Model Whirlpool 8ED20ZKXAW00 REFRIGERATOR – Common Parts &amp; Diagrams

WPL 1117510 WPL 1117510 Contact Us For Availability

WPL LIT2155745 WPL LIT2155745 Contact Us For Availability

WPL LIT2162708 WPL LIT2162708 Contact Us For Availability

WPL LIT2165273 WPL LIT2165273 Contact Us For Availability

WPL LIT4361351 WPL LIT4361351 Contact Us For Availability

1

WP486692 Whirlpool Refrigerator Nut Backorder WPL WP486692 $3.70

1

Refrigerator Door (White) WPL 1106923 Contact Us For Availability

1

Refrigerator Door (Gold) (Also Order Item 20) WPL 1108464 Contact Us For Availability

1

Refrigerator Door (Almond) WPL 1108465 Contact Us For Availability

1

Water, Tube WPL 2155247 Contact Us For Availability

1

Liner (Not A Serviceable Part) WPL ARI17969A8 Contact Us For Availability

1

Control Box WPL 2155518 Contact Us For Availability

2

WP2155590 Whirlpool Refrigerator Retainer Backorder WPL WP2155590 $2.51

2

Fan, Blade WPL 1108179 Contact Us For Availability

2

Mounting Bracket WPL 1110629 Contact Us For Availability

2

Tap Plate WPL 988402 Contact Us For Availability

2

Front Roller (2) WPL 2152011 Contact Us For Availability

2

Escutcheon, Meat Pan Control WPL 985468 Contact Us For Availability

3

4318165 Whirlpool Refrigerator Door Closure C In Stock WPL 4318165 $9.42

3

WP941839 Whirlpool Refrigerator Button Plug In Stock WPL WP941839 $3.70

3

Screw WPL 489393 Contact Us For Availability

3

Slide, Meat Pan Control WPL 984102 Contact Us For Availability

3

Condenser Assembly WPL 2154010 Contact Us For Availability

3

Screw (2) WPL 489190 Contact Us For Availability

4

WP2149705 Whirlpool Refrigerator Door Switch In Stock WPL WP2149705 $22.34

4

WP489464 Whirlpool Refrigerator Screw Backorder WPL WP489464 $3.70

4

WPW10250570 Whirlpool Refrigerator Cabinet Ro Backorder WPL WPW10250570 $14.49

4

Pad, Foam WPL 992358 Contact Us For Availability

5

Bracket, Door Stop WPL 1115906 Contact Us For Availability

6

681390 Whirlpool Refrigerator Screw Backorder WPL 681390 $9.13

6

WPW10329686 Whirlpool Door Cam Black In Stock WPL WPW10329686 $3.39

6

Ladder, Shelf (2) WPL 1108433 Contact Us For Availability

6

Defrost Timer WPL 2154984 Contact Us For Availability

7

489392 Whirlpool Refrigerator Screw Backorder WPL 489392 $9.59

7

WP488729 Whirlpool Refrigerator Door Screw In Stock WPL WP488729 $2.51

7

WP489069 Whirlpool Compactor Screw In Stock WPL WP489069 $2.51

7

WP489399 Whirlpool Refrigerator Screw In Stock WPL WP489399 $2.51

7

Heat Sheild, Drain Pan WPL 2149293 Contact Us For Availability

8

4388538 Whirlpool Refrigerator Shelf Stud Kit In Stock WPL 4388538 $11.05

8

940014 Whirlpool Refrigerator Primary Button Backorder WPL 940014 $10.25

8

WP1104787 Whirlpool Refrigerator Shim Backorder WPL WP1104787 $3.70

9

WP2149540 Whirlpool Shelf Support In Stock WPL WP2149540 $4.34

9

WP2198202 Whirlpool Refrigerator Temperature In Stock WPL WP2198202 $45.43

10

WP965173 Whirlpool Dishwasher Screw Backorder WPL WP965173 $2.64

10

Gasket Retainer, Side (2) WPL 1117766 Contact Us For Availability

WP488488 Whirlpool Refrigerator Screw Backorder WPL WP488488 $3.70

Gasket Retainer, Top & Bottom WPL 1118301 Contact Us For Availability

Spring, Relay Case WPL 943322 Contact Us For Availability

Cam Assembly WPL 2161250 Contact Us For Availability

