Model Electrolux EWMED70JSS4 LAUNDRY, RESIDENTIAL, ELECTRIC DRYER – Common Parts &amp; Diagrams

1

5304535760 Frigidaire Heater In Stock WCI 5304535760 $71.24

3

KNOB, RETRACTING, COMPLETE ASMY WCI 134766500 Contact Us For Availability

4

134792100 Frigidaire Bracket Assembly Backorder WCI 134792100 $18.56

4

134871900 Frigidaire Pipe Backorder WCI 134871900 $53.33

4

LOCK, BLOWER HOUSING WCI 134707900 Contact Us For Availability

5

134767800 Frigidaire Pipe Backorder WCI 134767800 $26.72

6

DUCT, AIR WCI 137611800 Contact Us For Availability

7

137046800 Frigidaire Bracket Assembly Backorder WCI 137046800 $11.78

7

5303161296 Frigidaire Washer Inlet Hose (1 Pi Backorder WCI 5303161296 $1,678.32

7

TUBE, EXHAUST, REAR WCI 134693900 Contact Us For Availability

7A

137046700 Frigidaire Bracket Backorder WCI 137046700 $15.38

8

134711401 Frigidaire Dryer Thermal Fuse In Stock WCI 134711401 $14.68

8

134767600 Frigidaire Lens Backorder WCI 134767600 $34.43

8

137032600 Frigidaire Washer Dryer Thermal Lim In Stock WCI 137032600 $12.00

8

137560800 Frigidaire Filter Housing Cover Backorder WCI 137560800 $28.96

8

137578600 Frigidaire Cover Assembly Backorder WCI 137578600 $7.67

8A

134935200 Frigidaire Screw Backorder WCI 134935200 $8.58

9

134768400 Frigidaire Pipe Backorder WCI 134768400 $9.04

10

134690800 Frigidaire Dryer Blower Housing Ass In Stock WCI 134690800 $140.01

10

137007900 Frigidaire Cap Backorder WCI 137007900 $37.18

10

ASSEMBLY, INDICATOR, COMPLETE WCI 134933900 Contact Us For Availability

11

137043100 Frigidaire Button Backorder WCI 137043100 $23.54

12

134696901 Frigidaire Frame Backorder WCI 134696901 $54.23

12

BUTTON, DOWN WCI 137010900 Contact Us For Availability

13

BUTTON, SET WCI 137021200 Contact Us For Availability

14

BUTTON, START/PAUSE WCI 137009900 Contact Us For Availability

134704600 Frigidaire Hinge Backorder WCI 134704600 $143.66

134711300 Frigidaire Dryer Thermistor In Stock WCI 134711300 $34.43

137031800 Frigidaire Cushion Assembly Backorder WCI 137031800 $5.42

BUTTON, OFF WCI 137008100 Contact Us For Availability

16

134788000 Frigidaire Screw Backorder WCI 134788000 $9.04

16

5304508449 Frigidaire Washer Dryer Air Duct In Stock WCI 5304508449 $67.23

16

BOARD, CONTROL, UI, W/HOUSING WCI 809160406 Contact Us For Availability

17

134792900 Frigidaire Protector Backorder WCI 134792900 $8.60

18

131168200 Frigidaire Dryer Screw In Stock WCI 131168200 $9.04

19

134402900 Frigidaire Screw Backorder WCI 134402900 $19.01

19

134711200 Frigidaire Dryer Thermistor In Stock WCI 134711200 $32.60

19

134790400 Frigidaire Screw Backorder WCI 134790400 $9.06

20

131017900 Frigidaire Screw Backorder WCI 131017900 $9.06

20

137553000 Frigidaire Dryer Gasket-Door In Stock WCI 137553000 $94.95

20

5304499489 Frigidaire Washer Felt Seal In Stock WCI 5304499489 $27.96

21

137610710 Frigidaire Drum Assembly Backorder WCI 137610710 $308.45

22

HARNESS, USER INTERFACE WCI 134790700 Contact Us For Availability

23

IDLER ARM ASSY, REVERSING, WITH PULLEY WCI 134784400 No Longer Available

23

134786100 Frigidaire Moisture Sensor In Stock WCI 134786100 $55.12

24

PANEL, WORK TOP, SILVER WCI 134638525 Contact Us For Availability

25

134719300 Frigidaire Dryer 5-Rib Belt In Stock WCI 134719300 $42.57

25

137567001 Frigidaire Bracket Assembly Backorder WCI 137567001 $23.09

25

LATCH, PUSH-PUSH DOOR WCI 137538802 Contact Us For Availability

26

134813660 Frigidaire Switch Backorder WCI 134813660 $14.03

26

BOARD, CNTL, MAIN, W/HOUSING WCI 809160314 Contact Us For Availability

27

134242400 Frigidaire Washer Clamp Assembly In Stock WCI 134242400 $11.76

27

137623900 Frigidaire Lint Filter In Stock WCI 137623900 $117.18

27A

134790600 Frigidaire Screw Backorder WCI 134790600 $9.50

27A

BRACKET, CONTROL PANEL, LEFT HAND, MOUNTING WCI 134710900 Contact Us For Availability

