Model Electrolux FFGS3025PWB GAS RANGE – Common Parts &amp; Diagrams

1B

318305410 Frigidaire Range Tube Backorder WCI 318305410 $170.81

2

316271303 Frigidaire Oven Valve Backorder WCI 316271303 $80.67

2B

WCI 316271305 WCI 316271305 Contact Us For Availability

2C

316271301 Frigidaire Oven Valve Backorder WCI 316271301 $87.65

3

139023301 Frigidaire Oven Trim Backorder WCI 139023301 $32.60

3

WCI 5304491103 WCI 5304491103 Contact Us For Availability

3A

139014401 Frigidaire Oven Trim Backorder WCI 139014401 $19.47

4

316240600 Frigidaire Igniter Mounting Screw In Stock WCI 316240600 $7.23

4

5304513280 Frigidaire Oven White Outer Door G Backorder WCI 5304513280 $201.75

4

PANEL, DRAWER, WHITE, FRONT WCI 318298906 Contact Us For Availability

6

139006905 Frigidaire Oven Baffle Backorder WCI 139006905 $71.70

6

WCI 139011800 WCI 139011800 Contact Us For Availability

7

318372017 Frigidaire Insulation Backorder WCI 318372017 $10.39

7A

318372016 Frigidaire Insulation Backorder WCI 318372016 $11.32

8

5304503232 Frigidaire Oven Inner Door Glass In Stock WCI 5304503232 $73.95

8

808608802 Frigidaire Range Spark Ignition Fou In Stock WCI 808608802 $52.45

9

139000403 Frigidaire Oven Liner Backorder WCI 139000403 $99.00

9

318138801 Frigidaire Oven Pan Backorder WCI 318138801 $24.43

10

316082001 Frigidaire Oven Insert Backorder WCI 316082001 $31.01

10

316438200 Frigidaire Range Sealed Burner, 5K In Stock WCI 316438200 $36.24

10

808190201 Frigidaire Oven Screw Backorder WCI 808190201 $12.22

10A

316558300 Frigidaire Oven 9.5L Sealed Burner In Stock WCI 316558300 $33.50

10B

316438600 Frigidaire Range Sealed Burner, 14K Backorder WCI 316438600 $50.46

11

316540800 Frigidaire Igniter/Orifice Assembly In Stock WCI 316540800 $5.09

11

807545502 Frigidaire Oven Seal Backorder WCI 807545502 $86.33

11

BRACKET, DRAWER SUPPORT, (2) WCI 318298600 Contact Us For Availability

11A

316540700 Frigidaire Igniter/Orifice Assembly In Stock WCI 316540700 $7.12

11B

316543206 Frigidaire Igniter Orifice Assembly In Stock WCI 316543206 $90.30

13

CHANNEL, DRAWER, RH WCI 318018100 Contact Us For Availability

13A

CHANNEL, DRAWER, LH WCI 318018101 Contact Us For Availability

15

5304528790 Frigidaire Lamp Assembly Appliance In Stock WCI 5304528790 $13.57

316446401 Frigidaire Oven Glass In Stock WCI 316446401 $73.97

CONSOLE, ASSY., WHITE WCI 318299100 Contact Us For Availability

TUBE, REGULATOR VALVE WCI 318289500 Contact Us For Availability

MAINTOP ASSEMBLY, WHITE WCI 318569261 Contact Us For Availability

17

316031501 Frigidaire Range Valve In Stock WCI 316031501 $172.02

18

5304502520 Frigidaire Oven Burner Backorder WCI 5304502520 $99.88

19A

PANEL, CONTROL MTG. WCI 318224402 Contact Us For Availability

20

139005100 Frigidaire Range Baffle Backorder WCI 139005100 $60.50

20

CLOCK/TIMER, ELECTRONIC, ES300 WCI 316557141 Contact Us For Availability

20A

316419137 Frigidaire Oven Overlay In Stock WCI 316419137 $11.73

20A

318560470 Frigidaire Range Grate Backorder WCI 318560470 $162.33

21

Backorder WCI 154079601 $0.28

22

5304508441 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508441 $20.91

22A

5304508442 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508442 $20.14

22C

5304508443 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508443 $27.48

23

139007101 Frigidaire Burner Backorder WCI 139007101 $73.51

24

ELBOW, MIXER WCI 316409703 Contact Us For Availability

