Model Electrolux FCRE3052BSA RANGE/OVEN, ELECTRIC, FREESTANDING, 30 INCH – Common Parts &amp; Diagrams

1

5304536629 Frigidaire Bracket Assembly Backorder WCI 5304536629 $24.04

2

5304526448 Frigidaire Drawer Assembly Backorder WCI 5304526448 $89.05

2

BRACKET, COMPONENTS, LOWER WCI 5304533425 Contact Us For Availability

3

5304526306 Frigidaire Glide Backorder WCI 5304526306 $12.72

3

5304526493 Frigidaire Bracket Backorder WCI 5304526493 $9.65

3A

5304526307 Frigidaire Glide Backorder WCI 5304526307 $12.72

4

387683300 Frigidaire Bracket Backorder WCI 387683300 $8.54

4

5304528328 Frigidaire Cover Assembly Backorder WCI 5304528328 $5.01

4

5304534354 Frigidaire Door Assembly Backorder WCI 5304534354 $100.87

5

316272900 Frigidaire Oven Leg Levelling Plast In Stock WCI 316272900 $8.60

5

5304526627 Frigidaire Spring Backorder WCI 5304526627 $4.86

6

5304526283 Frigidaire Shield Backorder WCI 5304526283 $68.77

6

5304528474 Frigidaire Clip Backorder WCI 5304528474 $4.53

6

5304531722 Frigidaire Rack In Stock WCI 5304531722 $35.52

7

5304526657 Frigidaire Insulation Backorder WCI 5304526657 $4.94

7

BURNER BOX, SMOOTHTOP WCI 5304533428 Contact Us For Availability

8

5304528549 Frigidaire Cover Assembly In Stock WCI 5304528549 $21.89

8

5304538115 Frigidaire Indicator-Light 250 Backorder WCI 5304538115 $8.01

8

GLASS, DOOR, INNER, HBII WCI 5304526388 Contact Us For Availability

9

5304526533 Frigidaire Screw Backorder WCI 5304526533 $1.37

9

5304528546 Frigidaire Receptacle Backorder WCI 5304528546 $20.58

9

5304533925 Frigidaire Liner Backorder WCI 5304533925 $51.39

10

316433305 Frigidaire Screw Backorder WCI 316433305 $1.35

10

5304526334 Frigidaire Panel Backorder WCI 5304526334 $81.82

10

5304533456 Frigidaire Screw Assembly Backorder WCI 5304533456 $2.22

11

5304526243 Frigidaire Seal Backorder WCI 5304526243 $30.97

11

CLIP, ALIGNMENT, COOKTOP WCI 5304526287 Contact Us For Availability

12

5304534653 Frigidaire Clip Assembly Backorder WCI 5304534653 $5.51

13

SHIELD, REAR WIRE WCI 5304533842 Contact Us For Availability

13A

5304522964 Frigidaire Switch Backorder WCI 5304522964 $35.33

14

SHIELD, INSULATION, LOWER WCI 5304533432 Contact Us For Availability

15

318178110 Frigidaire Oven Range 6" Surface El In Stock WCI 318178110 $79.97

15

5304533411 Frigidaire Lamp Assembly Backorder WCI 5304533411 $21.78

15B

5304533520 Frigidaire Element In Stock WCI 5304533520 $55.76

15C

140273621015 Frigidaire Warmer Element, Radia Backorder WCI 140273621015 $22.85

16

5304534795 Frigidaire Top Backorder WCI 5304534795 $156.88

17

INSULATION, OVEN WRAPPER WCI 5304534791 Contact Us For Availability

18

INSULATION, OVEN BACK WCI 5304528193 Contact Us For Availability

22

5304533415 Frigidaire Base Rail Backorder WCI 5304533415 $81.36

36B

5304521976 Frigidaire Knob Control Backorder WCI 5304521976 $19.03

37

5304526310 Frigidaire Probe In Stock WCI 5304526310 $24.91

39

5304535236 Frigidaire Door Handle Stainless S In Stock WCI 5304535236 $35.61

44

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $7.69

54

5304522966 Frigidaire Switch In Stock WCI 5304522966 $46.16

54A

5304522918 Frigidaire Range Surface Element S In Stock WCI 5304522918 $44.35

56

5304526234 Frigidaire Screw Backorder WCI 5304526234 $1.83

58

TUBE Backorder WCI 5304534826 $13.46

59

VENT TUBE, ASSEMBLY, UPPER WCI 5304534827 Contact Us For Availability

62

5303935271 Frigidaire Oven Terminal Block In Stock WCI 5303935271 $37.82

63

5304536404 Frigidaire Strap Backorder WCI 5304536404 $1.29

64

5304528550 Frigidaire Shield Backorder WCI 5304528550 $5.68

66

5304536311 Frigidaire Element Backorder WCI 5304536311 $36.63

67

ELEMENT, BAKE, 2600W WCI 5304536337 Contact Us For Availability

69

5304526494 Frigidaire Screw Backorder WCI 5304526494 $1.37

86

5304534789 Frigidaire Hinge Backorder WCI 5304534789 $23.76

86A

5304534790 Frigidaire Hinge Assembly Backorder WCI 5304534790 $17.97

87

5304526449 Frigidaire Bracket Backorder WCI 5304526449 $4.94

88

PIN, GUIDE WCI 316099501 Contact Us For Availability

170

316112010 Frigidaire Anti-Tip Kit Backorder WCI 316112010 $13.76

316483102 Frigidaire Range Label Backorder WCI 316483102 $2.26

349479702 Frigidaire Screw Backorder WCI 349479702 $1.37

387856311 Frigidaire Screw Backorder WCI 387856311 $1.83

5304534813 Frigidaire Harness Backorder WCI 5304534813 $55.25

SCREW, T20, 4.2 X 13MM, BLACK, ZINC PLATED WCI 5304533830 Contact Us For Availability

SCREW, 4.2 X 19.1MM, BLACK, ZINC PLATED WCI 5304533932 Contact Us For Availability

HARNESS, WIRING, ENERGY REGULTRS WCI 5304534814 Contact Us For Availability

STANDOFF, HARNESS, PLASTIC WCI 5304533469 Contact Us For Availability

SCREW, T20, 4.4 X 13 WCI 5304533471 Contact Us For Availability

SCREW, SELF DRILL, M3.5 X 9.5 WCI 5304534695 Contact Us For Availability

HARNESS, WIRING, MAIN WCI 5304534807 Contact Us For Availability

HARNESS, WIRING, COOKTOP POWER WCI 5304533872 Contact Us For Availability

316001017 Frigidaire Screw Backorder WCI 316001017 $1.83

5304526532 Frigidaire Screw Backorder WCI 5304526532 $1.83

SCREW, M4, 2 X 10, BLAC WCI 387872717 Contact Us For Availability

WCI 5304533472 WCI 5304533472 Contact Us For Availability

WCI 5304533495 WCI 5304533495 Contact Us For Availability

NIB

316205500 Frigidaire Oven Nut In Stock WCI 316205500 $7.25

NIC

WCI 5304528293 WCI 5304528293 Contact Us For Availability
