Model Samsung AW15ECB7XAA Air Conditioner – Common Parts & Diagrams
AIR CONDITIONER ASSY
Common parts from model Samsung AW15ECB7XAA Air Conditioner
1-3
Blade SMG DB66-00550B Contact Us For Availability
1-4
Blade-v,b SMG DB66-00551A Contact Us For Availability
1-5
SMG DB66-00552A SMG DB66-00552A Contact Us For Availability
1-6
Link Blade SMG DB66-00550A Contact Us For Availability
1-7
Blade SMG DB61-01524A Contact Us For Availability
2
Frame Blade SMG DB63-00807C Contact Us For Availability
3
Room Air Conditioner Air Filter SMG DB66-00553B Contact Us For Availability
4
Lever Damper SMG DB96-05580A Contact Us For Availability
5
Evaporator Assembly SMG DB94-00916A Contact Us For Availability
6
Plate Assembly SMG 6021-001142 Contact Us For Availability
7
Nut-hexago SMG DB67-00096A Contact Us For Availability
8
Air Conditioner Blower SMG DB61-02591A Contact Us For Availability
9
Case Evaporator SMG DB94-00915A Contact Us For Availability
10
Assy Parti SMG DB62-04231A Contact Us For Availability
11
Pipe Cover SMG DB61-01496A Contact Us For Availability
13
Fan Probe SMG DB60-30028A Contact Us For Availability
14
Nut Washer SMG DB61-01580B Contact Us For Availability
15
Case Condenser SMG DB96-02954F Contact Us For Availability
16
Condenser SMG DB92-00109A Contact Us For Availability
17
Assy Shutt SMG DB90-01217D Contact Us For Availability
18
Cabinet SMG DB64-01020A Contact Us For Availability
19
Shutter-an SMG DB92-00108A Contact Us For Availability
20
Assy Shutt SMG DB62-02469E Contact Us For Availability
21
Discharge Tube SMG DB62-02470C Contact Us For Availability
22
Suction Tube SMG 44B135HXAEL Contact Us For Availability
24
F/rotary C SMG DB63-00765A Contact Us For Availability
25
Gasket SMG DB63-00762A Contact Us For Availability
26
r/c SMG 6021-000124 Contact Us For Availability
26-1
Terminal Cover SMG DB61-02968A Contact Us For Availability
27
Nut-hexago SMG DB63-00763A Contact Us For Availability
29
Grommet SMG DB93-03018V Contact Us For Availability
31
Overload Protector SMG DB90-01215C Contact Us For Availability
32
Room Air Conditioner Remote Control SMG DB97-90014X Contact Us For Availability
33
Base Assembly SMG DB61-30219F Contact Us For Availability
34
Installation SMG DB31-00236A Contact Us For Availability
35
Bracket SMG DB70-00342A Contact Us For Availability
36
Room Air Conditioner Fan Motor SMG DB64-00891B Contact Us For Availability
37
Plate-rein SMG DB93-04301C Contact Us For Availability
37-1
Cabinet-re SMG DB61-01527A Contact Us For Availability
37-2
Control Assembly SMG DB61-01525A Contact Us For Availability
37-7
Thermistor SMG DB93-04822F Contact Us For Availability
37-8
Capacitor SMG DB64-00911A Contact Us For Availability
37-9
AC Power Cord SMG DB64-01714A Contact Us For Availability
NI
Inlay SMG DB81-00656A Contact Us For Availability
NI
Transformer SMG DB97-02973A Contact Us For Availability
× ![]()
