Model Electrolux CGC4S7WUTB RANGE – Common Parts &amp; Diagrams

1

5308007974 Frigidaire Pressure Regulator Backorder WCI 5308007974 $179.46

1

WCI 3015688 WCI 3015688 Contact Us For Availability

1

WCI 3014536 WCI 3014536 Contact Us For Availability

1

WCI 8014033 WCI 8014033 Contact Us For Availability

1

BODYSIDE PNL-WHITE (2) WCI 3051061 Contact Us For Availability

1

BODYSIDE PNL. (ALMOND) (2) WCI A64013004 Contact Us For Availability

2

WCI 3201149 WCI 3201149 Contact Us For Availability

2

PANEL DRAWER WHITE WCI 3017049 Contact Us For Availability

2

WCI A98333004 WCI A98333004 Contact Us For Availability

2

WCI 8013906 WCI 8013906 Contact Us For Availability

2

GRATE WCI 3009309 Contact Us For Availability

2

LINER OVEN DOOR S/C WCI 3016972 Contact Us For Availability

2

SHIELD SIDE HEAT (2) WCI 3131794 Contact Us For Availability

2

MICRO SWITCH (2) WCI 3131846 Contact Us For Availability

3

KNOB CLOCK (3) WCI 3131756 Contact Us For Availability

3

HANDLE SPACER (2) WCI 3131778 Contact Us For Availability

3

WCI 3131856 WCI 3131856 Contact Us For Availability

3

WCI 8011431 WCI 8011431 Contact Us For Availability

3

WCI 3131762 WCI 3131762 Contact Us For Availability

3

INSULATOR (2) WCI 3017411 Contact Us For Availability

4

WCI 5303208186 WCI 5303208186 Contact Us For Availability

4

HANDLE DOOR WCI 08013882 Contact Us For Availability

4

WCI 3131099 WCI 3131099 Contact Us For Availability

4

PANEL MANIFOLD (4) WCI 3013590 Contact Us For Availability

4

WCI 3131761 WCI 3131761 Contact Us For Availability

4

BRACKET LOCK SWITCH WCI 3131843 Contact Us For Availability

4A

LINER RIGHT SIDE BRONZE WCI 3016533 Contact Us For Availability

4C

LINER LEFT SIDE BRONZE WCI 3016534 Contact Us For Availability

5

5303292012 Frigidaire Oven Screw Assembly Backorder WCI 5303292012 $8.60

5

WCI 08006417 WCI 08006417 Contact Us For Availability

5

NUT 3/8 LOXIT WCI 3131064 Contact Us For Availability

5

WCI 08013898 WCI 08013898 Contact Us For Availability

5

SHIELD DOOR WCI 08068072 Contact Us For Availability

5

WCI 08068030 WCI 08068030 Contact Us For Availability

6

WCI 3017632 WCI 3017632 Contact Us For Availability

6

TRACK DRAWER RH WCI 3051055 Contact Us For Availability

6

WCI 8068028 WCI 8068028 Contact Us For Availability

6

WCI 08013891 WCI 08013891 Contact Us For Availability

6

SHIELD OVEN DR. HEAT WCI 3131764 Contact Us For Availability

6

SUPPORT CONTROL PNL WCI 3131811 Contact Us For Availability

6

COVER-CONTROL VALVE WCI 3016970 Contact Us For Availability

6A

TRACK DRAWER LH WCI 3051056 Contact Us For Availability

7

318348801 Frigidaire Oven Left Side Door Hing In Stock WCI 318348801 $50.71

7

WCI 08015488 WCI 08015488 Contact Us For Availability

7

WCI 08011442 WCI 08011442 Contact Us For Availability

7

WCI 9126 WCI 9126 Contact Us For Availability

7

GLASS OUTER BLACK WCI 3131765 Contact Us For Availability

7

WCI 08068040 WCI 08068040 Contact Us For Availability

7A

HINGE OVEN DOOR LEFT WCI 3204670 Contact Us For Availability

8

318088400 Frigidaire Oven Spring Assembly In Stock WCI 318088400 $68.57

8

BRACE SUPPORT (2) WCI 08013296 Contact Us For Availability

8

WCI 3051057 WCI 3051057 Contact Us For Availability

8

WCI 08008002 WCI 08008002 Contact Us For Availability

8

WCI 5308011492 WCI 5308011492 Contact Us For Availability

8

WCI 08013880 WCI 08013880 Contact Us For Availability

8

SHIELD BNR BOX RIGHT WCI 3131053 Contact Us For Availability

8A

SHIELD BNR BOX LEFT WCI 3131054 Contact Us For Availability

9

5308015487 Frigidaire Oven Light Switch Backorder WCI 5308015487 $36.70

9

VALVE TOP BURNERS (4) WCI 3131057 Contact Us For Availability

9

TRIM OVEN DOOR WCI 3131769 Contact Us For Availability

9

KNOB HANDLE WCI 3131851 Contact Us For Availability

9A

WCI 3016874 WCI 3016874 Contact Us For Availability

WCI 3015248 WCI 3015248 Contact Us For Availability

WCI 3131096 WCI 3131096 Contact Us For Availability

CLIP OVEN DOOR (2) WCI 08068068 Contact Us For Availability

LEG LEVELER (4) WCI AP059009 Contact Us For Availability

