Model Electrolux CLCE900FW0 LAUNDRY CENTER – Common Parts &amp; Diagrams

1

131960800 Frigidaire Timer Backorder WCI 131960800 $167.57

3

131883301 Frigidaire Panel In Stock WCI 131883301 $165.61

3

WCI 131793302 WCI 131793302 Contact Us For Availability

4

131873401 Frigidaire Washer Control Knob In Stock WCI 131873401 $31.16

4

WCI 134149220 WCI 134149220 Contact Us For Availability

5

5303281019 Frigidaire Ball Assembly Backorder WCI 5303281019 $10.39

5

WCI 134399900 WCI 134399900 Contact Us For Availability

6

5303281020 Frigidaire Ball Clip In Stock WCI 5303281020 $10.85

6

WCI 131975300 WCI 131975300 Contact Us For Availability

7

131205300 Frigidaire Screw In Stock WCI 131205300 $7.56

7

3204490 Frigidaire Seal Backorder WCI 3204490 $9.04

7

Spring,boot retainer WCI 131277300 Contact Us For Availability

8

134803600 Frigidaire Washer Timer In Stock WCI 134803600 $282.92

8

WCI 3205245 WCI 3205245 Contact Us For Availability

9

WCI 134400000 WCI 134400000 Contact Us For Availability

10

134399700 Frigidaire Washer Switch In Stock WCI 134399700 $54.25

10

134611700 Frigidaire Housing Backorder WCI 134611700 $31.58

10

WCI 134224600 WCI 134224600 Contact Us For Availability

11

131276900 Frigidaire Washer Spring Assembly Backorder WCI 131276900 $13.59

11

Panel,door glass WCI 131278800 Contact Us For Availability

131476300 Frigidaire Dryer Blower Wheel In Stock WCI 131476300 $29.45

131825900 Frigidaire Dryer Rear Drum Bearing In Stock WCI 131825900 $2.81

134040800 Frigidaire Switch In Stock WCI 134040800 $41.68

WCI 134195900 WCI 134195900 Contact Us For Availability

13

131618600 Frigidaire Front Shell TUB+O/S2 Backorder WCI 131618600 $247.38

13

131724301 Frigidaire Dryer Drum Bearing Brack In Stock WCI 131724301 $8.14

13

WCI 134227100 WCI 134227100 Contact Us For Availability

14

131205400 Frigidaire Screw Backorder WCI 131205400 $8.15

14

131763302 Frigidaire Washer Door Strike In Stock WCI 131763302 $18.80

14

134144700 Frigidaire Washer Suspension Spring In Stock WCI 134144700 $38.09

131303900 Frigidaire Screw In Stock WCI 131303900 $9.95

134048800 Frigidaire Thermostat Control P1 Backorder WCI 134048800 $69.91

WCI 134437700 WCI 134437700 Contact Us For Availability

WCI 134202200 WCI 134202200 Contact Us For Availability

16

131618500 Frigidaire Spin Tub + O/S2 In Stock WCI 131618500 $572.07

16

131696300 Frigidaire Screw 10-16 X 0.312 Qu Backorder WCI 131696300 $6.34

16

Lamp,status light WCI 131724700 Contact Us For Availability

16A

Lens,status light ,clear WCI 131724800 Contact Us For Availability

17

131274600 Frigidaire Baffle Assembly In Stock WCI 131274600 $42.12

17

3204254 Frigidaire Baffle Assembly Backorder WCI 3204254 $81.58

17

Pin,panel locator WCI 131346400 Contact Us For Availability

131168200 Frigidaire Dryer Screw In Stock WCI 131168200 $9.04

131302800 Frigidaire Drum Vane Screw In Stock WCI 131302800 $8.65

Panel,service ,white ,front WCI 131279300 Contact Us For Availability

WCI 131413600 WCI 131413600 Contact Us For Availability

19

218362501 Frigidaire Refrigerator Screw Backorder WCI 218362501 $7.71

19

WCI 5303286537 WCI 5303286537 Contact Us For Availability

20

131303500 Frigidaire Screw Backorder WCI 131303500 $7.67

20

WCI 131288101 WCI 131288101 Contact Us For Availability

20

Bracket,top panel mtg. ,front WCI 131460900 Contact Us For Availability

21

131873304 Frigidaire Dryer Timer Knob White In Stock WCI 131873304 $37.65

21

WCI 134146100 No Longer Available

21

WCI 134122552 WCI 134122552 Contact Us For Availability

21A

WCI 131167601 WCI 131167601 Contact Us For Availability

21B

Spacer,washer ,timer shaft WCI 5308015493 Contact Us For Availability

Retainer,spring steel WCI 131279500 No Longer Available

3205241 Frigidaire Idler Spring Backorder WCI 3205241 $47.97

Screw,switch mtg ,6-32 x 0 .19 ,(2) ,sems WCI 3161259 Contact Us For Availability

