Model Electrolux 417.99165120 Laundry Center (Kenmore 41799165120) – Common Parts &amp; Diagrams

1

ACCES PANEL, DRYER WCI N/P Contact Us For Availability

1

Housing WCI 5303209767 Contact Us For Availability

1

Screw WCI 5303161221 Contact Us For Availability

1

Laundry Center Timer WCI 5303207217 Contact Us For Availability

1

Washer Cover WCI 3205029 Contact Us For Availability

1A

Panel (White) WCI 5303209761 Contact Us For Availability

1B

Panel (Almond) WCI 5303209762 Contact Us For Availability

2

Clip WCI 5308001875 Contact Us For Availability

2

Hub WCI 5303280324 Contact Us For Availability

2

Switch WCI 5303209765 Contact Us For Availability

2

Cushion WCI 5377009100 Contact Us For Availability

2

Valve WCI 5308027515 Contact Us For Availability

2A

Panel (White) WCI 3204948 Contact Us For Availability

2B

Panel (Almond) WCI 3204949 Contact Us For Availability

3

Laundry Center Dryer Blower Wheel WCI 5303209769 Contact Us For Availability

3

Panel WCI 3017111 Contact Us For Availability

3

Clamp WCI 140887026 Contact Us For Availability

3

Screw WCI 3161211 Contact Us For Availability

4

Plate WCI 5303209770 Contact Us For Availability

4

Shim WCI 5303292723 Contact Us For Availability

4

Harness WCI 5303283105 Contact Us For Availability

4

Front Duct WCI 08015820 Contact Us For Availability

4

Nut WCI 3161212 Contact Us For Availability

4

Seal WCI 5303161121 Contact Us For Availability

5

5303161307 Frigidaire Dryer Seal Assembly In Stock WCI 5303161307 $13.67

5

Laundry Center Washer Tub Cover Clip WCI 5303161199 Contact Us For Availability

5

Laundry Center Washer Water Temperature Switc WCI 5303017895 Contact Us For Availability

