 154723801 $37.92

14A

5304506508 Frigidaire Bracket Support In Stock WCI 5304506508 $3.53

15

5304506540 Frigidaire Dishwasher Leg Assembly In Stock WCI 5304506540 $6.68

16

154246502 Frigidaire Dishwasher Bracket In Stock WCI 154246502 $25.38

20

154758501 Frigidaire Power Cord Cover Backorder WCI 154758501 $12.46

20

5304506509 Frigidaire Dishwasher Handle Backorder WCI 5304506509 $8.44

20

WCI 154741003 WCI 154741003 Contact Us For Availability

21

154754701 Frigidaire Dishwasher Screw Backorder WCI 154754701 $2.22

21

5304504913 Frigidaire Dishwasher Handle Backorder WCI 5304504913 $8.46

22

5304523457 Frigidaire Inlet Hose In Stock WCI 5304523457 $8.02

23

5304538466 Frigidaire Hose Clamp Backorder WCI 5304538466 $0.91

24

5304517203 Frigidaire Dishwasher Lower Wash A In Stock WCI 5304517203 $22.11

25

5304506520 Frigidaire Dishwasher Float Assemb In Stock WCI 5304506520 $8.00

28

154773201 Frigidaire Dishwasher Switch Assemb In Stock WCI 154773201 $34.76

29

154290204 Frigidaire Dishwasher Thermostat In Stock WCI 154290204 $40.11

30

154241101 Frigidaire Dishwasher Retainer Backorder WCI 154241101 $2.22

32A

154406401 Frigidaire Delivery Tube Gasket In Stock WCI 154406401 $6.68

33

154478901 Frigidaire Dishwasher Gasket Backorder WCI 154478901 $38.37

49

809006501 Frigidaire Bottom Seal/Gasket Door In Stock WCI 809006501 $14.86

51

WCI 154320301 WCI 154320301 Contact Us For Availability

55

5304534830 Frigidaire Dishwasher Bracket In Stock WCI 5304534830 $3.40

58

154246402 Frigidaire Dishwasher P-1 Ball Asse In Stock WCI 154246402 $35.20

59

154246901 Frigidaire Dishwasher Rear O-Ring f In Stock WCI 154246901 $35.65

59A

154247001 Frigidaire Dishwasher Pump Gasket S In Stock WCI 154247001 $35.65

61

5304506517 Frigidaire Dishwasher Grommet Asse In Stock WCI 5304506517 $9.79

62

5304518968 Frigidaire Lower Spray Arm Support In Stock WCI 5304518968 $7.13

65

154283005 Frigidaire Dishwasher Filter Assemb Backorder WCI 154283005 $148.68

66

5304532206 Frigidaire Trap In Stock WCI 5304532206 $4.66

71

154762601 Frigidaire Dishwasher Turbidity Sen Backorder WCI 154762601 $48.50

154106202 Frigidaire Dishwasher Heater Nut In Stock WCI 154106202 $4.80

154200701 Frigidaire Dishwasher Screw Backorder WCI 154200701 $8.46

154289801 Frigidaire Dishwasher Shield Backorder WCI 154289801 $4.89

154297701 Frigidaire Dishwasher Screw Backorder WCI 154297701 $8.46

154380601 Frigidaire Dishwasher Clamp Assembl In Stock WCI 154380601 $45.83

154388801 Frigidaire Dishwasher Rinse Aid Dis In Stock WCI 154388801 $15.57

154491101 Frigidaire Dishwasher Screw Backorder WCI 154491101 $2.22

154647101 Frigidaire Dishwasher Pin Hinge Backorder WCI 154647101 $8.91

154686401 Frigidaire Dishwasher Bearing Backorder WCI 154686401 $6.68

154741501 Frigidaire Dishwasher Screw Backorder WCI 154741501 $8.46

154754901 Frigidaire Dishwasher Screw In Stock WCI 154754901 $2.66

5304525214 Frigidaire Dishwasher Shield Backorder WCI 5304525214 $6.22

5304538695 Frigidaire Door Insulation Backorder WCI 5304538695 $0.91

808690701 Frigidaire Dishwasher Screw Backorder WCI 808690701 $2.22

WCI 154200601 WCI 154200601 Contact Us For Availability

WCI 5303316032 WCI 5303316032 Contact Us For Availability

WCI 154200602 WCI 154200602 Contact Us For Availability