27B

134690203 Frigidaire Base Assembly Backorder WCI 134690203 $163.61

27B

BRACKET, CONTROL PANEL, RIGHT HAND, MOUNTING WCI 134711000 Contact Us For Availability

27L

PANEL, LEFT SIDE, SILVER WCI 134712625 Contact Us For Availability

27R

PANEL, RIGHT SIDE, SILVER WCI 134712725 Contact Us For Availability

28

137034500 Frigidaire Clip In Stock WCI 137034500 $27.62

28

137116000 Frigidaire Dryer Motor Assembly In Stock WCI 137116000 $146.45

28

137560425 Frigidaire Panel Backorder WCI 137560425 $138.11

29

131205100 Frigidaire Screw In Stock WCI 131205100 $9.06

30

137610900 Frigidaire Vane Assembly Backorder WCI 137610900 $60.50

30A

137611100 Frigidaire Vane Backorder WCI 137611100 $73.73

35

BRACKET, TOP PANEL MTG., REAR WCI 134713100 Contact Us For Availability

40

5304523155 Frigidaire Dryer Kit In Stock WCI 5304523155 $60.74

40A

134716700 Frigidaire Washer Backorder WCI 134716700 $1.35

41

134716800 Frigidaire Nut Backorder WCI 134716800 $1.87

42

BULKHEAD, PANEL, FRONT WCI 137556105 Contact Us For Availability

45

137556623 Frigidaire Bulkhead Backorder WCI 137556623 $214.12

46

134707400 Frigidaire Bracket In Stock WCI 134707400 $50.64

46

GASKET, DOOR GLASS WCI 134934900 Contact Us For Availability

47

5304505715 Frigidaire Trim Ring In Stock WCI 5304505715 $214.17

47

SEAL, EXHAUST TUBE WCI 131633300 Contact Us For Availability

49

134651200 Frigidaire Retainer Clip Backorder WCI 134651200 $97.26

51

137459300 Frigidaire Striker Backorder WCI 137459300 $30.80

52

131202300 Frigidaire Screw Backorder WCI 131202300 $8.60

53

HOSE, WATER INLET, 12# WCI 137471800 No Longer Available

54

5304503984 Frigidaire Kit Assembly In Stock WCI 5304503984 $20.30

56

GLASS, DOOR WCI 137576000 Contact Us For Availability

58

137604200 Frigidaire Appliance Panel Backorder WCI 137604200 $61.40

59

134931500 Frigidaire Cover Assembly Backorder WCI 134931500 $16.31

60

134430300 Frigidaire Screw Backorder WCI 134430300 $9.50

61

137544800 Frigidaire Washer Valve In Stock WCI 137544800 $33.71

65

137017200 Frigidaire Grommet Backorder WCI 137017200 $2.27

66

5304529773 Frigidaire Assembly Nozzle Backorder WCI 5304529773 $47.91

68

134742002 Frigidaire Plug Backorder WCI 134742002 $9.93

70

137526000 Frigidaire LED Lamp Backorder WCI 137526000 $108.08

NI

134793200 Frigidaire Harness Backorder WCI 134793200 $37.19

NI

134926600 Frigidaire Damper In Stock WCI 134926600 $9.02

NI

3204267 Frigidaire Dryer Safety Thermostat In Stock WCI 3204267 $34.85

134693800 Frigidaire Dryer Motor Pulley Backorder WCI 134693800 $11.43

134716200 Frigidaire Retainer In Stock WCI 134716200 $2.00

134930800 Frigidaire Harness In Stock WCI 134930800 $5.57

137030800 Frigidaire Nut Backorder WCI 137030800 $4.51

137150200 Frigidaire Terminal In Stock WCI 137150200 $20.38

5304500486 Frigidaire Seal Backorder WCI 5304500486 $29.90

STRIKE, WCI 137555200 Contact Us For Availability

NIB

5304506746 Frigidaire Shield In Stock WCI 5304506746 $27.18

NIB

5308027429 Frigidaire Dryer High Temperature In Stock WCI 5308027429 $38.09

NIB

WCI 137555201 WCI 137555201 Contact Us For Availability

NIC

137605700 Frigidaire Front Panel Gasket Backorder WCI 137605700 $21.28
