Model Kenmore 790.32402901 COOKTOP – Common Parts & Diagrams

1
Manifold Pipe
Manifold Pipe WCI 318177010 Contact Us For Availability
View on Model
2#
Valve, top burner
Valve, top burner WCI 318087010 Contact Us For Availability
View on Model
10#
Burner, top, LF
Burner, top, LF WCI 3201432 Contact Us For Availability
View on Model
10A#
Burner, top, LR
Burner, top, LR WCI 3201433 Contact Us For Availability
View on Model
10B#
Burner, top, RF
Burner, top, RF WCI 3201434 Contact Us For Availability
View on Model
10C#
Burner, top, RR
Burner, top, RR WCI 3201435 Contact Us For Availability
View on Model
11#
Ignitor, top burner, 17.5" lead
Ignitor, top burner, 17.5" lead WCI 318148604 Contact Us For Availability
View on Model
11A#
Ignitor, top burner, 28.5" lead
Ignitor, top burner, 28.5" lead WCI 318148605 Contact Us For Availability
View on Model
14#
Regulator, pressure
Regulator, pressure WCI 318122712 Contact Us For Availability
View on Model
18
Hinge, maintop, (2)
Hinge, maintop, (2) WCI 318074310 Contact Us For Availability
View on Model
33
Bracket, support
Bracket, support WCI 318257400 Contact Us For Availability
View on Model
35
Bushing
Bushing WCI 318146301 Contact Us For Availability
View on Model
43
Knob, control, white, (4)
Knob, control, white, (4) WCI 318537700 Contact Us For Availability
View on Model
43
Knob, control, black, (4)
Knob, control, black, (4) WCI 318537702 Contact Us For Availability
View on Model
43
Knob, control, bisque, (4)
Knob, control, bisque, (4) WCI 318537701 Contact Us For Availability
View on Model
46
Burner Box
Burner Box WCI 318077411 Contact Us For Availability
View on Model
47
Cord, service
Cord, service WCI 318144006 Contact Us For Availability
View on Model
51
Bracket, spark module
Bracket, spark module WCI 318024201 Contact Us For Availability
View on Model
72
Screw, valve mtg, 1/4-20 x 5/16
Screw, valve mtg, 1/4-20 x 5/16 WCI 5303323141 Contact Us For Availability
View on Model
99
Nut, Palnut, (3)
Nut, Palnut, (3) WCI 5304474369 Contact Us For Availability
View on Model
100
Nut, Keps, 10-32
Nut, Keps, 10-32 WCI 5303325982 Contact Us For Availability
View on Model
137
Screw, lock bracket, 10-24 x 2.00
Screw, lock bracket, 10-24 x 2.00 WCI 5303285443 Contact Us For Availability
View on Model
183
Screw, 10-32 x 5/8, (8)
Screw, 10-32 x 5/8, (8) WCI 5304410665 Contact Us For Availability
View on Model
