Model Electrolux FCFG3083ASA RANGE/OVEN, GAS, FREESTANDING, FRONT-CONTROL, 30 INCH – Common Parts &amp; Diagrams

1

5304536629 Frigidaire Bracket Assembly Backorder WCI 5304536629 $24.04

2

5304506549 Frigidaire Range Valve In Stock WCI 5304506549 $41.69

2

5304526448 Frigidaire Drawer Assembly Backorder WCI 5304526448 $89.05

2

BRACKET, COMPONENTS, LOWER WCI 5304533425 Contact Us For Availability

2A

5304506548 Frigidaire Range Valve In Stock WCI 5304506548 $48.87

2B

5304506551 Frigidaire Range Valve Backorder WCI 5304506551 $36.68

2C

5304506547 Frigidaire Range Valve In Stock WCI 5304506547 $40.78

2D

5304507282 Frigidaire Range Gas Valve In Stock WCI 5304507282 $32.15

3

5304526306 Frigidaire Glide Backorder WCI 5304526306 $12.72

3

5304526493 Frigidaire Bracket Backorder WCI 5304526493 $9.65

3A

5304526307 Frigidaire Glide Backorder WCI 5304526307 $12.72

4

5304528328 Frigidaire Cover Assembly Backorder WCI 5304528328 $5.01

4

5304528492 Frigidaire Door Assembly In Stock WCI 5304528492 $136.86

5

316272900 Frigidaire Oven Leg Levelling Plast In Stock WCI 316272900 $8.60

6

Backorder WCI 5304528103 $56.79

6

5304531722 Frigidaire Rack In Stock WCI 5304531722 $35.52

7

5304528501 Frigidaire Insulation Assembly Backorder WCI 5304528501 $9.02

7

5304534661 Frigidaire Box Appliance Backorder WCI 5304534661 $33.49

7A

5304528500 Frigidaire Insulation Backorder WCI 5304528500 $8.69

8

5304528194 Frigidaire Glass Backorder WCI 5304528194 $61.27

8

5304533923 Frigidaire Cover Assembly Backorder WCI 5304533923 $6.69

8

808608804 Frigidaire Oven Gas Range Spark Mod In Stock WCI 808608804 $54.56

9

5304526533 Frigidaire Screw Backorder WCI 5304526533 $1.37

9

5304528546 Frigidaire Receptacle Backorder WCI 5304528546 $20.58

9

5304533466 Frigidaire Liner Backorder WCI 5304533466 $69.34

10

316433305 Frigidaire Screw Backorder WCI 316433305 $1.35

10

5304526334 Frigidaire Panel Backorder WCI 5304526334 $81.82

10A

5304537945 Frigidaire Crown,Burner,Medium Backorder WCI 5304537945 $6.73

10B

5304537948 Frigidaire Burner Crown 10K Oval Backorder WCI 5304537948 $20.39

10C

5304533592 Frigidaire Range Crown In Stock WCI 5304533592 $5.14

10D

5304537946 Frigidaire Crown Burner Extra Larg Backorder WCI 5304537946 $12.70

11

5304526243 Frigidaire Seal Backorder WCI 5304526243 $30.97

11

5304533857 Frigidaire Igniter/Orifice Backorder WCI 5304533857 $9.54

11

5304534686 Frigidaire Trim Backorder WCI 5304534686 $54.67

11A

5304533853 Frigidaire Igniter/Orifice Backorder WCI 5304533853 $8.69

11C

5304533582 Frigidaire Igniter/Orifice Assembl Backorder WCI 5304533582 $20.97

11D

5304533611 Frigidaire Igniter/Orifice Assembl Backorder WCI 5304533611 $31.90

12

5304534678 Frigidaire Tube Backorder WCI 5304534678 $4.81

12

808136601 Frigidaire Oven Switch In Stock WCI 808136601 $28.14

12

SCREW, M4.2X7X1.06, BLACK WCI 5304533410 Contact Us For Availability

12A

5304534680 Frigidaire Tube In Stock WCI 5304534680 $5.55

12B

5304534681 Frigidaire Tube Assembly Backorder WCI 5304534681 $5.10

12C

5304534679 Frigidaire Tube Backorder WCI 5304534679 $5.57

12D

5304534677 Frigidaire Tube Backorder WCI 5304534677 $5.25

13

BOLT Backorder WCI 354324402 $6.32

13

5304536325 Frigidaire Shield Assembly Backorder WCI 5304536325 $58.18

14

316091711 Frigidaire Regulator Assembly In Stock WCI 316091711 $61.84

14

SHIELD, INSULATION, LOWER WCI 5304533860 Contact Us For Availability

15

5304533411 Frigidaire Lamp Assembly Backorder WCI 5304533411 $21.78

15

5304533619 Frigidaire Range Cap Backorder WCI 5304533619 $24.11

15A

5304533596 Frigidaire Range Cap Backorder WCI 5304533596 $19.49

15B

5304534690 Frigidaire Cap Backorder WCI 5304534690 $22.45

15C

5304533595 Frigidaire Range Cap Assembly Backorder WCI 5304533595 $17.25

15D

5304533597 Frigidaire Range Cap Assembly Backorder WCI 5304533597 $27.68

16

5304534675 Frigidaire Maintop Backorder WCI 5304534675 $97.92

16

SHIELD, DRAWER STORAGE, FULL WCI 5304533453 Contact Us For Availability

17

Backorder WCI 5304528185 $36.63

17

5304533805 Frigidaire Valve Backorder WCI 5304533805 $130.17

18

5304533840 Frigidaire Burner Assembly Backorder WCI 5304533840 $11.32

18

INSULATION, OVEN BACK WCI 5304528187 Contact Us For Availability

19

