Model Electrolux 790.36939903 Gas Range (Kenmore 79036939903) – Common Parts &amp; Diagrams

1B

318305410 Frigidaire Range Tube Backorder WCI 318305410 $181.99

2

Cooktop Burner Valve WCI 318233920 Contact Us For Availability

2A

Valve WCI 318233930 Contact Us For Availability

2B

318233900 Frigidaire Oven Valve Backorder WCI 318233900 $96.03

2C

Cooktop Burner Valve WCI 318233910 Contact Us For Availability

3

Range Igniter Switch and Harness Assembly WCI 318232618 Contact Us For Availability

3

Crosley Range Oven Door Trim WCI 318260201 Contact Us For Availability

3A

Range Oven Door Trim WCI 318260401 Contact Us For Availability

4

318304124 Frigidaire Glass Assembly Backorder WCI 318304124 $234.76

4

318403502 Frigidaire Oven Glass Assembly In Stock WCI 318403502 $221.65

4

Range Storage Drawer Front Panel WCI 318298906 Contact Us For Availability

4

Range Storage Drawer Front Panel WCI 318298908 Contact Us For Availability

6

Range Oven Rack WCI 318262504 Contact Us For Availability

8

5304503232 Frigidaire Oven Inner Door Glass In Stock WCI 5304503232 $74.37

8

5304505695 Frigidaire Oven Module In Stock WCI 5304505695 $40.94

8

Range Oven Bottom Liner WCI 318290501 Contact Us For Availability

9

Oven Liner WCI 318411650 Contact Us For Availability

10

Range Surface Burner Head WCI 316212300 Contact Us For Availability

10

Range Oven Door Handle Screw WCI 5304477986 Contact Us For Availability

10A

Frigidaire Range Surface Burner Head WCI 316223400 Contact Us For Availability

10B

Electrolux Range Sealed Surface Burner WCI 316206401 Contact Us For Availability

10C

316212400 Frigidaire Oven Primary Burner Asse In Stock WCI 316212400 $19.60

11

Range Storage Drawer Support WCI 318298600 Contact Us For Availability

11

Cooktop Igniter Assembly WCI 318306005 Contact Us For Availability

11A

Range Surface Burner Igniter and Orifice Hold WCI 318306009 Contact Us For Availability

11B

Range Surface Burner Igniter and Orifice Hold WCI 318306008 Contact Us For Availability

11C

Range Surface Burner Igniter and Orifice Hold WCI 318306004 Contact Us For Availability

12

318053132 Frigidaire Oven Gasket Backorder WCI 318053132 $92.07

13

Range Broil Drawer Slide Rail, Right WCI 318018100 Contact Us For Availability

13A

Range Storage Drawer Support Track, Left WCI 318018101 Contact Us For Availability

14

316116400 Frigidaire Oven Light Socket In Stock WCI 316116400 $40.92

15

316538904 Frigidaire Oven Light Lamp In Stock WCI 316538904 $10.68

318296602 Frigidaire Oven Console Backorder WCI 318296602 $186.07

5304524341 Frigidaire Lens In Stock WCI 5304524341 $9.93

Range Oven Gas Supply Tube WCI 318289500 Contact Us For Availability

Range Control Panel WCI 318296600 Contact Us For Availability

17

316404901 Frigidaire Range Valve In Stock WCI 316404901 $213.83

17

Wall Oven Light Lens Retainer WCI 5304400195 Contact Us For Availability

18

Range Bake Burner WCI 318292200 Contact Us For Availability

18

Range Oven Light Housing WCI 318222400 Contact Us For Availability

19

5304505650 Frigidaire Control Panel Assembly Backorder WCI 5304505650 $313.32

19

Range Control Panel WCI 318297525 Contact Us For Availability

19A

Range Control Panel Support WCI 318289702 Contact Us For Availability

20

318296815 Frigidaire Timer Clock Backorder WCI 318296815 $349.39

20

318296817 Frigidaire Timer Clock Backorder WCI 318296817 $347.07

22

Range Surface Burner Cap, 12,000-BTU (Black) WCI 316213600 Contact Us For Availability

22

Range Surface Burner Cap, 12,000-BTU (Gray) WCI 316213604 Contact Us For Availability

22A

Range Surface Burner Cap, 14,000-BTU (Black) WCI 316219900 Contact Us For Availability

22A

Range Burner Cap WCI 316219903 Contact Us For Availability

22B

Range Surface Burner Cap WCI 316206600 Contact Us For Availability

22B

Range Surface Burner Cap (Gray) WCI 316206603 Contact Us For Availability

22C

316213500 Frigidaire Range Black Medium 9.5K In Stock WCI 316213500 $25.95

22C

Range Surface Burner Cap, 9,500-BTU (Gray) WCI 316213504 Contact Us For Availability

