Model Whirlpool ET18PKXYW00 TOP MOUNT REFRIGERATOR – Common Parts &amp; Diagrams

WPL 1117510 WPL 1117510 Contact Us For Availability

1

Unit, Frame WPL 1116619 Contact Us For Availability

1

Shelf, Ladder (2) WPL 1114466 Contact Us For Availability

1

Liner (Not A Serviceable Part) WPL ARI44981A8 Contact Us For Availability

1

Cabinet (Not A Serviceable Part) WPL ARI44980A2 Contact Us For Availability

1

Bottom, Compartment Separator WPL 1116561 Contact Us For Availability

2

Wiring, Fan Motor WPL 1127626 Contact Us For Availability

2

Compressor KIt Includes Items (11, 22, 23, 25 WPL 4318241 Contact Us For Availability

2

Shelf, Ladder Center WPL 1114465 Contact Us For Availability

2

Roller, Front WPL 2152011 Contact Us For Availability

2

Box, Control WPL 1105455 Contact Us For Availability

3

520965 Whirlpool Refrigerator Support Backorder WPL 520965 $10.14

3

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $22.34

3

Grommet, Compressor Bracket WPL 1105219 Contact Us For Availability

3

Screw, 5/16-24 x 1-1/4 WPL 489333 Contact Us For Availability

4

WP941839 Whirlpool Refrigerator Button Plug In Stock WPL WP941839 $3.70

4

WPW10250570 Whirlpool Refrigerator Cabinet Ro Backorder WPL WPW10250570 $14.49

4

Bracket, Mounting WPL 1105220 Contact Us For Availability

4

Timer, Defrost (10 Hour) WPL 1127570 Contact Us For Availability

5

W10854959 Whirlpool Refrigerator Shelf Stud Backorder WPL W10854959 $4.23

5

WP487353 Whirlpool Refrigerator Screw Backorder WPL WP487353 $2.51

5

WP488921 Whirlpool Refrigerator Screw Backorder WPL WP488921 $2.51

5

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

5

Grommet, Compressor (4) WPL 1105200 Contact Us For Availability

5

Screw, 8-32 x 1-1/4 (3) WPL 489345 Contact Us For Availability

6

WP488163 Whirlpool Refrigerator Screw In Stock WPL WP488163 $3.70

6

WP938213 Whirlpool Refrigerator Power Switch Backorder WPL WP938213 $13.76

6

Screw (4) WPL 489334 Contact Us For Availability

7

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $30.80

7

Condenser Assembly WPL 2154008 Contact Us For Availability

7

Shelf, Cantilever WPL 1116693 Contact Us For Availability

7

Screw, WPL 488454 Contact Us For Availability

8

W11679940 Whirlpool Refrigerator Light Bulb A In Stock WPL W11679940 $2.75

8

Trim, Shelf WPL 1118121 Contact Us For Availability

8

Electrical, Shield WPL 1106892 Contact Us For Availability

8

Screw WPL 489327 Contact Us For Availability

9

940014 Whirlpool Refrigerator Primary Button Backorder WPL 940014 $10.25

9

Crisper Cover WPL 2148047 Contact Us For Availability

9

Stud, Front (2) WPL 946356 Contact Us For Availability

9

Control, Front Cover WPL 2148055 Contact Us For Availability

1123394 Whirlpool Refrigerator Cold Control T Backorder WPL 1123394 $89.70

819091 Whirlpool Refrigerator Shelf Stud Backorder WPL 819091 $13.89

Trim, Crisper Cover WPL 1116712 Contact Us For Availability

Heater, Mullion WPL 2154064 Contact Us For Availability

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $23.50

Glass, Crisper Cover WPL 1116715 Contact Us For Availability

Clip, Strap WPL 1123230 Contact Us For Availability

Clip, Mullion (3) WPL 2149060 Contact Us For Availability

Knob, Thermostat WPL 2148150 Contact Us For Availability

WP965173 Whirlpool Dishwasher Screw Backorder WPL WP965173 $2.64

Evaporator Assembly WPL 2153977 Contact Us For Availability

Pan Shelf, Cantilever WPL 1116703 Contact Us For Availability

support stud (8) WPL 946355 Contact Us For Availability

Spacer (3) WPL 2149077 Contact Us For Availability

Shim, Handle WPL 943187 Contact Us For Availability

Shim, Handle End (Side) WPL 992872 Contact Us For Availability

Reflector, Glass WPL 1116701 Contact Us For Availability

Cover, Air Duct WPL 2153966 Contact Us For Availability

Center Rail (White) WPL 1116540 Contact Us For Availability

Center Rail (Golden Harvest) WPL 1116542 Contact Us For Availability

Center Rail (Almond) WPL 1116543 Contact Us For Availability

Spacer, Handle Door WPL 943188 Contact Us For Availability

Heater, Defrost WPL 2154737 Contact Us For Availability

Glass, Shelf WPL 1116699 Contact Us For Availability

Knob, Air Control WPL 2148151 Contact Us For Availability

15

WP2172748 Whirlpool Drawer Support Backorder WPL WP2172748 $50.82

15

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

482731 Whirlpool Refrigerator Evaporator Fan In Stock WPL 482731 $47.13

Drain Pan & Heat Shield WPL 2153973 Contact Us For Availability

Shelf, Full Cantilever WPL 1116688 Contact Us For Availability

Rod, Connecting WPL 1116565 Contact Us For Availability

WP1100938 Whirlpool Refrigerator Fan Blade Backorder WPL WP1100938 $27.58

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $2.51

Shelf, Freezer WPL 1116722 Contact Us For Availability

Hinge, Top WPL 1123514 Contact Us For Availability

Air Diffuser Assembly WPL 2157416 Contact Us For Availability

WP1101634 Whirlpool Refrigerator Cover In Stock WPL WP1101634 $4.50

WP487887 Whirlpool Refrigerator Screw Backorder WPL WP487887 $3.70

Nameplate WPL 2152334 Contact Us For Availability

Trim, Shelf Front WPL 1118112 Contact Us For Availability

Shim, Hinge Top WPL 1123517 Contact Us For Availability

Gasket, Air Diffuser WPL 1114325 Contact Us For Availability

1119787 Whirlpool Refrigerator Hinge Cover Backorder WPL 1119787 $12.24

Interior Door Panel WPL 1118123 Contact Us For Availability

Dampener WPL 2149670 Contact Us For Availability

Pan, Crisper WPL 2148977 Contact Us For Availability

Grommet (2) WPL 531933 Contact Us For Availability

Hinge Cover (Golden Harvest) WPL 989896 Contact Us For Availability

Cover, Air Diffuser WPL 1108176 Contact Us For Availability

WP999367 Whirlpool Refrigerator Screw Backorder WPL WP999367 $2.51

Trim, Door Shelf WPL 2148178 Contact Us For Availability

Tube Clamp (2) WPL 510716 Contact Us For Availability

Pan, Meat WPL 2148978 Contact Us For Availability

WPW10141625 Whirlpool Refrigerator Screw Asse Backorder WPL WPW10141625 $9.59

Kit, Foam Slab (Required When Replacing Exter WPL 876029 Contact Us For Availability

