  • LG 50QNED80URA Parts List

Model LG 50QNED80URA – Common Parts & Diagrams

121
Speaker Assembly
Speaker Assembly LGE EAB65831302 Contact Us For Availability
View on Model
200
LCD,Module-TFT
LCD,Module-TFT LGE EAJ65843201 Contact Us For Availability
View on Model
200A
Package Assembly,LED Array
Package Assembly,LED Array LGE AGF30434701 Contact Us For Availability
View on Model
200L
Plate Assembly,Light Guide
Plate Assembly,Light Guide LGE AGU30085301 Contact Us For Availability
View on Model
400
Cover Assembly,Rear
Cover Assembly,Rear LGE ACQ30542839 Contact Us For Availability
View on Model
521
Bracket
Bracket LGE MAZ67664713 Contact Us For Availability
View on Model
522
Bracket
Bracket LGE MAZ67664804 Contact Us For Availability
View on Model
540
Mainboard,BPR Total Assembly,SVC
Mainboard,BPR Total Assembly,SVC LGE EBU67372610 Contact Us For Availability
View on Model
570
Module,Wifi Bluetooth Module
Module,Wifi Bluetooth Module LGE EAT65193302 Contact Us For Availability
View on Model
570
Module,Wifi Bluetooth Module
Module,Wifi Bluetooth Module LGE EAT65193301 Contact Us For Availability
View on Model
900
Base Assembly
Base Assembly LGE AAN30013475 Contact Us For Availability
View on Model
AB2
Bracket
Bracket LGE MAZ67464206 Contact Us For Availability
View on Model
AH2
Holder
Holder LGE MEG66680803 Contact Us For Availability
View on Model
AW1
Screw,Machine
Screw,Machine LGE FAB31843211 Contact Us For Availability
View on Model
HW1
Cable,FFC
Cable,FFC LGE EAD65825867 Contact Us For Availability
View on Model
LV1
Cable,FFC
Cable,FFC LGE EAD64666339 Contact Us For Availability
View on Model
LV2
Cable,FFC
Cable,FFC LGE EAD64666340 Contact Us For Availability
View on Model
