Model Kenmore 790.36902901 RANGE – Common Parts & Diagrams

*#
LP Conversion Kit
LP Conversion Kit WCI 318186909 Contact Us For Availability
View on Model
2#
Valve, top burner, 14000 BTU
Valve, top burner, 14000 BTU WCI 318233930 Contact Us For Availability
View on Model
2A#
Valve, top burner, 16/17K
Valve, top burner, 16/17K WCI 318233940 Contact Us For Availability
View on Model
2C#
Valve, top burner, 9500 BTU
Valve, top burner, 9500 BTU WCI 318233910 Contact Us For Availability
View on Model
3
Trim, oven door, black, upper
Trim, oven door, black, upper WCI 318260201 Contact Us For Availability
View on Model
3#
Wiring Harness, w/igntr switch
Wiring Harness, w/igntr switch WCI 318232618 Contact Us For Availability
View on Model
3A
Trim, oven door, side, (2)
Trim, oven door, side, (2) WCI 318260401 Contact Us For Availability
View on Model
4
Glass Assy., oven door, bisque, outer, w/trim
Glass Assy., oven door, bisque, outer, w/trim WCI 318304145 Contact Us For Availability
View on Model
4
Panel, drawer, white, front
Panel, drawer, white, front WCI 318298906 Contact Us For Availability
View on Model
4
Panel, drawer, black, front
Panel, drawer, black, front WCI 318298908 Contact Us For Availability
View on Model
6
Rack, oven
Rack, oven WCI 318262504 Contact Us For Availability
View on Model
8
Panel, oven, bottom
Panel, oven, bottom WCI 318290501 Contact Us For Availability
View on Model
9
Pan, broiler OPTIONAL ACCESS0RY
Pan, broiler OPTIONAL ACCESS0RY WCI 316081900 Contact Us For Availability
View on Model
9
Liner, oven door
Liner, oven door WCI 318411650 Contact Us For Availability
View on Model
10
Insert, broiler pan OPTIONAL ACCESS0RY
Insert, broiler pan OPTIONAL ACCESS0RY WCI 316082000 Contact Us For Availability
View on Model
10#
Burner, sealed, 14K
Burner, sealed, 14K WCI 316223400 Contact Us For Availability
View on Model
10A#
Burner, sealed, 16/17K
Burner, sealed, 16/17K WCI 316223300 Contact Us For Availability
View on Model
10B#
Burner, sealed, 5K
Burner, sealed, 5K WCI 316206401 Contact Us For Availability
View on Model
11#
Ignitor Assembly, 14K, left rear, w/tube & ho
Ignitor Assembly, 14K, left rear, w/tube & ho WCI 318306006 Contact Us For Availability
View on Model
11B#
Ignitor Assembly, 5K, right rear, w/tube & ho
Ignitor Assembly, 5K, right rear, w/tube & ho WCI 318306008 Contact Us For Availability
View on Model
11C#
Ignitor Assembly, 9.5K, left front, w/tube &
Ignitor Assembly, 9.5K, left front, w/tube & WCI 318306004 Contact Us For Availability
View on Model
13
Glide, warmer, inner RH
Glide, warmer, inner RH WCI 318259504 Contact Us For Availability
View on Model
13A
Glide, warmer, inner LH
Glide, warmer, inner LH WCI 318259505 Contact Us For Availability
View on Model
16
Glass, oven door, heat barrier, lower door
Glass, oven door, heat barrier, lower door WCI 318212210 Contact Us For Availability
View on Model
16
Console, assy., white
Console, assy., white WCI 318296600 Contact Us For Availability
View on Model
16#
Tube, regulator valve
Tube, regulator valve WCI 318289500 Contact Us For Availability
View on Model
17
Retainer, light cover
Retainer, light cover WCI 5304400195 Contact Us For Availability
View on Model
18
Housing, oven light
Housing, oven light WCI 318222400 Contact Us For Availability
View on Model
18#
Burner, oven, 18000
Burner, oven, 18000 WCI 318292200 Contact Us For Availability
View on Model
19A
Panel, control mtg.