Trim, Door Shelf WPL 2148177 Contact Us For Availability

Trim, Full Shelf WPL 2148050 Contact Us For Availability

Screw WPL 489168 Contact Us For Availability

Hinge, Center WPL 2151453 Contact Us For Availability

WP841180A Whirlpool Microwave Glass Turntable In Stock WPL WP841180A $3.92

Compartment Door, Utility WPL 2148222 Contact Us For Availability

Relay (See Overload) WPL ARI44982A5 Contact Us For Availability

Grommet WPL 983604 Contact Us For Availability

Shim, Hinge Center WPL 836155 Contact Us For Availability

Wiring Assembly, Control Box WPL 2153995 Contact Us For Availability

WP2196157 Whirlpool Fill Tube In Stock WPL WP2196157 $4.59

Compartment, Butter Door WPL 2148220 Contact Us For Availability

Overload (Production (Includes Relay)) WPL 2149994 Contact Us For Availability

Overload (Service (Includes Relay)) WPL 2154945 Contact Us For Availability

Scroll, Fan WPL 1116598 Contact Us For Availability

Gasket, Bottom Separator WPL 1116566 Contact Us For Availability

WP2189000 Whirlpool Refrigerator Handle Plug Backorder WPL WP2189000 $3.70

WP250830 Whirlpool Refrigerator Screw Backorder WPL WP250830 $2.51

WP489467 Whirlpool Hinge Shim In Stock WPL WP489467 $4.59

Hole Plug, Handle (Almond) WPL 1122654 Contact Us For Availability

Hole Plug, Handle (Golden Harvest) WPL 1122694 Contact Us For Availability

Muffler WPL 2154033 Contact Us For Availability

Reflector, Shelf WPL 1116691 Contact Us For Availability

Evaporator Cover WPL 2151668 Contact Us For Availability

25

W11233072 Whirlpool Screw In Stock WPL W11233072 $9.59

25

Terminal Cover WPL 2154452 Contact Us For Availability

25

Glass, Full Shelf WPL 1116690 Contact Us For Availability

WP2217784 Whirlpool Refrigerator Cover Backorder WPL WP2217784 $15.98

WP982704 Whirlpool Refrigerator Container Backorder WPL WP982704 $13.05

Divider, Door Shelf WPL 1114380 Contact Us For Availability

Strap, Cover WPL 1105222 Contact Us For Availability

Hinge Butt, Bottom WPL 1123378 Contact Us For Availability

Insulation, Filler WPL 1108196 Contact Us For Availability

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $28.24

Hinge Pin, Bottom WPL 654366 Contact Us For Availability

Hole Plug WPL 1103725 Contact Us For Availability

Insulation, Compartment Separator WPL 1116569 Contact Us For Availability

28

Screw 10-32 x 5/16 WPL 488714 Contact Us For Availability

28

Screw Grommet WPL 509812 Contact Us For Availability

29

4318297 Whirlpool Refrigerator Shelf Bar Endc In Stock WPL 4318297 $10.39

29

W11693756 Whirlpool Screw Assembly Backorder WPL W11693756 $8.11

29

Shim, Bottom WPL 1123379 Contact Us For Availability

30

4386917 Whirlpool Endcap Kit In Stock WPL 4386917 $6.84

30

WP489200 Whirlpool Refrigerator Washer Backorder WPL WP489200 $4.61

30

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

31

Retainer, Gasket Side (2) WPL 1115136 Contact Us For Availability

31

Clip, Unit Cover WPL 548744 Contact Us For Availability

31

Spacer WPL 1121117 Contact Us For Availability

32

Retainer, Gasket Top & Bottom WPL 1115137 Contact Us For Availability

32

Clip, Wire (2) WPL 548745 Contact Us For Availability

WP1118001 Whirlpool Hinge Pin Backorder WPL WP1118001 $3.70

WP4387503 Whirlpool Refrigerator Bimetal Defr In Stock WPL WP4387503 $16.40

