Model Kenmore 790.48913410 WALL OVEN / MICROWAVE COMBO – Common Parts & Diagrams
Common parts from model Kenmore 790.48913410 WALL OVEN / MICROWAVE COMBO
*
Cleaner, stainless steel WCI 316136900 Contact Us For Availability
*#
Harness, wiring, communication, ES700W1 WCI 807461802 Contact Us For Availability
13
Door Assembly, outer, glass/steel, black/stai WCI 139037907 Contact Us For Availability
33
Support, turntable WCI 5304498730 Contact Us For Availability
34
Tray, turntable, ceramic WCI 5304498731 Contact Us For Availability
67*#
Wiring Harness, bake element WCI 318231870 Contact Us For Availability
72
Guide, air, RH WCI 5304480654 Contact Us For Availability
75
Door Assembly, complete, stainless, w/handle- WCI 5304503607 Contact Us For Availability
80
Spring, latch head, (2) WCI 5304483943 Contact Us For Availability
91
Trim, center, stainless WCI 808804904 Contact Us For Availability
96
Screw, 4 mm x 12 mm WCI 5304451553 Contact Us For Availability
108#
Blower Assembly, cooling, cross flow, w/baffl WCI 139038300 Contact Us For Availability
143
Support, wire WCI 318172904 Contact Us For Availability
165
Shield, heat, base WCI 318381740 Contact Us For Availability
166
Deflector, divider WCI 318577001 Contact Us For Availability
400
Box, cooling duct WCI 318576901 Contact Us For Availability
401
Bracket, plate, support WCI 807119705 Contact Us For Availability
404
Trim, top vent, black WCI 808804702 Contact Us For Availability
410
Bracket, fuse WCI 318933901 Contact Us For Availability
× ![]()