5

Pulley WCI 5303211473 Contact Us For Availability

5

Clamp WCI 5364154013 Contact Us For Availability

5

Pulley WCI 131026500 Contact Us For Availability

6

Snap Ring WCI 5303161223 Contact Us For Availability

6

Washer Screw WCI 5303270023 Contact Us For Availability

6

Screw WCI 5308027520 Contact Us For Availability

6

Pressure Switch WCI 131065400 Contact Us For Availability

6

Duct WCI 3205055 Contact Us For Availability

7

5303280326 Frigidaire Drive Belt Assembly In Stock WCI 5303280326 $26.41

7

Dryer Drum Belt WCI 5303161099 Contact Us For Availability

7

Timer WCI 5303283045 Contact Us For Availability

7

Panel WCI 3016426 Contact Us For Availability

8

Cap WCI 5303161122 Contact Us For Availability

8

Relay WCI 3205062 Contact Us For Availability

8

Electronic Harness WCI 131064200 Contact Us For Availability

8

Bushing WCI 08027535 Contact Us For Availability

9

131205100 Frigidaire Screw In Stock WCI 131205100 $9.11

9

Screw WCI 3161234 Contact Us For Availability

9

Hose WCI 5303283055 Contact Us For Availability

9

Shield WCI 5303283049 Contact Us For Availability

137546400 Frigidaire Screw 5/16-18 x 0.625 In Stock WCI 137546400 $18.21

Washer Tub Seal Kit WCI 5308950197 Contact Us For Availability

Motor WCI 5303209771 Contact Us For Availability

Dial WCI 3204999 Contact Us For Availability

Shield WCI 5303283071 Contact Us For Availability

11

Screw Shield WCI 5303283072 Contact Us For Availability

11

Plug WCI 5303161224 Contact Us For Availability

11

Agitator WCI 5303283050 Contact Us For Availability

137539500 Frigidaire Washer Lock Plate Trunni In Stock WCI 137539500 $12.76

Screw WCI 08002804 Contact Us For Availability

Switch WCI 3205000 Contact Us For Availability

Clamp WCI 5303283076 Contact Us For Availability

12A

Outer Door (White) WCI 3016427 Contact Us For Availability

12B

Outer Door (Almond) WCI 3016429 Contact Us For Availability

Washer Gear Case Housing Seal WCI 5308015778 Contact Us For Availability

Screw WCI 5303209426 Contact Us For Availability

Handle WCI 5303285455 Contact Us For Availability

Tub Trunnion WCI 5303284815 Contact Us For Availability

137107000 Frigidaire Plate In Stock WCI 137107000 $17.30

Washer WCI 5363602000 Contact Us For Availability

Gear WCI 5308011268 Contact Us For Availability

Screw WCI 3205020 Contact Us For Availability

14A

Cover (White) WCI 3204952 Contact Us For Availability

14B

Cover (Almond) WCI 3204953 Contact Us For Availability

Clip, Motor WCI 5308002293 Contact Us For Availability

Rod WCI 5303161169 Contact Us For Availability

Knob WCI 3205001 Contact Us For Availability

Bracket WCI 5303284141 Contact Us For Availability

15A

Door (White) WCI 3016433 Contact Us For Availability

15B

Door (Almond) WCI 3016435 Contact Us For Availability

Washer Drain Pump WCI 5303292169 Contact Us For Availability

Wheel WCI 5303161103 Contact Us For Availability

Gear WCI 5308015496 Contact Us For Availability

Screw WCI 08001544 Contact Us For Availability

Thermostat WCI 08015853 Contact Us For Availability

Tub Splash WCI 131033000 Contact Us For Availability

3204405 Frigidaire Outer Tub Spin Bearing In Stock WCI 3204405 $62.19

Laundry Center Control Knob WCI 3205004 Contact Us For Availability

Shaft WCI 5308014905 Contact Us For Availability

Clamp WCI 5303283073 Contact Us For Availability

17A

Panel (White) WCI 5303209763 Contact Us For Availability

17B

Panel (Almond) WCI 5303209764 Contact Us For Availability

Washer WCI 5303161226 Contact Us For Availability

Terminal WCI 5379171000 Contact Us For Availability

Panel WCI 5303280357 Contact Us For Availability

Bar WCI 3205942 Contact Us For Availability

Clip WCI 5303283052 Contact Us For Availability

131420300 Frigidaire Screw Backorder WCI 131420300 $8.65

Gasket WCI 5303209442 Contact Us For Availability

Pin WCI 5303161227 Contact Us For Availability

Hose WCI 5303283078 Contact Us For Availability

Trim WCI 3205006 Contact Us For Availability

Hinge WCI 3204959 Contact Us For Availability

Motor WCI 131097200 Contact Us For Availability

Spring WCI 5303212125 Contact Us For Availability

Washer Snubber Ring WCI 5308002385 Contact Us For Availability

Bracket WCI 3016464 Contact Us For Availability

Housing WCI 5303912535 Contact Us For Availability

