Model Electrolux 970R724387 FREEZER/REFRIGERATOR – Common Parts &amp; Diagrams

*

240494001 Frigidaire Refrigerator Plug Button In Stock WCI 240494001 $10.92

*

241503901 Frigidaire Refrigerator P-1 Tube Ad In Stock WCI 241503901 $32.94

*

241510904 Frigidaire Refrigerator Dispenser H Backorder WCI 241510904 $39.17

*

241947701 Frigidaire Refrigerator Spacer Backorder WCI 241947701 $59.49

*

242146401 Frigidaire Refrigerator Screw In Stock WCI 242146401 $9.17

*

5303918596 Frigidaire Refrigerator Dispenser In Stock WCI 5303918596 $232.47

*

5304521784 Frigidaire Refrigerator Harness Backorder WCI 5304521784 $36.90

1

218976435 Frigidaire Refrigerator Water Inlet Backorder WCI 218976435 $13.19

1

241844403 Frigidaire Refrigerator Tube Backorder WCI 241844403 $15.01

1

241860111 Frigidaire Refrigerator Evaporator Backorder WCI 241860111 $7.72

1

241862903 Frigidaire Refrigerator Condenser In Stock WCI 241862903 $83.37

1

241964707 Frigidaire Refrigerator Water Tube In Stock WCI 241964707 $11.83

1

241965906 Frigidaire Refrigerator Water Tube Backorder WCI 241965906 $15.48

1

242100111 Frigidaire Refrigerator Ice Contain Backorder WCI 242100111 $160.53

1

242220202 Frigidaire Refrigerator Water Inlet Backorder WCI 242220202 $18.69

1

242220204 Frigidaire Water Inlet Tube In Stock WCI 242220204 $23.25

1

5304537408 Frigidaire Gasket In Stock WCI 5304537408 $52.81

2

241778315 Frigidaire Door Gasket In Stock WCI 241778315 $62.74

2

243297613 Frigidaire Refrigerator Ice Maker In Stock WCI 243297613 $82.67

2

808714501 Frigidaire Refrigerator Harness Backorder WCI 808714501 $52.86

4

5303305677 Frigidaire Replacement Filters Fil In Stock WCI 5303305677 $16.89

4A

242194301 Frigidaire Refrigerator Trim Backorder WCI 242194301 $65.67

5

5308000010 Frigidaire Refrigerator Evaporator In Stock WCI 5308000010 $32.12

6

241516904 Frigidaire Refrigerator Service Cor In Stock WCI 241516904 $23.23

6

242141401 Frigidaire Refrigerator Harness Wir Backorder WCI 242141401 $128.15

8

215474201 Frigidaire Refrigerator Washer Backorder WCI 215474201 $11.85

8

242270106 Frigidaire Refrigerator Module In Stock WCI 242270106 $109.52

9

241518301 Frigidaire Refrigerator Bushing Backorder WCI 241518301 $42.82

10

241829001 Frigidaire Refrigerator Bar Drive In Stock WCI 241829001 $37.61

10

Cover-air duct WCI 242072002 Contact Us For Availability

10A

241860104 Frigidaire Refrigerator Coil Cover Backorder WCI 241860104 $19.14

10A

241860105 Frigidaire Refrigerator Coil Cover Backorder WCI 241860105 $10.92

10A

241860402 Frigidaire Refrigerator Evaporator In Stock WCI 241860402 $79.23

11

Door-frzr, stainless, complete assy WCI 241987927 Contact Us For Availability

11

Door-refr, stainless, RH WCI 242185607 Contact Us For Availability

12

241953905 Frigidaire Screw Backorder WCI 241953905 $6.81

13

241868401 Frigidaire Refrigerator Door Stop Backorder WCI 241868401 $11.85

13

809069220 Frigidaire Evaporator Fan Motor In Stock WCI 809069220 $81.27

13A

241868402 Frigidaire Refrigerator Door Stop Backorder WCI 241868402 $11.85

14

242060202 Frigidaire Refrigerator Light Switc In Stock WCI 242060202 $25.97

