Model Whirlpool EH150FXSN00 CHEST FREEZER – Common Parts & Diagrams
02 - SECTION
04 - SECTION
01 - SECTION
03 - SECTION
Common parts from model Whirlpool EH150FXSN00 CHEST FREEZER
Access Valve (5/8``) WPL 978029 Contact Us For Availability
PAINT, BULK (1 QT.) (WHITE (UNCUT)) WPL 799344 Contact Us For Availability
1
Compressor (Service Replacement) (Items 6,14, WPL 482981 Contact Us For Availability
1
``O`` Ring WPL 753610 Contact Us For Availability
2
Clip, Compressor Mounting (4) WPL 596798 Contact Us For Availability
3
Hole Plug (Almond) WPL 989197 Contact Us For Availability
4
Relay (Used W/Original Compressor) WPL 1100806 Contact Us For Availability
5
Cover, Terminal (Used W/Original Compressor) WPL 1105015 Contact Us For Availability
6
Spring, Overload WPL 1114190 Contact Us For Availability
6
Conector, Wire WPL 547217 Contact Us For Availability
7
Clip (36) WPL 596788 Contact Us For Availability
8
Plug Button WPL 482584 Contact Us For Availability
8
Drier WPL 728583 Contact Us For Availability
9
Rod Holder Assembly WPL 556013 Contact Us For Availability
9
Harness, Wiring WPL 730032 Contact Us For Availability
10
Screw, 8-32 x 5/8 WPL 595325 Contact Us For Availability
10
Gasket, Handle WPL 727809 Contact Us For Availability
11
Bolt, Machine WPL 681672 Contact Us For Availability
11
Running, Capacitor WPL 1108324 Contact Us For Availability
11
Clip, Spring WPL 983465 Contact Us For Availability
12
Clamp, Capacitor WPL 1101184 Contact Us For Availability
13
Basket WPL 730875 Contact Us For Availability
13
Plate, Bolt WPL 728115 Contact Us For Availability
14
Control, Cold WPL 728368 Contact Us For Availability
14
Nut WPL 489142 Contact Us For Availability
14
Hook, Lock WPL 728222 Contact Us For Availability
15
Collar (2) (Front & Rear) WPL 730736 Contact Us For Availability
15
Washer WPL 489143 Contact Us For Availability
15
Screw WPL 680483 Contact Us For Availability
16
Collar, End (2) WPL 730716 Contact Us For Availability
17
Corner WPL 730717 Contact Us For Availability
17
Lock WPL 586331 Contact Us For Availability
19
Handle WPL 730714 Contact Us For Availability
20
Overload (Used On Service Compressor) WPL 483037 Contact Us For Availability
20
Panel, Door Exterior (Almond) WPL 730739 Contact Us For Availability
21
Indicator, Light WPL 556230 Contact Us For Availability
21
Capacitor (Used On Service Compressor) WPL 483009 Contact Us For Availability
22
Screw (2) WPL 595022 Contact Us For Availability
23
Knob, Control WPL 727020 Contact Us For Availability
23
Cover, Terminal (Used On Service Compressor) WPL 1108115 Contact Us For Availability
24
Door WPL 753077 Contact Us For Availability
24
Strap, Cover (Used On Service Compressor) WPL 938384 Contact Us For Availability
24
Torsion Bar, L.H. WPL 728036 Contact Us For Availability
25
Screw WPL 681318 Contact Us For Availability
25
Washer, Compressor Mounting (4) WPL 680975 Contact Us For Availability
25
Torsion Bar, R.H. WPL 728037 Contact Us For Availability
26
Clip, Holding WPL 653035 Contact Us For Availability
26
Hinge, L.H. WPL 753874 Contact Us For Availability
26
Hinge, R.H. WPL 753875 Contact Us For Availability
27
Overload WPL 1100807 Contact Us For Availability
27
Cover, Hinge Rod (2) WPL 566219 Contact Us For Availability
28
Gasket WPL 728686 Contact Us For Availability
29
Panel, Door Interior WPL 730742 Contact Us For Availability
31
Harness, Exterior Door WPL 728838 Contact Us For Availability
34
Decal, Door Panel WPL 730037 Contact Us For Availability
35
Deflector, Light WPL 594458 Contact Us For Availability
36
Lampholder WPL 594815 Contact Us For Availability
× ![]()
