GE 911.41389893 Electric Range (Kenmore 91141389893) Parts List

1

Keypad GEN WB36T10390 Contact Us For Availability

View on Model

2

L Blk Endcap GEN WB36T10064 Contact Us For Availability

View on Model

2

L Blk Endcap GEN WB36T10065 Contact Us For Availability

View on Model

4

Cabinet GEN WB37K5017 Contact Us For Availability

View on Model

5

Thermostat GEN WB20T10008 Contact Us For Availability

View on Model

6

WB37K5041 GE Control Housing Backorder GEN WB37K5041 $20.52

View on Model

7

WB2K5406 GE Bracket Backorder GEN WB2K5406 $5.02

View on Model

9

Raceway GEN WB63M0007 Contact Us For Availability

View on Model

11

WB37K5040 GE Top Control Housing Backorder GEN WB37K5040 $20.48

View on Model

12

TOP CABINET Backorder GEN WB63K5120 $62.41

View on Model

15

WB2X9665 GE Wire Cover Backorder GEN WB2X9665 $21.39

View on Model

16

Oven Control GEN WB27T10477 Contact Us For Availability

View on Model

32

WB26K5072 GE Oven Fan Assembly Backorder GEN WB26K5072 $115.32

View on Model

33

WB25T10039 GE Oven Light Indicator Backorder GEN WB25T10039 $9.08

View on Model

42

Heat Shield GEN WB34K5249 Contact Us For Availability

View on Model

46

Wire Shield GEN WB34K5099 Contact Us For Availability

View on Model

47

WB38K5058 GE Vent Barrier Backorder GEN WB38K5058 $13.88

View on Model

49

Fan Screen GEN WB34T10066 Contact Us For Availability

View on Model

68

Front Trim Spacer GEN WB02T10164 Contact Us For Availability

View on Model

88

Thermostat Knob GEN WB03T10157 Contact Us For Availability

View on Model

101

WB35K5054 GE Oven Door Insulation Backorder GEN WB35K5054 $21.32

View on Model

112

Door Lining GEN WB55T10010 Contact Us For Availability

View on Model

112

Oven Drive Liner GEN WB55T10011 Contact Us For Availability

View on Model

113

WB2K5159 GE Oven Door Insulation Backorder GEN WB2K5159 $39.21

View on Model

121

Wall Oven Door Outer Panel (Black) GEN WB57K5327 Contact Us For Availability

View on Model

123

WB36X779 GE Oven Glass Center Backorder GEN WB36X779 $92.00

View on Model

132

Wall Oven Door Seal GEN WB32K5037 Contact Us For Availability

View on Model

136

Door Hndl-bl GEN WB15K5125 Contact Us For Availability

View on Model

140

Oven Door Frame GEN WB55K5075 Contact Us For Availability

View on Model

144

WB2K5395 GE Oven Reinforcement Plate Backorder GEN WB2K5395 $8.35

View on Model

147

Glass Spacer GEN WB02X9039 Contact Us For Availability

View on Model

151

WB49T10020 GE Stove Oven Lock Motor Latch Ass In Stock GEN WB49T10020 $131.64

View on Model

157

WB24K5046 GE Oven Limit Switch Backorder GEN WB24K5046 $63.08

View on Model

159

WB24K5085 GE Oven Limit Switch Backorder GEN WB24K5085 $45.09

View on Model

170

WB1K60 GE Screw 8-18 Backorder GEN WB1K60 $8.59

View on Model

184

WB34K5228 GE Oven Door Lock Plate Backorder GEN WB34K5228 $71.39

View on Model

185

WB15K5016 GE Oven Lock Lever Assembly Backorder GEN WB15K5016 $29.48

View on Model

201

WB63T10012 GE Oven Body Backorder GEN WB63T10012 $126.52

View on Model

202

Door Frame GEN WB63T10013 Contact Us For Availability

View on Model

203

MAIN BACK Backorder GEN WB63K5113 $80.22

