Model Electrolux E30GF74TPSB RANGE/OVEN, GAS, FREESTANDING, 30 INCH – Common Parts &amp; Diagrams

2B

5304506549 Frigidaire Oven Valve In Stock WCI 5304506549 $41.01

2D

316272310 Frigidaire Oven Valve Backorder WCI 316272310 $105.91

5

318175506 Frigidaire Oven Screw Backorder WCI 318175506 $24.07

6

139006905 Frigidaire Oven Baffle Backorder WCI 139006905 $70.52

7

318372017 Frigidaire Insulation Backorder WCI 318372017 $10.22

7A

318372016 Frigidaire Insulation Backorder WCI 318372016 $11.13

8

139005002 Frigidaire Oven Panel Backorder WCI 139005002 $67.45

8

5304503232 Frigidaire Oven Inner Door Glass In Stock WCI 5304503232 $72.74

8

808608802 Frigidaire Oven Spark Ignition Four In Stock WCI 808608802 $51.59

9

139000411 Frigidaire Oven Liner Backorder WCI 139000411 $86.15

9

316081901 Frigidaire Oven Baking Pan Backorder WCI 316081901 $42.99

10

316438200 Frigidaire Range Sealed Burner, 5K In Stock WCI 316438200 $35.65

10

5303310510 Frigidaire Oven Screw Backorder WCI 5303310510 $8.91

10A

WASHER, HANDLE SCREW WCI 5304498487 Contact Us For Availability

10B

316438600 Frigidaire Range Sealed Burner, 14K Backorder WCI 316438600 $49.38

10D

5304501023 Frigidaire Burner Assembly In Stock WCI 5304501023 $98.61

11

316540800 Frigidaire Igniter/Orifice Assembly Backorder WCI 316540800 $7.02

11

807545502 Frigidaire Oven Seal Backorder WCI 807545502 $84.88

11B

316543204 Frigidaire Igniter Orifice Assembly Backorder WCI 316543204 $7.73

12

316540900 Frigidaire Oven Screw In Stock WCI 316540900 $8.89

13

807722601 Frigidaire Door Assembly Backorder WCI 807722601 $452.71

15

LAMP ASSEMBLY, HALOGEN, 26" HARNESS, W/G9 40W WCI 139001800 Contact Us For Availability