14

5303918410 Frigidaire Refrigerator Defrost He In Stock WCI 5303918410 $67.51

15

242196204 Frigidaire Refrigerator Light Board Backorder WCI 242196204 $38.28

15

5303918569 Frigidaire Refrigerator Evaporator In Stock WCI 5303918569 $169.47

15A

242202701 Frigidaire Refrigerator Lens In Stock WCI 242202701 $19.57

16

242072101 Frigidaire Refrigerator Cover Backorder WCI 242072101 $30.97

16

242072501 Frigidaire Refrigerator Insulation Backorder WCI 242072501 $11.83

16

5308000110 Frigidaire Refrigerator Evaporator In Stock WCI 5308000110 $40.10

17

241791201 Frigidaire Refrigerator Drain Troug Backorder WCI 241791201 $69.42

17

241928201 Frigidaire Refrigerator Air Duct Ga In Stock WCI 241928201 $11.40

241816602 Frigidaire Refrigerator Auger Motor In Stock WCI 241816602 $88.63

241860101 Frigidaire Refrigerator Gasket Backorder WCI 241860101 $11.38

242095805 Frigidaire Refrigerator Wiring Harn Backorder WCI 242095805 $49.64

242198301 Frigidaire Refrigerator Door Handle In Stock WCI 242198301 $95.57

242198501 Frigidaire Refrigerator Drawer Hand Backorder WCI 242198501 $118.84

19

242072601 Frigidaire Refrigerator Support Backorder WCI 242072601 $28.70

20

242072201 Frigidaire Refrigerator Cover In Stock WCI 242072201 $58.64

20

242095702 Frigidaire Refrigerator Air Handler In Stock WCI 242095702 $57.24

20

808137001 Frigidaire Refrigerator Thermistor In Stock WCI 808137001 $20.94

241690602 Frigidaire Refrigerator Screw In Stock WCI 241690602 $6.83

241732101 Frigidaire Refrigerator Screw Backorder WCI 241732101 $10.03

242017501 Frigidaire Refrigerator Screw Backorder WCI 242017501 $10.01

5303918568 Frigidaire Thermostat Defrost In Stock WCI 5303918568 $58.14

5304521781 Frigidaire Refrigerator Thermostat In Stock WCI 5304521781 $28.09

21A

218362501 Frigidaire Refrigerator Screw Backorder WCI 218362501 $7.76

21A

242015001 Frigidaire Refrigerator Screw Backorder WCI 242015001 $10.47

21C

241899703 Frigidaire Refrigerator Screw In Stock WCI 241899703 $9.56

22

218252201 Frigidaire Refrigerator Screw Backorder WCI 218252201 $9.10

22

Cam, upper hinge, RH WCI 242075601 Contact Us For Availability

22A

242075602 Frigidaire Refrigerator Cam Assembl Backorder WCI 242075602 $15.01

22C

241760401 Frigidaire Refrigerator Bearing Backorder WCI 241760401 $12.28

218513300 Frigidaire Refrigerator Compressor In Stock WCI 218513300 $27.32

242094603 Frigidaire Refrigerator Evaporator Backorder WCI 242094603 $87.82

242176503 Frigidaire Refrigerator Sump In Stock WCI 242176503 $72.57

5304501541 Frigidaire Refrigerator Gasket Backorder WCI 5304501541 $10.47

24

242094802 Frigidaire Defrost Heater In Stock WCI 242094802 $72.42

24

5304515677 Frigidaire Package of 4 Screws In Stock WCI 5304515677 $5.43

24A

240383412 Frigidaire Refrigerator Screw In Stock WCI 240383412 $7.35

24A

242200502 Frigidaire Refrigerator "Spill-Safe Backorder WCI 242200502 $117.96

24C

242235502 Frigidaire Refrigerator "Spill-Safe Backorder WCI 242235502 $141.45

25

241949502 Frigidaire Refrigerator Clip Backorder WCI 241949502 $12.28

25

Screw-compressor mtg, 1/4-28 x 1.16, (4) WCI 240491503 Contact Us For Availability