1110560 Whirlpool Refrigerator Bearing Backorder WPL 1110560 $4.72

2188404A Whirlpool Refrigerator Door Gasket In Stock WPL 2188404A $119.63

Hinge, Top Freezer Door WPL 1123510 Contact Us For Availability

Hinge, Top Refrigerator Door WPL 1123514 Contact Us For Availability

Case, Relay WPL 1105055 Contact Us For Availability

WP2149959 Whirlpool Refrigerator Overload Backorder WPL WP2149959 $40.37

WP489478 Whirlpool Refrigerator Screw In Stock WPL WP489478 $2.51

Shim, Hinge Refrigerator, Door WPL 1123515 Contact Us For Availability

Cap, Hinge Sleeve WPL 509929 Contact Us For Availability

Shim, Hinge Freezer Door WPL 1123518 Contact Us For Availability

Shelf, Cantilever WPL 1118497 Contact Us For Availability

Handle WPL 987009 Contact Us For Availability

Hole, Plug (White) WPL 849391 Contact Us For Availability

Hole Plug (Gold) WPL 989957 Contact Us For Availability

Hole Plug (Almond) WPL 989958 Contact Us For Availability

Trim, Shelf (3) WPL 1114302 Contact Us For Availability

Clip, Defrost Heater WPL 2161329 Contact Us For Availability

Retainer, Damper WPL 938439 Contact Us For Availability

WP1126289 Whirlpool Refrigerator Cover Backorder WPL WP1126289 $68.02

Pivot Arm WPL 1110559 Contact Us For Availability

Reinforcement, Shelf WPL 2152266 Contact Us For Availability

Hole Plug (White) WPL 1115352 Contact Us For Availability

Hole Plug (Gold) WPL 1115353 Contact Us For Availability

Hole Plug (Almond) WPL 1115354 Contact Us For Availability

Relay (See Overload) WPL ARI17971A4 Contact Us For Availability

16

627068 Whirlpool Refrigerator Screw Backorder WPL 627068 $7.52

16

Hinge Bottom (R.H.) WPL 2151619 Contact Us For Availability

16

Trim, Cover WPL 1110795 Contact Us For Availability

2205764 Whirlpool Refrigerator Tube Backorder WPL 2205764 $26.75

4387478 Whirlpool Refrigerator Light Socket In Stock WPL 4387478 $30.80

Glass, Shelf WPL 1114687 Contact Us For Availability

Screw, 10-32 x 23/32 WPL 489327 Contact Us For Availability

W11233072 Whirlpool Screw In Stock WPL W11233072 $9.59

WP2148298 Whirlpool Refrigerator Deli Drawer Backorder WPL WP2148298 $93.36

WP2158826 Whirlpool Refrigerator Dampener Backorder WPL WP2158826 $0.90

Screw, 10-32 x 5/8 WPL 489075 Contact Us For Availability

8009 Whirlpool 40W 120V Light Bulb In Stock WPL 8009 $6.56

W11751592 Whirlpool Sleeve In Stock WPL W11751592 $12.17

WP2148279 Whirlpool Refrigerator Crisper Pan Backorder WPL WP2148279 $97.12

Insert Handle (Gold) WPL 1111550 Contact Us For Availability

Insert, Handle (White) WPL 2148102 Contact Us For Availability

Insert, Handle (Almond) WPL 2148103 Contact Us For Availability

hinge Bottom (L.H.) WPL 2151620 Contact Us For Availability

Spacer, Hinge WPL 836196 Contact Us For Availability

Pan, Meat WPL 2148192 Contact Us For Availability

Clip, Unit Cover (2) WPL 548744 Contact Us For Availability

Control Box Harness WPL 2149185 Contact Us For Availability

WP982704 Whirlpool Refrigerator Container Backorder WPL WP982704 $13.05

Insert Retainer (Top) WPL 987008 Contact Us For Availability

Filler, Wrapper (White) WPL 1110708 Contact Us For Availability

Filler, Wrapper (Almond) WPL 1110709 Contact Us For Availability

Filler, Wrapper (Gold) WPL 1110710 Contact Us For Availability

Clip, Heat Shield WPL 2155547 Contact Us For Availability

