Model Electrolux AS147R1A1 ROOM AIR CONDITIONER – Common Parts & Diagrams
Common parts from model Electrolux AS147R1A1 ROOM AIR CONDITIONER
*49821
NAMEPLATE-GRILLE WCI 5303271448 Contact Us For Availability
*49823
WCI 5303012110 WCI 5303012110 Contact Us For Availability
1
WCI 5303015315 WCI 5303015315 Contact Us For Availability
1
BULKHEAD - CONTROL WCI 3015296 Contact Us For Availability
1
WCI 5303017346 WCI 5303017346 Contact Us For Availability
1
WCI 5303925103 WCI 5303925103 Contact Us For Availability
1
WCI 5303002608 WCI 5303002608 Contact Us For Availability
2
FRAME-HORIZ. LOUVER WCI 5308017160 Contact Us For Availability
2
WCI 5303015297 WCI 5303015297 Contact Us For Availability
2
BULKHEAD - AIR WCI 3015295 Contact Us For Availability
2
WCI 5303017776 WCI 5303017776 Contact Us For Availability
2
GROMMET WCI 5303015945 Contact Us For Availability
2
ANGLE-STOP WCI 5303018951 Contact Us For Availability
3
VERTICAL LOUVER & LINK ASSY WCI 5303002459 Contact Us For Availability
3
WCI 08002968 WCI 08002968 Contact Us For Availability
3
SHROUD-CONDENSER UPPER WCI 5303015305 Contact Us For Availability
3
WCI 5303208581 WCI 5303208581 Contact Us For Availability
3
NUT (PLASTIC) WCI 5303015946 Contact Us For Availability
3
CLIP-PANEL WCI 5303001821 Contact Us For Availability
4
WCI 5303002162 WCI 5303002162 Contact Us For Availability
4
CABLE-DOOR VENT WCI 5303015298 Contact Us For Availability
4
SHROUD-CONDENSER LOWER WCI 5303015304 Contact Us For Availability
4
WCI 5303015595 WCI 5303015595 Contact Us For Availability
4
GASKET-COVER WCI 3206231 Contact Us For Availability
4
WCI 5303001820 WCI 5303001820 Contact Us For Availability
5
WCI 5303002163 WCI 5303002163 Contact Us For Availability
5
BRACKET-ACTUATOR WCI 5303202999 Contact Us For Availability
5
WCI 5303208665 WCI 5303208665 Contact Us For Availability
5
WCI 3206230 WCI 3206230 Contact Us For Availability
5
WCI 3001980 WCI 3001980 Contact Us For Availability
5A
ARM-ACTUATOR (NON-ILLUSTRATED) WCI 5303015299 Contact Us For Availability
6
CLIP-DETENT WCI 5303001844 Contact Us For Availability
6
SEAL WCI 3016696 Contact Us For Availability
6
WCI 3016219 WCI 3016219 Contact Us For Availability
6
WCI 5303211017 WCI 5303211017 Contact Us For Availability
6
SIDE - ANGLE WCI 3002059 Contact Us For Availability
7
WCI 3202502 WCI 3202502 Contact Us For Availability
7
CLIP-FRONT TO BASE WCI 5308010914 Contact Us For Availability
7
WCI 3016763 WCI 3016763 Contact Us For Availability
7
BRACKET-SHROUD TO BULKHEAD WCI 5303015306 Contact Us For Availability
7
WCI 5303016697 WCI 5303016697 Contact Us For Availability
7
SUPPORT-RH WCI 3016224 Contact Us For Availability
8
HINGE - DOOR WCI 5303017980 Contact Us For Availability
8
SWITCH, SELECT WCI 5303208666 Contact Us For Availability
8
WCI 5303017959 WCI 5303017959 Contact Us For Availability
8
KIT-START WCI 5303201723 Contact Us For Availability
8
BRACKET - WINDOW WCI 3001815 Contact Us For Availability
9
WCI 08017131 WCI 08017131 Contact Us For Availability
9
CONTROL WCI 5303015319 Contact Us For Availability
9
WCI 5303015309 WCI 5303015309 Contact Us For Availability
9
SCREW (2) WCI 3007756 Contact Us For Availability
10
SPACER - DIAL PLATE WCI 5303001775 Contact Us For Availability
10
SCREW-CONTROL SWITCH WCI 5303007754 Contact Us For Availability
10
SCROLL-EVAPORATOR WCI 5303015310 Contact Us For Availability
10
NUT-LOCKING (2) WCI 3007759 Contact Us For Availability
11
SEAL - DIAL PLATE WCI 5303001984 Contact Us For Availability
11
HARNESS-WIRE WCI 5303017345 Contact Us For Availability
11
SEAL WCI 5303015311 Contact Us For Availability
11
SUPPORT-LH WCI 3016225 Contact Us For Availability
12
WCI 5303212747 WCI 5303212747 Contact Us For Availability
12
WCI 5303015313 WCI 5303015313 Contact Us For Availability
13
WCI 5303002189 WCI 5303002189 Contact Us For Availability
13
INSULATION-COVER WCI 3015314 Contact Us For Availability
13
SCREW (4) WCI 3002735 Contact Us For Availability
14
WCI 5300331902 WCI 5300331902 Contact Us For Availability
14
SPACER-CONTROL BULB WCI 5303211009 Contact Us For Availability
14
WCI 3001819 WCI 3001819 Contact Us For Availability
14A
SCREW-MTG FRONT (NON-ILLUSTRATED) WCI 5308008175 Contact Us For Availability
15
SERVICE CORD WCI 5308017362 Contact Us For Availability
15
WCI 3001818 WCI 3001818 Contact Us For Availability
16
WCI 5303019026 WCI 5303019026 Contact Us For Availability
16
WCI 3002058 WCI 3002058 Contact Us For Availability
16A
BRACKET-FRONT (NON-ILLUSTRATED) WCI 5303016223 Contact Us For Availability
17
WCI 5303015323 WCI 5303015323 Contact Us For Availability
17
WCI 3002803 WCI 3002803 Contact Us For Availability
17A
SCREW-TRIM (8) (NON-ILLUSTRATED) WCI 3001802 Contact Us For Availability
18
WCI 5300124806 WCI 5300124806 Contact Us For Availability
18
SCREW TOP ANGLE (4) WCI 8012680 Contact Us For Availability
19
WCI 5303017979 WCI 5303017979 Contact Us For Availability
19
INSULATION-VERTICAL DIVIDER WCI 3015321 Contact Us For Availability
19
SEAL - CHASSIS, BOTTOM WCI 5303212504 Contact Us For Availability
20
WCI 5300454302 WCI 5300454302 Contact Us For Availability
20A
WCI 5303017314 WCI 5303017314 Contact Us For Availability
20B
NAMEPLATE (NON-ILLUSTRATED) WCI 5300138101 Contact Us For Availability
21
GRILLE-REAR WCI 5303210207 Contact Us For Availability
× ![]()