5304528260 Frigidaire Motor Backorder WCI 5304528260 $30.27

19

5304534663 Frigidaire Igniter In Stock WCI 5304534663 $61.87

20

5304528257 Frigidaire Latch Assembly Backorder WCI 5304528257 $11.32

20

5304534662 Frigidaire Baffle Backorder WCI 5304534662 $28.71

20

5304534693 Frigidaire Grate Assembly Backorder WCI 5304534693 $60.61

20A

5304534694 Frigidaire Grate Assembly Backorder WCI 5304534694 $73.23

21

5304528104 Frigidaire Bracket Assembly Backorder WCI 5304528104 $7.62

21

SHIELD, BAKE BRACKET WCI 5304533911 Contact Us For Availability

21

ROD, DOOR LATCH WCI 5304528258 Contact Us For Availability

22

5304528105 Frigidaire Bracket Assembly Backorder WCI 5304528105 $6.55

22

5304533415 Frigidaire Base Rail Backorder WCI 5304533415 $81.36

22

5304535280 Frigidaire Bracket Assembly Backorder WCI 5304535280 $2.35

23

5304533976 Frigidaire Guard Assembly Backorder WCI 5304533976 $31.38

23

BRACKET, TUBING WCI 5304534683 Contact Us For Availability

24

5304535291 Frigidaire Bottom Assembly Backorder WCI 5304535291 $58.86

24

BRACKET, HARNESS WCI 5304534687 Contact Us For Availability

25

5304534667 Frigidaire Tube Backorder WCI 5304534667 $7.16

25

SHIELD, HEAT, REAR WCI 5304534668 Contact Us For Availability

26

5304534673 Frigidaire Tube Backorder WCI 5304534673 $13.44

26

SHIELD, HEAT, FRONT WCI 5304534669 Contact Us For Availability

27

5304534665 Frigidaire Tube Assembly In Stock WCI 5304534665 $37.63

27

COVER, DUCT WCI 5304534672 Contact Us For Availability

28

WCI 5304534684 WCI 5304534684 Contact Us For Availability

28

DIVERTER, EXHAUST WCI 5304534674 Contact Us For Availability

29

SHIELD, DIVERTER WCI 5304534685 Contact Us For Availability

35

5304508440 Frigidaire Bushing Backorder WCI 5304508440 $6.80

36

5304509064 Frigidaire Range Knob In Stock WCI 5304509064 $39.44

37

5304533448 Frigidaire Probe In Stock WCI 5304533448 $29.33

39

5304534691 Frigidaire Cord Backorder WCI 5304534691 $39.90

39

5304535236 Frigidaire Door Handle Stainless S In Stock WCI 5304535236 $35.61

43

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $6.32

44

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $7.69

56

5304526234 Frigidaire Screw Backorder WCI 5304526234 $1.83

56A

5304526532 Frigidaire Screw Backorder WCI 5304526532 $1.83

59

FLUE, ASSEMBLY WCI 5304534664 Contact Us For Availability

62

5303935271 Frigidaire Oven Terminal Block In Stock WCI 5303935271 $37.82

64

5304528550 Frigidaire Shield Backorder WCI 5304528550 $5.68

66

5304533847 Frigidaire Element Assembly Backorder WCI 5304533847 $31.91

72

316215601 Frigidaire Screw Backorder WCI 316215601 $3.49

86

5304528099 Frigidaire Hinge Backorder WCI 5304528099 $37.34

87

BRACKET, POWER CORD WCI 5304533922 Contact Us For Availability

88

PIN, GUIDE WCI 316099501 Contact Us For Availability

107

5304526365 Frigidaire Cover Backorder WCI 5304526365 $58.32

108

5304528167 Frigidaire Blower Assembly In Stock WCI 5304528167 $86.51

109

5304525455 Frigidaire Blade In Stock WCI 5304525455 $8.60

110

DUCT ASSEMBLY, EXHAUST, COOLING WCI 5304528419 Contact Us For Availability

111

561231207 Frigidaire Nut Backorder WCI 561231207 $10.95

125

5304528165 Frigidaire Motor Backorder WCI 5304528165 $45.19

130

WCI 5304534670 WCI 5304534670 Contact Us For Availability

170

316112010 Frigidaire Anti-Tip Kit Backorder WCI 316112010 $13.76

316483102 Frigidaire Range Label Backorder WCI 316483102 $2.26

387856311 Frigidaire Screw Backorder WCI 387856311 $1.83

5304534088 Frigidaire Harness Assembly Backorder WCI 5304534088 $73.60

GRLP5 Frigidaire Range Natural Gas to LP Prop In Stock WCI GRLP5 $19.67

WCI 387872717 WCI 387872717 Contact Us For Availability

WCI 5304533469 WCI 5304533469 Contact Us For Availability

WCI 5304533471 WCI 5304533471 Contact Us For Availability

WCI 5304533472 WCI 5304533472 Contact Us For Availability

WCI 5304534090 WCI 5304534090 Contact Us For Availability

WCI 5304534695 WCI 5304534695 Contact Us For Availability

316001017 Frigidaire Screw Backorder WCI 316001017 $1.83

WCI 349098702 WCI 349098702 Contact Us For Availability

WCI 5304528293 WCI 5304528293 Contact Us For Availability

WCI 5304533495 WCI 5304533495 Contact Us For Availability

NIB

316205500 Frigidaire Oven Nut In Stock WCI 316205500 $7.25