17

318264733 Frigidaire Oven Spacer Backorder WCI 318264733 $41.87

17

5303210798 Frigidaire Gas Safety Valve Range In Stock WCI 5303210798 $304.16

18

139077700 Frigidaire Burner Assembly Backorder WCI 139077700 $34.31

20

139005100 Frigidaire Oven Baffle Backorder WCI 139005100 $59.51

21

5303013272 Frigidaire Oven Nut Backorder WCI 5303013272 $11.11

22

5304508441 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508441 $20.05

22A

5304520332 Frigidaire Oven Cap Backorder WCI 5304520332 $59.51

22B

5304508443 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508443 $26.28

22C

5304508442 Frigidaire Oven Surface Burner Cap In Stock WCI 5304508442 $20.95

23

316575949 Frigidaire Hinge Backorder WCI 316575949 $21.39

24

5308015487 Frigidaire Oven Light Switch Backorder WCI 5308015487 $36.11

24

ELBOW, MIXER, BROIL WCI 316409703 Contact Us For Availability

25

BAFFLE, BROIL BURNER WCI 316401301 Contact Us For Availability

26

139013700 Frigidaire Igniter In Stock WCI 139013700 $103.76

26

5304452799 Frigidaire Oven Board Backorder WCI 5304452799 $194.44

26A

139013701 Frigidaire Igniter Backorder WCI 139013701 $103.32

29

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $7.57

31

316242002 Frigidaire Range Burner Seal In Stock WCI 316242002 $14.70

31

318242275 Frigidaire Oven Burner Knob In Stock WCI 318242275 $60.39

31A

316515203 Frigidaire Oven Seal Backorder WCI 316515203 $39.66

31B

316242000 Frigidaire Burner Seal Backorder WCI 316242000 $45.83

33

318242230 Frigidaire Oven Knob Backorder WCI 318242230 $75.38

36

5304509823 Frigidaire Grate Assembly Backorder WCI 5304509823 $55.96

37

5304504897 Frigidaire Oven Temperature Sensor In Stock WCI 5304504897 $26.72

39

5304534000 Frigidaire Cord Backorder WCI 5304534000 $19.59

39

HANDLE, DOOR, STAINLESS WCI 808992401 Contact Us For Availability

40

318242702 Frigidaire Oven Bracket Assembly Backorder WCI 318242702 $11.59

41

318370602 Frigidaire Oven Bracket Backorder WCI 318370602 $8.02

42

318382302 Frigidaire Bracket Backorder WCI 318382302 $29.87

43

316282700 Frigidaire Oven Screw Backorder WCI 316282700 $6.22

46

SHEILD, COOKTOP PANEL, LOWER WCI 5304498470 Contact Us For Availability

46A

318228310 Frigidaire Oven Lens In Stock WCI 318228310 $7.11

47

PANEL, SIDE, RH WCI 318241706 Contact Us For Availability

47A

PANEL, SIDE, LH WCI 318241707 Contact Us For Availability

48

PANEL, COOKTOP REAR WCI 5304509824 Contact Us For Availability

49

PANEL, SERVICE, FAN WCI 318578803 Contact Us For Availability

50

DEFLECTOR, BACKSPLASH, FRONT WCI 318537400 Contact Us For Availability

51

DEFLECTOR, BACKSPLASH, BLACK, REAR WCI 318537501 Contact Us For Availability

54

5304452797 Frigidaire Oven Control Backorder WCI 5304452797 $203.35

54A

5304452798 Frigidaire Oven Control Backorder WCI 5304452798 $200.49

56

5304480396 Frigidaire Screw Backorder WCI 5304480396 $7.11

59

139078002 Frigidaire Oven Duct Backorder WCI 139078002 $48.93

64

318165800 Frigidaire Oven Door Glass Spacer w Backorder WCI 318165800 $11.13

70

139000601 Frigidaire Oven Shield Backorder WCI 139000601 $41.86

72

316215600 Frigidaire Oven Screw Backorder WCI 316215600 $8.89

77A

316114100 Frigidaire Oven Spacer Backorder WCI 316114100 $37.90

86

318561100 Frigidaire Receptacle Backorder WCI 318561100 $12.46

89

5304528836 Frigidaire Motor Backorder WCI 5304528836 $45.40

91

BACKSPLASH, STAINLESS WCI 318533400 Contact Us For Availability

97

316519205 Frigidaire Oven Board In Stock WCI 316519205 $157.44

107

139013902 Frigidaire Oven Cover Assembly Backorder WCI 139013902 $78.91

108

318575612 Frigidaire Oven Cooling Fan Motor In Stock WCI 318575612 $116.62

109

318398302 Frigidaire Stove Oven Range Convect In Stock WCI 318398302 $15.13

111

316136600 Frigidaire Oven Range Lock Nut Backorder WCI 316136600 $12.01

119

807144901 Frigidaire Thermostat Backorder WCI 807144901 $34.31

125

139008601 Frigidaire Oven Motor Backorder WCI 139008601 $89.18

131

139078102 Frigidaire Oven Duct Backorder WCI 139078102 $40.11

161

139013800 Frigidaire Oven Element Backorder WCI 139013800 $51.14

165

DEFLECTOR, HEAT WCI 5304509834 Contact Us For Availability

272

139021700 Frigidaire Oven Tube Backorder WCI 139021700 $11.13

316021105 Frigidaire Oven Screw Backorder WCI 316021105 $7.11

316021109 Frigidaire Oven Screw In Stock WCI 316021109 $8.91

316483102 Frigidaire Oven Label Backorder WCI 316483102 $2.22

316566901 Frigidaire Oven Sleeve Backorder WCI 316566901 $7.57

5303271648 Frigidaire Oven Screw Backorder WCI 5303271648 $8.44

5303324184 Frigidaire Wall Oven Range Screw Backorder WCI 5303324184 $8.91

SCREW, CUP PT, 8-18 X 0.375, CHROME WCI 316021108 Contact Us For Availability

CLEANER, STAINLESS STEEL WCI 318163602 Contact Us For Availability

NUT, KEPS, 8-32, (2) WCI 5303325170 Contact Us For Availability

316001017 Frigidaire Screw Backorder WCI 316001017 $1.80

316089500 Frigidaire Oven Screw In Stock WCI 316089500 $8.46

316418900 Frigidaire Oven Screw In Stock WCI 316418900 $8.91

316418901 Frigidaire Oven Screw Backorder WCI 316418901 $8.91

318946400 Frigidaire Oven Bulb Backorder WCI 318946400 $32.07

5303289910 Frigidaire Oven Screw Backorder WCI 5303289910 $3.55

HARNESS, WIRING, IGNITOR MODULE WCI 5304515244 Contact Us For Availability
