Model Electrolux EWMED65HSS0 ELECTRIC DRYER – Common Parts &amp; Diagrams

1

134792700 Frigidaire Dryer Heating Element In Stock WCI 134792700 $87.50

3

KNOB, RETRACTING, COMPLETE ASMY WCI 134766500 Contact Us For Availability

4

134792100 Frigidaire Bracket Assembly Backorder WCI 134792100 $18.26

4

134871900 Frigidaire Pipe Backorder WCI 134871900 $52.46

4

LOCK, BLOWER HOUSING WCI 134707900 Contact Us For Availability

5

134767800 Frigidaire Pipe Backorder WCI 134767800 $26.28

5

RACK, DRYING WCI 134912700 Contact Us For Availability

6

DUCT, AIR WCI 134708300 Contact Us For Availability

7

137046800 Frigidaire Bracket Assembly Backorder WCI 137046800 $11.59

7

5303161296 Frigidaire Washer Inlet Hose (1 Pi Backorder WCI 5303161296 $8.48

7

5304509710 Frigidaire Tube Backorder WCI 5304509710 $16.93

7A

137046700 Frigidaire Bracket Backorder WCI 137046700 $15.13

8

134694400 Frigidaire Cover Backorder WCI 134694400 $44.97

8

134711401 Frigidaire Dryer Thermal Fuse In Stock WCI 134711401 $14.68

8

134767600 Frigidaire Lens Backorder WCI 134767600 $33.87

8

137032600 Frigidaire Washer Dryer Thermal Lim In Stock WCI 137032600 $15.09

8

COVER, LINT HOUSING WCI 134700900 Contact Us For Availability

8A

134935200 Frigidaire Screw Backorder WCI 134935200 $8.44

9

134768400 Frigidaire Pipe Backorder WCI 134768400 $8.89

10

134690800 Frigidaire Dryer Blower Housing Ass In Stock WCI 134690800 $107.91

10

137007900 Frigidaire Cap Backorder WCI 137007900 $36.57

10

ASSEMBLY, INDICATOR, COMPLETE WCI 134933900 Contact Us For Availability

11

137043100 Frigidaire Button Backorder WCI 137043100 $23.16

12

137010900 Frigidaire Button Backorder WCI 137010900 $80.59

13

137021200 Frigidaire Button Backorder WCI 137021200 $33.85

14

137009900 Frigidaire Button Backorder WCI 137009900 $41.42

134704600 Frigidaire Hinge Backorder WCI 134704600 $141.17

134711300 Frigidaire Washer Thermistor In Stock WCI 134711300 $33.87

137031800 Frigidaire Cushion Assembly Backorder WCI 137031800 $5.33

BUTTON, OFF WCI 137008100 Contact Us For Availability

16

134788000 Frigidaire Screw Backorder WCI 134788000 $8.89

16

134994600 Frigidaire Control Board Backorder WCI 134994600 $251.03

17

134792900 Frigidaire Protector Backorder WCI 134792900 $8.46

18

131168200 Frigidaire Dryer Screw In Stock WCI 131168200 $8.89

19

134402900 Frigidaire Screw Backorder WCI 134402900 $18.70

19

134711200 Frigidaire Washer Thermistor In Stock WCI 134711200 $32.07

19

134790400 Frigidaire Screw Backorder WCI 134790400 $8.91

20

131017900 Frigidaire Screw Backorder WCI 131017900 $8.91

20

137553000 Frigidaire Dryer Gasket-Door In Stock WCI 137553000 $80.67

20

SEAL, FELT, DRUM WCI 134705900 Contact Us For Availability

22

134790700 Frigidaire Harness Backorder WCI 134790700 $48.48

23

134784400 Frigidaire Idler Arm Assembly Backorder WCI 134784400 $70.97

23

134786100 Frigidaire Moisture Sensor In Stock WCI 134786100 $54.22

23

WCI 137030000 WCI 137030000 Contact Us For Availability

24

134638525 Frigidaire Panel Backorder WCI 134638525 $133.21

25

134719300 Frigidaire Dryer 5-Rib Belt In Stock WCI 134719300 $41.87

26

WCI 137032400 WCI 137032400 Contact Us For Availability

27

134242400 Frigidaire Washer Clamp Assembly In Stock WCI 134242400 $11.57

27

134793600 Frigidaire Dryer Lint Screen Filter In Stock WCI 134793600 $56.43

27A

134710900 Frigidaire Bracket Assembly Backorder WCI 134710900 $13.37

27A

134790600 Frigidaire Screw Backorder WCI 134790600 $9.35

27B

134711000 Frigidaire Bracket Assembly Backorder WCI 134711000 $13.37

27L

PANEL, LEFT SIDE, SILVER WCI 134712625 Contact Us For Availability

27R

PANEL, RIGHT SIDE, SILVER WCI 134712725 Contact Us For Availability

28

137034500 Frigidaire Clip In Stock WCI 137034500 $27.18

28

137116000 Frigidaire Dryer Motor Assembly In Stock WCI 137116000 $195.71

29

131205100 Frigidaire Screw In Stock WCI 131205100 $8.91

33

3204267 Frigidaire Dryer Safety Thermostat In Stock WCI 3204267 $46.66

35

BRACKET, TOP PANEL MTG., REAR WCI 134713100 Contact Us For Availability

40

5304523155 Frigidaire Washer Kit In Stock WCI 5304523155 $52.01

40A

134716700 Frigidaire Washer Backorder WCI 134716700 $1.33

41

134716800 Frigidaire Nut Backorder WCI 134716800 $1.75

46

134707400 Frigidaire Bracket Backorder WCI 134707400 $49.81

46

GASKET, DOOR GLASS WCI 134934900 Contact Us For Availability

47

5304505715 Frigidaire Trim Ring Backorder WCI 5304505715 $210.34

47

SEAL, EXHAUST TUBE WCI 131633300 Contact Us For Availability

49

134651200 Frigidaire Retainer Clip Backorder WCI 134651200 $95.62

52

131202300 Frigidaire Screw Backorder WCI 131202300 $8.46

53

137471800 Frigidaire Hose In Stock WCI 137471800 $7.57

54

5304503984 Frigidaire Kit Assembly In Stock WCI 5304503984 $19.97

59

134931500 Frigidaire Cover Assembly Backorder WCI 134931500 $16.04

60

134430300 Frigidaire Screw Backorder WCI 134430300 $9.35

65

137017200 Frigidaire Grommet Backorder WCI 137017200 $2.24

66

5304529773 Frigidaire Assembly Nozzle Backorder WCI 5304529773 $47.13

68

134742002 Frigidaire Plug Backorder WCI 134742002 $9.77

NI

134700400 Frigidaire Kit Backorder WCI 134700400 $50.22

NI

134793200 Frigidaire Harness Backorder WCI 134793200 $36.58

NI

134926600 Frigidaire Damper Backorder WCI 134926600 $8.88

134716200 Frigidaire Retainer In Stock WCI 134716200 $1.96

134930800 Frigidaire Harness Backorder WCI 134930800 $29.85

137030800 Frigidaire Nut Backorder WCI 137030800 $4.44

137150200 Frigidaire Terminal In Stock WCI 137150200 $20.05

5308027429 Frigidaire Dryer High Temperature In Stock WCI 5308027429 $37.47