23

Range Broil Burner WCI 318292300 Contact Us For Availability

23

Range Oven Door Hinge WCI 318567113 Contact Us For Availability

24

Range Broil Burner Orifice WCI 316409703 Contact Us For Availability

25

Range Broil Burner Baffle WCI 316401301 Contact Us For Availability

26

5303935066 Frigidaire Oven Flat Igniter 17-In In Stock WCI 5303935066 $31.55

29

316517600 Frigidaire Oven Spacer Backorder WCI 316517600 $7.74

35

Range Control Panel Knob Retainer WCI 318233720 Contact Us For Availability

35

Range Control Panel Knob Retainer WCI 318233721 Contact Us For Availability

37

5304504897 Frigidaire Oven Temperature Sensor In Stock WCI 5304504897 $27.32

39

Range Oven Door Handle WCI 318372416 Contact Us For Availability

39

Range Oven Door Handle WCI 318372417 Contact Us For Availability

42

318382302 Frigidaire Bracket Backorder WCI 318382302 $30.54

44

316237901 Frigidaire Oven Orifice Backorder WCI 316237901 $38.73

44A

Range Surface Burner Orifice WCI 316237900 Contact Us For Availability

44B

Range Surface Burner Orifice Assembly WCI 316237903 Contact Us For Availability

44C

316237902 Frigidaire Orifice Top Burner In Stock WCI 316237902 $39.17

52

318291126 Frigidaire Cover Backorder WCI 318291126 $55.68

56A

Range Screw WCI 5304476599 Contact Us For Availability

72

316215600 Frigidaire Oven Screw In Stock WCI 316215600 $9.10

81

Wall Oven Rear Shield Spring Clip WCI 318192400 Contact Us For Availability

86

318561100 Frigidaire Receptacle Backorder WCI 318561100 $12.74

90

Range Side Filler Panel, Right (Black) WCI 318296904 Contact Us For Availability

90

Panel Filler, Right WCI 318296902 Contact Us For Availability

90A

5304511890 Frigidaire Oven Panel Backorder WCI 5304511890 $48.75

90A

Range Panel WCI 318296903 Contact Us For Availability

91

903113-9010 Frigidaire Filler Kit Assembly Backorder WCI 903113-9010 $42.39

91

Crosley Range Main Top Filler Trim, Rear WCI 318304301 Contact Us For Availability

99A

Range Control Panel Gasket (Black) WCI 318313201 Contact Us For Availability

108

318575603 Frigidaire Range Cooling Fan Motor In Stock WCI 318575603 $109.46

119

318578506 Frigidaire Oven High Limit Thermost In Stock WCI 318578506 $32.90

166

318298410 Frigidaire Oven Bracket Backorder WCI 318298410 $45.57

170

Anti-Tip WCI 318335500 Contact Us For Availability

200

Range Warming Drawer Frame and Roller Assembl WCI 318335600 Contact Us For Availability

201

318298233 Frigidaire Oven Frame Backorder WCI 318298233 $29.16

316240600 Frigidaire Igniter Mounting Screw In Stock WCI 316240600 $7.27

318165800 Frigidaire Oven Door Glass Spacer w Backorder WCI 318165800 $11.38

318531701 Frigidaire Spacer Backorder WCI 318531701 $7.74

5303211311 Frigidaire Refrigerator Screw Backorder WCI 5303211311 $9.11

5303300265 Frigidaire Oven Screw Backorder WCI 5303300265 $9.10

5303323129 Frigidaire Oven Screw Backorder WCI 5303323129 $9.11

5303323137 Frigidaire Oven Screw Backorder WCI 5303323137 $7.14

5303323277 Frigidaire Oven Screw Backorder WCI 5303323277 $6.38

5303324184 Frigidaire Wall Oven Range Screw Backorder WCI 5303324184 $9.11

5304415832 Frigidaire Oven Screw Backorder WCI 5304415832 $8.65

5304436875 Frigidaire Oven Screw In Stock WCI 5304436875 $8.65

5304461333 Frigidaire Oven Screw Backorder WCI 5304461333 $8.63

Range Igniter Wire Harness WCI 318199776 Contact Us For Availability

Range Screw, #10-24 x 1/2-in WCI 08002868 Contact Us For Availability

Range LP Conversion Kit WCI 318186918 Contact Us For Availability

Screw WCI 5304417153 Contact Us For Availability