26

241695904 Frigidaire Refrigerator Screw Backorder WCI 241695904 $8.65

26

241920608 Frigidaire Defrost Pan Backorder WCI 241920608 $83.48

27

241752702 Frigidaire Refrigerator Retainer Backorder WCI 241752702 $23.68

30

241778701 Frigidaire Refrigerator Anti-Tip Br In Stock WCI 241778701 $15.96

30

5304512686 Frigidaire Refrigerator Inverter K In Stock WCI 5304512686 $293.90

33

242095425 Frigidaire Gasket Backorder WCI 242095425 $6.51

33

Housing-evaporator WCI 242094401 Contact Us For Availability

34

241868301 Frigidaire Refrigerator Washer Asse In Stock WCI 241868301 $20.03

36

241868201 Frigidaire Refrigerator Spacer Backorder WCI 241868201 $31.88

36A

241868202 Frigidaire Refrigerator Spacer Backorder WCI 241868202 $14.12

38

241761301 Frigidaire Upper Bracket Hinge Backorder WCI 241761301 $42.58

38A

241761302 Frigidaire Refrigerator Upper Hinge Backorder WCI 241761302 $41.46

38C

5304527934 Frigidaire Refrigerator User Inter In Stock WCI 5304527934 $215.69

40

5304504483 Frigidaire Refrigerator Gray Upper Backorder WCI 5304504483 $40.68

40A

5304504482 Frigidaire Refrigerator Upper Left Backorder WCI 5304504482 $39.80

40B

218515401 Frigidaire Refrigerator Clip Backorder WCI 218515401 $11.38

40B

241862405 Frigidaire Refrigerator Upper Hinge Backorder WCI 241862405 $63.37

41

240555002 Frigidaire Refrigerator Screw #8-32 In Stock WCI 240555002 $8.63

42

240578902 Frigidaire Screw Mounting Hinge Backorder WCI 240578902 $9.10

42

242079401 Frigidaire Refrigerator Left Side C Backorder WCI 242079401 $20.03

42A

242079402 Frigidaire Refrigerator Support Backorder WCI 242079402 $20.50

43

241641502 Frigidaire Refrigerator Screw Backorder WCI 241641502 $5.43

45

241500303 Frigidaire Refrigerator Screw Backorder WCI 241500303 $2.73

45

241675704 Frigidaire Refrigerator Solenoid As In Stock WCI 241675704 $37.11

45

5304455650 Frigidaire Refrigerator Screw Backorder WCI 5304455650 $9.11

47B

Glass, deli cover WCI 242082304 Contact Us For Availability

48

242071401 Frigidaire Refrigerator White Door Backorder WCI 242071401 $55.66

48

242122101 Frigidaire Refrigerator Channel She Backorder WCI 242122101 $51.50

242079701 Frigidaire Refrigerator Door Bin In Stock WCI 242079701 $64.22

242122202 Frigidaire Refrigerator Channel Backorder WCI 242122202 $43.28

5304526200 Frigidaire Refrigerator Basket Backorder WCI 5304526200 $92.00

Liner-door bin, gallon WCI 242012201 Contact Us For Availability

49A

241780811 Frigidaire Refrigerator Basket Backorder WCI 241780811 $130.57

49A

242071301 Frigidaire Refrigerator Clear Door In Stock WCI 242071301 $44.00

49A

242122001 Frigidaire Refrigerator Shelf Mount Backorder WCI 242122001 $28.23

49B

242080201 Frigidaire Refrigerator Door Bin Backorder WCI 242080201 $32.90

49B

242122301 Frigidaire Refrigerator Shelf Mount Backorder WCI 242122301 $50.13

49C

242079901 Frigidaire Refrigerator Door Bin In Stock WCI 242079901 $55.66

50

241810104 Frigidaire Refrigerator Seal Backorder WCI 241810104 $7.27

50

242119001 Frigidaire Refrigerator Wiring Harn Backorder WCI 242119001 $72.57

50

5304502778 Frigidaire Refrigerator Main Power In Stock WCI 5304502778 $170.20

51

242095501 Frigidaire Refrigerator Anti-Twist Backorder WCI 242095501 $13.21

51

242120001 Frigidaire Refrigerator Slide In Stock WCI 242120001 $105.49

51

