Model Kenmore 970155226 FREEZER – Common Parts & Diagrams

1
Condenser
Condenser WCI 5300120779 Contact Us For Availability
View on Model
5#
Harness-main
Harness-main WCI 216952000 Contact Us For Availability
View on Model
10
Plug button, 1/4", white
Plug button, 1/4", white WCI 216923001 No Longer Available
View on Model
18
Handle, recessed, white, incl/gasket
Handle, recessed, white, incl/gasket WCI 297034200 Contact Us For Availability
View on Model
28
Hinge Assy, w/o spring, white
Hinge Assy, w/o spring, white WCI 297313202 Contact Us For Availability
View on Model
28*
Hinge Assy
Hinge Assy WCI 297313200 Contact Us For Availability
View on Model
30
Breaker-corners, white
Breaker-corners, white WCI 216105500 Contact Us For Availability
View on Model
30
Controller, compressor, 5 speed
Controller, compressor, 5 speed WCI 216954219 Contact Us For Availability
View on Model
55
Capacitor, run, 12 MF
Capacitor, run, 12 MF WCI 216985002 Contact Us For Availability
View on Model
75
Panel-access, white
Panel-access, white WCI 216782000 Contact Us For Availability
View on Model
85
Wire-ground
Wire-ground WCI 216818300 Contact Us For Availability
View on Model
86
Screw, PH, 8-32 x 1/2, wiring harness
Screw, PH, 8-32 x 1/2, wiring harness WCI 216707801 Contact Us For Availability
View on Model
94
Lens, frost indicator, blue
Lens, frost indicator, blue WCI 216140400 Contact Us For Availability
View on Model