Switch WCI 5308014888 Contact Us For Availability

21A

Panel (White) WCI 3204961 Contact Us For Availability

21B

Panel (Almond) WCI 3204963 Contact Us For Availability

5303209428 Frigidaire Serv.Cord Bushing Backorder WCI 5303209428 $10.94

Housing WCI 5308950058 Contact Us For Availability

Knob WCI 3205007 Contact Us For Availability

Seal WCI 5303206877 Contact Us For Availability

Plate WCI 08002472 Contact Us For Availability

Screw WCI 5303161284 Contact Us For Availability

Plug WCI 3205063 Contact Us For Availability

Screw WCI 5303211089 Contact Us For Availability

Nut-hex WCI 5303283079 Contact Us For Availability

Block WCI 5303161202 Contact Us For Availability

Screw, Retainer WCI 08004646 Contact Us For Availability

Nut WCI 3205008 Contact Us For Availability

Spacer WCI 5303161303 Contact Us For Availability

Nut WCI 3161203 Contact Us For Availability

24A

Lid (White) WCI 3204965 Contact Us For Availability

24B

Lid (Almond) WCI 3204966 Contact Us For Availability

Ring WCI 5308015536 Contact Us For Availability

Seal WCI 5303286418 Contact Us For Availability

Motor Pulley WCI 131031900 Contact Us For Availability

Spring WCI 5303161131 Contact Us For Availability

Spring WCI 5308015828 Contact Us For Availability

Baffle WCI 3161076 Contact Us For Availability

Grommet Hinge WCI 3204362 Contact Us For Availability

Screw WCI 5303206869 Contact Us For Availability

Support WCI 5303283054 Contact Us For Availability

Spring WCI 5308002456 Contact Us For Availability

Retainer WCI 08015824 Contact Us For Availability

Drum WCI 3205010 Contact Us For Availability

Latch WCI 5303292720 Contact Us For Availability

Screw WCI 3161205 Contact Us For Availability

28

Cradle WCI 3016466 Contact Us For Availability

28

Screw WCI 5303283080 Contact Us For Availability

28

Plate WCI 5303269887 Contact Us For Availability

29

Thermostat WCI 5308004644 Contact Us For Availability

29

Arm WCI 5303937001 Contact Us For Availability

29

Spring WCI 5303161133 Contact Us For Availability

29A

Panel (White) WCI 5303207099 Contact Us For Availability

29B

Panel (Almond) WCI 5303207100 Contact Us For Availability

5303912532 Frigidaire Inlet Hose 60" Backorder WCI 5303912532 $55.56

Screw WCI 5308027582 Contact Us For Availability

Washer WCI 5308002475 Contact Us For Availability

Screw WCI 5303161187 Contact Us For Availability

131390000 Frigidaire Door Catch-Strike Backorder WCI 131390000 $34.78

5303161296 Frigidaire Washer Inlet Hose (1 Pi Backorder WCI 5303161296 $1,678.32

Buzzer WCI 5308004087 Contact Us For Availability

Spacer WCI 5303207426 Contact Us For Availability

Bracket WCI 3017901 Contact Us For Availability

31A

Bracket WCI 3017902 Contact Us For Availability

5303161173 Frigidaire Seal Assembly Backorder WCI 5303161173 $5.99

Cord WCI 08004650 Contact Us For Availability

Drum Roller Shaft WCI 5308004076 Contact Us For Availability

Screw WCI 08001578 Contact Us For Availability

32A

Panel (White) WCI 3204973 Contact Us For Availability

32B

Panel (Almond) WCI 3204975 Contact Us For Availability

33

131168200 Frigidaire Dryer Screw In Stock WCI 131168200 $9.10

33

Spring WCI 5303161174 Contact Us For Availability

33

Retaining Ring WCI 3161255 Contact Us For Availability

Base WCI 3205024 Contact Us For Availability

Gear WCI 5303161175 Contact Us For Availability

Roller Shaft Washer WCI 08012152 Contact Us For Availability

Base WCI 5303283018 Contact Us For Availability

Bracket WCI 3205035 Contact Us For Availability

134548800 Frigidaire Washer Leg Levelling In Stock WCI 134548800 $9.10

Switch WCI 3205033 Contact Us For Availability

Washer, Motor Cradle Bolt WCI 5308002468 Contact Us For Availability

Roller WCI 5308004077 Contact Us For Availability

Housing WCI 5303937039 Contact Us For Availability

Gasket WCI 5303209445 Contact Us For Availability

Panel WCI 3204980 Contact Us For Availability

Hose WCI 3205034 Contact Us For Availability

37

3204368 Frigidaire Strike Screw Backorder WCI 3204368 $8.18

37

Housing WCI 5303288388 Contact Us For Availability

37

Clamp WCI 064154-004 Contact Us For Availability

Washer WCI 08001572 Contact Us For Availability

Laundry Center Washer Gear Case Water Slinger WCI 5303272073 Contact Us For Availability

