Model Accelerated Cooking Products AXP22TLT-P2005602M Amana Menumaster AXP22TLT – Common Parts &amp; Diagrams

1

14114053 Amana Stirrer Cover and Antenna Kit Backorder ACP 14114053 $388.92

1

20208401 Amana Oven Harness Backorder ACP 20208401 $286.44

1

RETAINER-HTR INSUL ACP 21007301 Contact Us For Availability

1

ESCUTCHEON- TOP ACP 13098505 Contact Us For Availability

2

12991605 Amana Screw TC/HEX ROHS Backorder ACP 12991605 $4.82

2

DUCT-LH ACP 13087603 Contact Us For Availability

2

WIRE, JUMPER - MAG FA TO CAP ACP 13017713 Contact Us For Availability

3

12990529 Amana Hex Screw Backorder ACP 12990529 $4.82

3

13074001 Amana RoHS TORX Pan Head Screw Backorder ACP 13074001 $5.31

3

13087301 Amana Control Board to Filter Board Backorder ACP 13087301 $35.11

3

14169104 Amana Antenna Motor and Gears Kit Backorder ACP 14169104 $58.26

3

59002076 Amana Convection Motor Assembly Backorder ACP 59002076 $1,753.08

3

59002125 Amana Top Convection Element Backorder ACP 59002125 $292.32

4

59204719 Amana J5 Connector Harness Backorder ACP 59204719 $116.76

4

DUCT-RH ACP 13087102 Contact Us For Availability

4

BOTTOM-PLENUM ACP 21004702 Contact Us For Availability

4

OUTER PANEL, TOP ACP 59002136 Contact Us For Availability

5

13077702 Amana Plenum Nozzle Gasket Backorder ACP 13077702 $9.41

5

13077902 Amana Plenum Return Gasket Backorder ACP 13077902 $15.54

5

14169110 Amana Control Assembly Kit AXP/MXP Backorder ACP 14169110 $1,666.49

5

R0000413 Amana Base Pan Gasket 90 Inch In Stock ACP R0000413 $41.34

5

INSULATION-TOP/SIDES CAVITY ACP 13084602 Contact Us For Availability

5

OUTER PANEL, LEFT SIDE ACP 59002138 Contact Us For Availability

5

CABLE, ETHERNET ACP 59164514 Contact Us For Availability

6

59001682 Amana Fuse Block, 3 Pole Backorder ACP 59001682 $18.70

6

PLATE-R PLENUM ACP 21005001 Contact Us For Availability

6

TAPE-DUCT ACP M0275089 Contact Us For Availability

7

M0805105 Amana 12 AMP Fuse In Stock ACP M0805105 $3.54

7

PLATE-TOP PLENUM ACP 21004802 Contact Us For Availability

7

WIRE-JUMPER ACP 13017726 Contact Us For Availability

8

10091101 Amana Fuse Holder Backorder ACP 10091101 $7.53

8

PLATE-L PLENUM ACP 21004901 Contact Us For Availability

8

OC BACK WELD ACP 13081916 Contact Us For Availability

8

STRAP, GROUND- CONTROL TO ESC ACP 21032602 Contact Us For Availability

9

M0805201 Amana Fuse In Stock ACP M0805201 $5.31

9

CONVERTER - CATALYTIC ACP 59204723 Contact Us For Availability

9

HOOD-EXHAUST ACP 59194639 Contact Us For Availability

9

24"H CART ACP CA24 Contact Us For Availability

12002874 Amana Bottom Element Kit Backorder ACP 12002874 $315.04

12992302 Amana RoHS Hex Head Screw Backorder ACP 12992302 $4.82

59174520 Amana TRIAC (40A) & Snubber Kit In Stock ACP 59174520 $54.35

OUTER PANEL, RIGHT SIDE ACP 59002137 Contact Us For Availability

30"H CART ACP CA30 Contact Us For Availability

14119054 Amana Left Waveguide Kit Backorder ACP 14119054 $656.88

59154429 Amana Air Filter In Stock ACP 59154429 $76.04

B5677215 Amana Terminal Block Backorder ACP B5677215 $6.55

SCREW-TR/ROUND RoHS ACP 13042202 Contact Us For Availability

XPRESS OVEN SAMPLE CLEANER KIT ACP CK10 Contact Us For Availability

12

14119055 Amana Waveguide Kit - RH Backorder ACP 14119055 $656.88

12

B5677214 Amana Terminal Block Backorder ACP B5677214 $6.17

12

CL10 Amana Xpress Oven Cleaner (6) 1 Liter Backorder ACP CL10 $85.48

13