View on Model

205

WB6K5026 GE Range Smoke El Screw Backorder GEN WB6K5026 $20.65

View on Model

211

Ovsd Ins Ret GEN WB02K5180 Contact Us For Availability

View on Model

212

Ovbt Ins Ret GEN WB02K5171 Contact Us For Availability

View on Model

212

Cabinet GEN WB63K5116 Contact Us For Availability

View on Model

213

Ov Top Ret L GEN WB02K5174 Contact Us For Availability

View on Model

213

Insert Retainer GEN WB02K5256 Contact Us For Availability

View on Model

221

WB63K5112 GE Oven Side Cabinet Backorder GEN WB63K5112 $76.91

View on Model

224

WB2K5172 GE Door Spring Retainer Backorder GEN WB2K5172 $25.07

View on Model

227

Cab Top Ret GEN WB02K5173 Contact Us For Availability

View on Model

230

WB35K5041 GE Inner Wrap Insulation Backorder GEN WB35K5041 $55.84

View on Model

230

WB35K5048 GE Inner Wrapper Insulation Backorder GEN WB35K5048 $100.10

View on Model

230

Cabinet Insert GEN WB35K5066 Contact Us For Availability

View on Model

231

WB35K5068 GE Insulation Wrapper Backorder GEN WB35K5068 $51.54

View on Model

232

WB35K5057 GE Upper Back/Bottom Insulation Backorder GEN WB35K5057 $19.53

View on Model

232

Insul Bk/btm GEN WB35K5067 Contact Us For Availability

View on Model

239

WB2X9189 GE Range Plug - REC Backorder GEN WB2X9189 $4.89

View on Model

239

Plug GEN WB02X9587 Contact Us For Availability

View on Model

241

WB48T10094 GE Oven Rack Backorder GEN WB48T10094 $30.88

View on Model

245

Scroll Bracket GEN WB02M0030 Contact Us For Availability

View on Model

246

WB48X10056 GE Broil Pan Set, Large Porcelain In Stock GEN WB48X10056 $18.60

View on Model

251

WB44K5013 GE Oven Bake Element Range In Stock GEN WB44K5013 $45.14

View on Model

251

WB44T10007 GE Oven Bake Element Backorder GEN WB44T10007 $88.15

View on Model

252

WB44K5009 GE Oven Broil Element In Stock GEN WB44K5009 $53.34

View on Model

253

WB21X5301 GE Range Oven Temperature Sensor Pr In Stock GEN WB21X5301 $125.41

View on Model

256

WB8X303 GE Oven Lamp Holder Backorder GEN WB8X303 $34.65

View on Model

257

BULB OVEN LI GEN BUY LOCAL Contact Us For Availability

View on Model

258

WB02T10037 GE Oven Light Cup Backorder GEN WB02T10037 $5.65

View on Model

259

WB36X192 GE Oven Light Cover In Stock GEN WB36X192 $10.83

View on Model

260

Bail GEN WB02X7694 Contact Us For Availability

View on Model

261

Jam Switch GEN WB24K5061 Contact Us For Availability

View on Model

262

WB7K5263 GE Vertical Side Trim Backorder GEN WB7K5263 $40.81

View on Model

262

WB7K5491 GE Trim Vent Black Backorder GEN WB7K5491 $38.26

View on Model

263

Trim-i-brow GEN WB07K5123 Contact Us For Availability

View on Model

263

I-brow Trm-b GEN WB07K5478 Contact Us For Availability

View on Model

264

Vent Trim Ex GEN WB07K5121 Contact Us For Availability

View on Model

266

Channel GEN WB02X9634 Contact Us For Availability

View on Model

268

WB07T10415 GE Oven Trim Lower Front Backorder GEN WB07T10415 $26.36

View on Model

269

WB2K5164 GE Light Cup Support Backorder GEN WB2K5164 $5.28

View on Model

270

Cover Plate GEN WB02X9642 Contact Us For Availability

View on Model

276