5303918694 Frigidaire Refrigerator Right Hand Backorder WCI 5303918694 $135.23

51A

241894221 Frigidaire Refrigerator Assembly-Sl Backorder WCI 241894221 $84.75

51A

242039701 Frigidaire Refrigerator Screw Backorder WCI 242039701 $8.65

52

Slide Assembly, basket lower, RH WCI 242147113 Contact Us For Availability

52A

241894222 Frigidaire Refrigerator Slide Assem Backorder WCI 241894222 $85.17

53A

5303918801 Frigidaire Refrigerator Retainer S Backorder WCI 5303918801 $7.74

54

Support, housing, main board WCI 807854301 Contact Us For Availability

55

240363602 Frigidaire Refrigerator Shoulder Sc Backorder WCI 240363602 $8.18

55

242253002 Frigidaire Refrigerator Water Valve In Stock WCI 242253002 $110.68

58

241500305 Frigidaire Refrigerator Screw In Stock WCI 241500305 $1.84

59

240346701 Frigidaire Refrigerator Foam Seal T Backorder WCI 240346701 $19.12

59

240442708 Frigidaire Refrigerator Screw - #10 In Stock WCI 240442708 $5.00

59

241946106 Frigidaire Refrigerator Condenser F Backorder WCI 241946106 $29.15

60

242018301 Frigidaire Refrigerator Condenser F In Stock WCI 242018301 $95.39

61

241639502 Frigidaire Refrigerator Condenser F In Stock WCI 241639502 $11.48

63

216396900 Frigidaire Dryer Adjustable Levelin In Stock WCI 216396900 $15.01

65

808462601 Frigidaire Refrigerator Cover Backorder WCI 808462601 $23.68

68

242095002 Frigidaire Refrigerator Cover In Stock WCI 242095002 $57.39

68

242096001 Frigidaire Refrigerator Insulation Backorder WCI 242096001 $11.85

72

242054804 Frigidaire Refrigerator Kickplate G Backorder WCI 242054804 $53.75

73

242075701 Frigidaire Refrigerator Lower Hinge Backorder WCI 242075701 $13.67

80

218755504 Frigidaire Refrigerator Shoulder Sc In Stock WCI 218755504 $8.65

81

134154100 Frigidaire Screw 10-32 x 0.375 Co Backorder WCI 134154100 $8.67

81

240359403 Frigidaire Refrigerator Fan Shroud Backorder WCI 240359403 $2.27

81

240383407 Frigidaire Refrigerator Screw Backorder WCI 240383407 $8.20

82

241779401 Frigidaire Refrigerator Flipper Hin In Stock WCI 241779401 $11.49

82

5304418225 Frigidaire Refrigerator Roller P-1 In Stock WCI 5304418225 $30.99

83

241812202 Frigidaire Refrigerator Magnet Backorder WCI 241812202 $46.46

83

5304455655 Frigidaire Refrigerator Rivet Backorder WCI 5304455655 $23.18

84

241780905 Frigidaire Refrigerator Divider Backorder WCI 241780905 $58.14

84

242036801 Frigidaire Refrigerator Plastic Cli In Stock WCI 242036801 $61.29

84

808274201 Frigidaire Door Guide Assembly Backorder WCI 808274201 $21.87

84A

242190501 Frigidaire Refrigerator Mullion Ass Backorder WCI 242190501 $16.85

85

241778811 Frigidaire Refrigerator Flipper Mul In Stock WCI 241778811 $167.17

85

242068601 Frigidaire Refrigerator Bumper Backorder WCI 242068601 $8.65

85

5304520993 Frigidaire Refrigerator Mullion Ha Backorder WCI 5304520993 $25.22

85A

242139301 Frigidaire Refrigerator Support Bea Backorder WCI 242139301 $47.39

85B

241872203 Frigidaire Refrigerator Beam Suppor Backorder WCI 241872203 $32.36

240409302 Frigidaire Refrigerator Condenser T Backorder WCI 240409302 $40.55

241779802 Frigidaire Door Hinge Mullion Flipp In Stock WCI 241779802 $22.19

242011101 Frigidaire Refrigerator Pin Lock Backorder WCI 242011101 $9.11

5304507340 Frigidaire Refrigerator Trim Backorder WCI 5304507340 $28.70

87