Corner Filler, Grille WPL 1118078 Contact Us For Availability

Separator, Compartment (Top) WPL 1116570 Contact Us For Availability

34

Filler, Wrapper Corner (2) (White) WPL 1118058 Contact Us For Availability

34

Filler, Wrapper Corner (2) (Almond) WPL 1118059 Contact Us For Availability

34

Filler, Wrapper Corner (2) (Golden Harvest) WPL 1118060 Contact Us For Availability

Trim, Door Shelf WPL 2148179 Contact Us For Availability

Unit, Rail WPL 1116622 Contact Us For Availability

Grille WPL 1118079 Contact Us For Availability

Cup, Drain WPL 937065 Contact Us For Availability

Trim, Compartment Door WPL 1118006 Contact Us For Availability

Hole Plug (4) (White) WPL 1129062 Contact Us For Availability

Hole Plug (4) (Almond) WPL 1129063 Contact Us For Availability

Hole Plug (4) (Golden Harvest) WPL 1129064 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

489340 Whirlpool Refrigerator Screw Backorder WPL 489340 $4.56

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $26.21

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

72110 Whirlpool Dryer Touch-Up Paint, Golden In Stock WPL 72110 $10.07

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $96.00

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

WPL 479502 WPL 479502 Contact Us For Availability

Trim, WPL 1118014 Contact Us For Availability

WPL 261890 WPL 261890 Contact Us For Availability

WPL 261891 WPL 261891 Contact Us For Availability

WPL 350941 WPL 350941 Contact Us For Availability

WPL 542639 WPL 542639 Contact Us For Availability

WPL 799833 WPL 799833 Contact Us For Availability

WPL 978883 WPL 978883 Contact Us For Availability

Wire Assembly Intermediate WPL 2153994 Contact Us For Availability

Bracket, Control Knob WPL 1105457 Contact Us For Availability

39

WP487996 Whirlpool Refrigerator Cap Tube Backorder WPL WP487996 $4.48

40

WP1106508 Whirlpool Refrigerator Gasket Backorder WPL WP1106508 $4.14

40

Air, Baffle WPL 2154102 Contact Us For Availability

WP2151652 Whirlpool Refrigerator Button Plug Backorder WPL WP2151652 $8.20

Fan, Mounting Bracket WPL 2154110 Contact Us For Availability

Hole Plug (Almond) WPL 2151653 Contact Us For Availability

Hole Plug (Gold) WPL 2151654 Contact Us For Availability

42

Screw, 8 x 3/8 WPL 488624 Contact Us For Availability

43

833697 Whirlpool Condenser Fan Motor In Stock WPL 833697 $41.18

44

681390 Whirlpool Refrigerator Screw Backorder WPL 681390 $9.13

44

Cord, Service WPL 937360 Contact Us For Availability

45

Fan Blade WPL 1115135 Contact Us For Availability

46

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

47

Tray, Evaporator WPL 1116604 Contact Us For Availability

48

Wedge, Air Baffle WPL 1118017 Contact Us For Availability

48

Cover, Unit WPL 1116613 Contact Us For Availability

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

Drain Extension WPL 2154118 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability

60

WP489174 Whirlpool Refrigerator Screw Backorder WPL WP489174 $3.70

61

Tap-Plate, Bottom Hinge WPL 2147310 Contact Us For Availability

65

WP2155013 Whirlpool Refrigerator Clip In Stock WPL WP2155013 $3.70

68

549193 Whirlpool Refrigerator Power Clamp Backorder WPL 549193 $6.94