WCI 08068025 WCI 08068025 Contact Us For Availability

WCI 08008009 WCI 08008009 Contact Us For Availability

BURNER FRONT TOP (2) WCI 3131080 Contact Us For Availability

RUBBER BUMPER (6) WCI 3017414 Contact Us For Availability

RAIL - BASE (2) WCI 08068047 Contact Us For Availability

WCI 3131853 WCI 3131853 Contact Us For Availability

5300806846 Frigidaire Dishwasher Insulator Backorder WCI 5300806846 $2.00

5303912606 Frigidaire Oven Range Spark Module In Stock WCI 5303912606 $82.86

BURNER REAR TOP (2) WCI 3131079 Contact Us For Availability

WCI 08013865 WCI 08013865 Contact Us For Availability

12A

BNR BOX BTM BRONZE WCI 3016971 Contact Us For Availability

WCI 08008255 WCI 08008255 Contact Us For Availability

IGNITER TOP (2) WCI 3016869 Contact Us For Availability

WCI 3131774 WCI 3131774 Contact Us For Availability

WCI 08008051 WCI 08008051 Contact Us For Availability

RECEPTACLE-BACKGUARD (2) WCI 08008075 Contact Us For Availability

SUPPORT TOP BNR (2) WCI 3016870 Contact Us For Availability

LINING OVEN BOTTOM WCI 3131820 Contact Us For Availability

WCI 08068049 WCI 08068049 Contact Us For Availability

15

WCI 8013925 WCI 8013925 Contact Us For Availability

15

WCI 3015714 WCI 3015714 Contact Us For Availability

16

BRACKET CLOCK MTG WCI 08008076 Contact Us For Availability

16

WCI 8009420 WCI 8009420 Contact Us For Availability

16A

PAN BROILER BRONZE WCI 3016973 Contact Us For Availability

17

WCI 08007925 WCI 08007925 Contact Us For Availability

17

WCI 3131860 WCI 3131860 Contact Us For Availability

17A

5304442087 Frigidaire Range Wall Oven Broil P Backorder WCI 5304442087 $33.26

18

PANEL - BACK WCI 08013966 Contact Us For Availability

18

RETAINER OVEN LIGHT LENS WCI AP309003 Contact Us For Availability

19

5304524341 Frigidaire Lens In Stock WCI 5304524341 $9.87

19

WCI 08008071 WCI 08008071 Contact Us For Availability

19

TUBE BROIL FEED WCI 3131866 Contact Us For Availability

20

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $10.61

20

WCI 3017415 WCI 3017415 Contact Us For Availability

21

BAFFLE BROILER BURNER WCI 08011508 Contact Us For Availability

21

SOCKET HOUSING WCI 3016399 Contact Us For Availability

22

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $40.25

22

WCI 8011470 WCI 8011470 Contact Us For Availability

23

WCI 3051511 WCI 3051511 Contact Us For Availability

23

SHIELD IGNITER WCI 3131871 Contact Us For Availability

24

WCI 3131873 WCI 3131873 Contact Us For Availability

24A

LINER OVEN BACK BRONZE WCI 3200915 Contact Us For Availability

25

5303935067 Frigidaire Range Oven Flat Igniter In Stock WCI 5303935067 $49.63

25

WCI 08011509 WCI 08011509 Contact Us For Availability

26

WCI 3131802 WCI 3131802 Contact Us For Availability

27

WCI 3131800 WCI 3131800 Contact Us For Availability

28

VENT BOX ASSY BRONZE WCI 3016877 Contact Us For Availability

29

WCI 3131041 WCI 3131041 Contact Us For Availability

30

SHIELD STORAGE DWR WCI 08068050 Contact Us For Availability

31

LINER OVEN TBTM WCI 3016875 Contact Us For Availability

32

BAFFLE BAKE BURNER WCI 3131823 Contact Us For Availability

33A

OVEN BOTTOM PL. BRONZE WCI 3016975 Contact Us For Availability

34

WCI 3201170 WCI 3201170 Contact Us For Availability

35

COVER CONTROL VALVE WCI 08068039 Contact Us For Availability

36

SUPPORT CONTROL VALVE WCI 3131831 Contact Us For Availability

37

BACK MAIN 30 S/C WCI 3131833 Contact Us For Availability

38

Support,oven rear WCI 3051096 Contact Us For Availability

39

WCI 08068038 WCI 08068038 Contact Us For Availability

40

THERMOSTAT BAKE BROIL SELECT WCI 3131839 Contact Us For Availability

41

CLIP,BODYSIDE WCI 3131791 Contact Us For Availability

42

GROMMET PLASTIC WCI 3051063 Contact Us For Availability

43

GROMMET MAIN TOP WCI 3016129 Contact Us For Availability

44

INSUL. OV. WRAP WCI 3131795 Contact Us For Availability

44A

INSUL. OV. TOP & BOTTOM WCI 3131840 Contact Us For Availability

45

CHANNEL MAIN BACK WIRE WCI 3131046 Contact Us For Availability

46

WCI 08068046 WCI 08068046 Contact Us For Availability
