Model Accelerated Cooking Products AMSO35-P2003917M Amana Menumaster AMSO35 – Common Parts &amp; Diagrams

1

20167901 Amana Right Hinge Bracket Weld Backorder ACP 20167901 $75.36

1

59164485 Amana Primary Switch Assembly Backorder ACP 59164485 $70.04

1

59174552 Amana Motor Assembly, Blower MSO60 Backorder ACP 59174552 $262.24

1

ACTUATOR-SWITCH ACP 20168301 Contact Us For Availability

1

BRKT-DIVIDER ACP 21032002 Contact Us For Availability

1

INTLK BRKT ASSY-LEFT ACP 59164495 Contact Us For Availability

1

PLENUM ACP 21027102 Contact Us For Availability

1

HARNESS, MAIN ACP 20309201 Contact Us For Availability

1

ENDCAP-L ESC ACP 20145401 Contact Us For Availability

2

10091101 Amana Fuse Holder Backorder ACP 10091101 $7.34

2

12990522 Amana Screw SM/HEX RoHS Backorder ACP 12990522 $5.14

2

59144395 Amana Bottom Ceramic Tray Backorder ACP 59144395 $334.73

2

59174541 Amana Capacitor Kit and Diode - .90 Backorder ACP 59174541 $49.08

2

SCREW ACP 12876603 Contact Us For Availability

2

SEAL-DOOR ARM ACP 20148501 Contact Us For Availability

2

CAP-SCREW ACP M0308801 Contact Us For Availability

2

HARNESS-LV ACP 20167401 Contact Us For Availability

3

59144403 Amana HV Transformer Backorder ACP 59144403 $187.95

3

59164486 Amana Main Control Board Backorder ACP 59164486 $642.61

3

COVER-DIAPHRAM ACP 10990601 Contact Us For Availability

3

SPRING-HINGE ACP 20142301 Contact Us For Availability

3

SPACER-.44 NYLON ACP 20020106 Contact Us For Availability

3

HARNESS-PC BOARD ACP 20168901 Contact Us For Availability

3

COVER, USB ACP 59144391 Contact Us For Availability

3

WRAPPER ACP 59144401 Contact Us For Availability

4

20142201 Amana Roller Backorder ACP 20142201 $16.22

4

20175801 Amana Door Latch Arm Backorder ACP 20175801 $34.37

4

59144390 Amana USB Board Backorder ACP 59144390 $174.53

4

59164516 Amana Cavity Thermal Cutout Backorder ACP 59164516 $42.78

4

M0805205 Amana 30A Fuse In Stock ACP M0805205 $7.46

4

COVER-EXH BLOWER ACP 21079602 Contact Us For Availability

4

COVER-HOLE ACP 20151801 Contact Us For Availability

4

PCB SUPPORTS (10) & SCREWS (10) ACP 59174558 Contact Us For Availability

4

HEX KEY- 2mm ACP 59144402 Contact Us For Availability

4

SCREW-SM/OVAL ACP 20151701 Contact Us For Availability

5

12991605 Amana Screw TC/HEX ROHS Backorder ACP 12991605 $5.14

5

59164481 Amana Antenna Shield and Rivets Backorder ACP 59164481 $434.97

5

A4055406 Amana Capacitor Strap Backorder ACP A4055406 $5.42

5

A4539619 Amana Pop Rivet Backorder ACP A4539619 $5.14

5

PLUG-HOLE ACP 20147401 Contact Us For Availability

5

SCREW-TC/PAN ACP 13041802 Contact Us For Availability

5

ROLLER BRKT ASSY ACP 20152701 Contact Us For Availability

5

GROMMET-RUBBER ACP 20095701 Contact Us For Availability

5

PCB BRKT ASSY ACP 20168201 Contact Us For Availability

5

SEALANT-THREAD LOCK ACP M0910008 Contact Us For Availability

6

20147301 Amana Shoulder Bolt Backorder ACP 20147301 $5.14

6

54116064 Amana Rivet Assembly Backorder ACP 54116064 $12.46

6

59164489 Amana Display Board Backorder ACP 59164489 $269.40

6

DUCT-EXHAUST ACP 21025402 Contact Us For Availability

6

WIRE, JUMPER-RED (12 in / 30 cm) ACP 13017723 Contact Us For Availability

