Model Electrolux EIED50LIW2 LAUNDRY, RESIDENTIAL, ELECTRIC DRYER – Common Parts &amp; Diagrams

1

5304535760 Frigidaire Heater In Stock WCI 5304535760 $71.24

3

KNOB, RETRACTING, COMPLETE ASMY WCI 134766500 Contact Us For Availability

4

134792100 Frigidaire Bracket Assembly Backorder WCI 134792100 $18.56

4

LOCK, BLOWER HOUSING WCI 134707900 Contact Us For Availability

4

PIPE, KNOB LIGHT WCI 134907400 Contact Us For Availability

6

LENS, LCD WCI 134767700 Contact Us For Availability

6

DUCT, AIR WCI 137611800 Contact Us For Availability

7

137046800 Frigidaire Bracket Assembly Backorder WCI 137046800 $11.78

7

TUBE, EXHAUST, REAR WCI 134693900 Contact Us For Availability

7A

137046700 Frigidaire Bracket Backorder WCI 137046700 $15.38

8

134711401 Frigidaire Dryer Thermal Fuse In Stock WCI 134711401 $14.68

8

137032600 Frigidaire Washer Dryer Thermal Lim In Stock WCI 137032600 $12.00

8

137560800 Frigidaire Filter Housing Cover Backorder WCI 137560800 $28.96

8

137578600 Frigidaire Cover Assembly Backorder WCI 137578600 $7.67

8A

134935200 Frigidaire Screw Backorder WCI 134935200 $8.58

9

RING, OPTION BUTTON, LIGHT WCI 134894200 Contact Us For Availability

10

137552300 Frigidaire Dryer Blower Assembly In Stock WCI 137552300 $185.20

10

ASSEMBLY, INDICATOR, COMPLETE WCI 134933900 Contact Us For Availability

11

131749800 Frigidaire Spacer Backorder WCI 131749800 $28.07

11

BUTTON, MODIFIER, BUTTON 2 & 3 WCI 137032200 Contact Us For Availability

12

134696901 Frigidaire Frame Backorder WCI 134696901 $54.23

14

137015900 Frigidaire Button Backorder WCI 137015900 $20.71

134704600 Frigidaire Hinge Backorder WCI 134704600 $143.66

134711300 Frigidaire Dryer Thermistor In Stock WCI 134711300 $34.43

137031800 Frigidaire Cushion Assembly Backorder WCI 137031800 $5.42

BUTTON, DISPLAY WCI 137031900 Contact Us For Availability

16

134788000 Frigidaire Screw Backorder WCI 134788000 $9.04

16

5304508449 Frigidaire Washer Dryer Air Duct In Stock WCI 5304508449 $67.23

16

CONTROL BOARD, UI W/HOUSING WCI 809160409 Contact Us For Availability

17

134792900 Frigidaire Protector Backorder WCI 134792900 $8.60

18

131168200 Frigidaire Dryer Screw In Stock WCI 131168200 $9.04

19

134402900 Frigidaire Screw Backorder WCI 134402900 $19.01

19

134711200 Frigidaire Dryer Thermistor In Stock WCI 134711200 $32.60

19

134790400 Frigidaire Screw Backorder WCI 134790400 $9.06

20

137553000 Frigidaire Dryer Gasket-Door In Stock WCI 137553000 $80.99

20

5304499489 Frigidaire Washer Felt Seal In Stock WCI 5304499489 $42.15

20

BOLT, HEX HEAD, 1/4-20T X 1.25, THREAD CUTTIN WCI 131017900 Contact Us For Availability

