Model Frigidaire FFHT2045VS0 REFRIGERATOR – Common Parts & Diagrams

1
Badge, Frigidaire, chrome
Badge, Frigidaire, chrome WCI 5304511146 Contact Us For Availability
View on Model
2
Hinge Assembly, bottom, LH
Hinge Assembly, bottom, LH WCI 5304519776 Contact Us For Availability
View on Model
3#
Gasket, door, gray, refrigerator
Gasket, door, gray, refrigerator WCI 5304523138 Contact Us For Availability
View on Model
4#
Gasket, door, gray, freezer
Gasket, door, gray, freezer WCI 5304523139 Contact Us For Availability
View on Model
6#
Harness, wiring, machine compt.
Harness, wiring, machine compt. WCI 5304519649 Contact Us For Availability
View on Model
7
Pan Assembly, crisper, w/rollers
Pan Assembly, crisper, w/rollers WCI 5304522242 Contact Us For Availability
View on Model
8
Screw, hex wsh hd quad, M5 x 16
Screw, hex wsh hd quad, M5 x 16 WCI 5304522279 Contact Us For Availability
View on Model
9
Bearing, hinge, gray
Bearing, hinge, gray WCI 5304522194 Contact Us For Availability
View on Model
9
Cover, hinge, gray, lower, non-hinged
Cover, hinge, gray, lower, non-hinged WCI 5304522221 Contact Us For Availability
View on Model
10
Cover, hinge side, gray, lower
Cover, hinge side, gray, lower WCI 5304522246 Contact Us For Availability
View on Model
11
Hook, door closer, gray
Hook, door closer, gray WCI 5304522238 Contact Us For Availability
View on Model
11
Shroud, evaporator fan
Shroud, evaporator fan WCI 5304519752 Contact Us For Availability
View on Model
12
Screw, 8-18 X 1.25
Screw, 8-18 X 1.25 WCI 241953905 Contact Us For Availability
View on Model
15
BULB, light, E17/12 LED
BULB, light, E17/12 LED WCI 5304522314 Contact Us For Availability
View on Model
16#
Motor, evaporator fan, blower
Motor, evaporator fan, blower WCI 242219206 Contact Us For Availability
View on Model
16#
Socket, LED light
Socket, LED light WCI 5304522315 Contact Us For Availability
View on Model
17#
Starter, compressor, TSD 2.1
Starter, compressor, TSD 2.1 WCI 5304522269 Contact Us For Availability
View on Model
18
Cover, I/M Connector
Cover, I/M Connector WCI 5304519662 Contact Us For Availability
View on Model
19
Cover Assembly, evaporator, w/frz slide
Cover Assembly, evaporator, w/frz slide WCI 5304519654 Contact Us For Availability
View on Model
25
Tube, drain extension
Tube, drain extension WCI 5304519743 Contact Us For Availability
View on Model
28
Diffuser, control box, bottom
Diffuser, control box, bottom WCI 5304522317 Contact Us For Availability
View on Model
30#
Fan Assembly, condenser, w/shroud-foam
Fan Assembly, condenser, w/shroud-foam WCI 5304522173 Contact Us For Availability
View on Model
32
Switch, door/light, white
Switch, door/light, white WCI 5304520495 Contact Us For Availability
View on Model
33
Harness, wiring, control box, w/temp sensor
Harness, wiring, control box, w/temp sensor WCI 5304522320 Contact Us For Availability
View on Model
35
Hinge, door, upper
Hinge, door, upper WCI 5304519646 Contact Us For Availability
View on Model
39
Trough, evap drain
Trough, evap drain WCI 5304519679 Contact Us For Availability
View on Model
40
Hinge, door, gray, center
Hinge, door, gray, center WCI 5304522100 Contact Us For Availability
View on Model
40#
Evaporator, assembly
Evaporator, assembly WCI 5304522324 Contact Us For Availability
View on Model
41
Pin, center hinge, door
Pin, center hinge, door WCI 5304519642 Contact Us For Availability
View on Model
41#
Heater, defrost
Heater, defrost WCI 5304522325 Contact Us For Availability
View on Model
42
Screw, flt hd qdrx, M5 x 16, gray
Screw, flt hd qdrx, M5 x 16, gray WCI 5304522282 Contact Us For Availability
View on Model
89
Access Cover, rear
Access Cover, rear WCI 5304522114 Contact Us For Availability
View on Model