6

SPACER-.38 NYLON ACP 20020102 Contact Us For Availability

7

59001981 Amana Relay Backorder ACP 59001981 $41.13

7

59004010 Amana Magnetron In Stock ACP 59004010 $118.14

7

59144396 Amana Ceramic Shelf Divider Backorder ACP 59144396 $194.22

7

59154442 Amana Touch Panel Assembly Backorder ACP 59154442 $327.57

7

SCREW-MACH/HEX ACP 20163302 Contact Us For Availability

7

INTLK BRKT ASSY-RIGHT ACP 59164494 Contact Us For Availability

7

WIRE, JUMPER- WHITE (18 in / 45 cm) ACP 13017725 Contact Us For Availability

7

SCREW-SM/HEX RoHS ACP 12990512 Contact Us For Availability

8

20241404 Amana Thermal Cutout Switch Backorder ACP 20241404 $8.36

8

59204722 Amana Door Assembly Backorder ACP 59204722 $625.61

8

M0322202 Amana Tie Wire Backorder ACP M0322202 $5.14

8

R0000413 Amana Base Pan Gasket 90 Inch In Stock ACP R0000413 $43.09

8

CLIP-CORD ACP M0104106 Contact Us For Availability

8

BRKT-ENCODER BD ACP 21027401 Contact Us For Availability

8

SCREEN-EXH DUCT ACP 20152501 Contact Us For Availability

9

54116050 Amana HV Fuse Backorder ACP 54116050 $12.55

9

59144389 Amana Encoder Board Backorder ACP 59144389 $126.20

9

59174520 Amana TRIAC (40A) & Snubber Kit In Stock ACP 59174520 $57.41

9

NAMEPLATE,AM ACP 20272708 Contact Us For Availability

9

SCREW-TC/SOCKET TORX ACP 20095801 Contact Us For Availability

9

CHANNEL-EXH DUCT ACP 21027302 Contact Us For Availability

20094901 Amana Grille Magnet Backorder ACP 20094901 $12.71

A3293506 Amana Snap Bushing Backorder ACP A3293506 $5.14

SWITCH ACP 59244835 Contact Us For Availability

BOX-BLOWER ACP 21025002 Contact Us For Availability

ENDCAP-R ESC ACP 20145301 Contact Us For Availability

CHANNEL-EXH DUCT ACP 21027202 Contact Us For Availability

20114401 Amana Control Knob Backorder ACP 20114401 $6.93

21027502 Amana Air Inlet Grille Backorder ACP 21027502 $35.53

SCREW-TC/HEX ACP 12991610 Contact Us For Availability

AIR DUCT-E CT ACP 21025303 Contact Us For Availability

BRKT-ANTI INTRUSION ACP 21024102 Contact Us For Availability

SCREW-TF/HEX ACP 12992309 Contact Us For Availability

SHIELD-DRIP ACP 21033602 Contact Us For Availability

ACCESS PANEL-E CT ACP 21031502 Contact Us For Availability

59144387 Amana LED Lamp Backorder ACP 59144387 $34.10

ACCESS-BOTTOM ACP 20172101 Contact Us For Availability

SCREW-SM/FLAT ACP 20021702 Contact Us For Availability

SCREW-SM/HEX RoHS ACP 12990523 Contact Us For Availability

14

RAIL-SIDE ACP 21026802 Contact Us For Availability

15

20167902 Amana Left Hinge Bracket Weld Backorder ACP 20167902 $69.74

15

59164484 Amana Damper Assembly Backorder ACP 59164484 $85.88

15

SPACER-OC SIDE ACP 20145501 Contact Us For Availability

16

59154447 Amana Vinyl Gasket Tape Backorder ACP 59154447 $12.39

17

59004077 Amana Gasket per Foot Backorder ACP 59004077 $1.31

18

12990529 Amana Hex Screw Backorder ACP 12990529 $5.14

18

PWR CORD BRKT ASSY ACP 20150301 Contact Us For Availability

19

B5677214 Amana Terminal Block Backorder ACP B5677214 $6.43

20

13074001 Amana RoHS TORX Pan Head Screw Backorder ACP 13074001 $5.59

21

13045501 Amana Nut #6 KEPS Backorder ACP 13045501 $5.08

22

59004001 Amana Power Cord Backorder ACP 59004001 $76.31