WP2188822 Whirlpool Refrigerator Evaporator In Stock WPL WP2188822 $194.99

WP2256085 Whirlpool Refrigerator Retainer Backorder WPL WP2256085 $13.73

Insert Retainer (Bottom) WPL 987010 Contact Us For Availability

Grille WPL 1129001 Contact Us For Availability

CLIP, WIRING WPL 1115375 Contact Us For Availability

WP1129262 Whirlpool Refrigerator Cover Backorder WPL WP1129262 $10.38

End Cap WPL 987006 Contact Us For Availability

Hinge Cover (Gold) WPL 2150342 Contact Us For Availability

Connecting Rod WPL 1123959 Contact Us For Availability

833697 Whirlpool Condenser Fan Motor In Stock WPL 833697 $41.18

WPW10151374 Whirlpool Refrigerator Diffuser In Stock WPL WPW10151374 $33.42

Foam Insulation WPL 876029 Contact Us For Availability

Fastener, Push-On WPL 489285 Contact Us For Availability

Trim, Door Shelf (2) WPL 2148267 Contact Us For Availability

Screw WPL 489284 Contact Us For Availability

2152019 Whirlpool Refrigerator Cover Backorder WPL 2152019 $32.98

WPW10614158 Whirlpool Refrigerator Evaporator In Stock WPL WPW10614158 $53.89

Divider, Shelf WPL 2160049 Contact Us For Availability

Escutcheon, Control Box WPL 2161213 Contact Us For Availability

2182111 Whirlpool Refrigerator Thermal Knob Backorder WPL 2182111 $9.53

Screw, WPL 488454 Contact Us For Availability

Cover, Conduit WPL 2150330 Contact Us For Availability

Harness, Intermediate WPL 2153994 Contact Us For Availability

W10759522 Whirlpool Screw Backorder WPL W10759522 $2.51

W10843121 Whirlpool Refrigerator Tube In Stock WPL W10843121 $23.50

Interior Door Panel Also Order Item 15 (3) WPL 1124961 Contact Us For Availability

Knob, Air Control WPL 1116853 Contact Us For Availability

28

W10439652 Whirlpool Refrigerator Compressor Backorder WPL W10439652 $276.71

28

Trim, Door Shelf (2) WPL 2148268 Contact Us For Availability

28

Knob, Retainer WPL 837444 Contact Us For Availability

212643 Whirlpool Refrigerator Permagum Sealer In Stock WPL 212643 $27.18

285006 Whirlpool Spray In Stock WPL 285006 $27.45

350930 Whirlpool White Spray Paint In Stock WPL 350930 $12.50

350942 Whirlpool Spray Paint Backorder WPL 350942 $32.57

350956 Whirlpool Spray Assembly In Stock WPL 350956 $19.22

4388286 Whirlpool Refrigerator Shelf Bar Endc In Stock WPL 4388286 $8.55

489203 Whirlpool Refrigerator Washer Backorder WPL 489203 $4.36

511873 Whirlpool Refrigerator Paint Backorder WPL 511873 $19.22

606755 Whirlpool Refrigerator Bag Backorder WPL 606755 $26.21

72017 Whirlpool Appliance Touch-Up Paint Whit In Stock WPL 72017 $3.35

72032 Whirlpool Touch Up Paint Black In Stock WPL 72032 $5.60

72110 Whirlpool Dryer Touch-Up Paint, Golden In Stock WPL 72110 $10.07

799344 Whirlpool Refrigerator Paint Backorder WPL 799344 $93.22

833938 Whirlpool Refrigerator Terminal Backorder WPL 833938 $3.70

876370 Whirlpool Refrigerator Insulation Backorder WPL 876370 $96.00

WP503695 Whirlpool Refrigerator Sealer Backorder WPL WP503695 $39.18

WP505587 Whirlpool Refrigerator Sealer Backorder WPL WP505587 $57.83

WP542638 Whirlpool Refrigerator Grease In Stock WPL WP542638 $22.07

WP72107 Whirlpool Touchup In Stock WPL WP72107 $5.80

WP841180A Whirlpool Microwave Glass Turntable In Stock WPL WP841180A $3.92

TAPE, VINYL (3/4 X 108``) WPL 479502 Contact Us For Availability

xEnamel, Golden Harvest (13 Oz. Spray Can) WPL 261890 Contact Us For Availability