Guide WCI 3205013 Contact Us For Availability

Washer Drain Hose Coupler WCI 5308015078 Contact Us For Availability

Screw WCI 5303010202 Contact Us For Availability

39

134190200 Frigidaire Washer Water Valve In Stock WCI 134190200 $92.79

39

Cover WCI 3205014 Contact Us For Availability

39

Rivet WCI 3161237 Contact Us For Availability

Screw WCI 3161240 Contact Us For Availability

Washer WCI 5303161232 Contact Us For Availability

Bumper WCI 3204981 Contact Us For Availability

Spring WCI 5308006573 Contact Us For Availability

41

Laundry Center Dryer Lint Screen WCI 3205015 Contact Us For Availability

41

Mechanism WCI 5308057579 Contact Us For Availability

41

Clip WCI 3161288 Contact Us For Availability

134154100 Frigidaire Screw 10-32 x 0.375 Co Backorder WCI 134154100 $8.67

5308002401 Frigidaire Washer Primary Backorder WCI 5308002401 $10.08

Washer WCI 5308057430 Contact Us For Availability

Screw WCI 5303208454 Contact Us For Availability

42B

131302800 Frigidaire Drum Vane Screw In Stock WCI 131302800 $8.70

43

3205150 Frigidaire Tub Bearing Screw Backorder WCI 3205150 $2.27

43

Dispenser WCI 3204983 Contact Us For Availability

44

Screw WCI 08010804 Contact Us For Availability

44A

Screw WCI 3204984 Contact Us For Availability

44B

Screw WCI 08011280 Contact Us For Availability

45

Retainer Ring WCI 08006557 Contact Us For Availability

46

Hinge Pin WCI 3016440 Contact Us For Availability

46A

Washer WCI 5303208633 Contact Us For Availability

47

5304401845 Frigidaire Pressure Tube Backorder WCI 5304401845 $37.35

47

Screw WCI 3205016 Contact Us For Availability

47

Screw WCI 3204269 Contact Us For Availability

48

Lower Brace WCI 3016468 Contact Us For Availability

48

Elbow WCI 3205017 Contact Us For Availability

48

Fustat WCI 5303208647 Contact Us For Availability

49

Connector WCI 08006559 Contact Us For Availability

50

Plate WCI 3016469 Contact Us For Availability

50

Shield WCI 3016460 Contact Us For Availability

51

Screw WCI 5303285467 Contact Us For Availability

53

Strike Plate WCI 3016442 Contact Us For Availability

55

Cushion WCI 5303004083 Contact Us For Availability

57

Screw WCI 5303161185 Contact Us For Availability

58

Element WCI 5303292721 Contact Us For Availability

60

Hose WCI 5303292372 Contact Us For Availability

61

Retainer WCI 5303204987 Contact Us For Availability

64

Valve WCI 5308014555 Contact Us For Availability

65

Bracket WCI 5303161252 Contact Us For Availability

66

Capacitor WCI 5308014903 Contact Us For Availability

68

Cover WCI 5303212087 Contact Us For Availability

5308027429 Frigidaire Dryer High Temperature In Stock WCI 5308027429 $38.73

Washer Timer Shaft Spacer WCI 5308015493 Contact Us For Availability

Electrolux Laundry Center Washer WCI 5303161306 Contact Us For Availability

Operating Instructions WCI 5303283115 Contact Us For Availability

Use and Care Guide WCI 5303283116 Contact Us For Availability

Technical Sheet WCI 5303283117 Contact Us For Availability

Insulation WCI 5303937030 Contact Us For Availability

Lubricant WCI 5306598047 Contact Us For Availability

Compound WCI 5308006576 Contact Us For Availability

Bearing WCI 5308950214 Contact Us For Availability

Gasket WCI 5373565000 Contact Us For Availability

Parts Catalog WCI 5995229456 Contact Us For Availability
