Model Electrolux FCRG3052BBA RANGE/OVEN, GAS, FREESTANDING, 30 INCH – Common Parts &amp; Diagrams

1

5304528114 Frigidaire Manifold Backorder WCI 5304528114 $33.52

1

5304536629 Frigidaire Bracket Assembly Backorder WCI 5304536629 $24.04

2

5304506549 Frigidaire Range Valve In Stock WCI 5304506549 $41.69

2

5304526448 Frigidaire Drawer Assembly Backorder WCI 5304526448 $89.05

2

BRACKET Backorder WCI 5304533425 $36.52

2A

5304506548 Frigidaire Range Valve In Stock WCI 5304506548 $48.87

2C

5304506547 Frigidaire Range Valve In Stock WCI 5304506547 $40.78

2D

5304507282 Frigidaire Range Gas Valve In Stock WCI 5304507282 $32.15

3

5304526306 Frigidaire Glide Backorder WCI 5304526306 $12.72

3

5304526493 Frigidaire Bracket Backorder WCI 5304526493 $9.65

3

5304533894 Frigidaire Harness Backorder WCI 5304533894 $17.57

3A

5304526307 Frigidaire Glide In Stock WCI 5304526307 $12.72

4

5304526636 Frigidaire Door Assembly Backorder WCI 5304526636 $97.51

4

5304528328 Frigidaire Cover Assembly Backorder WCI 5304528328 $5.01

5

316272900 Frigidaire Oven Leg Levelling Plast In Stock WCI 316272900 $8.60

6

5304526283 Frigidaire Shield Backorder WCI 5304526283 $68.77

6

5304531722 Frigidaire Rack In Stock WCI 5304531722 $35.52

7

5304526657 Frigidaire Insulation Backorder WCI 5304526657 $4.94

7

5304534661 Frigidaire Box Appliance Backorder WCI 5304534661 $33.49

8

5304533923 Frigidaire Cover Assembly Backorder WCI 5304533923 $6.69

8

808608804 Frigidaire Oven Gas Range Spark Mod In Stock WCI 808608804 $54.56

8

GLASS, DOOR, INNER, HBII WCI 5304526388 Contact Us For Availability

9

5304526533 Frigidaire Screw Backorder WCI 5304526533 $1.37

9

5304528546 Frigidaire Receptacle Backorder WCI 5304528546 $20.58

9

5304533925 Frigidaire Liner Backorder WCI 5304533925 $51.39

9

TUBE, CONNECTION, MANIFOLD TO, REGULATOR TUBE WCI 5304535849 Contact Us For Availability

