  • Electrolux EFMC427UIW2 Parts List

Model Electrolux EFMC427UIW2 LAUNDRY, RESIDENTIAL, ELECTRIC DRYER – Common Parts & Diagrams

1
BOARD ASSEMBLY, UI LINEAR, W/HOUSING-SCREW
BOARD ASSEMBLY, UI LINEAR, W/HOUSING-SCREW WCI 5304521514 Contact Us For Availability
View on Model
5
GASKET, HOUSING, FOAM
GASKET, HOUSING, FOAM WCI 5304505313 Contact Us For Availability
View on Model
5
SEAL, DISPLAY AREA
SEAL, DISPLAY AREA WCI 5304505345 Contact Us For Availability
View on Model
6
DUCT ASSEMBLY, AIR, W/FOAM TOP SEAL
DUCT ASSEMBLY, AIR, W/FOAM TOP SEAL WCI 5304521401 Contact Us For Availability
View on Model
7
SCREW, PAN HEAD, #8-18X.750
SCREW, PAN HEAD, #8-18X.750 WCI 137285100 Contact Us For Availability
View on Model
7
TUBE, EXHAUST, REAR
TUBE, EXHAUST, REAR WCI 5304515233 Contact Us For Availability
View on Model
9
BLOWER WHEEL, ASSEMBLY
BLOWER WHEEL, ASSEMBLY WCI 5304513609 Contact Us For Availability
View on Model
11
SPACER, IDLER
SPACER, IDLER WCI 5304525724 Contact Us For Availability
View on Model
16
SCREW, COMB PNHD B, #10-16X.75, (9)
SCREW, COMB PNHD B, #10-16X.75, (9) WCI 137087000 Contact Us For Availability
View on Model
16
DUCT ASSEMBLY, HEAT, REAR
DUCT ASSEMBLY, HEAT, REAR WCI 5304513571 Contact Us For Availability
View on Model
17
PROTECTOR, EDGE, RIGHT TOP FRONT, 85.0+/-1.5
PROTECTOR, EDGE, RIGHT TOP FRONT, 85.0+/-1.5 WCI 134792900 Contact Us For Availability
View on Model
19
THERMISTOR, EXHAUST
THERMISTOR, EXHAUST WCI 5304513591 Contact Us For Availability
View on Model
19
THERMISTOR, INLET
THERMISTOR, INLET WCI 5304520302 Contact Us For Availability
View on Model
19
SCREW, PPH B, 6-20X.375
SCREW, PPH B, 6-20X.375 WCI 5304505441 Contact Us For Availability
View on Model
20
SCREW, #8 PAN HEAD, 10-10B X 0.500, CR/SQ DRI
SCREW, #8 PAN HEAD, 10-10B X 0.500, CR/SQ DRI WCI 131205100 Contact Us For Availability
View on Model
22
SPRING, IDLER ARM
SPRING, IDLER ARM WCI 131601000 Contact Us For Availability
View on Model
22
PANEL, DRYER FRONT, WHITE
PANEL, DRYER FRONT, WHITE WCI 5304513563 Contact Us For Availability
View on Model
23
IDLER ARM ASSY, W/PULLEY
IDLER ARM ASSY, W/PULLEY WCI 134793511 Contact Us For Availability
View on Model
25
LATCH ASSEMBLY, DOOR, W/COVER
LATCH ASSEMBLY, DOOR, W/COVER WCI 5304513568 Contact Us For Availability
View on Model
26
SWITCH, DOOR, WHITE
SWITCH, DOOR, WHITE WCI 134813663 Contact Us For Availability
View on Model
26
MAIN BOARD, ASSEMBLY, W/HOUSING, & HARNESS
MAIN BOARD, ASSEMBLY, W/HOUSING, & HARNESS WCI 5304521373 Contact Us For Availability
View on Model
26A
HARNESS, WIRING, DOOR SWITCH
HARNESS, WIRING, DOOR SWITCH WCI 5304505258 Contact Us For Availability
View on Model
27
FILTER ASSEMBLY, LINT, CLAMSHELL
FILTER ASSEMBLY, LINT, CLAMSHELL WCI 5304513574 Contact Us For Availability
View on Model
28A
BRACKET, REINFORCEMENT, BACKSHEET
BRACKET, REINFORCEMENT, BACKSHEET WCI 137029801 Contact Us For Availability
View on Model
29
CONSOLE ASSEMBLY, W/OVERLAY
CONSOLE ASSEMBLY, W/OVERLAY WCI 5304515403 Contact Us For Availability
View on Model
30A
VANE, MIXING, SMOOTH
VANE, MIXING, SMOOTH WCI 137610510 Contact Us For Availability
View on Model
36
SPACER, DRUM ROLLER
SPACER, DRUM ROLLER WCI 5304523154 Contact Us For Availability
View on Model
38
SHAFT, DRUM ROLLER, SHOULDER BOLT
SHAFT, DRUM ROLLER, SHOULDER BOLT WCI 5304523151 Contact Us For Availability
View on Model
39
HINGE ASSEMBLY, NEST
HINGE ASSEMBLY, NEST WCI 5304505133 Contact Us For Availability
View on Model
40
ROLLER WHEEL, ASSEMBLY, W/BEARING
ROLLER WHEEL, ASSEMBLY, W/BEARING WCI 5304523152 Contact Us For Availability
View on Model
45
BULKHEAD, PANEL, REAR
BULKHEAD, PANEL, REAR WCI 5304521407 Contact Us For Availability
View on Model
46
BRACKET, MOTOR
BRACKET, MOTOR WCI 5304525693 Contact Us For Availability
View on Model
48
FRAME, OUTER DOOR, WHITE
FRAME, OUTER DOOR, WHITE WCI 5304504997 Contact Us For Availability
View on Model
51
INSTALL KIT, STEAM DRYER, OPTIONAL, ACCESSORY
INSTALL KIT, STEAM DRYER, OPTIONAL, ACCESSORY WCI 5304495002 Contact Us For Availability
View on Model
51
SCREW, QUAD PH, 10-16 X 0.375
SCREW, QUAD PH, 10-16 X 0.375 WCI 137241000 Contact Us For Availability
View on Model
52
SCREW, COMB PAN HD, 1/4-14X.375
SCREW, COMB PAN HD, 1/4-14X.375 WCI 137573900 Contact Us For Availability
View on Model
54
CLAMP, DOOR GLASS, (2)
CLAMP, DOOR GLASS, (2) WCI 5304505012 Contact Us For Availability
View on Model
58
LAMP ASSEMBLY, DRUM, W/HARNESS
LAMP ASSEMBLY, DRUM, W/HARNESS WCI 5304521399 Contact Us For Availability
View on Model
60
BRACKET, SUPPORT, DRUM LAMP
BRACKET, SUPPORT, DRUM LAMP WCI 5304521476 Contact Us For Availability
View on Model
NIA
WCI 5304500486
WCI 5304500486 WCI 5304500486 Contact Us For Availability
View on Model
NIA
WCI 5304506746
WCI 5304506746 WCI 5304506746 Contact Us For Availability
View on Model
NIA
WCI 5304515364
WCI 5304515364 WCI 5304515364 Contact Us For Availability
View on Model
NIB
WCI 5304513601
WCI 5304513601 WCI 5304513601 Contact Us For Availability
View on Model