21

137610700 Frigidaire Drum Backorder WCI 137610700 $277.20

22

131601000 Frigidaire Idler Spring Assembly In Stock WCI 131601000 $33.06

22

HARNESS, USER INTERFACE WCI 134790700 Contact Us For Availability

22

PANEL, FRONT, WHITE WCI 137553710 Contact Us For Availability

23

134786110 Frigidaire Moisture Sensor In Stock WCI 134786110 $58.27

23

134793511 Frigidaire Idler Arm Assembly In Stock WCI 134793511 $27.98

24

PANEL, WORK TOP, WHITE WCI 134638510 Contact Us For Availability

25

134719300 Frigidaire Dryer 5-Rib Belt In Stock WCI 134719300 $40.87

25

137567001 Frigidaire Bracket Assembly Backorder WCI 137567001 $23.09

25

LATCH, PUSH-PUSH DOOR WCI 137538802 Contact Us For Availability

26

134813600 Frigidaire Dryer Door Switch In Stock WCI 134813600 $27.18

26

809160320 Frigidaire Control Board Backorder WCI 809160320 $204.94

27

134242400 Frigidaire Washer Clamp Assembly In Stock WCI 134242400 $11.76

27

137623900 Frigidaire Lint Filter In Stock WCI 137623900 $77.50

27

PANEL, CONTROL. DEC, WHITE WCI 134995211 Contact Us For Availability

27A

SCREW, #10-24 X 1.0", PAN HD WCI 134790600 Contact Us For Availability

27A

BRACKET, CONTROL PANEL, LEFT HAND, MOUNTING WCI 134710900 Contact Us For Availability

27B

134690203 Frigidaire Base Assembly Backorder WCI 134690203 $163.61

27B

BRACKET, CONTROL PANEL, RIGHT HAND, MOUNTING WCI 134711000 Contact Us For Availability

27L

PANEL, LEFT SIDE, WHITE WCI 134712610 Contact Us For Availability

27R

PANEL, RIGHT SIDE, WHITE WCI 134712710 Contact Us For Availability

28

137034500 Frigidaire Clip In Stock WCI 137034500 $27.62

29

131205100 Frigidaire Screw In Stock WCI 131205100 $9.06

30

137610610 Frigidaire Vane In Stock WCI 137610610 $41.22

30A

VANE, MIXING, SMOOTH WCI 137610510 Contact Us For Availability

33

3204267 Frigidaire Dryer Safety Thermostat In Stock WCI 3204267 $34.85

35

BRACKET, TOP PANEL MTG., REAR WCI 134713100 Contact Us For Availability

40

5304523155 Frigidaire Dryer Kit In Stock WCI 5304523155 $60.74

40A

134716700 Frigidaire Washer Backorder WCI 134716700 $1.35

41

134716800 Frigidaire Nut Backorder WCI 134716800 $1.87

42

BULKHEAD, PANEL, FRONT WCI 137556106 Contact Us For Availability

45

BULKHEAD, PANEL, REAR WCI 137556615 Contact Us For Availability

46

134707400 Frigidaire Bracket In Stock WCI 134707400 $50.64

46

GASKET, DOOR GLASS WCI 134934900 Contact Us For Availability

47

5304505715 Frigidaire Trim Ring In Stock WCI 5304505715 $214.17

47

SEAL, EXHAUST TUBE WCI 131633300 Contact Us For Availability

48

COVER, TRIM RING WCI 134618910 Contact Us For Availability

49

134651200 Frigidaire Retainer Clip Backorder WCI 134651200 $97.26

51

137459300 Frigidaire Striker Backorder WCI 137459300 $30.80

56

GLASS, DOOR WCI 137576000 Contact Us For Availability

58

PANEL, OUTER DOOR WCI 137604200 Contact Us For Availability

59

COVER, INDICATOR HOLE WCI 134931500 Contact Us For Availability

60

134430300 Frigidaire Screw Backorder WCI 134430300 $9.50

68

134742000 Frigidaire Plug Backorder WCI 134742000 $6.79

70

137526000 Frigidaire LED Lamp Backorder WCI 137526000 $108.08

134693800 Frigidaire Dryer Motor Pulley Backorder WCI 134693800 $11.43

134716200 Frigidaire Retainer In Stock WCI 134716200 $2.00

134793200 Frigidaire Harness Backorder WCI 134793200 $37.19

134926600 Frigidaire Damper In Stock WCI 134926600 $9.02

134930800 Frigidaire Harness In Stock WCI 134930800 $5.57

137150200 Frigidaire Terminal In Stock WCI 137150200 $20.38

137380600 Frigidaire Screw - M5 x 0.8 In Stock WCI 137380600 $5.88

137605700 Frigidaire Front Panel Gasket Backorder WCI 137605700 $21.28

STRIKE, DOOR WCI 137555200 Contact Us For Availability

NIB

5304500486 Frigidaire Seal Backorder WCI 5304500486 $29.90

NIB

STRIKER, WCI 137555201 Contact Us For Availability

NIC

5308027429 Frigidaire Dryer High Temperature In Stock WCI 5308027429 $38.09