10

316433305 Frigidaire Screw Backorder WCI 316433305 $1.35

10

5304526334 Frigidaire Panel Backorder WCI 5304526334 $81.82

10

CROWN Backorder WCI 5304537947 $9.67

10A

5304537945 Frigidaire Crown,Burner,Medium Backorder WCI 5304537945 $6.73

10C

CROWN Backorder WCI 5304537944 $5.14

10D

5304537946 Frigidaire Crown Burner Extra Larg Backorder WCI 5304537946 $12.70

11

5304526243 Frigidaire Seal Backorder WCI 5304526243 $30.97

11

CLIP Backorder WCI 5304526287 $0.72

11

5304533857 Frigidaire Igniter/Orifice Backorder WCI 5304533857 $9.54

11A

5304533853 Frigidaire Igniter/Orifice Backorder WCI 5304533853 $8.69

11C

5304533582 Frigidaire Igniter/Orifice Assembl Backorder WCI 5304533582 $20.97

11D

5304533611 Frigidaire Igniter/Orifice Assembl Backorder WCI 5304533611 $31.90

12

TUBE Backorder WCI 5304528307 $4.86

12A

TUBE Backorder WCI 5304528309 $5.23

12B

TUBE, BURNER, CENTER WCI 5304528315 Contact Us For Availability

12C

TUBE, BURNER, RH REAR WCI 5304528308 Contact Us For Availability

12D

TUBE, BURNER, RH FRONT WCI 5304528306 Contact Us For Availability

13

SCREW Backorder WCI 8583543244054 $0.46

13

SHIELD, REAR WIRE WCI 5304533842 Contact Us For Availability

14

316091711 Frigidaire Regulator Assembly In Stock WCI 316091711 $61.84

14

SHIELD, INSULATION, LOWER WCI 5304533860 Contact Us For Availability

15

5304533411 Frigidaire Lamp Assembly Backorder WCI 5304533411 $21.78

15

5304533619 Frigidaire Range Cap Backorder WCI 5304533619 $24.11

15A

5304533596 Frigidaire Range Cap Backorder WCI 5304533596 $19.49

15C

5304533595 Frigidaire Range Cap Assembly Backorder WCI 5304533595 $17.25

15D

5304533597 Frigidaire Range Cap Assembly Backorder WCI 5304533597 $27.68

16

316610078 Frigidaire Main Top Backorder WCI 316610078 $116.22

17

5304533805 Frigidaire Valve In Stock WCI 5304533805 $130.17

17

INSULATION Backorder WCI 5304538074 $36.63

18

5304533840 Frigidaire Burner Assembly Backorder WCI 5304533840 $11.32

18

INSULATION, OVEN BACK WCI 5304533848 Contact Us For Availability

19

5304534663 Frigidaire Igniter In Stock WCI 5304534663 $61.87

20

5304534662 Frigidaire Baffle Backorder WCI 5304534662 $28.71

20

5304535359 Frigidaire Grate In Stock WCI 5304535359 $58.98

20A

5304534694 Frigidaire Grate Assembly Backorder WCI 5304534694 $73.23

21

SHIELD Backorder WCI 5304533911 $6.82

22

5304533415 Frigidaire Base Rail Backorder WCI 5304533415 $81.36

22

5304535280 Frigidaire Bracket Assembly Backorder WCI 5304535280 $2.35

23

BRACKET, TUBING WCI 5304534683 Contact Us For Availability

24

BRACKET Backorder WCI 5304534687 $12.09

24

5304535291 Frigidaire Bottom Assembly Backorder WCI 5304535291 $58.86

25

5304534667 Frigidaire Tube Backorder WCI 5304534667 $7.16

26

5304534673 Frigidaire Tube Backorder WCI 5304534673 $13.44

27

FLUE Backorder WCI 5304533916 $13.48

27

5304534665 Frigidaire Tube Assembly In Stock WCI 5304534665 $37.63

28

SCREW, TUBE BRACKET WCI 5304534684 Contact Us For Availability

36

5304507386 Frigidaire Range Control Knob In Stock WCI 5304507386 $39.37

37

5304526310 Frigidaire Probe In Stock WCI 5304526310 $24.91

39

HANDLE Backorder WCI 5304534656 $32.49

39

5304534691 Frigidaire Cord Backorder WCI 5304534691 $39.90

43

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $6.32

44

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $7.69

56

5304526234 Frigidaire Screw Backorder WCI 5304526234 $1.83

59

FLUE Backorder WCI 5304534664 $55.80

62

5303935271 Frigidaire Oven Terminal Block In Stock WCI 5303935271 $37.82

64

5304528550 Frigidaire Shield Backorder WCI 5304528550 $5.68

66

5304533847 Frigidaire Element Assembly Backorder WCI 5304533847 $31.91

72

316215601 Frigidaire Screw Backorder WCI 316215601 $3.49

86

5304534789 Frigidaire Hinge Backorder WCI 5304534789 $23.76

86A

5304534790 Frigidaire Hinge Assembly Backorder WCI 5304534790 $17.97

87

BRACKET, POWER CORD WCI 5304533922 Contact Us For Availability

88

PIN Backorder WCI 316099501 $2.77

170

316112010 Frigidaire Anti-Tip Kit Backorder WCI 316112010 $13.76

316089500 Frigidaire Oven Screw In Stock WCI 316089500 $8.60

316483102 Frigidaire Range Label Backorder WCI 316483102 $2.26

349479702 Frigidaire Screw Backorder WCI 349479702 $1.37

387856311 Frigidaire Screw Backorder WCI 387856311 $1.83

5304526532 Frigidaire Screw Backorder WCI 5304526532 $1.83

SCREW Backorder WCI 5304533471 $2.77

HARNESS Backorder WCI 5304534808 $51.56

STANDOFF Backorder WCI 5304536410 $1.31

GRLP5 Frigidaire Range Natural Gas to LP Prop In Stock WCI GRLP5 $20.65

SCREW, M4, 2 X 10, BLACK, W/WASHER WCI 387872717 Contact Us For Availability

SCREW, T20 WASHER, 4.5 X 14.5 WCI 5304533472 Contact Us For Availability

SCREW, SELF DRILL, M3.5 X WCI 5304534695 Contact Us For Availability

316001017 Frigidaire Screw Backorder WCI 316001017 $1.83

316205500 Frigidaire Oven Nut In Stock WCI 316205500 $7.25

SCREW Backorder WCI 349098702 $1.37

SCREW Backorder WCI 5304528293 $1.83

SCRW Backorder WCI 5304533495 $3.49