WCI 131636280 WCI 131636280 Contact Us For Availability

23

5304507499 Frigidaire Washer Idler Pulley In Stock WCI 5304507499 $26.74

23

WCI 134125900 WCI 134125900 Contact Us For Availability

24

WCI 134086862 WCI 134086862 Contact Us For Availability

25

131658800 Frigidaire Dryer Door Catch Repair In Stock WCI 131658800 $39.43

25

134051000 Frigidaire Washer Drive Belt In Stock WCI 134051000 $7.74

25

WCI 131167701 WCI 131167701 Contact Us For Availability

26

134178901 Frigidaire Screw Backorder WCI 134178901 $9.50

26

WCI 131883400 WCI 131883400 Contact Us For Availability

27

134242400 Frigidaire Washer Clamp Assembly In Stock WCI 134242400 $11.76

27

5304516871 Frigidaire Replacement Filters Lin In Stock WCI 5304516871 $16.78

27

Washer,0.41 x 1.50 ,0.12 thick WCI 131304400 Contact Us For Availability

28

134196602 Frigidaire Washer Dryer Motor In Stock WCI 134196602 $153.02

28

WCI 131304500 WCI 131304500 Contact Us For Availability

29

131382300 Frigidaire Vane Screw Backorder WCI 131382300 $8.58

29

Screw,pulley mtg. ,m10 x 0.92 ,metric WCI 131303700 Contact Us For Availability

30

WCI 5304405283 WCI 5304405283 Contact Us For Availability

31

131202300 Frigidaire Screw Backorder WCI 131202300 $8.60

31

131268300 Frigidaire Leveling Pin In Stock WCI 131268300 $7.67

31

WCI 131288211 WCI 131288211 Contact Us For Availability

32

131777700 Frigidaire Dryer Bearing Drum In Stock WCI 131777700 $58.71

32

Bracket,shock mtg. WCI 131268100 Contact Us For Availability

33

3204267 Frigidaire Dryer Safety Thermostat In Stock WCI 3204267 $34.85

33

WCI 134812800 WCI 134812800 Contact Us For Availability

34

131243800 Frigidaire Screw Backorder WCI 131243800 $6.53

35

131892100 Frigidaire Screw Backorder WCI 131892100 $6.32

36

131841600 Frigidaire Washer Levelling Leg In Stock WCI 131841600 $18.58

36

131974700 Frigidaire Dispensing Valve Assembl In Stock WCI 131974700 $64.53

36

134120900 Frigidaire Dryer Limiter Thermal In Stock WCI 134120900 $3.43

37

131271600 Frigidaire Washer Dryer Tub Hose Backorder WCI 131271600 $56.92

37

WCI 131304200 WCI 131304200 Contact Us For Availability

38

WCI 131803710 WCI 131803710 Contact Us For Availability

39

WCI 131863300 WCI 131863300 Contact Us For Availability

41

134222900 Frigidaire Dryer Door Hinge In Stock WCI 134222900 $14.48

42

134156200 Frigidaire Screw Assembly In Stock WCI 134156200 $9.50

42

134737300 Frigidaire Clamp Assembly Backorder WCI 134737300 $12.85

43

WCI 131749200 WCI 131749200 Contact Us For Availability

43

WCI 131277500 WCI 131277500 Contact Us For Availability

44

131707800 Frigidaire Drain Hose Ring Backorder WCI 131707800 $28.33

44

137551901 Frigidaire Gasket Backorder WCI 137551901 $24.94

44

WCI 131786000 WCI 131786000 Contact Us For Availability

45

131306202 Frigidaire Clamp Backorder WCI 131306202 $7.43

45

134592700 Frigidaire Washer Drain Hose In Stock WCI 134592700 $56.49

45

WCI 131786100 WCI 131786100 Contact Us For Availability

46

131789400 Frigidaire Handle In Stock WCI 131789400 $46.47

46

WCI 134191412 WCI 134191412 Contact Us For Availability

48

5304536802 Frigidaire Hose Clamp Backorder WCI 5304536802 $2.42

48

WCI 134818201 WCI 134818201 Contact Us For Availability

48

WCI 131789303 WCI 131789303 Contact Us For Availability

49

134266500 Frigidaire Clamp Backorder WCI 134266500 $34.08

50

134535300 Frigidaire Insulator In Stock WCI 134535300 $38.09

52

WCI 134216300 WCI 134216300 Contact Us For Availability

54

WCI 131272100 WCI 131272100 Contact Us For Availability

55

WCI 131272000 WCI 131272000 Contact Us For Availability

56

WCI 131271910 WCI 131271910 Contact Us For Availability

58

Handle,dispenser ,with trim WCI 131729500 Contact Us For Availability

59

131843500 Frigidaire Washer Assembly Lamp Lig In Stock WCI 131843500 $46.16

59

Latch,drawer handle ,white WCI 131714900 Contact Us For Availability

60

WCI 131427500 WCI 131427500 Contact Us For Availability

NI

131592200 Frigidaire Upper Spring Sleeve Backorder WCI 131592200 $22.54

NI

5303161296 Frigidaire Washer Inlet Hose (1 Pi Backorder WCI 5303161296 $1,678.32