59001981 Amana Relay Backorder ACP 59001981 $39.61

13

SCREW-MACH/SHLD (RACK SUPPORT) ACP 59224797 Contact Us For Availability

13

PANINI GRILL FOR XP XPRESS OVENS ACP GR10 Contact Us For Availability

14169111 Amana Inner Door Backorder ACP 14169111 $547.68

20176201 Amana Threaded Spacer Backorder ACP 20176201 $22.90

59002017 Amana Snubber Assembly Backorder ACP 59002017 $36.09

LG10 Amana Oven Leg Kit for XP Xpress Backorder ACP LG10 $110.43

15

59002140 Amana Oven Rack Backorder ACP 59002140 $126.84

15

59174519 Amana Mechanical Cavity Thermal Cuto Backorder ACP 59174519 $159.60

15

13.87" (352 mm) x 13.87" (352 mm) Non-Stick B ACP OB10 Contact Us For Availability

16

59004077 Amana Gasket per Foot Backorder ACP 59004077 $1.23

16

59164513 Amana Element Cover Backorder ACP 59164513 $125.16

16

PA10 Amana Oven Paddle Backorder ACP PA10 $183.88

17

59002124 Amana High Voltage Transformer Backorder ACP 59002124 $294.84

17

SB10 Amana Inner Bin Backorder ACP SB10 $193.59

17

NUT -#8 KEPS ACP 13045502 Contact Us For Availability

18

SH10 Amana Oven Shield 1 Liter Backorder ACP SH10 $100.26

18

CLIP-CORD ACP M0104106 Contact Us For Availability

19

59224798 Amana Primary Switch and Boot Backorder ACP 59224798 $54.45

19

ALUMINUM PAN FOR XP XPRESS OVENS ACP SQ10 Contact Us For Availability

20

ST10X Amana Pizza Stone Backorder ACP ST10X $298.92

21

20241404 Amana Thermal Cutout Switch Backorder ACP 20241404 $8.15

21

TB10 Amana 10" x 12" (254 mm x 305 mm) Backorder ACP TB10 $159.40

21

SCREW-TC/SOCKET TORX ACP 20095801 Contact Us For Availability

59004010 Amana Magnetron In Stock ACP 59004010 $120.83

DUCT-MAGNETRON ACP 21007102 Contact Us For Availability

GASKET, PER FT ACP 59002162 Contact Us For Availability

SET OF 4 NON-STICK LINERS FOR XP XPRESS OVENS ACP TL10T Contact Us For Availability

23

TL10T2 Amana Non-Stick Liners Backorder ACP TL10T2 $67.92

23

VENT, CAVITY STEAM ACP 13078001 Contact Us For Availability

24

14189151 Amana Fuse and Switches Kit In Stock ACP 14189151 $285.51

24

ACP PRODUCT LITERATURE WEBKEY ACP WK10 Contact Us For Availability

25

12990522 Amana Screw SM/HEX RoHS Backorder ACP 12990522 $4.82

25

59174578 Amana Main Control Board In Stock ACP 59174578 $683.78

25

XP XPRESS PANINI PRESS ACP PRS10 Contact Us For Availability

26

59004001 Amana Power Cord Backorder ACP 59004001 $74.00

27

14149088 Amana Fan Motor Kit In Stock ACP 14149088 $273.87

27

SCREW-SM/HEX RoHS ACP 12990515 Contact Us For Availability

28

59204716 Amana Power Supply Board (24V DC) Backorder ACP 59204716 $206.64

28

PCB SUPPORTS (10) & SCREWS (10) ACP 59174558 Contact Us For Availability

30

59001709 Amana Temperature Sensor Backorder ACP 59001709 $26.71

31

59154448 Amana Foam Tape (1 Roll) Backorder ACP 59154448 $56.55

32

INSUL RETAINER WELD ACP 20004202Q Contact Us For Availability

34

PLATE-L HINGE PARTITION ACP 21005904 Contact Us For Availability

35

14179138 Amana Kit - Studs and Hardware Backorder ACP 14179138 $23.17

36

PLATE-R HINGE PARTITION ACP 21073602 Contact Us For Availability

37

59194677 Amana Door Hinge Set of Two Backorder ACP 59194677 $374.11

37

SEAL-HINGE ACP 13087001 Contact Us For Availability

38

59174542 Amana Capacitor and Diode Kit Backorder ACP 59174542 $56.46

38

A4055406 Amana Capacitor Strap Backorder ACP A4055406 $5.09

38

SCREW-SM/HEX RoHS ACP 12990524 Contact Us For Availability

39

RESISTORS- FAN ACP 59174565 Contact Us For Availability