Panel, control mtg. WCI 318289702 Contact Us For Availability
View on Model
20#
Controller, electronic, ES515
Controller, electronic, ES515 WCI 316462862 No Longer Available
View on Model
22
Cap, 14K burner, black
Cap, 14K burner, black WCI 316219900 Contact Us For Availability
View on Model
22
Cap, 14K burner, gray
Cap, 14K burner, gray WCI 316219903 Contact Us For Availability
View on Model
22A
Cap, 17K burner, black
Cap, 17K burner, black WCI 316271900 Contact Us For Availability
View on Model
22A
Cap, 17K burner, brown
Cap, 17K burner, brown WCI 316271902 Contact Us For Availability
View on Model
22B
Cap, 5K burner, black
Cap, 5K burner, black WCI 316206600 Contact Us For Availability
View on Model
22B
Cap, 5K burner, gray, small
Cap, 5K burner, gray, small WCI 316206603 Contact Us For Availability
View on Model
22C
Cap, 9.5K burner, gray, medium
Cap, 9.5K burner, gray, medium WCI 316213504 Contact Us For Availability
View on Model
22C
Cap, 9.5K burner, brown
Cap, 9.5K burner, brown WCI 316213503 Contact Us For Availability
View on Model
23
Hinge, oven door, (2)
Hinge, oven door, (2) WCI 318567101 Contact Us For Availability
View on Model
23#
Burner, broil, 14000
Burner, broil, 14000 WCI 318292300 Contact Us For Availability
View on Model
24#
Elbow, mixer
Elbow, mixer WCI 316409703 Contact Us For Availability
View on Model
25
Baffle, broil burner
Baffle, broil burner WCI 316401301 Contact Us For Availability
View on Model
35
Retainer, control panel, black
Retainer, control panel, black WCI 318233720 Contact Us For Availability
View on Model
35
Retainer, control panel, white
Retainer, control panel, white WCI 318233721 Contact Us For Availability
View on Model
39
Handle, door, white, w/spacer
Handle, door, white, w/spacer WCI 318372416 Contact Us For Availability
View on Model
39
Handle, door, black, w/spacer
Handle, door, black, w/spacer WCI 318372417 Contact Us For Availability
View on Model
44#
Orifice, top burner, 14K
Orifice, top burner, 14K WCI 316237900 Contact Us For Availability
View on Model
44B#
Orifice, top burner, 5K
Orifice, top burner, 5K WCI 316237903 Contact Us For Availability
View on Model
56A
Screw, 8-18 x 3/8
Screw, 8-18 x 3/8 WCI 5304476599 Contact Us For Availability
View on Model
81
Spring, oven
Spring, oven WCI 318192400 Contact Us For Availability
View on Model
90
Panel, filler, black, RH
Panel, filler, black, RH WCI 318296904 Contact Us For Availability
View on Model
90
Panel, filler, white, RH
Panel, filler, white, RH WCI 318296902 Contact Us For Availability
View on Model
90A
Panel, filler, white, LH
Panel, filler, white, LH WCI 318296903 Contact Us For Availability
View on Model
91
Trim, filler, white, rear
Trim, filler, white, rear WCI 318304301 Contact Us For Availability
View on Model
99A
Gasket, black
Gasket, black WCI 318313201 Contact Us For Availability
View on Model
101
Bushing, retainer
Bushing, retainer WCI 318233401 Contact Us For Availability
View on Model
107
Cover, fan
Cover, fan WCI 318219405 Contact Us For Availability
View on Model
124
Glide, drawer, outer/RH & LH, (2)
Glide, drawer, outer/RH & LH, (2) WCI 318330600 No Longer Available
View on Model
170
Anti-tip & accessories
Anti-tip & accessories WCI 318335500 Contact Us For Availability
View on Model