24A

139075001 Frigidaire Range Cover Backorder WCI 139075001 $36.15

25

BAFFLE, BROIL BURNER WCI 316401301 Contact Us For Availability

26

139013700 Frigidaire Igniter In Stock WCI 139013700 $105.54

26A

139013701 Frigidaire Igniter Backorder WCI 139013701 $105.09

29

139023400 Frigidaire Oven Spacer Backorder WCI 139023400 $12.22

29

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $7.69

35

RETAINER, CONTROL PANEL, BLACK WCI 318233720 Contact Us For Availability

37

5304504897 Frigidaire Oven Temperature Sensor In Stock WCI 5304504897 $27.16

39

316545301 Frigidaire Oven White Drawer Handle In Stock WCI 316545301 $81.12

39

5304534377 Frigidaire Cord Backorder WCI 5304534377 $16.03

40

318242702 Frigidaire Oven Bracket Assembly Backorder WCI 318242702 $11.78

41

318370602 Frigidaire Oven Bracket Backorder WCI 318370602 $8.15

42

318382302 Frigidaire Bracket Backorder WCI 318382302 $30.36

43

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $6.32

44

316527504 Frigidaire Oven Orifice Assembly In Stock WCI 316527504 $14.48

44A

316527500 Frigidaire Oven Burner Orifice Asse In Stock WCI 316527500 $13.65

44B

316527513 Frigidaire Oven Orifice Backorder WCI 316527513 $13.16

50

PANEL, SERVICE, FAN WCI 318578803 Contact Us For Availability

52

318291126 Frigidaire Cover Backorder WCI 318291126 $55.36

56A

5303324184 Frigidaire Wall Oven Range Screw Backorder WCI 5303324184 $9.06

57

316283600 Frigidaire Range Cover In Stock WCI 316283600 $7.25

59

139078002 Frigidaire Oven Duct Backorder WCI 139078002 $49.74

64

318165800 Frigidaire Oven Door Glass Spacer w Backorder WCI 318165800 $11.32

70

139000601 Frigidaire Oven Shield Backorder WCI 139000601 $42.55

72

316215600 Frigidaire Oven Screw In Stock WCI 316215600 $9.04

86

318561100 Frigidaire Receptacle Backorder WCI 318561100 $12.67

89

5304528836 Frigidaire Motor Backorder WCI 5304528836 $47.31

90

PANEL, FILLER, WHITE, RH WCI 318296902 Contact Us For Availability

90A

PANEL, FILLER, WHITE, LH WCI 318296903 Contact Us For Availability

99A

318223900 Frigidaire Oven Gasket Backorder WCI 318223900 $47.53

108

318575612 Frigidaire Oven Cooling Fan Motor In Stock WCI 318575612 $136.65

119

807144901 Frigidaire Thermostat Backorder WCI 807144901 $34.87

131

139078102 Frigidaire Oven Duct Backorder WCI 139078102 $40.78

166

318298410 Frigidaire Oven Bracket Backorder WCI 318298410 $44.82

170

5304486410 Frigidaire Range Kit Backorder WCI 5304486410 $91.14

200

FRAME & WHEEL ASSEMBLY, BLACK WCI 318335600 Contact Us For Availability

201

318298233 Frigidaire Oven Frame Backorder WCI 318298233 $28.99

316021105 Frigidaire Oven Screw Backorder WCI 316021105 $7.23

316021109 Frigidaire Oven Screw In Stock WCI 316021109 $9.06

316418901 Frigidaire Oven Screw Backorder WCI 316418901 $9.06

318199776 Frigidaire Electrical Harness Backorder WCI 318199776 $32.60

318565404 Frigidaire Conversion Kit Backorder WCI 318565404 $60.50

5304497401 Frigidaire Range Harness Backorder WCI 5304497401 $99.86

808041201 Frigidaire Range Harness In Stock WCI 808041201 $30.80

316001017 Frigidaire Screw Backorder WCI 316001017 $1.83

316418900 Frigidaire Oven Screw Backorder WCI 316418900 $9.06

318531701 Frigidaire Spacer Backorder WCI 318531701 $7.69

318946500 Frigidaire Oven Light Bulb Range/Wa Backorder WCI 318946500 $33.97

NIB

5303289910 Frigidaire Oven Screw Backorder WCI 5303289910 $3.61
