Model LG DOTR12CBIV MWO-OTR – Common Parts & Diagrams
Diagram 0
Diagram 1
Diagram 2
Diagram 3
Diagram 4
Diagram 5
Diagram 6
Common parts from model LG DOTR12CBIV MWO-OTR
![PWB(PCB) ASSY,[MAIN]](https://d2923bgwwiylbi.cloudfront.net/media/catalog/product/placeholder/default/image-coming-soon.jpg)
PWB(PCB) ASSY,[MAIN] LGE 6871W2S152A Contact Us For Availability
2008
BRACKET,[CONTROL PANEL] LGE 4810W1P004A Contact Us For Availability
3000
CANOPY MICA LGE 3052W3M008B Contact Us For Availability
3001
Case,Flat LGE 3112W0F012G Contact Us For Availability
3002
Tray,Glass LGE 3390W1G004C Contact Us For Availability
3008
ROTATING RING ASSY A 0.9.1.0.1 LGE 5889W2A011A Contact Us For Availability
3008
Turntable Assembly LGE 5889W2A014B Contact Us For Availability
3009
MOTOR(CIRC),SYNCHRONOUS LGE 6549W1S013B Contact Us For Availability
3011
GLASS ALL MV-1320M MV-1325S W/ LGE 4890W4A001B Contact Us For Availability
3014
LEAD WIRE ASSY LGE 6877W2A003A Contact Us For Availability
3024
GRILLE LGE 3530W0A010B Contact Us For Availability
3025
BRACKET ALL MV-1320,C/TOP LAMP LGE 4810W3G100A Contact Us For Availability
3026
FILTER(MECH) LGE 5230W2A001A Contact Us For Availability
3028
LAMP[OVEN/BASELESS] LGE 6912W3Q001D Contact Us For Availability
3065
RESISTOR,CEMENT LGE 3B72552D Contact Us For Availability
4000
BOARD,LATCH LGE 3500W1A008A Contact Us For Availability
4001
BOARD ASSEMBLY,LATCH LGE 3501W1A003U Contact Us For Availability
4002
SWITCH,MICRO LGE 6600W1K004C Contact Us For Availability
4002
MICRO SWITCH(PRIMARY) VP-533A LGE 3B73362E Contact Us For Availability
4003
SWITCH,MICRO LGE 6600W1K004B Contact Us For Availability
4003
MICRO SWITCH(MONITOR) VP-532A LGE 3B73361D Contact Us For Availability
4005
MOUNTING ROD MV-1003T, MVH119 LGE 4B73423A Contact Us For Availability
5000
CAPACITOR,DRAWING[HIGH VOLTAGE LGE 0CZZW1H003G Contact Us For Availability
5002
BRACKET HVC MV-1320,SECC 0.5T LGE 4810W3C002A Contact Us For Availability
5006
DUCT LGE 5262W0A010A Contact Us For Availability
5007
PROPELLER LGE 2B72125A Contact Us For Availability
5008
Transformer,high voltage LGE 6170W1D002K Contact Us For Availability
5009
MAGNETRON LGE 2B71165N Contact Us For Availability
5009
MAGNETRON ALL LGE 2B71165K Contact Us For Availability
5010
POWER CORD ASSY LGE 6411W1A014H Contact Us For Availability
5014
LEAD WIRE ASSY LGE 6877W1A253B Contact Us For Availability
5020
BASE THERMOSTAT LGE 3B70068V Contact Us For Availability
5020
Thermostat LGE 6930W1A003M Contact Us For Availability
5035
PLATE,[BOTTOM] LGE 3300W1B003A Contact Us For Availability
5037
Filter,Charcoal LGE 5230W2A003B Contact Us For Availability
5038
LAMP HOLDER - ALL LGE 6804W3A001A Contact Us For Availability
5041
NOISE FILTER ASSY 100V 50/60HZ LGE 2B72130F Contact Us For Availability
5045
COVER,[LAMP COVER] LGE 3550W3L002A Contact Us For Availability
5049
GUIDE,[AIR] LGE 4974W1C001A Contact Us For Availability
6000
BASE PLATE-GRAY LGE 3302W0A023B Contact Us For Availability
6001
BASE PLATE ASSY LGE 3303W1A046B Contact Us For Availability
6008
PLATE ASSY LGE 3301W1A023A Contact Us For Availability
6011
EXHAUST DAMPER ER-841PV CBESE LGE 3B71432A Contact Us For Availability
× ![]()