Tube-connector, suction WCI 241871501 Contact Us For Availability

89

241972302 Frigidaire Refrigerator Drawer Brac Backorder WCI 241972302 $64.92

89

Tube-process WCI 215346900 Contact Us For Availability

240597220 Frigidaire Sensor In Stock WCI 240597220 $3.07

241842301 Frigidaire Refrigerator Thermistor Backorder WCI 241842301 $21.86

241953902 Frigidaire Refrigerator Screw In Stock WCI 241953902 $10.99

241953908 Frigidaire Refrigerator Screw Backorder WCI 241953908 $2.73

Bar-timing WCI 242136901 Contact Us For Availability

92

241710601 Frigidaire Refrigerator Screw In Stock WCI 241710601 $8.65

93

241835505 Frigidaire Refrigerator Light Switc Backorder WCI 241835505 $45.12

93

5304521649 Frigidaire Refrigerator Wiring Har Backorder WCI 5304521649 $60.37

96

241860601 Frigidaire Refrigerator Evaporator Backorder WCI 241860601 $83.83

96

Door-air filter WCI 242048002 Contact Us For Availability

97

242220501 Frigidaire Refrigerator Water Tank Backorder WCI 242220501 $63.11

97A

242004802 Frigidaire Refrigerator Foam Strip Backorder WCI 242004802 $3.63

97A

Cover-water tank WCI 242117301 Contact Us For Availability

100

242157601 Frigidaire Refrigerator Cover Backorder WCI 242157601 $7.27

101

242157801 Frigidaire Refrigerator Cover Backorder WCI 242157801 $14.58

102

242157501 Frigidaire Refrigerator Cover Backorder WCI 242157501 $14.58

105

242116801 Frigidaire Refrigerator Basket Trim Backorder WCI 242116801 $11.38

107

Duct-air, top WCI 241963102 Contact Us For Availability

115

5303918899 Frigidaire Damper Control Assembly In Stock WCI 5303918899 $46.50

116

241518601 Frigidaire Refrigerator Damper Seal In Stock WCI 241518601 $5.91

122

241860117 Frigidaire Gasket Backorder WCI 241860117 $6.86

123

242135301 Frigidaire Refrigerator Evaporator Backorder WCI 242135301 $5.00

124

242006903 Frigidaire Refrigerator Air Duct Backorder WCI 242006903 $38.28

125

242071201 Frigidaire Refrigerator Cover Backorder WCI 242071201 $73.01

139

BASE-WATER FILTER In Stock WCI 242009604 $20.27

145

242120101 Frigidaire Refrigerator Support Backorder WCI 242120101 $46.04

145A

242120102 Frigidaire Refrigerator Support Backorder WCI 242120102 $46.48

147

5304493604 Frigidaire Refrigerator Gasket & F In Stock WCI 5304493604 $56.08

148

242095406 Frigidaire Refrigerator Gasket In Stock WCI 242095406 $11.42

149

5303918784 Frigidaire Refrigerator Air Handle In Stock WCI 5303918784 $61.96

151

242069701 Frigidaire Refrigerator Water Filte Backorder WCI 242069701 $38.07

154

Support WCI 242082401 Contact Us For Availability

157

Beam support WCI 241872201 Contact Us For Availability

207

242047901 Frigidaire Refrigerator Air Filter Backorder WCI 242047901 $48.29

209

242291001 Frigidaire Refrigerator Housing Backorder WCI 242291001 $12.29

210

241779101 Frigidaire Refrigerator Magnet In Stock WCI 241779101 $20.03

210

241983816 Frigidaire Refrigerator Water Filte In Stock WCI 241983816 $47.41

210

5304453707 Frigidaire Oven Screw In Stock WCI 5304453707 $9.56

210A

241998303 Frigidaire Refrigerator Water Filte In Stock WCI 241998303 $6.51

211

241979601 Frigidaire Refrigerator Bumper Backorder WCI 241979601 $14.56

212

242236801 Frigidaire Refrigerator Roller Asse In Stock WCI 242236801 $13.21

213

242010901 Frigidaire Refrigerator Assembly Ro Backorder WCI 242010901 $31.90