Enamel, Golden Harvest (1 Qt. Uncut) WPL 261891 Contact Us For Availability

Leveler, Enamel (13 Oz. Spray Can) WPL 350941 Contact Us For Availability

Transformer (115-230 Volt) WPL 515393 Contact Us For Availability

CEMENT, ALUMILASTIC (1 1/4 OZ.) WPL 542639 Contact Us For Availability

WPL 799340 WPL 799340 Contact Us For Availability

WPL 799833 WPL 799833 Contact Us For Availability

WPL 978883 WPL 978883 Contact Us For Availability

30

2215823 Whirlpool Refrigerator Clip Backorder WPL 2215823 $4.61

30

WP939101 Whirlpool Refrigerator Plate Backorder WPL WP939101 $3.70

30

Unit Mounting Frame WPL 2160498 Contact Us For Availability

32

Door, Compartment WPL 2148218 Contact Us For Availability

32

Bracket, Fan Motor WPL 2162062 Contact Us For Availability

33

Heater, Defrost WPL 2162079 Contact Us For Availability

34

WP488366 Whirlpool Refrigerator Clamp Backorder WPL WP488366 $4.81

34

WPW10662129 Whirlpool Refrigerator Run Capaci In Stock WPL WPW10662129 $28.24

35

WPW10225581 Whirlpool Refrigerator Defrost Th In Stock WPL WPW10225581 $19.51

35

Panel, Interior Door WPL 1129241 Contact Us For Availability

36

Nameplate (For Almond Model) WPL 2165147 Contact Us For Availability

36

Nameplate WPL 2165148 Contact Us For Availability

36

Nameplate (For Gold Model) WPL 2165174 Contact Us For Availability

37

Trim, Door Shelf WPL 2148200 Contact Us For Availability

37

Screw WPL 489387 Contact Us For Availability

38

WP2172890 Whirlpool Refrigerator Wire Backorder WPL WP2172890 $2.51

38

WP2196100 Whirlpool Shelf Retainer Bar Suppor Backorder WPL WP2196100 $3.70

39

Grommet (4) WPL 2162067 Contact Us For Availability

40

489340 Whirlpool Refrigerator Screw Backorder WPL 489340 $4.56

40

Cord, Service WPL 937360 Contact Us For Availability

41

W11566763 Whirlpool Fitting In Stock WPL W11566763 $18.87

41

Air, Baffle WPL 1127938 Contact Us For Availability

42

WP1108438 Whirlpool Refrigerator Extension Backorder WPL WP1108438 $10.07

43

WP1108439 Whirlpool Refrigerator Clip Backorder WPL WP1108439 $4.63

43

Trim, Door Compartment WPL 1110717 Contact Us For Availability

43

Relay (Order Overload, No.44, To Obtain Relay WPL ARI17972A6 Contact Us For Availability

44

Overload WPL 1108114 Contact Us For Availability

45

Cover WPL 1108115 Contact Us For Availability

46

Strap WPL 938384 Contact Us For Availability

48

Cabinet (Not A Serviceable Part) WPL ARI17968A8 Contact Us For Availability

48

Unit Mounting Rail WPL 2149717 Contact Us For Availability

49

1119787 Whirlpool Refrigerator Hinge Cover Backorder WPL 1119787 $12.24

49

Screw WPL 488624 Contact Us For Availability

50

1105612 Whirlpool Fan Guard Backorder WPL 1105612 $24.10

52

549193 Whirlpool Refrigerator Power Clamp Backorder WPL 549193 $6.94

52

WPW10339879 Whirlpool Wire Tie In Stock WPL WPW10339879 $2.51

53

WP489427 Whirlpool Refrigerator Screw Backorder WPL WP489427 $3.70

53

Cover, Unit WPL 2161316 Contact Us For Availability

56

W11693756 Whirlpool Screw Assembly Backorder WPL W11693756 $8.11

59

Clip, Wire And Water Tube WPL 2155658 Contact Us For Availability

876764 Whirlpool Refrigerator Primary Valve In Stock WPL 876764 $27.18

978026 Whirlpool Refrigerator Primary Valve Backorder WPL 978026 $32.32

978027 Whirlpool Refrigerator Primary Valve Backorder WPL 978027 $33.95

978030 Whirlpool Refrigerator Valve Backorder WPL 978030 $35.52

WP978025 Whirlpool Refrigerator Valve In Stock WPL WP978025 $25.89

VALVE, ACCESS (5/8``) WPL 978029 Contact Us For Availability

Clip (2) WPL 2161330 Contact Us For Availability

VALVE, ACCESS (1/2``) WPL 978028 Contact Us For Availability