Wall Oven Door Seal GEN WB32K5050 Contact Us For Availability

View on Model

279

Vent Box GEN WB38K5028 Contact Us For Availability

View on Model

281

Oven Drive Hinge GEN WB14K5006 Contact Us For Availability

View on Model

281

Wall Oven Door Hinge, Left GEN WB14K5007 Contact Us For Availability

View on Model

286

Oven Drive Spring GEN WB09K5017 Contact Us For Availability

View on Model

286

Oven Door Spring GEN WB09K5018 Contact Us For Availability

View on Model

288

Button Plug GEN WB03K5043 Contact Us For Availability

View on Model

289

WB34K5068 GE Latch Opening Cover Backorder GEN WB34K5068 $5.95

View on Model

291

COVER GEN WB02X9152 Contact Us For Availability

View on Model

294

WB2X9719 GE Oven Support Bracket Clip In Stock GEN WB2X9719 $7.66

View on Model

595

WB2K5126 GE Oven Condenser Clamp Backorder GEN WB2K5126 $6.70

View on Model

600

WB18X32567 GE Conduit Wire Assembly Backorder GEN WB18X32567 $41.94

View on Model

690

WB1K5167 GE Screw 8-18 X 3/8" Backorder GEN WB1K5167 $5.28

View on Model

691

WB1K5162 GE Oven Black Screw Backorder GEN WB1K5162 $5.65

View on Model

691

WB1K5177 GE Range Trim Screw Backorder GEN WB1K5177 $5.02

View on Model

692

Screw GEN WZ04X0416 Contact Us For Availability

View on Model

696

WB1K5156 GE Range Screw Backorder GEN WB1K5156 $5.65

View on Model

699

WB1M1 GE Oven Screw Backorder GEN WB1M1 $5.43

View on Model

752

WB1K5200 GE Oven Screw 340531 Backorder GEN WB1K5200 $5.65

View on Model

755

WZ4X44D GE Screw Package Backorder GEN WZ4X44D $28.79

View on Model

760

WB1X536 GE Oven Screw Backorder GEN WB1X536 $6.90

View on Model

804

WB1X681 GE Oven Screw Backorder GEN WB1X681 $5.65

View on Model

809

WB1X1137 GE Oven Screw Backorder GEN WB1X1137 $5.65

View on Model

810

WB1X1130 GE Oven Screw 10-32 Backorder GEN WB1X1130 $5.65

View on Model

812

WB1K5191 GE Oven Zinc FL Screw Backorder GEN WB1K5191 $5.65

View on Model

813

WB1X1261 GE Oven Screw Backorder GEN WB1X1261 $5.65

View on Model

847

WB1X1118 GE Oven Screw 6-32T Backorder GEN WB1X1118 $5.65

View on Model

856

WB1X1293 GE Oven Screw In Stock GEN WB1X1293 $5.65

View on Model

904

SCR 8/32 TF FLR 5/16 S GEN WB01X0521 Contact Us For Availability

View on Model

909

WB1X1173 GE Rivet Backorder GEN WB1X1173 $5.02

View on Model

918

WB1K5071 GE Oven Plastic Rivet Backorder GEN WB1K5071 $5.28

View on Model

926

GROUND WASHER GEN WB01X1260 Contact Us For Availability

View on Model

934

Washer GEN WB01K5054 Contact Us For Availability

View on Model

938

WB1K5209 GE Oven Clip Backorder GEN WB1K5209 $9.19

View on Model

941

WB1X119D GE Oven Range Washer In Stock GEN WB1X119D $10.25

View on Model

954

WB02K10073 GE Range Clip Capillary Backorder GEN WB02K10073 $7.09

View on Model

999

LIST PARTS REPAIR GEN 31-14180 Contact Us For Availability

View on Model

999

Owner's Manual GEN SR10483 Contact Us For Availability

View on Model

999

Lock Motor Harness GEN WB18K5645 Contact Us For Availability

View on Model

999

Dr Sw Wire H GEN WB18T10032 Contact Us For Availability

View on Model

999

Wire Harness GEN WB18T10288 Contact Us For Availability

View on Model
